Wire DSL - VS Code Extension

Syntax highlighting, autocompletion, and preview for Wire DSL .wire files.

Features

🎨 Syntax Highlighting

Complete syntax highlighting for Wire DSL with intelligent tokenization:

Keywords (project, screen, stack, grid, panel, split, form, table)
Components (40+ UI components: Button, Input, Card, Table, etc.)
Properties (id, label, color, background, width, height, etc.)
Values (colors, spacing tokens, numbers)
Comments (// and /* */ with proper styling)
Bracket matching and auto-pairing

💡 Code Intelligence

Context-aware development experience:

Autocompletion (Ctrl+Space) - Intelligent suggestions for keywords, components, and properties
Hover Documentation - Full component and property documentation on hover
Go-to-Definition (Ctrl+Click) - Jump to component definitions
Find References (Ctrl+Shift+H) - Find all usages of components

👁️ Live Preview

Real-time visual feedback as you code:

Interactive SVG Rendering - See your Wire DSL rendered as interactive SVG
Multi-Screen Support - Switch between screens with a dropdown selector (when file has multiple screens)
Persistent Zoom - Zoom level is maintained when switching screens or editing code
Dark/Light Theme Support - Toggle between themes with automatic VS Code detection
Zoom Controls - Zoom in/out with Ctrl+Scroll wheel or on-screen buttons
Auto-Refresh - Updates automatically on file save
Keyboard Shortcuts (Ctrl+Shift+V to open)

Installation

From Marketplace (Coming Soon)

Search for "Wire DSL" in VS Code Extensions

Local Installation (Development)

Prerequisites

Node.js 18+ (download)
npm (comes with Node.js)
VS Code 1.75+

Quick Start

cd packages/vscode-extension
npm install
npm run package

This command:

Compiles TypeScript to JavaScript (esbuild, minified)
Packages the extension as .vsix (VS Code Extension format)
Installs the extension in VS Code automatically

Restart VS Code to activate the extension.

Why Standalone npm?

This project is a standalone npm project (independent from the monorepo pnpm):

✅ No npm/pnpm conflicts - contributors use standard npm install
✅ Compatible with VS Code tooling (vsce and code --install-extension)
✅ Clear dependency resolution without monorepo interference

Important: Always use npm (not pnpm) in this directory:

npm install      # ✅ Correct
pnpm install     # ❌ Will cause conflicts

The .npmrc file enforces npm usage for this project.

Development Workflow

# One-time setup
npm install

# During development (watch mode)
npm run esbuild-watch

# Run in debug mode
# In VS Code: Press F5 to launch extension with debugger

# Run tests
npm run test

# Package without installing
npm run package-only

Project Structure

This is a standalone npm project (independent from the monorepo pnpm).

vscode-extension/
├── src/
│   ├── extension.ts                  # Entry point & provider registration
│   ├── completionProvider.ts         # Intelligent context-aware completions
│   ├── hoverProvider.ts              # Hover documentation tooltips
│   ├── definitionProvider.ts         # Go-to-definition navigation
│   ├── referenceProvider.ts          # Find references (all usages)
│   ├── webviewPanelProvider.ts       # Live SVG preview panel
│   ├── webviewProvider.ts            # Alternative webview provider
│   ├── data/                         # Component metadata & documentation
│   │   ├── components.ts             # Component definitions
│   │   └── documentation.ts          # Component & property docs
│   └── utils/
│       └── documentParser.ts         # DSL parsing utilities
├── syntaxes/
│   └── wire.tmLanguage.json          # TextMate grammar (syntax highlighting)
├── package.json                      # npm dependencies & manifest
├── package-lock.json                 # Locked versions (use npm)
├── tsconfig.json                     # TypeScript configuration
├── language-configuration.json       # Bracket pairing, indentation
├── .npmrc                            # npm config (force npm usage)
└── icons/                            # VS Code extension icons

For detailed architecture information, see ARCHITECTURE.md.

Usage

Open a .wire file - The extension automatically activates and applies syntax highlighting
Get code completion - Press Ctrl+Space (Cmd+Space on macOS) or start typing to see intelligent suggestions
Explore documentation - Hover over components and properties to see detailed documentation
Navigate your code - Use Ctrl+Click to jump to definitions or Ctrl+Shift+H to find all references
Preview in real-time - Press Ctrl+Shift+V (or click "Open Preview" in the editor title bar) to see live SVG rendering

Keyboard Shortcuts

Action	Shortcut	Mac
Open Preview	Ctrl+Shift+V	Cmd+Shift+V
Find References	Ctrl+Shift+H	Cmd+Shift+H
Go to Definition	Ctrl+Click	Cmd+Click
Zoom In (Preview)	Ctrl+Scroll	Cmd+Scroll
Zoom Out (Preview)	Ctrl+Scroll	Cmd+Scroll

Example

Create a file named dashboard.wire:

project "My Dashboard" {
  screen Dashboard {
    grid {
      columns: 2
      gap: md

      Card {
        id: "card1"
        label: "Users"
      }

      Card {
        id: "card2"
        label: "Revenue"
      }
    }
  }
}

The Wire DSL extension will highlight:

project as a declaration keyword
screen and Dashboard appropriately
grid as a layout control
Card as a component type
Properties like id, label, columns, gap in property color
String values in string color
Numbers and spacing tokens in numeric color

Documentation

Contributing

For Wire DSL Contributors

The VS Code extension is a standalone npm project for easier contribution:

# Clone the repository
git clone https://github.com/develop-wire-dsl/wire-dsl.git
cd wire-dsl/packages/vscode-extension

# Setup (one-time)
npm install

# Development with watch mode
npm run esbuild-watch

# Debug in VS Code
# Press F5 to launch with debugger

Why Standalone npm?

✅ Independent from pnpm monorepo (no conflicts)
✅ Easy for new contributors (npm install works)
✅ Clear dependency resolution
✅ Standard VS Code extension setup
✅ Prevents npm/pnpm conflicts

The extension is still part of the Wire DSL git repo for coordinated releases and documentation.

License

MIT - See LICENSE file in root directory
