LocalRAG — Enhanced Local RAG for VS Code

Find precise answers from your files and repos using local embeddings, smart query planning, and embedded vector search.

LocalRAG helps developers, knowledge workers, and enterprise teams search, summarize, review, and answer questions over local documents, repositories, and the active VS Code workspace — with privacy and compliance in mind. Use it fully offline with local Transformers.js embeddings and LanceDB storage, or enable optional LLM-based planning and evaluation via VS Code Copilot models without any external API key for advanced query decomposition and result assessment.

🙏 Acknowledgments

This extension is a fork of the original RAGnarōk project. We extend our heartfelt thanks to the original author hyorman and all contributors for their excellent work in creating a powerful, privacy-focused RAG solution for VS Code.

Why install?

Fast, private semantic search over PDFs, Markdown, HTML, and code
Enterprise-friendly: per-topic stores, file-based persistence, and secure token handling for private repos
Agentic query planning and evaluation: optionally use LLMs for decomposition, iterative refinement, and answer evaluation
Include workspace context: surface relevant open files, symbols, and code snippets to enrich answers
Code-review assistance: apply retrieved guidelines and documentation to review your code and get actionable suggestions
Embedded LanceDB vector store — no external servers required
Works offline with local Transformers.js embedding models

🌟 Features

🧩 Local Embedding Model Support

Run embeddings locally: Use Transformers.js models (ONNX/wasm) without external APIs.
Local model picker: Load models from localrag.localModelPath and switch models in the tree view.
Offline & private: Keep embeddings and inference on-device for privacy and compliance.
Default model included: Ships with Xenova/all-MiniLM-L6-v2 by default for fast, 384-dimension embeddings.

🧠 Agentic RAG with Query Planning

Intelligent Query Decomposition: Automatically breaks complex queries into sub-queries -- LLM-Powered Planning: Uses Copilot (VS Code LM API) models such as gpt-4o for advanced reasoning (Copilot required; no external API key). LLM usage is optional
Heuristic Fallback: Works without LLM using rule-based planning
Iterative Refinement: Confidence-based iteration for high-quality results
Parallel/Sequential Execution: Smart execution strategy based on query complexity

🔍 Multiple Retrieval Strategies

Hybrid Search (recommended): Combines vector + keyword (70%/30% weights, configurable)
Vector Search: Pure semantic similarity using embeddings
Ensemble Search: Advanced RRF (Reciprocal Rank Fusion) with BM25 for highest accuracy
BM25 Search: Pure keyword search using Okapi BM25 algorithm (no embeddings needed)
Position Boosting: Keywords near document start weighted higher
Result Explanations: Human-readable scoring breakdown for all strategies

📚 Document Processing

Multi-Format Support: PDF, Markdown, HTML, plain text, GitHub repositories
Semantic Chunking: Automatic strategy selection (markdown/code/recursive)
Structure Preservation: Maintains heading hierarchy and context
Batch Processing: Multi-file upload with progress tracking
GitHub Integration: Load entire repositories from GitHub.com or GitHub Enterprise Server
LangChain Loaders: Industry-standard document loading

💾 Vector Storage

LanceDB: Embedded vector database with file-based persistence (no server needed)
Cross-Platform: Works on Windows, macOS, Linux, and ARM
Per-Topic Stores: Efficient isolation and management
Serverless: Truly embedded, like SQLite for vectors
Caching: Optimized loading and reuse

🎨 Enhanced UI

Configuration View: See agentic settings at a glance
Embedding Model Picker: Tree view lists curated + local models (from localrag.localModelPath) with download status; click to switch
Statistics Display: Documents, chunks, store type, model info
Progress Tracking: Real-time updates during processing
Rich Icons: Visual hierarchy with emojis and theme icons

🛠️ Developer Experience

Comprehensive Logging: Debug output at every step
Type-Safe: Full TypeScript with strict mode
Error Handling: Robust error recovery throughout
Async-Safe: Mutex locks prevent race conditions
Configurable: 15+ settings for customization

🚀 Quick Start

Installation

From Source

git clone https://github.com/borgius/localrag.git
cd localrag
npm install
npm run compile
# Press F5 to run in development mode

From VSIX

code --install-extension localrag-0.2.8.vsix

Basic Usage

0. (Optional) Choose/prepare your embedding model

Default: Xenova/all-MiniLM-L6-v2
Offline/local: set localrag.localModelPath to a folder containing Transformers.js-compatible models (each model in its own subfolder). The tree view will list those models alongside curated ones; click any entry to load it.
When you change the embedding model, existing topics keep their original embeddings—create a new topic if you need to ingest with the new model.

1. Create a Topic

Cmd/Ctrl+Shift+P → RAG: Create New Topic

Enter name (e.g., "React Docs") and optional description.

2. Add Documents

Cmd/Ctrl+Shift+P → RAG: Add Document to Topic

Select topic, then choose one or more files. The extension will:

Load documents using LangChain loaders
Apply semantic chunking
Generate embeddings
Store in vector database

Supported formats: .pdf, .md, .html, .txt

2b. Add GitHub Repository

Cmd/Ctrl+Shift+P → RAG: Add GitHub Repository to Topic

Or right-click a topic in the tree view and select the GitHub icon. You can:

GitHub.com or GitHub Enterprise Server: Choose between public GitHub or your organization's GitHub Enterprise Server
Enter repository URL:
- GitHub.com: https://github.com/facebook/react
- GitHub Enterprise: https://github.company.com/team/project
Specify branch (defaults to main)
Configure ignore patterns (e.g., *.test.js, docs/*)
Add access token for private repositories (see Token Management below)

The extension will recursively load all files from the repository and process them just like local documents.

Note: Supports GitHub.com and GitHub Enterprise Server only. The repository must be accessible from your network. For other Git hosting services (GitLab, Bitbucket, etc.), clone the repository locally and add it as local files.

2c. GitHub Token Management

For accessing private repositories, LocalRAG securely stores GitHub access tokens per host using VS Code's Secret Storage API.

Add a Token:

Cmd/Ctrl+Shift+P → RAG: Add GitHub Token

Enter the GitHub host (e.g., github.com, github.company.com)
Paste your GitHub Personal Access Token (PAT)
The token is securely stored and automatically used for that host

List Saved Tokens:

Cmd/Ctrl+Shift+P → RAG: List GitHub Tokens

Shows all hosts with saved tokens (tokens themselves are never displayed).

Remove a Token:

Cmd/Ctrl+Shift+P → RAG: Remove GitHub Token

Select a host to remove its stored token.

2d. Export and Import Topics

Export a Topic:

Cmd/Ctrl+Shift+P → RAG: Export Topic

Or select a topic in the tree view and select the export icon. This creates a portable archive containing:

Topic metadata (name, description)
Vector embeddings and documents
Model configuration

Exported topics can be shared with teammates or imported into other workspaces.

Import a Topic:

Cmd/Ctrl+Shift+P → RAG: Import Topic

Or click the import icon in the tree view title bar. Select an exported topic archive to restore it into your workspace.

Rename a Topic:

Cmd/Ctrl+Shift+P → RAG: Rename Topic

Or select a topic in the tree view and click the edit icon.

How to Create a GitHub PAT:

Go to GitHub Settings → Developer settings → Personal access tokens → Tokens (classic)
Click "Generate new token (classic)"
Select the repo scope
Generate and copy the token
Use the "RAG: Add GitHub Token" command to save it

Benefits:

✅ Tokens stored securely in VS Code's Secret Storage (not in settings.json)
✅ Support for multiple GitHub hosts (GitHub.com + multiple Enterprise servers)
✅ Automatic token selection based on repository URL
✅ No need to enter token every time you add a repository

2e. Using Common/Shared Databases

RAGnarōk supports read-only access to shared team knowledge bases via the ragnarok.commonDatabasePath setting.

Setup:

Export topics from a source workspace
Place exported topic archives in a shared location (network drive, shared folder)
Configure ragnarok.commonDatabasePath to point to this folder:

{
  "ragnarok.commonDatabasePath": "/path/to/shared/rag-databases"
}

Benefits:

✅ Share curated knowledge bases across teams
✅ Read-only topics prevent accidental modification
✅ Centralized documentation and policy storage
✅ Works with any file-sharing system

Note: Topics from common database path appear in the tree view but cannot be deleted or modified.

3. Query with Copilot

Open Copilot Chat (@workspace)
Type: @workspace #ragQuery What is [your question]?

The RAG tool will:

Match your topic semantically
Decompose complex queries (if agentic mode enabled)
Perform hybrid retrieval
Return ranked results with context

Maintenance Commands

Clear Model Cache:

Cmd/Ctrl+Shift+P → RAG: Clear Model Cache

Removes cached embedding models. Useful when switching models or troubleshooting.

Clear Database:

Cmd/Ctrl+Shift+P → RAG: Clear Database

⚠️ Warning: Deletes all topics and documents. This action cannot be undone.

Refresh Topics:

Cmd/Ctrl+Shift+P → RAG: Refresh Topics

Reloads the topic tree view. Useful after importing topics or external changes.

⚙️ Configuration

Basic Settings

{
  // Path to local Transformers.js embedding model folder
  "ragnarok.localModelPath": "",

  // Number of results to return
  "localrag.topK": 5,

  // Chunk size for splitting documents
  "localrag.chunkSize": 512,

  // Chunk overlap for context preservation
  "localrag.chunkOverlap": 50,

  // Optional absolute/tilde path to a local Transformers.js model directory
  "localrag.localModelPath": "",

  // Embedding DB path (empty = default). Relative paths are resolved from the workspace root.
  "localrag.embeddingDbPath": "",

  // Retrieval strategy: hybrid, vector, ensemble, bm25
  "localrag.retrievalStrategy": "hybrid",

  // Folder watching (optional)
  "localrag.watchFolder": "",  // Absolute path to folder to watch
  "localrag.watchFolders": ["./docs", "./confluence"],

  // Path to shared/common RAG database (read-only topics)
  "localrag.commonDatabasePath": ""
}

Note: GitHub access tokens are now managed via secure Secret Storage, not settings.json. See GitHub Token Management section.

Automatic Folder Watching

LocalRAG can automatically monitor a folder for changes and keep a default topic up-to-date:

Set the watch folder(s): Configure localrag.watchFolders with workspace-relative or absolute paths. (Legacy localrag.watchFolder is still supported.)
Automatic updates: When files with supported extensions (.pdf, .md, .html, .txt, etc.) are added, modified, or deleted in the watched folders (including subfolders), they are automatically processed and added to the "Default" topic.

Example configuration:

{
  "localrag.watchFolders": ["/Users/username/Documents/my-docs"],
  "localrag.includeExtensions": [".pdf", ".md", ".html", ".txt"]
}

Benefits:

✅ Automatic document indexing - no manual "Add Document" needed
✅ Always up-to-date embeddings for your active documents
✅ Supports all document types (PDF, Markdown, HTML, text)
✅ Debounced updates - multiple changes are batched together
✅ Default topic created automatically if no topics exist

CLI Tool (`lrag`)

LocalRAG includes a command-line interface for searching indexed topics from your terminal. Perfect for quick searches, scripting, and AI agent integration.

Installation

# Run directly with npx (no installation needed)
npx localrag --help

# Or install globally
npm install -g localrag

Prerequisites

The CLI requires the LocalRAG VS Code extension to be running. The extension starts a REST server on port 3875 when activated.

Open VS Code with your workspace
Ensure the LocalRAG extension is installed and enabled
The server starts automatically when the extension activates

Usage

# Search (default command)
lrag "how to configure webpack"
lrag --search "authentication flow"

# List all topics
lrag --list

# Get topic details
lrag --topic Default

# Check status
lrag --status

Options

Option	Short	Description
`--search`	`-s`	Search indexed documents (default)
`--list`	`-l`	List all topics
`--topic <name>`	`-t`	Show details for a specific topic
`--status`		Show extension status
`--json`	`-j`	Output results in JSON format
`--compact`	`-c`	Output compact JSON (implies --json)
`--limit <n>`	`-n`	Maximum results to return (default: 10)
`--help`	`-h`	Show help message
`--version`	`-v`	Show version

Output Formats

Default (Markdown): Human-readable output with colors and formatting

lrag "error handling"

JSON: Full metadata for programmatic use

lrag --json "error handling"

Compact JSON: Minimal output for AI agents (content, path, score only)

lrag --compact "error handling"

Examples

# Search with limited results
lrag -n 5 "database connection"

# Get topics in JSON format
lrag --list --json

# Check if indexing is in progress
lrag --status --compact

# Use in scripts
RESULTS=$(lrag --compact "API authentication")
echo "$RESULTS" | jq '.results[0].content'

Extension Not Running?

If the CLI can't connect to the server, it will:

Check if the extension is installed
Offer to install it if missing
Provide instructions to start VS Code with your workspace

Agentic Mode Settings

{
  // Enable agentic RAG with query planning
  "localrag.useAgenticMode": true,

  // Use LLM for query planning (requires Copilot)
  "localrag.agenticUseLLM": false,

  // Maximum refinement iterations (1-10)
  "localrag.agenticMaxIterations": 3,

  // Confidence threshold (0-1) for stopping iteration
  "localrag.agenticConfidenceThreshold": 0.7,

  // Enable iterative refinement
  "localrag.agenticIterativeRefinement": true,

  // LLM model for planning (when agenticUseLLM is true) — models provided via VS Code Copilot/LM API
  "localrag.agenticLLMModel": "gpt-4o",

  // Include workspace context in queries
  "localrag.agenticIncludeWorkspaceContext": true
}

Set localrag.localModelPath to point at a folder that already contains compatible Transformers.js models (one subfolder per model—e.g., an ONNX export downloaded ahead of time). Entries found here appear in the tree view and can be selected directly, and this local path takes precedence over localrag.embeddingModel.

Available Embedding Models to Download (local, no API needed):

Xenova/all-MiniLM-L6-v2 (default) - Fast, 384 dimensions
Xenova/all-MiniLM-L12-v2 - More accurate, 384 dimensions
Xenova/paraphrase-MiniLM-L6-v2 - Optimized for paraphrasing
Xenova/multi-qa-MiniLM-L6-cos-v1 - Optimized for Q&A

The extension ships with Xenova/all-MiniLM-L6-v2 by default; to use other local models, set localrag.localModelPath or click the model name in tree view.

Any models you place under localrag.localModelPath show up in the tree view alongside these curated options (with download indicators) and can be loaded with one click.

LLM Models (when agentic planning is enabled): models are available via VS Code Copilot / LM API (no external API key required).

gpt-4o (default) - 0x
gpt-4.1 - 0x
gpt-5-mini - 0x
gpt-5 - 1x
gpt-5-codex - 1x
gpt-5.1 - 1x
gpt-5.1-codex - 1x
gpt-5.1-codex-mini - 0.33x
gpt-5.1-codex-max - 1x
gpt-5.2 - 1x
gpt-5.2-codex - 1x
claude-haiku-4.5 - 0.33x
claude-sonnet-4 - 1x
claude-sonnet-4.5 - 1x
claude-opus-4.1 - 10x
claude-opus-4.5 - 3x
gemini-2.5-pro - 1x
gemini-3-flash - 0.33x
gemini-3-pro - 1x
grok-code-fast-1 - 0.25x
raptor-mini - 0x

Legend: 0x = no premium requests (Copilot Free), 1x = premium requests (Copilot paid). Other values indicate premium multipliers.

🏗️ Architecture

Component Overview

┌─────────────────────────────────────────────────────┐
│                   VS Code Extension                 │
├─────────────────────────────────────────────────────┤
│                                                     │
│  ┌─────────────┐  ┌──────────────┐   ┌────────────┐ │
│  │ Commands    │  │ Tree View    │   │ RAG Tool   │ │
│  │ (UI)        │  │ (UI)         │   │ (Copilot)  │ │
│  └─────┬───────┘  └──────┬───────┘   └─────┬──────┘ │
│        │                 │                 │        │
│  ┌─────┴─────────────────┴─────────────────┴──────┐ │
│  │              Topic Manager                     │ │
│  │  (Topic lifecycle, caching, coordination)      │ │
│  └─────┬──────────────────────────────────┬───────┘ │
│        │                                  │         │
│  ┌─────┴─────────┐                 ┌──────┴───────┐ │
│  │ Document      │                 │ RAG Agent    │ │
│  │ Pipeline      │                 │ (Orchestr.)  │ │
│  └┬─────────┬────┘                 └┬─────────┬───┘ │
│   │         │                       │         │     │
│ ┌─┴────┐ ┌──┴────┐           ┌──────┴──┐ ┌────┴───┐ │
│ │Loader│ │Chunker│           │ Planner │ │Retriev.│ │
│ │      │ │       │           │         │ │        │ │
│ └──┬───┘ └───┬───┘           └────┬────┘ └───┬────┘ │
│    │         │                    │          │      │
│  ┌─┴─────────┴────┐          ┌────┴──────────┴────┐ │
│  │ Embedding      │          │ Vector Store       │ │
│  │ Service        │          │ (LanceDB)          │ │
│  │ (Local Models) │          │ (Embedded DB)      │ │
│  └────────────────┘          └────────────────────┘ │
│                                                     │
└─────────────────────────────────────────────────────┘
                          │
                   ┌──────┴───────┐
                   │ LangChain.js │
                   │ (Foundation) │
                   └──────────────┘

🎯 How It Works

Agentic Query Flow

User Query: "Compare React hooks vs class components"
    ↓
┌───┴────────────────────────────────────────┐
│ 1. Topic Matching (Semantic Similarity)    │
│    → Finds best matching topic             │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 2. Query Planning (LLM or Heuristic)       │
│    Complexity: complex                     │
│    Sub-queries:                            │
│    - "React hooks features and usage"      │
│    - "React class components features"     │
│    Strategy: parallel                      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 3. Hybrid Retrieval (for each sub-query)   │
│    Vector search: 70% weight               │
│    Keyword search: 30% weight              │
│    → Returns ranked results                │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 4. Iterative Refinement (if enabled)       │
│    Check confidence: 0.65 < 0.7            │
│    → Refine query and retrieve again       │
│    Check confidence: 0.78 ≥ 0.7 ✓          │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 5. Result Processing                       │
│    - Deduplicate by content hash           │
│    - Rank by score                         │
│    - Limit to topK                         │
└───┬────────────────────────────────────────┘
    ↓
Return: Ranked results with metadata

Document Processing Flow

User uploads: document1.pdf, document2.md
    ↓
┌───┴────────────────────────────────────────┐
│ 1. Document Loading (LangChain Loaders)    │
│    PDF: PDFLoader                          │
│    MD: TextLoader                          │
│    HTML: CheerioWebBaseLoader              │
│    → Returns Document[] with metadata      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 2. Semantic Chunking                       │
│    Strategy selection:                     │
│    - Markdown: MarkdownTextSplitter        │
│    - Code: RecursiveCharacterTextSplitter  │
│    - Other: RecursiveCharacterTextSplitter │
│    → Preserves headings and structure      │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 3. Embedding Generation (Batched)          │
│    Model: Xenova/all-MiniLM-L6-v2 (local)  │
│    Batch size: 32 chunks                   │
│    → Generates 384-dim vectors             │
└───┬────────────────────────────────────────┘
    ↓
┌───┴────────────────────────────────────────┐
│ 4. Vector Storage                          │
│    LanceDB embedded database               │
│    → Stores embeddings + metadata          │
└───┬────────────────────────────────────────┘
    ↓
Complete: Documents ready for retrieval

📊 Performance

Benchmarks (M1 Mac, 16GB RAM)

Operation	Time	Notes
Load PDF (10 pages)	~2s	Using PDFLoader
Chunk document (50 chunks)	~100ms	Semantic chunking
Generate embeddings (50 chunks)	~3-5s	Local Transformers.js model
Store in LanceDB	~100ms	File-based persistence
Hybrid search (k=5)	~50ms	Vector + BM25
Query planning (LLM)	~2s	GPT-4o via Copilot
Query planning (heuristic)	<10ms	Rule-based

Optimization Tips

Use local embeddings for privacy and no API costs
Enable agent caching (automatic per topic)
Adjust chunk size based on document type
Use simple mode for fast queries
Batch document uploads for efficiency
LanceDB scales well - no size limits like in-memory stores

🔬 Testing

Run Tests

npm test

🤝 Contributing

We welcome contributions! Please see CONTRIBUTING.md for guidelines.

Development Setup

git clone https://github.com/borgius/localrag.git
cd localrag
npm install
npm run watch  # Watch mode for development

📄 License

MIT License - see LICENSE for details

🙏 Acknowledgments

Built with:

LangChain.js - Document processing framework
Transformers.js - Local embeddings
LanceDB - Embedded vector database
VS Code Extension API - Extension platform
VS Code LM API - Copilot integration

Made with ❤️ by the hyorman

⭐ Star us on GitHub if you find this useful!

LocalRAG: Local RAG for VS Code

Victor Borgius

LocalRAG — Enhanced Local RAG for VS Code

🙏 Acknowledgments

🌟 Features

🧩 Local Embedding Model Support

🧠 Agentic RAG with Query Planning

🔍 Multiple Retrieval Strategies

📚 Document Processing

💾 Vector Storage

🎨 Enhanced UI

🛠️ Developer Experience

🚀 Quick Start

Installation

From Source

From VSIX

Basic Usage

0. (Optional) Choose/prepare your embedding model

1. Create a Topic

2. Add Documents

2b. Add GitHub Repository

2c. GitHub Token Management

2d. Export and Import Topics

2e. Using Common/Shared Databases

3. Query with Copilot

Maintenance Commands

⚙️ Configuration

Basic Settings

Automatic Folder Watching

CLI Tool (lrag)

Installation

Prerequisites

Usage

Options

Output Formats

Examples

Extension Not Running?

Agentic Mode Settings

🏗️ Architecture

Component Overview

🎯 How It Works

Agentic Query Flow

Document Processing Flow

📊 Performance

Benchmarks (M1 Mac, 16GB RAM)

Optimization Tips

🔬 Testing

Run Tests

🤝 Contributing

Development Setup

📄 License

🙏 Acknowledgments

CLI Tool (`lrag`)
