Cortex Debug MCP

VS Code extension for exposing Cortex-Debug / PlatformIO debug capabilities to MCP clients through stdio.

MCP client configuration

If you use VS Code User mcp.json (C:\Users\<user>\AppData\Roaming\Code\User\mcp.json), a recommended version-independent config is:

{
  "servers": {
    "cortex-debug-mcp": {
      "type": "stdio",
      "command": "powershell",
      "args": [
        "-NoProfile",
        "-ExecutionPolicy",
        "Bypass",
        "-Command",
        "$root = Join-Path $env:USERPROFILE '.vscode\\extensions'; $ext = Get-ChildItem $root -Directory | Where-Object { $_.Name -like 'yuelongzhang.cortex-debug-mcp-*' } | Sort-Object LastWriteTime -Descending | Select-Object -First 1; if (-not $ext) { throw 'cortex-debug-mcp extension not found' }; node (Join-Path $ext.FullName 'dist\\stdioProxy.js')"
      ]
    }
  }
}

This avoids editing the config every time the extension version changes.

Upstream and secondary development

This project is open source at:

• https://github.com/MrAlexZhang/cortex-debug-mcp

This project is a secondary development project. Based on the upstream project:

• https://github.com/paulopalaoro/cortex-mcp-bridge

Main changes in this fork:

1. External MCP access changed from SSE to stdio
2. Removed automatic .mcp.json creation/update
3. Renamed extension identity to cortex-debug-mcp
4. Renamed command IDs, config keys, output channel, and backend state file to avoid conflict with the upstream plugin
5. Auto-start semantics simplified: backend now starts by default on extension activation/debug session when cortexDebugMcp.autoStart=true, and the first-run permission dialog was removed
6. Improved arm-none-eabi-nm discovery for get_symbols: removed user-specific hardcoded path, added environment variable override, dynamic Windows toolchain scan, and PATH fallback
7. Updated publisher/author information for this fork
8. Added MCP tools start_debug_session and stop_debug_session to control supported debug sessions from MCP clients
9. Added cortexDebugMcp.autoManageDebugSession setting (default false): MCP can auto-start a supported debug session when tools require one
10. Added managed-session lifecycle: sessions started by MCP can be auto-stopped when bridge stops or extension deactivates
11. Added Cortex Debug MCP: Clean Debug State command to clear MCP breakpoint cache and issue GDB delete breakpoints when supported session is active
12. Status bar action changed to MCP Clear for quick debug-state cleanup
13. Improved breakpoint cache behavior: cache is auto-cleared on supported debug session termination to avoid stale replay
14. Updated session guidance message to include manual start, start_debug_session, or autoManageDebugSession options

How to use

1. Install the .vsix
2. The backend usually starts automatically (cortexDebugMcp.autoStart=true by default). If needed, run Cortex Debug MCP: Start Bridge Server manually
3. Restart or reload your MCP client
4. If no debug session is running, call start_debug_session (optionally pass launchName)
5. Call tools such as get_session_info, get_variables, set_breakpoint, remove_breakpoint, step, gdb_command
6. When done, call stop_debug_session

Debug session control mode

• Default (manual): cortexDebugMcp.autoManageDebugSession=false
  • Keep current behavior. You start/stop debug sessions manually (or with start_debug_session / stop_debug_session).
• Auto mode: set cortexDebugMcp.autoManageDebugSession=true
  • When a DAP tool is called and no supported session exists, MCP auto-starts one from launch.json.
  • When the MCP bridge is stopped, sessions started by MCP are auto-stopped.

Breakpoint/watchpoint cleanup behavior

• On supported debug session termination, MCP automatically clears its internal breakpoint cache.
• To manually clean debug state from VS Code, run Cortex Debug MCP: Clean Debug State from Command Palette.

What it can do

Current MCP tools mainly cover:

• start/stop debug session (start_debug_session, stop_debug_session)
• session status and call stack
• variables, registers, memory, expression evaluation
• set/remove breakpoints
• pause / continue / step
• raw gdb_command
• OpenOCD-based live memory and peripheral tools

VS Code command palette also provides:

• Cortex Debug MCP: Clean Debug State
  • Clears MCP internal breakpoint cache
  • If a supported debug session is active, also runs GDB delete breakpoints (clears breakpoints + watchpoints)

Status bar quick action:

• MCP Clear button (left status bar)
  • Click to run the same debug-state cleanup action quickly

Install from VSIX

If you start from this source repository, build, package, and install it from the repository root:

npm install
npm run build
npm run package
code --install-extension cortex-debug-mcp-1.4.0.vsix

If node_modules already exists from a previous install, you usually only need:

npm run build
npm run package
code --install-extension cortex-debug-mcp-1.4.0.vsix

The generated VSIX file name follows the extension version in package.json. If you change the version, replace cortex-debug-mcp-1.4.0.vsix with the new file name.

code --install-extension cortex-debug-mcp-<version>.vsix

Limitations

• Most DAP read operations require the target to be paused
• get_registers and get_memory depend on Cortex-Debug custom DAP requests
• OpenOCD-based tools such as get_chip_info, read_live_memory, and peripheral helpers may fail in J-Link-only sessions
• gdb_command can be used as an escape hatch for reset / monitor commands

License

MIT
