Codebase Graph for VS Code

This extension provides VS Code agents with the codebase-graph MCP server. It indexes supported source languages into one graph per actual Git repository and one aggregate graph per opened workspace.

GitHub repository · Report an issue

<workspace>/<repo>/.codebase-graph/graph.json
<workspace>/.codebase-graph/workspace.json

All agents share those files. The extension does not create agent-specific indexes and does not run a daemon or watcher.

Cross-repository dependencies

The workspace graph adds DEPENDS_ON when an indexed typed import names the target repository's exact module path (or a path beneath it), or when source code contains an HTTP(S) URL whose exact host is mapped to that repository. Substring matches in repository names, SQL table names, and asset names do not create edges.

To map service hosts, create codebase-graph.services.json in the workspace root:

{
  "services": [
    { "repository": "api", "hosts": ["api.example.test:8080"] }
  ]
}

repository is a path relative to the workspace root. List the exact URL host; include its port when the source URL uses one. These edges record static source evidence and do not trace HTTP requests at runtime. URLs assembled from variables and actual service-to-service traffic are not detected.

Language coverage

Go uses the standard-library AST. JavaScript, TypeScript, TSX, Python, Rust, Java, Kotlin, and C# use pure-Go syntax-tree parsing for declarations, methods, imports, direct calls, and exact source line ranges, with conservative same-repository resolution limited to same-file direct calls and unambiguous relative JavaScript, TypeScript, and Python imports to files in that repository. Other imports remain external unless covered by those rules. SQL, shell, Ruby, PHP, C, C++, Protocol Buffers, Vue, Svelte, HTML, CSS, SCSS, and configuration formats use older regex and file-level fallback extraction. Dynamic dispatch, reflection, runtime loading, and ambiguous calls remain external; syntax parser failures and syntax-parsed files larger than 4 MiB appear in index coverage. Broader cross-file and cross-repository symbol resolution and grammar-based support for the remaining languages are planned.

Commands

• Codebase Graph: Index Workspace
• Codebase Graph: Show Index Status
• Codebase Graph: Open Workspace Graph

In a multi-root VS Code window, select the workspace root to operate on. Each local workspace root gets one workspace-scoped MCP server, which discovers its internal repositories automatically.

The universal package contains native server binaries for x64 and ARM64 Windows, Linux, and macOS hosts. VS Code selects the matching binary at runtime.
