LaTeX Editing Toolkit 2.0.0

VS Code / Cursor extension for local-first LaTeX projects and fast mathematical writing. Toolkit 2.0 combines project creation, themes, compile and structure tools with the complete programmable hsnips engine, profiles, workspace snippets, Smart Enter/Tab, a Monaco-powered snippet workbench, and integrated Overleaf mirrors, realtime sync, conflict resolution, and remote compilation.

Overleaf integration

The former Overleaf Codex workflow is now part of the same yiqiyang33.latex-editing-toolkit extension. Use the Toolkit Activity Bar's Overleaf Mirrors and Sync sections to log in, open local mirrors, inspect local/remote/base changes, resolve conflicts, and run a remote compile. Remote PDFs open in the native VS Code/Cursor viewer; the Toolkit never embeds a PDF iframe.

Toolkit source and configuration files can be synchronized by default, including .tex, .bib, .sty, .cls, .bst, commands.tex, theorems.tex, theme.sty, theme.colors.tex, theme.ui.json, and theme.overrides.tex. Sync metadata, .vscode, build outputs, PDFs, logs, conflict copies, and machine caches remain local. Destructive deletes, conflict replacement, and binary uploads require explicit confirmation.

For security, Overleaf cookies are not migrated from the old extension. Sign in once through the native Login with Cookie command; credentials are stored in VS Code SecretStorage.

Build

npm install
npm test
npm run package

Install the generated latex-editing-toolkit-*.vsix in VS Code or Cursor, then run:

LaTeX Editing Toolkit: Open Toolkit
LaTeX Editing Toolkit: Create Project
LaTeX Editing Toolkit: Initialize Workspace
LaTeX Editing Toolkit: Upgrade Workspace Theme Assets

The extension also contributes a LaTeX Toolkit Activity Bar view with TreeView shortcuts for project setup, build, structure, and theme actions.

Version 2.0 keeps the responsive Toolkit workbench and adds first-class Snippets and Sync sections. The former Yiqi's LatexSnips engine now runs inside this extension; existing hsnips.* commands, settings, shortcuts, profiles, and snippet directories continue to work without moving user data. The Webview does not embed PDFs: compile results open through the native VS Code/Cursor PDF viewer.

Upgrading from Yiqi's LatexSnips

Toolkit 2.0 is the single host for the local Toolkit, programmable snippets, and Overleaf workflow. After installing it:

Open the Snippets section and confirm that base, profile, and workspace snippets are present.
Disable or uninstall Yiqi's LatexSnips (yiqiyang33.yiqis-latexsnips).
Run Developer: Reload Window.

Keeping both extensions enabled may register duplicate completions and Smart Enter/Tab handlers. Toolkit detects the old extension and shows a one-time warning, but it never disables or uninstalls another extension automatically. Existing snippet data is reused in place:

macOS: ~/Library/Application Support/Code/User/hsnips
Windows: %APPDATA%/Code/User/hsnips
Linux: $HOME/.config/Code/User/hsnips
Workspace: .vscode/hsnips
Profiles: hsnips/profiles/<name>/

Custom hsnips.windows, hsnips.mac, and hsnips.linux paths remain supported.

Programmable Snippets

Run LaTeX Editing Toolkit: Snippets: Open Snippet Manager or select Snippets in the Toolkit. The same panel works without an open workspace for global and profile snippets. With a workspace, it also shows that folder's .vscode/hsnips files. The manager provides:

base, active-profile, and workspace file groups;
search plus scope, language, and diagnostics filters;
a lazily loaded Monaco .hsnips source editor with textarea fallback;
parsed trigger, description, flags, priority, dynamic/regex status, and diagnostics;
duplicate-trigger and duplicate-automatic-trigger warnings across loaded files;
New, Delete, Reload, Open Source, and explicit Save operations;
file hash, modification-time, dirty-editor, and allowed-directory checks before saving.

Snippet source uses explicit Save because it is executable user script, not Toolkit theme state. It does not participate in project autosave or Toolkit Undo/Redo.

Snippet files and profiles

Use language-named files such as latex.hsnips, markdown.hsnips, or all.hsnips. A profile is loaded on top of base snippets, and the active workspace's snippets are added last before all snippets are sorted by priority:

hsnips/
  all.hsnips
  latex.hsnips
  profiles/
    notes/
      latex.hsnips

project/
  .vscode/
    hsnips/
      latex.hsnips

hsnips.profiles.activeProfile stores the current global profile. Multi-root workspaces resolve workspace snippets from the folder that owns the active document.

`.hsnips` syntax

global
// JavaScript shared by snippets in this file
endglobal

priority 10
snippet RR "Real numbers" iAm
\\mathbb{R}
endsnippet

Supported flags include:

A: automatic expansion;
i, w, b: inside-word, word-boundary, and line-beginning matching;
M: multiline regex context;
m: math-only expansion;
t: text-only expansion.

Triggers may be literal or backtick-wrapped regular expressions. Snippet bodies support tabstops, ${VISUAL}, and JavaScript interpolation between double backticks. Interpolation receives rv, t, m, w, and path, preserving the behavior of the original Snips extension.

Mathematical editing

The shared LaTeX context engine recognizes $...$ , $$...$$, \$...\$, \\[...\\], common math environments, comments, Markdown code fences, verbatim-like environments, and text-like commands. It powers:

math-only and text-only snippet flags;
Smart Enter row breaks in align, matrices, cases, array, and table environments;
Smart Tab alignment separators with normal placeholder fallback;
environment conversion and matching \\begin/\\end renaming;
wrapping and unwrapping supported math structures.

Extra environments and text-like commands can be configured with the existing hsnips.context.* settings.

Create Project Wizard

Create Project now chooses a parent location, project name, and starter template. The extension creates the project folder automatically. It remembers recent parent locations and checks write access, project-name safety, template validity, and file conflicts before writing anything.

A missing target folder is created automatically.
An existing empty folder requires explicit confirmation.
A non-empty folder is rejected with a conflict summary.
Failed creation leaves partial resources available for inspection but does not register the project in Local Notes.

Local Notes Registry

The Activity Bar includes a Local Notes group that remembers projects created with LaTeX Editing Toolkit: Create Project, even when they live outside the current workspace. The registry is stored in the extension's local global state and is available after switching workspaces or restarting VS Code/Cursor.

Click a valid entry to open its project folder in the current window.
Missing project folders remain visible with a warning status.
Use Relocate Local Project on a missing entry to select its new folder. The selected folder must contain main.tex.
Use Forget Local Project to remove an entry from the Activity Bar without deleting files.
The list refreshes when the VS Code/Cursor window regains focus, so folders moved or deleted outside the editor are marked Missing without polling.
Existing folders are compared using their real path. Registering the same project through a symbolic link or differently-cased macOS/Windows path updates the existing record instead of creating a duplicate.

The extension does not scan arbitrary directories and does not automatically register files created with Generate Starter In Workspace.

Style Presets

Toolkit now exposes one unified Style Preset selector instead of separate block, heading/TOC, and bold-color selectors. The five presets are Default, Midnight, Meadow, Ember, and UChicago.

Applying a preset updates the complete visual token package together: chapter and section headings, TOC and page-header colors, theorem/definition/note/callout blocks, inline commands (\\hl, \\key, \\term, \\warn, \\todo, and \\code), sidenotes, chapter overviews, and \\textbf. \\hl remains a background highlight while \\key remains a bold rounded emphasis box; they share the selected preset's color system without losing their different semantics.

The Toolkit displays styles as keyboard-accessible miniature document cards. Hovering or focusing a card temporarily updates the live Style preview without writing project files; clicking applies its complete color package and saves automatically. The preview demonstrates headings, inline commands, theorem/note/callout blocks, sidenotes, and chapter overviews. A card shows Customized when any current color differs from its baseline.

View Changes groups changed tokens and shows baseline/current swatches. Individual tokens or the whole style can be reverted. Customized colors can be saved into a global My Styles library. Personal styles are available in every workspace in the current VS Code/Cursor profile and can be renamed, updated, deleted, imported, or exported as JSON.

The Colors panel still allows advanced per-token adjustments. Clicking a Style Preset again intentionally restores every token in that preset's complete package. Older block_preset/heading_toc_preset entries in theme.ui.json are read automatically, with the legacy block value taking precedence, and are mirrored on the next save for compatibility.

Automatic Saving and Undo

There are no separate Apply Style, Apply Target, Apply Recipe, or Save Overrides steps in the main Toolkit. Toggles, class rules, targets, recipes, colors, body size, and styles save automatically. The header reports Saving, Saved, or Could not save, and failed drafts remain available for Retry instead of being discarded.

Each project keeps one persistent Toolkit change with both Undo and Redo. Supported changes include settings, theme upgrades and resets, workspace initialization, VS Code settings generation, starters, Split, Renumber, and Unsplit. Compile, Clean, Local Notes registry operations, and whole project creation do not replace the Undo record. File conflicts caused by external edits are detected before restore and require explicit Force Restore.

Undo history is stored in the extension's global storage rather than inside the LaTeX repository.

Safe Theme Asset Upgrades

Upgrade Workspace Theme Assets always backs up files before replacing theme.sty, theorems.tex, and commands.tex. It offers two color policies:

Preserve Colors (default) upgrades only the bundled TeX assets and leaves theme.colors.tex, theme.ui.json, theme.overrides.tex, and every Toolkit setting unchanged.
Reset to Default applies the complete Default color package while preserving toggles, body size, class rules, compile target, recipe, fallback mode, and compile status. It rewrites only color/style state in theme.colors.tex and theme.ui.json; theme.overrides.tex is untouched.

Replacement uses temporary files and atomic renames. If any step fails, already-modified files are restored from the operation backup and files that did not previously exist are removed.

Configuration Recovery and Logs

Configuration is loaded field by field. A broken JSON file or one invalid toggle, color, preset, font size, class option, target, recipe, or compile-status field no longer prevents the Toolkit from opening. Valid fields continue to load, invalid fields fall back locally, and warnings appear in the Activity Bar Diagnostics group and the Toolkit Diagnostics section. Warnings are diagnostic only and are not saved into theme.ui.json; the next successful automatic save writes normalized state.

Extension commands share a LaTeX Editing Toolkit Output channel. Errors include timestamp, command, workspace, and stack information, and notifications offer Show Log. Compile output is also written there in full. If Create Project fails, the selected directory is not removed and is not added to Local Notes; it may contain partial generated resources and can be opened directly from the failure notification.

Workspace Files

The extension reads and writes these project files:

theme.ui.json
theme.overrides.tex
theme.colors.tex
.vscode/settings.json

Template assets live under assets/template/ and are copied into a workspace only when missing.

Starter Templates

Available starters:

book-minimal
article-minimal
homework-assignment

The default starter remains book-minimal.

Visual Workbench

The Toolkit Webview uses a responsive three-part layout:

Section navigation for Style, Build, Document, Colors, Project Setup, Structure, and Diagnostics.
A task-focused center panel that shows only the active tool.
A contextual panel that shows the live Style preview or the current build/setup/operation summary.

Wide editor tabs use three columns, medium tabs use horizontal navigation with two columns, and narrow tabs stack the active task above its context. The selected section is remembered per project. The interface follows VS Code theme colors, high-contrast mode, reduced-motion preferences, and keyboard tab navigation.

Compile and PDF

Compile PDF flushes pending automatic saves and runs the selected target and recipe. The Toolkit shows the last result, expected output path, and whether the PDF currently exists. Open PDF opens the generated file through the native VS Code/Cursor viewer. The Toolkit does not embed, reload, or automatically compile a PDF when Style or document settings change.

Main Features

Centralized LaTeX theme module in theme.sty.
Theorem and callout environments from theorems.tex.
Note-writing helpers from commands.tex.
Theme color, toggle, class mode, body font size, and compile target controls.
Built-in color presets, including UChicago maroon/greystone.
Global personal styles with difference inspection and JSON import/export.
Automatic saving with persistent one-step Undo and Redo.
Responsive Style, Build, Document, Colors, Setup, Structure, Snippets, and Diagnostics workspace.
Programmable .hsnips completion engine with profiles and per-workspace snippets.
Smart mathematical Enter/Tab, environment conversion, matching-name sync, and wrap/unwrap tools.
Transactional workspace theme asset upgrades with Preserve Colors as the safe default.
Internal fallback compile pipeline plus optional VS Code recipe mode.
Generate .vscode/settings.json for LaTeX Workshop-compatible recipes.
Clean build artifacts while preserving source files and PDFs.
Split root documents into Sections/, renumber referenced units, and merge a unit back into the root.

Local Compile

Compile the guide document directly:

latexmk -xelatex -bibtex main.tex

Fallback compile flow:

xelatex main.tex
biber main
xelatex main.tex
xelatex main.tex

Reset All Toolkit Overrides

Reset All Toolkit Overrides is intentionally destructive: it removes theme, class, toggle, compile, and status settings stored in all three generated files. The equivalent shell command is:

rm -f theme.colors.tex theme.overrides.tex theme.ui.json

Acknowledgements

The programmable snippet engine was developed in Yiqi's LatexSnips, itself based on the ideas and syntax of HyperSnips/UltiSnips-style programmable snippets. Toolkit 2.0 preserves that project's commands, configuration keys, data layout, and .hsnips language while making this repository the single maintained extension and user interface.
