Git Branches

A VS Code extension that adds dedicated Branches and Tags panels to the Source Control sidebar, plus a built-in branch history viewer with a side-by-side commit graph, file diff, and pagination — inspired by the branch management UI in IntelliJ IDEA.

Features

Branches Panel

Displays local and remote branches together in a single tree, grouped by scope:

▼ BRANCHES
  ▼ Local
      ★ main (current)  ↑2 ↓1
        feature/login   ↑3
        fix/typo
  ▼ Remote
    ▼ origin
        main
        feature/login

Current branch is pinned to the top with a star icon. Remote branches are grouped under their remote name.

Local branch actions (right-click)

Remote branch actions (right-click)

Local group actions (right-click on "Local")

Remote group actions (right-click on "Remote" or a remote name)

Tags Panel

Lists all local tags alphabetically, with a sync status indicator for each tag:

Sync status is fetched in the background after the view opens; remote unreachable means no indicator is shown (rather than treating every tag as unpublished).

Tag actions (right-click)

Toolbar (Tags panel)

Toolbar (Branches panel)

Ahead / Behind indicator

Local branches with a configured upstream show a sync status next to their name:

The current branch uses live data from VS Code's git state (same source as the status bar). Other branches update after a fetch + refresh.

History viewer

Selecting View History on any branch opens a built-in webview with a two-pane layout: a paginated commit table on top and a "files changed" panel at the bottom.

Layout

┌────────────────────────────────────────────────────────────────────────┐
│ History · [ feature/login ▼ ]            Graph: (─Left─│─Right─│─Off─) │
├────────────────────────────────────────────────────────────────────────┤
│ Graph  Hash      Refs            Message              Date    Author   │
│  ●     310a3a3   [⎇ HEAD→main]   Add hide/show repo   2d ago  song     │
│  ●     76133a5                   Enhance refs styling 3d ago  song     │
│  ●     9a6da5b                   Add history webview  3d ago  song     │
│  …                                                                     │
│                       [  Load more (200 loaded)  ]                     │
├══════════════════════════════════════════════════════════════════════ │  ← drag splitter
│ FILES CHANGED  76133a5  Enhance reference rendering                    │
├────────────────────────────────────────────────────────────────────────┤
│  [M]  src/                 branchTreeProvider.ts                       │
│  [M]  src/                 commands.ts                                 │
│  [A]  src/                 tagSyncBadge.ts                             │
│  [R]  src/utils/old.ts  →  src/util/renamed.ts                         │
└────────────────────────────────────────────────────────────────────────┘

Branch dropdown

The branch name after History · is a <select> dropdown:

• Defaults to the branch you opened the viewer from
• Lists all local branches alphabetically below
• A -- ALL -- entry at the bottom shows the entire repo history (equivalent to git log --all) — useful for finding commits not on the current branch, locating merge points, or following multiple feature branches in parallel

Switching the dropdown reloads the history from the first page; the file panel resets.

Pagination

Histories load 200 commits per page. A Load more (N loaded) button at the bottom of the table fetches the next batch via git log --skip=N --max-count=200. When you reach the start of history the button is replaced with — end of history (N commits) —. Per-page loading keeps very large repos responsive — the first page is usually under a second even for thousands-of-commits histories.

Graph column controls

The leftmost column is an SVG lane graph showing branch topology, color-coded per lane. A pill-shaped switch in the toolbar controls its placement:

When the graph would otherwise exceed 200px of width (many parallel branches), the column itself stays at 200px and the SVG inside scrolls horizontally.

Lane positions are computed incrementally across pages, so loading more commits never re-shuffles the graph for already-rendered rows.

Commit selection → files changed

Click any commit row to highlight it. The bottom panel populates with the list of files that commit modified (vs. its first parent), with color-coded status badges:

For root commits (no parent), all files are shown as A against git's empty tree.

Click a file → side-by-side diff

Clicking a file row opens VS Code's native diff editor in a new tab:

• Left = file content at the parent commit
• Right = file content at the selected commit
• Added files show an empty left side; deleted files show an empty right side
• Renamed files diff old path → new path
• Tab title: path/to/file (shortHash), or old → new (shortHash) for renames
• The diff editor honors all VS Code diff settings (diffEditor.renderSideBySide, diffEditor.ignoreTrimWhitespace, etc.)

Content is served by a custom URI scheme (gitbranches-show:) that runs git show <ref>:<path> on demand. Files that don't exist at a given ref (added or deleted in this commit) return empty content, so the diff renders cleanly without "file not found" errors.

Compare any two commits (range diff)

Cmd-click (macOS) / Ctrl-click (Windows/Linux) a second commit row to switch the file panel from "this commit vs. parent" to "commit A vs. commit B". The two rows stay highlighted; the file panel shows the cumulative diff. Cmd/Ctrl-click again to return to single-commit mode.

Search / filter

A search box in the toolbar filters the loaded commits in place — matches on subject, author, short hash, or full hash. Non-matching rows are hidden (lane graph remains intact). Press Esc to clear.

Filter operates over the commits already loaded; click Load more to extend the searchable set.

Right-click menus

On a commit row:

On a changed file row:

Resizable splitter

The horizontal bar between the commit table and the files panel is draggable — pull up to give the files panel more room, pull down to focus on commits. The chosen height is remembered per workspace.

Layout persistence

Graph position (Left / Right / Off) and splitter height persist to workspaceState, so opening the history viewer next time uses your last layout.

Reference badges in commit rows

The "Refs" column shows pill-shaped badges for any refs pointing at that commit:

• HEAD and HEAD → branch in teal
• Local branches in green
• Remote-tracking branches in red
• Tags in yellow

Each pill is capped at 110px with ellipsis for long names.

Multi-repo workspace support

When multiple git repositories are open, branches and tags are grouped under repository nodes:

▼ BRANCHES
  ▼ frontend
    ▼ Local
        ★ main
    ▼ Remote
      ▼ origin
          main
  ▼ backend
    ▼ Local
        ...

Hide / show repositories

Repositories you don't actively work in can be hidden from the Branches and Tags views to reduce clutter:

Show in Git Branches also makes sub-folder repositories discoverable — useful for monorepos where nested .git directories aren't always picked up automatically.

Requirements

• VS Code 1.85.0 or later
• The built-in Git extension must be enabled
• Git installed and accessible (uses the path configured in git.path)

Installation

From VSIX (local build)

git clone https://github.com/your-username/vscode-git-branches.git
cd vscode-git-branches
npm install
npm run compile
npx @vscode/vsce package --allow-missing-repository
code --install-extension vscode-git-branches-0.0.1.vsix

Then reload VS Code (Developer: Reload Window).

Development

npm install       # install dependencies
npm run compile   # build once (esbuild → out/extension.js)
npm run watch     # build in watch mode
npm run typecheck # tsc --noEmit (esbuild does NOT type-check)

Press F5 in VS Code to launch an Extension Development Host.

How It Works

This extension delegates git operations to the built-in vscode.git extension API (v1) wherever possible (checkout, merge, push, pull, fetch, createBranch, deleteBranch, getBranches, getRefs). Operations not exposed by the public API — rebase, cherry-pick, rename, stash, delete remote branch, tag manipulation, --squash / --no-ff merge strategies, for-each-ref, ls-remote, paged git log, git show for diff content — are executed via child_process.execFile using the binary at git.path.

After each operation the built-in git extension is notified via git.refresh so its internal state stays in sync.

The history viewer is a webview with a custom TextDocumentContentProvider (scheme gitbranches-show:) that serves commit-time file content directly via git show <ref>:<path>, bypassing the built-in git: scheme to avoid edge cases with non-ASCII paths, nested submodule repos, and missing-at-ref lookups.
