XCX Language Support

Rich language support for the XCX 4.2 programming language in Visual Studio Code.

🌐 Website · 📦 PAX Registry · ▶ Playground · GitHub

Features

Syntax Highlighting — comprehensive highlighting for all XCX keywords, types, operators, literals, column attributes (@pk, @unique, @optional, @default, @fk), terminal commands, and the input module.
Snippets — handy snippets for all language constructs (see list below).
Diagnostics (Linter) — real-time detection of common errors: missing semicolons, missing then;/do;, unclosed <<< blocks, malformed yield from, and more.
Language Configuration — bracket matching, auto-closing pairs, comment toggling (---), and smart indentation.
File Icons — custom icons for .xcx and .pax files.
PAX Support — full syntax highlighting for project.pax and pax.lock files including version pins, GitHub shortcuts, dependency URLs, and metadata fields.

Syntax Highlighting

The extension highlights:

Keywords — if, then, elif, else, end, while, for, do, func, fiber, yield, return, include, serve, const, and all aliases.
Types — i, f, s, b (and long forms int, float, str, bool), array, set, map, table, json, date, fiber:T, database.
Set domains — N, Z, Q, S, B, C after set:.
Column attributes — @auto, @pk, @unique, @optional, @default, @fk in table column definitions.
Built-in modules — crypto, net, env, store, random, date, input, perf (when used as module.method).
Built-in functions — halt, alert, error, fatal, store, random, choice, input, perf.
Operators — arithmetic, comparison, logical (AND, OR, NOT, HAS, !!, &&, ||), set (UNION, INTERSECTION, DIFFERENCE, SYMMETRIC_DIFFERENCE, ∪, ∩, \, ⊕), I/O (>!, >?), digit concatenation (++), and special XCX operators (->, <->, <=>, ::, ++).
Decorators — @step, @wait.
Terminal commands — .terminal !clear, !exit, !run, !raw, !normal, !cursor, !move, !write.
Literals — integers, floats, booleans, strings, raw JSON blocks (<<< ... >>>).
Constants — true, false, EMPTY.
PAX files — metadata keys (name, version, author, description, main, tags, files, deps), version pins (@1.2.0), GitHub shortcuts, and direct URLs.

Snippets

Snippets are grouped by category. Trigger them with the listed prefix.

Variables & Types

Prefix	Description
`xvar`	Variable declaration (i / f / s / b)
`const`	Constant declaration
`toi`	Cast to int: `i(x)`
`tof`	Cast to float: `f(x)`
`tos`	Cast to string: `s(x)`

Functions

Prefix	Description
`func`	Void function
`funcr`	Function with return value
`funcnp`	No-parameter function with return
`funcv`	No-parameter void function

Fibers

Prefix	Description
`fiber`	Typed fiber definition
`fiberv`	Void fiber definition
`fiberh`	HTTP handler fiber
`fiberi`	Typed fiber instance + `.next()`
`fiberiv`	Void fiber instance + `.run()`
`fiberpipe`	Fiber pipeline (chaining sub-fibers)
`fiberloop`	`while isDone()` consume loop
`forfib`	`for` loop over fiber
`yield`	`yield value;`
`yieldv`	`yield;` (void fiber)
`yieldfrom`	`yield from` — delegate to sub-fiber

Control Flow

Prefix	Description
`if`	If statement
`ifelse`	If-else
`ifelif`	If-elif-else
`ifg`	Inline guard
`ifguard`	Guard with `yield net.respond` + `return`

Loops

Prefix	Description
`while`	While loop
`forr`	For range loop
`forrs`	For range with `@step`
`forin`	For over collection (array / set / fiber)
`forset`	For over set
`foridx`	For with explicit index

HTTP Server

Prefix	Description
`serve`	`serve:` block
`respond`	`yield net.respond(status, body)`
`respondh`	`yield net.respond` with headers
`respondi`	`yield net.respond` with inline JSON
`handleopts`	CORS OPTIONS preflight handler
`handle404`	404 fallback handler
`authextract`	Extract Bearer token from Authorization header
`netget`	`net.get(url)`
`netpost`	`net.post(url, body)`
`netput`	`net.put(url, body)`
`netdel`	`net.delete(url)`
`netreq`	Low-level `net.request` builder
`netcheck`	Guard on response `.ok` field

Database

Prefix	Description
`database`	SQLite connection declaration
`databasef`	SQLite connection with all options
`dbsync`	`yield db.sync(table)` — CREATE TABLE IF NOT EXISTS
`dbdrop`	`yield db.drop(table)`
`dbhas`	`db.has(table)` — check table exists (no yield)
`dbfetch`	`yield db.fetch(table)` — SELECT *
`dbfetchw`	`yield db.fetch(table).where(...)` — SELECT with filter
`dbinsert`	`yield db.insert(table, values)` — positional args
`dbinsertn`	`yield db.insert(table, col = val)` — named args
`dbinsertid`	INSERT and read `insertId`
`dbpush`	`yield db.push(table)` — bulk INSERT
`dbsave`	`yield db.save(table)` — upsert
`dbremove`	`yield db.remove(table).where(...)` — DELETE with filter
`dbtruncate`	`yield db.truncate(table)` — DELETE all rows
`dbexec`	`yield db.exec(sql, params)` — raw SQL
`dbquery`	`yield db.query(table, sql, params)` — typed raw SQL
`dbraw`	`yield db.queryRaw(sql)` — returns JSON array
`dbrawfirst`	`queryRaw(...).first()` — aggregate result
`dbtx`	`begin` / `commit` transaction block
`dbtxr`	Transaction with explicit `rollback` guard
`dbclose`	`db.isOpen()` + `db.close()`
`tabledb`	Table with `@auto @pk` for database use
`tablefk`	Table with `@fk` foreign key column
`dbvarfix`	Fiber-scoped DB variable workaround (Windows S101)

Tables

Prefix	Description
`table`	Empty table with `@auto` id
`tabledata`	Table with initial rows
`where`	`.where(col == val)` filter
`wherechain`	Chained `.where()` filters
`wherelambda`	`.where(row -> ...)` lambda filter
`wherehas`	`.where(col HAS "substring")`
`join`	Key-based inner join
`joinlambda`	Lambda inner join
`insert`	`.insert(values)`
`tadd`	`.add(values)` (alias for insert)
`taddn`	`.add(col = val)` named arguments
`update`	`.update(idx, values)`
`delete`	`.delete(idx)`
`tcount`	`.count()` — number of rows
`tshow`	`.show()` — print table to terminal
`ttojson`	`.toJson()` — serialize to JSON array
`tget`	Get field from row
`tfind`	Find row index by field value

JSON

Prefix	Description
`jsonraw`	JSON raw block literal
`jsonp`	`json.parse(string)`
`jset`	`.set(key, value)`
`jbind`	`.bind(key, var)` — extract into variable
`jbindpath`	`.bind("parent.child", var)` — nested dot-path
`jexists`	`.exists(key)` guard
`jpush`	Append to JSON array node via `.push()`
`jbracket`	Set JSON array element via bracket notation
`jinject`	`.inject()` — bulk import array into table
`jstr`	`.toStr()` — serialize to string
`jsize`	`.size()` / `.count()`
`jfirst`	`.first()` — first element of JSON array
`jresp`	Build JSON response and yield

Arrays

Prefix	Description
`array`	Array declaration (includes `array:json`)
`arraye`	Empty array
`arrayjsonloop`	Iterate over `array:json` with index

Sets

Prefix	Description
`setr`	Set with inclusive range
`setrs`	Set with range and `@step`
`sete`	Set with explicit elements
`setunion`	`UNION` operation
`setintersect`	`INTERSECTION` operation
`setdiff`	`DIFFERENCE` operation
`setsymdiff`	`SYMMETRIC_DIFFERENCE` operation
`setadd`	`.add(value)`
`setremove`	`.remove(value)`
`setcontains`	`.contains(value)`

Random

Prefix	Description
`randchoice`	`random.choice from` set or array
`randint`	`random.int(min, max)`
`randints`	`random.int(min, max @step n)`
`randfloat`	`random.float(min, max)`
`randfloats`	`random.float(min, max @step n)`

Maps

Prefix	Description
`map`	Empty map
`mapd`	Map with initial data
`mapget`	Safe `.get()` with `.contains()` guard
`maptojson`	`.toJson()` — serialize to JSON object
`mapkv`	`.keys()` / `.values()` — get arrays

Strings

Prefix	Description
`strlen`	`.length` property
`strcase`	`.upper()` / `.lower()`
`strtrim`	`.trim()`
`strreplace`	`.replace(find, replace)`
`strslice`	`.slice(start, end)`
`strindex`	`.indexOf(search)` / `.lastIndexOf(search)`
`strsplit`	`.split(separator)` → `array:s`
`strbound`	`.startsWith()` / `.endsWith()`
`strparse`	`.toInt()` / `.toFloat()`
`strchain`	Normalization chain: trim + lower + replace
`strconcat`	Integer digit concatenation `++`

Date

Prefix	Description
`datenow`	`date.now()`
`datelit`	Date from ISO string
`datelitf`	Date from string with custom format
`datefmt`	Format date to string
`datearith`	Add / subtract days
`datediff`	Days between two dates
`dateprop`	Access `.year`, `.month`, `.day`, `.hour`, `.minute`, `.second`
`ratelimitkey`	Per-minute rate limit key from IP + timestamp

Perf (Performance Timer)

Prefix	Description
`perfms`	`perf.ms()` — elapsed milliseconds since VM start
`perfus`	`perf.us()` — elapsed microseconds since VM start
`perfns`	`perf.ns()` — elapsed nanoseconds since VM start
`perfbench`	Benchmark block: start + end + print elapsed ms

Env

Prefix	Description
`envget`	`env.get("VAR")` — read environment variable
`envargs`	`env.args()` — CLI arguments as `array:s`
`envargsloop`	Get and iterate CLI arguments

Input (Raw Keys)

Prefix	Description
`inputkey`	`input.key()` — read key if available
`inputkeyw`	`input.key() @wait` — block until key pressed
`inputready`	`input.ready()` — check if key is waiting
`inputhandle`	Arrow key + ESC handler (if/elif block)

Terminal Commands

Prefix	Description
`termclear`	`.terminal !clear`
`termexit`	`.terminal !exit`
`termraw`	`.terminal !raw` — enable raw mode
`termnormal`	`.terminal !normal` — restore normal mode
`termcursor`	`.terminal !cursor on/off`
`termmove`	`.terminal !move x y`
`termwrite`	`.terminal !write expr`
`termrun`	`.terminal !run "file.xcx"`
`gameloop`	Full game loop with raw terminal + arrow key input

Error Handling

Prefix	Description
`alert`	`halt.alert` — warning, continues
`herror`	`halt.error` — aborts current frame
`fatal`	`halt.fatal` — terminates VM
`safediv`	Guard against division by zero

Store (File I/O)

Prefix	Description
`storewrite`	`store.write(path, content)`
`storeread`	`store.read(path)` with `exists()` guard
`storeappend`	`store.append(path, content)`
`storedelete`	`store.delete(path)`
`storelist`	`store.list(path)` → `array:s`
`storeisdir`	`store.isDir(path)`
`storesize`	`store.size(path)` → bytes
`storemkdir`	`store.mkdir(path)`
`storeglob`	`store.glob(pattern)` → `array:s`
`storezip`	`store.zip` / `store.unzip`

Crypto

Prefix	Description
`cryptohash`	`crypto.hash(password, "argon2")`
`cryptobcrypt`	`crypto.hash(password, "bcrypt")`
`cryptob64enc`	`crypto.hash(data, "base64_encode")`
`cryptob64dec`	`crypto.hash(data, "base64_decode")`
`cryptoverify`	`crypto.verify(input, hash, "argon2")`
`cryptotoken`	`crypto.token(32)`

Modules & I/O

Prefix	Description
`inc`	`include "module.xcx"`
`incas`	`include "module.xcx" as alias`
`print`	`>! value;`
`input`	Print prompt + read `>?`
`wait`	`@wait milliseconds;`

Diagnostics

The linter checks each .xcx file on every save/edit and reports:

Missing ; at end of statements (declarations, assignments, calls, I/O, halt, include, yield, return, break, continue, input.*, .terminal !*, database methods).
Missing then; after if/elif/elf conditions.
Missing do; after while and for.
Missing { after func/fiber signature.
end without ;.
else/els without ;.
Unclosed <<< raw JSON block on a single line (warning).
Unbalanced <<</>>> across the whole file.
Malformed yield from — must be yield from <identifier>;.

PAX Package Manager

The extension fully supports .pax files used by the PAX package manager.

Highlighted elements in `project.pax`

Block delimiters / — opening and closing of the configuration block.
Metadata keys — name, version, author, description, main, tags, files, deps.
String values — all quoted strings.
Version pins — @1.2.0 in dependency strings.
Semantic version values — "1.0.0" literal version strings.
GitHub shortcuts — user/repo format inside dependency strings.
Direct URLs — https://... dependency URLs.
Operators — :: separator, , delimiter.
Comments — --- single line and --- / *--- block comments.

Example `project.pax`

---
PAX Project Configuration
*---
/
    name        :: "my_project",
    version     :: "1.0.0",
    author      :: "DeveloperName",
    description :: "A quick description.",
    main        :: "src/app.xcx",
    tags        :: ["math", "utility"],
    files       :: ["src/main.xcx", "src/lib.xcx"],
    deps        :: [
        "mathlib@1.2.0",
        "user/repo",
        "https://domain.com/lib.xcx"
    ]
/

Links


Official website	xcxlang.com
PAX Registry	pax.xcxlang.com
Web Playground	playground.xcxlang.com
GitHub	xcxlang-org/xcx

Installation

Download the .vsix file.
Open VS Code.
Go to the Extensions view (Ctrl+Shift+X).
Click the ... menu and select Install from VSIX....
Choose the downloaded .vsix file.

XCX Support Suite

xcxlang-org
