xRegistry Code Generator - VS Code Extension

Generate type-safe messaging/eventing SDKs from xRegistry message catalog definitions directly in Visual Studio Code.

Features

• Multi-Language Support: Generate SDKs for Python, TypeScript, C#, Java
• Multiple Protocol Styles: AMQP, MQTT, Kafka, HTTP, Azure Event Hubs, Azure Service Bus, Azure Event Grid
• Producer & Consumer Templates: Generate both message producers and consumers
• Context Menu Integration: Right-click on .xreg.json files to generate code
• CloudEvents Support: Full CloudEvents envelope support
• AsyncAPI & OpenAPI: Generate API definitions from message catalogs

Requirements

• Python 3.10 or later
• xRegistry Code Generator CLI installed (pip install xrcg)

The extension will prompt you to install the CLI if it's not found.

Usage

1. Create or open an xRegistry message catalog file (.xreg.json)
2. Right-click on the file in the Explorer
3. Select Generate Code from the context menu
4. Choose your target language (Python, TypeScript, C#, Java, etc.)
5. Select the style (producer, consumer, or protocol-specific variant)
6. Choose an output location

The extension will generate a complete, compile-ready project with tests and dependencies.

Supported Languages & Styles

Python

• AMQP 1.0 Producer/Consumer
• Apache Kafka Producer/Consumer
• Azure Event Hubs Producer/Consumer
• Azure Service Bus Producer/Consumer
• MQTT Client

TypeScript

• AMQP 1.0 Producer/Consumer
• Apache Kafka Producer/Consumer
• Azure Event Hubs Producer/Consumer
• Azure Event Grid Producer
• Azure Service Bus Producer/Consumer
• HTTP Producer
• MQTT 5.0 Client
• Dashboard

C#

• AMQP 1.0 Producer/Consumer
• Apache Kafka Producer/Consumer
• Azure Event Hubs Producer/Consumer/Azure Function
• Azure Event Grid Producer/Azure Function
• Azure Service Bus Producer/Consumer/Azure Function
• MQTT 5.0 Client

Java

• AMQP 1.0 Producer/Consumer
• AMQP JMS Producer
• Apache Kafka Producer/Consumer
• Azure Event Hubs Producer/Consumer
• Azure Service Bus Producer/Consumer
• MQTT 5.0 Client

API Definitions

• AsyncAPI (Producer/Consumer)
• OpenAPI (Producer/Subscriber)

Azure Stream Analytics

• Query Dispatch
• Query Dispatch with Payload

Known Issues

• None currently reported

Release Notes

0.13.0

• Updated branding and metadata
• Full xRegistry code generation support

0.0.1

• Initial release

More Information

• xRegistry Specification
• Code Generator GitHub Repository
• Sample Message Catalogs

License

Apache 2.0
