IRIS OAS Test Gen

IRIS OAS Test Gen is a Visual Studio Code extension designed to accelerate the development of REST API tests in InterSystems IRIS.

It detects OpenAPI (Swagger) files in your editor and allows you to generate robust ObjectScript unit test classes with a single click. The extension handles the file upload to your IRIS server, triggers the generation logic, and reports the status back to VSCode.

✨ Features

• Context-Aware: Automatically detects if the active file is an OpenAPI/Swagger JSON specification ("openapi": "3.x" or "swagger": "2.x").
• One-Click Generation: Adds a convenient "Cloud Upload" button $(cloud-upload) to the editor title bar.
• Seamless Integration: Uploads the JSON spec directly to the IRIS server (Base64 encoded), eliminating the need for manual file transfers or volume mapping complexities.
• Immediate Feedback: Displays success or error notifications directly in VSCode.

⚙️ Extension Settings

This extension contributes the following settings to your VSCode configuration (settings.json):

🛠️ Prerequisites (Backend Setup)

⚠️ Important: This extension requires a backend service running on your InterSystems IRIS instance to process the files.

1. Install the Backend Classes

You need the generator logic installed on your IRIS instance. You can clone the repository and use Docker, or install the classes manually.

Repository: https://github.com/musketeers-br/iris-oas-test-gen

If installing manually, ensure you have the following classes compiled:

1. dc.musketeers.irisOasTestGen.Main (The generator logic)
2. dc.musketeers.irisOasTestGen.Service (The REST API wrapper)

2. Configure the Web Application

You must configure a Web Application in the IRIS Management Portal to expose the functionality:

1. Go to System Administration > Security > Applications > Web Applications.
2. Create a new application (e.g., /api/oas-gen).
3. Namespace: Select the namespace where the classes are installed.
4. Dispatch Class: Set to dc.musketeers.irisOasTestGen.Service.
5. Security: Enable "Password" (Basic Auth).

🚀 How to Use

1. Open an OpenAPI File: Open any .json file that contains an OpenAPI or Swagger specification in VSCode.
2. Check the Icon: Look at the top-right corner of the editor (Title Bar). You should see a Cloud Upload icon $(cloud-upload).
   • Note: The icon only appears if the file is recognized as an OpenAPI spec.
3. Generate: Click the icon.
   • The extension will convert the file content to Base64.
   • It sends the payload to the configured IRIS URL.
   • IRIS processes the file and generates the test classes in the configured remoteOutputDir.
4. Result: You will see a notification: ✅ Gerado com sucesso em /tmp/output.

🔧 Troubleshooting

• Icon not appearing? Ensure the file is a valid JSON and contains "openapi": "..." or "swagger": "..." at the root level.
• "Connection Refused" or 404 Error: Check if the irisOasGenerator.url setting matches your IRIS Web Application configuration and port.
• "Error Backend": If the server responds with an error, ensure the remoteTempDir and remoteOutputDir paths exist on the server (or the container) and that the IRIS user (usually irisowner) has write permissions.

👥 Credits

Developed with ❤️ by the Musketeers Team:

• José Roberto Pereira
• Henry Pereira
• Henrique Dias

Repository: GitHub
