WcStack IntelliSense

A VS Code extension for @wcstack/state 4.0. Provides TypeScript language features for <wcs-state> inline scripts, and completions / hover / navigation / diagnostics for data-wcs bindings in HTML.

@wcstack/state 4.0. The bundled parser and manifest are 4.0's, and the checks follow the 4.0 rules: names 4.0 removed (the 3.2 old names, $scan, substr) are reported with their replacement, numeric index paths (items.0.name, groups.0.items.1.v) are not, and the 4.0 settings ($behavior, $features, <wcs-state features>) and the #direct modifier are understood. For a project still on 3.x, keep extension 1.21.x (1.21.0 bundles 3.5 and points out, as wcs/v4-migration hints, what 4.0 changes).

The same validator core is shipped headlessly as the wcs-validate CLI (@wcstack/lint), so the editor and CI report the same diagnostic codes on the same ranges.

Features

Inline Script Type Support

TypeScript completions work inside <script type="module"> within <wcs-state>. No import or defineState() required — the script is wrapped for you.

<wcs-state>
  <script type="module">
export default {
  count: 0,
  users: [{ name: "Alice", age: 30 }],

  increment() {
    this.count++;                 // number
    this["users.*.name"];         // string
    this["users.*.age"];          // number
    this.$getAll("users.*.age");  // number[]
  },

  get "users.*.ageCategory"() {
    return this["users.*.age"] < 25 ? "Young" : "Adult";
  }
};
  </script>
</wcs-state>

The wrapper's preamble knows the runtime API surface: $getAll(path, indexes?), $setAll, $resolve, $command.<name>, $streamStatus.<name> / $streamError.<name>, and the contextual types of $watch handlers and $listKeys key functions (no false noImplicitAny errors). It types the 4.0 declarations $behavior (enableMustache / sameValueGuard / enableDirectionalInitialSync, booleans) and $features (add-on names), and has no member for the names 4.0 removed — this.$trackDependency(…) is a type error, as it is a runtime error.

Attribute Binding Completions

Completions for property names, state paths, modifiers, and filter names in data-wcs attribute values.

data-wcs=" → textContent, class., style., attr., onclick, for, if, ..., radio, checkbox, command., eventToken. ...
data-wcs="textContent: → count, users, users.*.name ...
data-wcs="textContent: count| → gt, eq, upper, trim ... (all 48 built-in filters of 4.2)
data-wcs="value| → write-back (input) filters such as int
data-wcs="onclick# → prevent, stop, ro, direct (the modifier list is the same after any #; ro suppresses write-back on two-way bindings; direct attaches an on*: listener to the element itself instead of delegating it to the root — 4.0)
data-wcs="for: → only array-typed paths
data-wcs="onclick: → only methods and $command.<name>
data-wcs="command.play: → only $command.<name> (from the $commandTokens declaration)
data-wcs="eventToken.value: → only token names from the $eventTokens declaration

Path candidates are derived from the <wcs-state> script (and from JSON state): nested arrays are followed (a.*.b.*.c), $stream entries appear as values plus $streamStatus.<name> / $streamError.<name>, and $listKeys declarations materialize list paths whose initial value is an empty array (the list path, .*, .length and the key field — not the other row fields).

The row shape of a list that starts as [] is read from the row literals in the assignments that add or replace rows — this.items = this.items.concat({ id, kind: "general" }), .toSpliced(i, n, { … }), .with(i, { … }), and [...this.items, { … }] / [{ … }, ...this.items] — anywhere in the script (methods, getters, $connectedCallback, $watch handlers). Only a path already known to be an array gains fields this way, and an explicit initial value always wins. A $listKeys entry is the other way to say "this is a list": $listKeys: { items: "id" } alone makes the analyzer know items, items.*, items.length, and the key field items.*.id — nothing else about the row. A row passed as a variable (concat(row)) cannot be read — declare a stateSchema for that case.

for-context Completions

Inside <template data-wcs="for: items">, shorthand paths (.name, .age) are generated as completion candidates.

<wcs-state>
  <script type="module">
export default {
  items: [{ name: "Alice", age: 30 }]
};
  </script>
</wcs-state>

<template data-wcs="for: items">
  <!-- .name, .age appear as candidates for data-wcs="textContent: " -->
  <span data-wcs="textContent: .name"></span>
</template>

Pattern paths (items.*.name) and shorthand paths (.name) are excluded from completions outside <template for>.

Template Syntax Support

Completions and diagnostics also work in Mustache {{ }} and comment binding  syntax. Both are parsed through the same text-channel parser as the runtime, so {{ a; b }} is one path, exactly as the runtime reads it.

@wcstack/state 4.0 still binds comment bindings — even with $behavior: { enableMustache: false } — and they remain the recommended way to avoid FOUC outside a <template> on a page without SSR. Expressions may span lines in both forms. A comment inside <textarea> or <title> is text to the browser, so it is not a binding there (and is not validated as one); {{ }} inside them is a text node and is bound.

<!-- Mustache syntax — path and filter completions -->
<p>{{ count|gt(0) }}</p>

<!-- Comment binding syntax — no FOUC -->
<p><!--@@:count|gt(0)--></p>
<p><!--@@wcs-text:count--></p>

wcs-* Tag Completions (HTML Custom Data)

The extension ships wcs.html-data.json — VS Code HTML custom data generated from every I/O package's static wcBindable surface and observedAttributes (npm run emit:builtin-tags; freshness against the committed bundles is CI-gated). It provides, in any HTML file with no <wcs-state> required:

Tag-name completion for all wcs-* elements (<wcs-f → <wcs-fetch>)
Hover on a tag showing its contract — bindable properties, inputs, command.* names — with a link to the package README
Attribute completion (observed attributes and input attribute mirrors)
data-wcs declared as a global attribute with a binding-syntax summary

Other editors that use the standard HTML language service (and VS Code setups without this extension) get the same completions by copying the file into the project and referencing it from the html.customData setting:

{ "html.customData": ["./wcs.html-data.json"] }

Hover, Go to Definition, Find References, Inlay Hints

Binding paths are runtime identifiers written directly in HTML, so navigation works without source maps. All four features are queries over the same positional reference index that powers diagnostics.

Hover on a binding path shows its kind (data / computed / list / method / command token / event token), inferred type, owning state, and declaration line. for-shorthand paths show their expansion (`.name` → `users.*.name`). Hovering a filter name shows its signature, description, and type transform (number → string); hovering a modifier (#prevent, #stop, #ro, #direct, #init=, #sync=, #on<event>) explains its semantics. Hovering a filter name 4.0 removed (uc, fix, substr, …) names its replacement. Unresolvable paths get no hover (zero-false-hint policy) — except src-external states, which are explicitly labeled as externally defined.
Go to Definition (F12) jumps from a path in data-wcs / {{ }} /  to its declaration in the inline <wcs-state> script. Dotted paths fall back to their first segment; $command.<name> jumps to $commandTokens, $streamStatus.* / $streamError.* jump to $stream, event-token wirings jump to $eventTokens. Paths of a src-external state jump to the <wcs-state src=…> tag.
Find References (Shift+F12) works in both directions: from a binding path to all its occurrences across every channel (shorthand occurrences are unified with their expanded form), and from a declaration name inside the state script to every binding that reads it (including subpaths). $1…$9 are scoped to their for template, so unrelated loops are not merged.
Inlay hints show the expanded path after a for-shorthand (.name = users.*.name) — the exact attribute rewrite the runtime performs — the result type at the end of a filter chain (→ string), and the expansion size of a spread (...: target → → 13 props, built-in wcs-* tags only — user-defined tags cannot be statically expanded). Hints are omitted whenever the type cannot be statically determined.

Hover text follows wcstack.messageLanguage (default: the VS Code display language).

Diagnostics

Real-time validation of data-wcs attributes, {{ }}, , the <wcs-state> script, and the page's wcstack <script> setup. Every finding carries a stable code (wcs/…); the code and range are identical in the editor and in the CLI, and messages are available in Japanese and English.

Severity policy: error = the runtime raises or the binding can never work; warning = it runs but silently does the wrong thing (the class of bug these checks exist for); info = advisory.

Nothing inside an element marked data-wcs-ignore (the bind attribute plus -ignore) is reported, the element's own attributes included. The runtime does not read that markup as bindings either.

Deliberate exception — the 4.0 runtime throws at init, but the finding is a warning: wcs/wildcard-rank (a pattern path, a shorthand path or a loop index outside any for, #1401 / #1402; too few loop levels, #1401; or another list's *, #1403), because the for scope is reconstructed from the markup and is not exact in every shape. wcs/binding-path-missing is a warning for a similar reason: a missing top-level key fails its binding (#301), but without a stateSchema the validator cannot be sure the key is missing (the value may arrive from outside). Run wcs-validate --strict to fail CI on them too. (wcs/filter-unknown was a warning up to 2.0.0, on the grounds that a page could register filters of its own; no public API does that — not in 4.0, not in 3.x — so an unknown filter always stops the state, and it is an error.)

The outerHTML: / outerText: check (#203) looks at the for / if templates the state binds: those in the document, and those inside a top-level non-structural <template> only when the state binds that template's content — a route template under <wcs-router>, or a layout template that a <wcs-layout layout="id"> names (unless every such <wcs-layout> has enable-shadow-root: its template goes into the outlet's shadow root, which the page's state does not bind). A top-level <template id="tpl"> that only the app's JavaScript clones is not checked, nor a <template> with its own <wcs-state> (a declarative shadow root, a DCC). wcs/delegated-current-target uses the same scope. Both assume the router's defaults, which a page can change only in script: the tag names wcs-router / wcs-layout (config.tagNames) and light-DOM layouts (config.enableShadowRoot: false — set it to true and the layout templates are checked although the page's state does not bind them); a <wcs-layout> with both src and layout still counts its layout template, although the router loads src. The check rebuilds the element nesting from the raw markup: it closes omitted end tags (<li>…<li>, <p>…<div>, table rows and cells) by looking at the element opened last only — an approximation of the HTML parser's scope rules — and honors /> only on void elements and inside <svg> / <math>. A data-wcs attribute without quotes is read for the enclosing templates and elements, but the bindings themselves are validated only in a quoted attribute.

Binding expressions (`data-wcs` / `{{ }}` / ``)

Code	Detects	Severity
`wcs/binding-path-missing`	Path not found in the state (`textContent: typo`). Skipped when no path candidates can be derived, and for a path in a state the validator cannot read: under the mount path of a volume whose source cannot be read (`<wcs-state mount="cart" src="./cart.js">` when `cart.js` cannot be read — no file reader, a URL, a leading-`/` path, a missing file; a script that is not a plain `export default { … }` literal, or has a top-level spread; or a `<wcs-state>` with no source, which waits for `setInitialState()`), on the ancestors of that mount path (`shop` of `shop.cart`), and outside every volume when the page's root state cannot be read (a `<wcs-state>` inside a `<template>` or with `bind-component` is another tree and does not count). An empty state that was read (`json='{}'`, `export default {}`) is read: its paths are reported. A volume's `src=` that can be read (`.js` tries the same-named `.ts` first) adds its keys and its methods under the mount path (4.0 grafts methods: `onclick: cart.add`). With a `stateSchema` the schema decides instead, except for an event handler in a state that cannot be read (the schema carries no methods). A numeric index path (`items.0.name`, `groups.0.items.1.v`, `groups..sel.0.id`) is looked up with its indexes read as `` — 4.0 reads any number of indexes as the row at that position and follows writes, so the path itself is not a finding (warning). `$0`, `$01` or `$1000` — not a loop index (no `$1`…`$128` form), and the `$` namespace holds no state path: the runtime fails the binding with this code, inside a `for` or not (error, reported even without path candidates)	⚠ / ❌
`wcs/index-param-range`	`$129` (or up to `$999`) inside a `for` — a loop index past the limit; the runtime fails the binding with this code. The limit, `$128`, comes from the manifest (`syntax.indexParam.maxDepth`). Outside a `for` it is the loop-index-outside-`for` warning (`wcs/wildcard-rank`), since the runtime throws #1401 first. Also `this.$0` / `this.$129` / `this.$1000` in the `<wcs-state>` script (see below)	❌ error
`wcs/path-nonexistent`	Same, but the state is declared in a sidecar `stateSchema`, so absence is definite. A numeric segment is read as a row (`*`) only where the schema has an array; under an object it is a plain key, as at runtime (`sales.2024.totl` and an undeclared `sales.2025` are reported)	❌ error
`wcs/path-type-mismatch`	`for:` on a path the `stateSchema` proves is not an array	❌ error
`wcs/binding-type-expectation`	Non-array `for:` (error); non-boolean `class.`, non-string `attr.` / `style.` (warning). `if:` / `elseif:` take any value: 4.0 picks the first branch whose condition is truthy	❌ / ⚠
`wcs/filter-unknown`	Unknown filter name (`count\\|fake`) — as the 4.0 runtime reports it. This includes the filters 4.0 removed: the 3.2 old names (`uc` → `upper`, `fix` → `toFixed`, …; the message names the replacement) and `substr`, folded into `slice` — the message says to write `slice(start, start + length)` (with the literal result, `substr(2, 3)` → `slice(2, 5)`, when the arguments are non-negative literals)	❌ error
`wcs/filter-arity`	Too few / too many filter arguments (`count\\|mul`)	❌ error
`wcs/filter-arg-type`	A numeric argument that does not read as a number (`count\\|gt(abc)`) — the runtime throws #27 when the bindings are planned (error; a quoted `gt('5')` reads as 5, as at runtime). Other mismatches, such as a number for a string argument (`join(1)`), which the runtime passes as a string (warning)	❌ / ⚠
`wcs/filter-input-type`	Filter chain input type mismatch (`count\\|upper`)	⚠ warning
`wcs/token-undeclared`	`command.<method>: $command.<name>` with a name not in `$commandTokens` — the runtime throws #1302 when it attaches the binding (error). `$command.<name>` in an event binding or `eventToken.<prop>: <name>` not declared — logged as #1301 each time the event fires (warning). In a state's script, `this.$command.<name>` (or a `$on` handler's `state.$command.<name>`) with a name not in `$commandTokens` — `$command` holds the declared tokens only, so `.emit()` throws a TypeError that names nothing (error, with a did-you-mean)	❌ / ⚠
`wcs/token-misconfigured`	`command.<method>:` right-hand side that is not a `$command.<name>` — the runtime throws #1201 when the bindings are planned (error). A native element's `command.<method>:` whose method is not in the manifest's `nativeCommands` (the `native-commands` feature's table: `showModal` on `<dialog>`, `focus` on any element, …; with a "did you mean") — the runtime throws #1205 at initialization (error)	❌ error
`wcs/template-syntax`	Structural directive (`for` / `if` / `elseif` / `else`) combined with other bindings; spread with a filter or without a target; `outerHTML:` / `outerText:` inside a `for` / `if` template — a row or branch keeps its nodes by position, and 4.0 throws at init (#203; in a route or layout template too, not in a top-level `<template>` that only app code clones) (error). A filter on an event handler (`onclick: fn\\|gt(10)`); `#direct` on a binding that is not an `on*:` event binding (ignored) (warning). `{{ }}` outside a `<template>` (FOUC) and `<!--@@:-->` visualization (info)	❌ / ⚠ / ℹ
`wcs/delegated-current-target`	An `on:` binding of an event 4.0 delegates to the root (`click`, `dblclick`, `input`, `change`, `submit`, `keydown`, `keyup`, `mousedown`, `mouseup`, `pointerdown`, `pointerup`) whose handler — a method of the root state (`pick`) or of a volume (`cart.pick`: 4.0 grafts a volume's methods and invokes them the same way) — reads `currentTarget` from its event parameter before its first `await` resumes (acorn): there it is the root, not the element. Write `on#direct:` (keeping the other modifiers) or use `event.target.closest(…)`. Not reported for `#direct`, for `input` / `change` / `submit` on a custom element (it may dispatch them without bubbling, heard on the element), inside a `<template>` with its own `<wcs-state>` (declarative shadow root, DCC), or inside a top-level `<template>` the state does not bind (one that only app code clones); router route templates and `<wcs-layout layout>` templates are checked — the same scope as #203	⚠ warning
`wcs/submit-without-prevent`	`onsubmit:` on a `<form>` without `#prevent`, whose handler — a method the page declares — does not call `preventDefault`: the browser submits the form too, so the page reloads, or with the router a GET puts the fields (a password too) in the URL and the history. Silent on a form with an `action`, and when the handler cannot be read	⚠ warning
`wcs/binding-syntax`	What the runtime parser rejects since `@wcstack/state` 3.0 (error): an unterminated quote in filter arguments, a second `#` (`value#ro#wo` — write `value#ro,wo`), a value after `else:`, modifiers or left-side filters on `for` / `if` / `elseif` / `else` / `...`, an empty filter (`x\|`, `x\|\|y`), and (4.0, #120) a state path through `__proto__` / `prototype` (`a.__proto__.x` — not `$command.<name>`, an event token, or a method named alone, as at runtime). Judged by the canonical parser (`@wcstack/state/parser`), so lint and the runtime agree; quoted `;` / `\|` in filter arguments are not separators
`wcs/wildcard-rank`	A pattern path `items..name`, a shorthand `.name` or a loop index `$1` outside `<template for>` (4.0 throws #1401 / #1402 at init — the code is the runtime's); more `` ranks (or a higher `$N`) than the enclosing `for` nesting provides; or a `` that ranges over a list other than the one the enclosing `for` renders at that level (`b..y` inside `for: a` — 4.0 throws, #1403; read another list's row in a getter with `$resolve(path, indexes)`)	⚠ warning
`wcs/index-arity`	`$getAll` / `$setAll` / `$resolve` index count does not match the `*` count of the path — the runtime throws #901 / #902 where it is called	❌ error
`wcs/path-readonly`	A binding that writes back — `value:` on an `<input>` / `<select>` / `<textarea>`, `checked:` on a checkbox or radio, `radio:` / `checkbox:`; not with `#ro` — on a getter without a setter: every edit throws `"<path>" is a getter without a setter`, and the state keeps its value. Add a setter, or write `value#ro:`	❌ error
`wcs/aria-attr-unknown`	`attr.aria-*` name that does not exist in WAI-ARIA (with a "did you mean" suggestion)	⚠ warning

Built-in `wcs-*` tag contracts

Code	Detects	Severity
`wcs/tag-member-unknown`	Binding to a property / `command.` / `eventToken.` key the tag does not declare in `wcBindable` — the runtime refuses it with #38 / #1203 / #1204 (at the root the state fails to initialize, in a row the binding fails). That includes DOM properties such as `hidden`, `title`, `id` and `textContent`; only the HTML sinks (`html:`, `innerHTML:`, `outerHTML:`, `srcdoc:`) are written without a declaration. A custom element the page defines itself is checked the same way: `customElements.define("tag", Class)` in an inline script, an `src=` module or a module it imports by a relative path, whose class (or a superclass the page defines) declares `static wcBindable` as a literal — `properties` / `inputs` / `commands` lists of `{ name: "…" }`. An element whose declaration is computed, spread or inherited from elsewhere is not checked, nor a dotted property on it (a component's `state.x:` wiring)	❌ error
`wcs/handle-bound-as-value`	An output its tag declares `semantics: "handle"` — `<wcs-camera>`'s `streamReady`, the live `MediaStream` — bound to a state path (`streamReady: cam.stream`). It works, but puts an object no snapshot, DevTools view or SSR can carry into the state; receive it with `eventToken.streamReady:` and hand it to the next element as a command argument	⚠ warning
`wcs/on-prefixed-member`	A tag member whose name starts with `on` (`once` on `<wcs-timer>`), bound without the leading dot: the runtime makes it an event binding and the value never arrives. Write `.once:` (`@wcstack/state` 3.1)	⚠ warning
`wcs/spread-no-bindable`	`...:` spread onto a helper tag without `wcBindable` (`wcs-fetch-header`, `wcs-fetch-body`, `wcs-infinite-scroll`, `wcs-voice`) — the runtime raises	❌ error
`wcs/trigger-seeded-truthy`	A `trigger` slot seeded with `true` (fires immediately, no edge)	⚠ warning
`wcs/storage-seed-clobber`	Non-manual `<wcs-storage>` value bound without `#init=element` to a slot seeded with a literal (`null`, `''`, `[]`, or an object with content alike), or to an accessor pair (a getter with a setter — the restore form) — the initial write-back overwrites the stored value on every load, so it is data loss. The fix is `value#init=element:` (with a `null` seed for a data slot). A getter without a setter is not reported (it may be save-only), nor is an `undefined` seed or an expression	❌ error
`wcs/storage-init-seed`	`<wcs-storage>` `value#init=element:` bound to a slot seeded with a literal other than `null` (`cart: []`, `theme: "light"`) — `#init=element` pulls the element's value in, and an empty key loads as `null`, so the seed is gone on a first visit (`this.cart.findIndex(…)` throws). Seed `null` and supply the default where you read it, or bind an accessor pair whose setter ignores `null`	⚠ warning
`wcs/input-nested-write`	Non-manual `<wcs-storage>` `value` bound to a path the page writes below (`value: cart` with this[`cart.${i}.quantity`] += 1, `this["cart.0.quantity"] = 2`, or `value: .quantity` in a `for: cart` row): a binding is re-applied only when its path itself is assigned, so those writes are never saved — no error, and a reload brings back the old value. Bind a getter that reads the fields by path (a row getter and `$getAll`) and returns a new value, or replace the array instead of writing below it. `manual` is exempt: its `trigger` save reads the current object. Also `<wcs-fetch>`'s `body` bound to such a path (`body: newUser` with `value: newUser.name`), `manual` or not: `body` resets to `null` after every request, so the second one goes without it — build a new object in the handler that starts the request. An error: the data is lost and the runtime says nothing (a page that also replaces the whole path afterwards does not need the write below it)	❌ error

`<wcs-state>` script

Code	Detects	Severity
`wcs/nested-assign`	`this.user.name = x`, `+=`, `++`, expression-index chains — not reactive; use `this["user.name"] = x`. Also an in-place change the patterns above do not spell with `this.`: `Object.assign(this.form, v)`, a change through an alias of a state value (`const cards = this.cards; cards[0].title = x`, `const { form } = this`), and a write two segments deep through a `$on` handler's state argument (`state.board.cards = x`). The message names the path to assign a new value to	❌ error
`wcs/array-mutation`	`push` / `splice` / `sort` … (9 destructive methods) — not reactive; the message names the non-destructive alternative (`concat`, `toSpliced`, `toSorted` …). Also through an alias (`const cards = this.cards; cards.push(x)` — assigning the same array back adds no row) and through a `$on` handler's state argument (`state.cards.push(x)`)	❌ error
`wcs/array-index-assign`	`this.items[0] = x` (bracket-only chain, all compound forms) — use `this["items.0"] = x` or `with()`. Also through an alias (`const cards = this.cards; cards[i] = card; this.cards = cards` — the same array back does not replace the row) and through a `$on` handler's state argument	❌ error
`wcs/getter-cycle`	Path getters that reference each other in a cycle — the runtime throws #701 when they are evaluated, and every binding that reads them fails. The check does not follow conditions, so a cycle behind mutually exclusive branches is reported too	❌ error
`wcs/getter-untracked-read`	`this.form.name` inside a getter — only `form` is tracked, so the getter never re-runs when `form.name` changes; reported only when the document writes `form.name` somewhere (`value:` / `checked:` / spread / an I/O node output / `this["form.name"] = …`, or `state["form.name"] = …` in a `$on` handler — where SSE and WebSocket data land), so a root that is only ever replaced wholesale (router params, `$stream` folds) stays quiet. Read `this["form.name"]` instead. Also a getter that reads the URL from `location` (`location.pathname`, `window.location.search`, `new URL(location)`): it is not state, so the getter keeps the URL it first read — bind `<wcs-router>`'s `path` / `searchParams`. `location.protocol` / `host` / `origin` do not change within a page and are not reported. Also a getter that reads the clock — `Date.now()`, a `new Date()` of no argument, `performance.now()`: the time is not state, so the cached getter keeps its first value (an event token firing every frame does not re-run it). Keep the time in state (the value `<wcs-raf>` or `<wcs-timer>` writes)	⚠ warning
`wcs/on-handler-this`	`this.…` in a `$on` handler. The runtime calls it as `handler(state, event, …)`, so `this` is `undefined` and the handler throws when called — unlike `$watch` handlers and methods. Write `name(state, event) { state.x = … }`	❌ error
`wcs/updated-callback-unbound`	`$renderedCallback` tests a path that no binding reads — the branch never runs (the callback is binding-driven). Also a path the state does not have, beside a near one it has (`paths.includes("labell")` and `label`, `items..onn` and `items..on`): it is never in `paths` either	⚠ warning
`wcs/command-token-unbound`	A token `$commandTokens` declares, emitted — `.emit()` in the script, or `on*: $command.<name>` in the markup — that no `command.<method>: $command.<name>` binding in the document receives: the emit reaches nothing, without a word. Only the page's root states (a volume's `$commandTokens` are ignored)	⚠ warning
`wcs/write-path-missing`	`this.<key> = …` (or `+=`, `++`, …) of a key the state does not declare, beside a near one it does (`this.selectedID` and `selectedId`): the write creates a new key, and nothing bound to the declared one changes. A new key with no near name is not reported — a state may add keys on purpose	⚠ warning
`wcs/read-path-missing`	A path a getter, setter or method reads through `this` — `this["items..amout"]`, `this.totl`, `this.$getAll("items..amout", [])`, `$resolve` / `$dependOn` with a literal path — that the state does not have, beside a near one it has: a nested read gives `undefined` and a wrong value without a word (the runtime's `diagnostics` add-on warns once with the same code, once a getter has read it); a top-level key throws on read (#301). Looked up as a binding's path is, under the mount path for a volume's script. Only with a near name — `this["opts.flag"] ?? false` reads an optional key on purpose — and never a path built at run time (`this[key]`, a template with `${…}`). Warning; error where a `stateSchema` says the path is not there	⚠ / ❌
`wcs/path-dynamic-unknown`	A top-level spread in `export default { … }` (`...defaults()`) with no `stateSchema`: the keys it brings in cannot be read, so no path of that state is checked — said once, at the spread, with what turns the checks on (a `stateSchema`, which `wcs-schema` derives from JSDoc or TypeScript types). A limit of the lint, not a mistake	ℹ info
`wcs/name-alias`	A dependency API name that 3.2 renamed and 4.0 removed (`$trackDependency` → `$dependOn`, `$untrackDependency` → `$untracked`) — the runtime throws when it is read (its `diagnostics` feature, which `@wcstack/state` and `/auto` include, detects it); the message suggests the canonical name	❌ error
`wcs/declaration-alias`	A declaration key that 3.2 renamed and 4.0 removed (`$streams` → `$stream`, `$updatedCallback` → `$renderedCallback`) — the runtime throws at load time with its `diagnostics` feature (a volume, `mount=`, is refused at graft instead and reported with `console.error`). Warning when the script cannot be parsed statically (a `class` state, found by a pattern)	❌ / ⚠
`wcs/declaration-alias-read`	Reading a removed declaration key (`this.$streams`) — 4.0's state has no such key, so the read is silently `undefined`. Warning when the AST proves the read; info when the script cannot be parsed statically	⚠ / ℹ
`wcs/behavior-invalid`	`$behavior` (4.0) that the runtime rejects at load time: not an object, a key the manifest's `behaviorOptions` does not list (now `enableMustache` / `sameValueGuard` / `enableDirectionalInitialSync`; with a "did you mean"), a value of another type than the option's (all boolean now), or `$behavior` declared in a volume (`mount=`)	❌ error
`wcs/feature-unknown`	A name in `$features` or in the root `<wcs-state features="…">` that is not an add-on (the manifest's `features`: `formats`, `diagnostics`, `temporal`, `list-keys`, `scopes`, `recursion`, `ssr`, `devtools`, `native-commands`; with a "did you mean") — the runtime throws. A `$features` name fails as `wcs/feature-unknown` on a split `auto` page and as `wcs/feature-not-installed` elsewhere; the `features=` attribute is read only by the split `auto` (`dist/split/auto.js`), which fails with `wcs/feature-unknown` (other entries ignore the attribute)	❌ error
`wcs/features-invalid`	`$features` that is not an array, or declared in a volume (error); `features=` on a `<wcs-state>` that is not the document's root — the runtime reads it only on the first `<wcs-state>` without `mount` and `bind-component` (warning)	❌ / ⚠
`wcs/index-param-range`	`this.$0` / `this.$129` / `this["$1000"]` in a getter, a method or a `$watch` handler — 4.0 throws when a `$` followed by a digit is read and is not `$1`…`$128`. Warning when the script cannot be parsed statically (a `class` state, found by a pattern)	❌ / ⚠
`wcs/watch-declaration-invalid`	`$watch` key the runtime rejects: `$`-prefixed, empty segment, non-function handler literal	❌ error
`wcs/watch-path-missing`	`$watch` key that does not exist in the state — the handler silently never fires. A key of the page's root may name a path under a volume (`"cart.total"` — it fires on writes to the grafted state): it is checked against the volume's keys, and not reported when the volume's source cannot be read (as for bindings). A volume belongs to the innermost enclosing `<template>` that holds a root `<wcs-state>` (a declarative shadow root, a DCC) and is checked by that root's `$watch`; any other volume — in the document, or in a route or layout template — belongs to the page's root. (A volume's own `$watch` is not checked: the volume is refused as a whole — `wcs/volume-declaration`.)	⚠ warning
`wcs/scan-declaration-invalid`	`$scan` — removed in 4.0: the runtime throws at load time with its `diagnostics` feature (in a mounted component too; a volume is refused at graft and reported with `console.error`). Fold a path's changes in a `$watch` handler, or events in an `$on` handler. One finding on the key; warning when the script cannot be parsed statically (a `class` state). (The 3.x checks of the entries, `wcs/scan-source-computed` and `wcs/scan-path-missing`, are gone with it.)	❌ / ⚠
`wcs/type-annotation`	JSDoc `@type` incompatible with the initial value (see below)	⚠ warning

$listKeys declarations are consumed rather than diagnosed: malformed keys (empty path, trailing *, non-flat field) simply produce no path candidates, so a broken declaration is never confirmed by the static side.

Page setup

Code	Detects	Severity
`wcs/script-order`	`@wcstack/devtools/auto` loaded after `@wcstack/state/auto`: the DevTools timeline starts when it attaches (4.0 sends it the wiring that is there already)	ℹ info
`wcs/base-href-missing`	`router/auto` present without `<base href>` (basename would be mis-derived). Pinned URLs count (`@wcstack/router@4/auto`, jsDelivr's `@wcstack/router@4.0.2/dist/auto.min.js`), and so does the `wcstack/auto` bundle on a page that has a `<wcs-router>`	⚠ warning
`wcs/router-outlet-misplaced`	A `<wcs-outlet>` that is not right after a `<wcs-router>`, on a page where some router has no outlet right after it. A router uses only the element right after it and otherwise creates its own outlet there, so the routes render there and this outlet stays empty (docs/router-outlet-placement.md)	⚠ warning
`wcs/route-bare-mustache`	`{{ }}` in text directly under `<wcs-route>` (bound only on the landing route; a route entered by navigation shows it as written), or directly under a layout's `<template>` (not bound on a navigation). Wrap it in an element	⚠ warning
`wcs/layout-slot-missing`	A `<wcs-layout layout="X">` that holds content outside its named slots — the nested routes — while `<template id="X">` has no default `<slot>`: the content is not shown. The outlet warns with the same code at runtime	⚠ warning
`wcs/signals-dual-entry`	`@wcstack/signals` and `@wcstack/signals/dom` on the same page (duplicated reactive core)	❌ error
`wcs/signals-dual-entry`	An import map that maps both `@wcstack/signals` and `@wcstack/signals/dom` to CDN bundles, though the page imports one: a module it loads (a sidecar `.js`) that imports `@wcstack/signals` gets a second core. Map only `/dom` (it exports the whole core)	⚠ warning

v2 migration

Code	Detects	Severity
`wcs/named-state-deprecated`	Named states — `<wcs-state name="x">`, `path@x`, `{{ path@x }}` — removed in v2; the message points to `<wcs-state mount="x">` and the prefixed path `x.path`	❌ error
`wcs/mount-path-invalid`	`mount=` value the runtime rejects: empty, an empty segment, `*` anywhere in a segment, whitespace, or the reserved characters `$` `#` `@`	❌ error

Volumes, component mounts and roots (4.0)

Code	Detects	Severity
`wcs/volume-declaration`	A declaration a volume (`<wcs-state mount="…">`) does not take — the lists are 4.0's `scopes/volume.ts`. `$stream`, `$watch`, `$listKeys`, `$renderedCallback`: the runtime refuses to graft the volume and reports it with `console.error` — the state is not on the tree (error). `$commandTokens`, `$eventTokens`, `$on`, `$errorCallback`: the runtime says so with `console.warn` and ignores the declaration — they belong to the root (warning). One level lower when the script cannot be parsed statically (a `class` state). The other keys the runtime refuses in a volume keep their own codes (`$scan`, `$recursion`, `$behavior`, `$features`, the old names `$streams` / `$updatedCallback`). A value of literal `undefined` is no declaration, as at runtime	❌ / ⚠
`wcs/bind-component-source`	A `<wcs-state bind-component>` with a `state` / `src` / `json` attribute or an inline `<script type="module">`: a mounted component's state is the host element's property only, and the runtime refuses to load it (`console.error`; the component does not mount). Reported on the start tag; the script inside is not checked further, since the runtime never reads it	❌ error
`wcs/second-root`	A second `<wcs-state>` without `mount` and `bind-component` in the document (outside `<template>`): there is one state tree per root, and the runtime refuses the one that loads second (`console.error`). Graft a subtree with `<wcs-state mount="path">`. Reported on each further start tag	❌ error

Sidecar manifest (`wcstack.manifest.json`)

All wcs/manifest-* and wcs/drift-* findings are errors, except wcs/manifest-namespace-version (warning) and wcs/manifest-override (info — an intentional, declared shadow). Codes: manifest-broken, manifest-schema-version, manifest-kind-invalid, manifest-unknown-keyword, manifest-external-ref, manifest-ref-cycle, manifest-ref-unresolved, manifest-namespace-version, manifest-tag-collision, manifest-filter-collision, manifest-state-collision, manifest-override, drift-missing-member, drift-event-mismatch.

One further code (wcs/path-reserved-name) is reserved in the code table but not emitted yet. The single source of truth for codes is src/core/diagnostics.ts.

The codes are the runtime's: a message the 4.0 runtime prints in the console carries the same [wcs/…] code. Without the diagnostics add-on (@wcstack/state/core alone) the runtime prints only a message number and the values — [@wcstack/state] [#203](https://github.com/wcstack/wcstack/issues/203) "outerHTML" (the hundreds of the number name the code: 2xx is wcs/template-syntax) — and the full auto bundle (which installs the add-on) prints the code and the sentence. Some runtime codes depend on what only the running page knows and have no static counterpart: wcs/feature-not-installed (which entry and installFeatures the page uses), wcs/recursion-context, and the wcs/template-syntax #204 case (a structural template at the top of content inserted later). The wcs/mount-dollar-declaration warning ($watch / $stream / $renderedCallback on a mounted component) has none either: that state is the component's JavaScript property, which the validator does not read — a script inside <wcs-state bind-component> is never loaded (wcs/bind-component-source).

JSDoc Type Validation

Validates consistency between @type annotations and initial values (wcs/type-annotation):

/** @type {string} */
label: null,        // ⚠ Type "null" is not compatible with @type {string}

/** @type {string|null} */
label: null,        // ✅ OK

The same @type also declares a shape. A list that starts as null (or []) and is filled by <wcs-fetch> or <wcs-storage> has no row to read its fields from, so its rows would be reported as wcs/binding-path-missing; with an object type for the rows, catalog.*.id and catalog.*.name exist (with their types), and a typo under them is still reported. Name the row type with a @typedef in the same script if you like:

/** @typedef {{ id: number, name: string, price: number }} Product */
export default {
  /** @type {Product[] | null} */
  catalog: null,                           // for: catalog → .id / .name / .price
  get products() { return this.catalog ?? []; },   // a getter's result keeps the shape
};

The types understood are a subset of TypeScript's JSDoc: names, object types ({ a: T; b?: U }), T[] / Array<T>, unions, ?T, and @typedef names (a self-referencing typedef stops at the nesting limit). A type the validator cannot read (a function type, Record<…>) declares no shape; any / unknown / * are not checked against the initial value.

Sidecar Manifest, `stateSchema`, and the CLI

Sidecar manifests. wcstack.manifest.json files are validated against the supported JSON-Schema subset: envelope / kind checks, cross-file package resolution, same-name tag/filter collision, forbidden override-after-collision, and drift against the live static wcBindable surface. The sidecar is tooling-only: it never overrides the runtime static wcBindable declaration, and a missing or stale file never changes runtime behavior. The normative schema and resolution rules live in docs/wcstack-manifest-schema.md.

stateSchema. An application manifest may declare the shape of a state (wcstack.application.states[<name>].stateSchema). The nearest wcstack.manifest.json above the HTML file is discovered automatically (one file, no merging). For a declared state, a missing path is reported as wcs/path-nonexistent (error) instead of wcs/binding-path-missing (warning), and for: on a schema-confirmed non-array is wcs/path-type-mismatch. Methods, getters, and $listKeys from the script count as existing even when absent from the schema; beneath a bare {} the validator stays silent. Write the schema by hand, or generate it from a TypeScript state file with wcs-schema from @wcstack/typescript — see docs/typescript.md. The same package's wcs-tsc type-checks inline <wcs-state> scripts across a project using this extension's language plugin in tsc mode.

CLI. A single validateDocument entry point drives both the in-editor diagnostics and the CLI, so the IDE and CI report identically for the same inputs. Both read the external state referenced via <wcs-state src="..."> (the root's and the volumes') and discover the nearest wcstack.manifest.json through the same file reader, relative to the HTML file. The IDE does so for a document saved on disk (a file: URI); an untitled or virtual document skips src (its paths are not reported, as for a src that cannot be read), and an external state file with unsaved edits is read as it is on disk. The script rules (wcs/nested-assign, wcs/array-mutation, wcs/on-handler-this, …) check a .js / .ts external state too: the IDE shows a finding in the file on the page's src value, with the file's line and column in front of the message and a link to the file; the CLI reports it in the file. The bundled wcs-validate CLI runs the same checks headlessly — over wcstack.manifest.json sidecars (any *.manifest.json argument) and/or HTML data-wcs bindings — and is distributed on npm as @wcstack/lint, a zero-dependency wrapper around the exact same CLI bundle:

npx @wcstack/lint [--attr=data-wcs] [--state-tag=wcs-state] [--lang=ja|en] [--errors-only] [--strict] <file> [<file> ...]

Option	Effect
`--attr=<name>`	Bind attribute name (default `data-wcs`)
`--state-tag=<name>`	State element tag name (default `wcs-state`)
`--lang=ja\\|en`	Message language. Default: environment locale (`LC_ALL` / `LC_MESSAGES` / `LANG`, then the OS locale); codes and ranges do not depend on it
`--errors-only` (alias `--quiet`)	Print only error-severity lines; warning / info counts and the exit code are unchanged
`--strict`	Exit `1` on warnings too. Severities are unchanged — only the exit-code threshold moves. Use it to fail CI on a path typo (`wcs/binding-path-missing` is a warning)

Exit code: 0 no error (with --strict: no error or warning) · 1 at least one error (with --strict: error or warning) · 2 usage or file-read failure.

When working on the validator itself, or in this repo's CI (the wcs-validate job runs it exactly this way), build from source and invoke the CLI with node:

# one-time build (from the repo root)
cd packages/vscode-wcs && npm ci && npm run build && cd ../..

node packages/vscode-wcs/dist/cli.cjs [--attr=data-wcs] [--state-tag=wcs-state] [--lang=ja|en] [--errors-only] [--strict] <file> [<file> ...]

Settings

Setting	Default	Description
`wcstack.bindAttributeName`	`"data-wcs"`	Bind attribute name
`wcstack.stateTagName`	`"wcs-state"`	Custom element tag name for state definition
`wcstack.messageLanguage`	`"auto"`	Language of diagnostic and hover messages: `auto` (VS Code display language; non-Japanese locales get English), `ja`, or `en`. Codes and ranges are language-independent

Requirements

VS Code 1.110+
HTML files containing <wcs-state> elements (tag completions and hover for wcs-* elements work in any HTML file)

Reporting Issues

Use the extension issue form — it asks for the extension and VS Code versions and a minimal <wcs-state> reproduction, and files the report under the @wcstack/vscode-wcs label.

License

MIT

WcStack IntelliSense

wcstack

WcStack IntelliSense

Features

Inline Script Type Support

Attribute Binding Completions

for-context Completions

Template Syntax Support

wcs-* Tag Completions (HTML Custom Data)

Hover, Go to Definition, Find References, Inlay Hints

Diagnostics

Binding expressions (data-wcs / {{ }} / )

Built-in wcs-* tag contracts

<wcs-state> script

Page setup

v2 migration

Volumes, component mounts and roots (4.0)

Sidecar manifest (wcstack.manifest.json)

JSDoc Type Validation

Sidecar Manifest, stateSchema, and the CLI

Settings

Requirements

Reporting Issues

License

Binding expressions (`data-wcs` / `{{ }}` / ``)

Built-in `wcs-*` tag contracts

`<wcs-state>` script

Sidecar manifest (`wcstack.manifest.json`)

Sidecar Manifest, `stateSchema`, and the CLI
