🏛️ Arch Design — Visual Architecture Canvas for VS Code

Visual Studio Marketplace Version Website Live Demo Docs & CLI Reference License: MIT Support Author

The interactive visual canvas for mapping Low-Level Design (LLD), system boundaries, and code dependencies — built for engineers and modern AI coding agents.

🌐 Try Interactive Web Demo • 📦 VS Code Marketplace • 🤖 Agent Skill Guide


💡 Overview

Arch Design brings interactive architectural modeling directly inside Visual Studio Code. It provides a visual canvas for mapping modules, UI screens, business services, data contracts, and external infrastructure dependencies for .arch and .lld files.

Every diagram is saved as clean, version-controllable JSON (v2.1). This creates a single source of truth that humans can visually design and inspect, and AI coding agents (Google Antigravity, Claude Code, Cursor, Windsurf, OpenCode, Aider) can parse, validate, and faithfully implement into real code.

[!TIP] Try without installing: Test the interactive canvas directly in your browser at anujanthwal-dotcom.github.io/Arch-Design/.


⚡ Key Highlights

┌────────────────────────────────────────────────────────────────────────┐
│                        ARCH DESIGN ECOSYSTEM                           │
│                                                                        │
│   👨‍💻 Human Architect                  🤖 AI Coding Agents              │
│   Visual Canvas • Drag & Drop         Reads JSON • Implements Code      │
│   Focus Mode • 1-Click Code Jump       Validates Rules • Auto-Layout     │
│             │                                     │                    │
│             ▼                                     ▼                    │
│   ┌──────────────────────────────────────────────────────────────┐     │
│   │               architecture.arch (JSON v2.1)                  │     │
│   │     6 Architectural Tiers • Strict Connection Rules          │     │
│   └──────────────────────────────────────────────────────────────┘     │
│                                 │                                      │
│                                 ▼                                      │
│   ┌──────────────────────────────────────────────────────────────┐     │
│   │                 Workspace Source Code Files                  │     │
│   │       src/auth/service.ts  •  src/components/Login.tsx       │     │
│   └──────────────────────────────────────────────────────────────┘     │
└────────────────────────────────────────────────────────────────────────┘
  • 🎯 14 Domain & Framework Presets: Instant scaffolding for Next.js, React SPA, Nuxt/Vue, NestJS, Spring Boot, FastAPI, Android Jetpack Compose, iOS SwiftUI, Flutter, Rust/Tokio, Go Clean Architecture, and Hexagonal Clean Architecture.
  • 🔗 1-Click Code Jump (Beside Split): Attach source file paths (filePath) to any card. Click to instantly open the source file in a side-by-side split editor — or auto-create it if it doesn't exist yet!
  • 🛡️ 6 Universal Architectural Tiers & Validation: Enforces clean Low-Level Design boundaries (container, presentation, logic, contract, execution, infrastructure) and blocks architectural anti-patterns like UI components querying databases directly.
  • 🔍 Focus Mode & Dependency Tracing: Click or hover any card to spotlight its upstream and downstream connection flow while dimming canvas clutter.
  • 🤖 Native Agent Skill: Includes automated setup for Google Antigravity, Claude Code, Cursor, and Windsurf, complete with CLI validation and Dagre layout scripts.
  • 📐 Dagre Hierarchical Auto-Layout: One-click automatic organization (Auto Layout) with intelligent collision detection on drag.
  • 🎨 Visual Tech Badges: Native vector logos and brand colors for PostgreSQL, Redis, MongoDB, Kafka, RabbitMQ, S3, MinIO, MySQL, SQLite, Room, SwiftData, ClickHouse, GraphQL, REST, WebSockets, and Tokio.
  • 🗂️ Default Collapsed Clean View: Cards render collapsed by default to keep high-level architectures tidy, with one-click chevron expansion for deep property inspection.

🚀 Features Deep Dive

1. 🧭 Cascading Framework & Domain Presets

Switch architectural contexts anytime from the toolbar selector featuring categorized groups and quick search:

Category Presets Archetypes Included
Web & Frontend Next.js (App Router)
React SPA (Vite / CRA)
Nuxt 3 / Vue
Page/Layout, Component (RSC/Client), Store/Hook, Server Action, Schema (Zod), View/Route, Pinia Store, Composable, Nitro Route
Backend & APIs NestJS
Spring Boot
FastAPI (Python)
Modular Backend
Nest Module, RestController, Service/Provider, Guard/Interceptor, JPA Repository, Entity, APIRouter, Pydantic Model, Controller, DTO
Mobile Apps Android (Compose)
iOS (SwiftUI)
Flutter (BLoC/Riverpod)
Screen Composable, StateFlow ViewModel, UseCase, Repository, Room DAO, SwiftUI View, Observable ViewModel, Coordinator, SwiftData Model, Widget
Systems & Runtime Rust (Tokio Systems)
Go (Clean Architecture)
Crate/Mod, Struct, Trait, Enum, Tokio/FFI Driver, Go Package, HTTP Handler, Usecase, Repository, SQL Driver
Patterns & General Clean / Hexagonal Arch
Universal Standard
Domain Entity, UseCase/Interactor, Controller/Adapter, Port/Gateway, Presenter/UI, Module, Component, Service, Type, Function, External

[!NOTE] Need custom entities like Actor, Signal, Pipeline, or EventBus? Click + Custom Card... in the toolbar to create arbitrary cards bound to any architectural tier.


2. 🗂️ 1-Click Code Navigation (Card-to-File Beside Split)

Every card can be linked directly to its implementation file via the filePath property:

  • Quick Jump: Click the file chip or header icon to open the target file in a side-by-side split editor (ViewColumn.Beside).
  • Scaffold on Demand: If the referenced file doesn't exist yet, Arch Design prompts you to auto-create it with standard header scaffolding.
  • Editable Path: Click the pencil icon to update or clear the target file path at any time.

3. 🎯 Focus Mode & Dependency Tracing

Tackle complex architectures with hundreds of connections without feeling overwhelmed:

  • Hover or Select: Instantly highlights the complete dependency tree for the active card.
  • Directional Glow:
    • 🟢 Incoming Dependencies: Highlighted in vibrant green with incoming counts.
    • 🔵 Outgoing Injections: Highlighted in bright blue with animated directional dash lines.
  • Context Dimming: Unrelated cards and connections fade to low opacity, letting you trace specific execution paths without distraction.
  • Bottom Status Panel: Displays live incoming/outgoing injection counts or canvas card and connection summaries.

4. 🛡️ Architectural Tiers & Validation Rules

Arch Design abstracts architectures into 6 Universal Tiers to enforce clean separation of concerns:

┌────────────────────────────────────────────────────────┐
│  CONTAINER      (Module, Crate, Package)               │
│      ▲                                                 │
│      │                                                 │
│  PRESENTATION   (Screen, View, Component, Page)       │
│      │ ▲                                               │
│ uses │ │ observes                                      │
│      ▼ │                                               │
│  LOGIC          (Service, ViewModel, Store, UseCase)   │
│      ▲                                                 │
│      │ injects                                         │
│  INFRASTRUCTURE (Database, Queue, Driver, Tokio, API)  │
│                                                        │
│  CONTRACT       (Type, Struct, Trait, Schema, DTO)     │
│  EXECUTION      (Function, Action, Endpoint, Method)   │
└────────────────────────────────────────────────────────┘

Connection Matrix

Source Tier Target Tier Inferred Relationship Status Real-World Architectural Rationale
presentation presentation renders ✅ Allowed UI component composition, screen navigation, modal embedding
logic presentation observes ✅ Allowed Reactive state emitted by Store / ViewModel to Screen
presentation logic uses ✅ Allowed UI dispatches user intents to ViewModel / UseCase
logic logic injects / uses ✅ Allowed Layered domain delegation (ViewModel $\rightarrow$ UseCase $\rightarrow$ Repository)
execution logic implements ✅ Allowed Server action or routine implements business logic
execution presentation helper ✅ Allowed UI formatting helper or event callback
execution contract implements ✅ Allowed Routine implemented on Struct/Trait (impl Trait for Struct)
contract contract implements ✅ Allowed Struct implements Trait, Interface inheritance
contract logic / presentation defines ✅ Allowed DTO contract or UI Props schema definition
infrastructure logic injects ✅ Allowed DB, Cache, or Network injected into Repository or Service
infrastructure container injects ✅ Allowed OS driver, Hardware, or Cloud boundary injected into package
Any Tier container belongsTo / declares ✅ Allowed Structural grouping into feature module, package, or crate
infrastructure presentation — ❌ Blocked UI components must never query raw databases directly
presentation infrastructure — ❌ Blocked Direct coupling from UI to infrastructure is an antipattern
infrastructure infrastructure — ❌ Blocked External infrastructure nodes do not directly inject into each other
container Child Tier — ❌ Blocked Containers do not point downwards into children

5. 🏷️ Visual Tech Badges

External infrastructure cards automatically render authentic vector logos and brand colors:

  • Databases: PostgreSQL, MySQL, MongoDB, SQLite, ClickHouse
  • Caches & Storage: Redis, AWS S3, MinIO
  • Queues & Streaming: Apache Kafka, RabbitMQ, WebSockets
  • Protocols & APIs: GraphQL, REST API
  • Mobile Storage: Room, SwiftData, CoreData, Realm
  • Systems & Runtimes: Tokio (Async Runtime), Hardware/Drivers, FFI

🤖 AI Agent Integration & Skills

Arch Design includes a built-in Agent Skill specification so coding assistants can autonomously read, edit, lay out, and validate architecture files.

1. Install the Skill

Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) and run:

Arch: Install Agent Skill

Choose your scope:

  • Workspace Scope (.agents/skills/arch-design/ & AGENTS.md): Configures the project for the entire team and workspace agents.
  • Global User Profile (~/.gemini/config/skills/arch-design/): Available globally across all projects on your machine.

2. Multi-Agent Compatibility Matrix

Coding Assistant Configured Files Capability
Google Antigravity Scans .agents/skills/arch-design/ Native skill execution & auto-tooling
Claude Code Root AGENTS.md and CLAUDE.md Reads schema, architecture rules, CLI tools
Cursor (Composer) .cursor/rules/arch-design.mdc & AGENTS.md Project rule context injection
Windsurf (Cascade) Root AGENTS.md & rule files Automatic workflow guidance
OpenCode / Aider Root AGENTS.md Standard prompt instructions

3. Bundled Agent CLI Tools

AI agents and CI pipelines can run deterministic scripts without guessing math or syntax:

# 1. Validate schema integrity & tier rules
node .agents/skills/arch-design/scripts/validate.js architecture.arch

# 2. Automatically compute visual Dagre layout coordinates
node .agents/skills/arch-design/scripts/layout.js architecture.arch

4. Example AI Agent Prompts

<!-- Design from scratch -->
"Create an architecture diagram for an e-commerce checkout flow in architecture.arch using the nextjs preset. Include a CheckoutScreen, CartStore, StripeService, and Postgres DB. Run the layout script when finished."

<!-- Audit existing architecture -->
"Inspect architecture.arch, check it against our project source files in src/, and update the filePath fields on all service and repository cards."

<!-- Implement code from canvas -->
"Read architecture.arch, find all cards in the AuthService domain, and generate the TypeScript implementations for each linked filePath."

📄 File Format Specification (v2.1)

Arch Design diagrams (.arch or .lld) are stored as clean JSON:

{
  "version": 2,
  "domain": "backend",
  "framework": "nestjs",
  "name": "auth-system",
  "nodes": [
    {
      "id": "m1",
      "type": "module",
      "tier": "container",
      "label": "AuthModule",
      "pos": { "x": 100, "y": 100 },
      "filePath": "src/auth/auth.module.ts",
      "description": "User authentication domain boundary"
    },
    {
      "id": "s1",
      "type": "service",
      "tier": "logic",
      "label": "AuthService",
      "pos": { "x": 460, "y": 100 },
      "filePath": "src/auth/auth.service.ts",
      "description": "Validates credentials and issues signed JWT tokens",
      "properties": [
        { "id": "p1", "title": "Dependencies", "description": "JwtService, UserRepository" }
      ]
    },
    {
      "id": "f1",
      "type": "function",
      "tier": "execution",
      "label": "loginWithOAuth",
      "pos": { "x": 820, "y": 100 },
      "description": "Exchanges provider code for session token",
      "parameters": [
        { "id": "param1", "name": "code", "type": "string", "required": true, "description": "OAuth authorization code" }
      ],
      "returns": [
        { "id": "ret1", "name": "token", "type": "AuthResponse", "required": true, "description": "JWT bearer payload" }
      ]
    },
    {
      "id": "e1",
      "type": "external",
      "tier": "infrastructure",
      "label": "PostgreSQL",
      "pos": { "x": 460, "y": 380 },
      "tech": "postgres",
      "description": "Primary user database"
    }
  ],
  "edges": [
    { "id": "e1", "from": "s1", "to": "m1", "type": "injects" },
    { "id": "e2", "from": "f1", "to": "s1", "type": "implements" },
    { "id": "e3", "from": "e1", "to": "s1", "type": "injects" }
  ]
}

🛠️ Getting Started

1. Create a Diagram

  1. Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P).
  2. Run Arch: New Architecture File.
  3. Choose a destination file (e.g. architecture.arch).

Or simply create any file ending with .arch or .lld in your workspace and click to open it.

2. Canvas Controls & Shortcuts

  • Add Cards: Select a framework preset from the dropdown and click any card button (e.g. + Service, + Screen).
  • Connect: Click and drag from the handle at the bottom/top of any card to another card.
  • Focus Tree: Hover or click a card to isolate its upstream and downstream flow.
  • Auto Layout: Click Auto Layout in the toolbar to auto-organize all cards hierarchically.
  • Jump to Code: Click any card's file chip to open the implementation file beside your canvas.
  • Expand / Collapse: Toggle the chevron on any card to switch between compact and detailed views.
  • Pan & Zoom: Scroll wheel or drag the canvas surface. Minimap and zoom controls are available at the bottom left.

💻 Development & Building

Built with TypeScript, React 18, React Flow (@xyflow/react), Dagre, and Bun.

# 1. Install dependencies
bun install

# 2. Build extension and webview bundle
bun run compile

# 3. Watch for changes during development
bun run watch

# 4. Run automated test suite
bun run test

# 5. Package VSIX extension
bun run package

🤝 Community & Support

  • 🌐 Live Web Demo: https://anujanthwal-dotcom.github.io/Arch-Design/
  • 📖 Documentation & Agent Skill Reference: Web Docs
  • 🐛 Issue Tracker: GitHub Issues
  • ☕ Support the Project: Buy Me a Coffee

Released under the MIT License. Designed & maintained with care by Anuj Anthwal.
