Ngx Module Linker (Internal)

Your helper inside VS Code for working with the shared ngx-module library in your WebFactory DE Angular apps.

What this extension does

Ngx Module Linker makes it easy to work with a central ngx-module library while developing multiple WebFactory DE Angular apps.

• Remembers your shared ngx-module location so you set it once and reuse it.
• Shows the current ngx-module Git branch and link status in the status bar (e.g. NGX: develop [Linked] or NGX: develop [Not Linked]).
• Provides a dedicated "Ngx Module Linker" sidebar panel where you can see:
  • the configured ngx-module path
  • the current Git branch
  • whether your app is Linked or Not Linked
• Lets you switch ngx-module branches from a quick pick (no need to open a terminal).
• Builds the ngx-module library for you.
• Builds and links ngx-module into the current WebFactory DE Angular app so you can immediately use the latest changes.
• Opens the ngx-module workspace in a separate VS Code window and can start the library in watch/dev mode.

This is designed for teams who share a single ngx-module library across several WebFactory DE Angular applications.

Quick visual tour

1. Overview – status bar and commands


2. Configure shared ngx-module folder




3. Switch ngx-module branch


Getting started

1. Install and open a compatible WebFactory DE Angular app

1. Install the Ngx Module Linker extension in VS Code.
2. Open a WebFactory DE Angular project that is allowed to use the shared ngx-module library (as configured by your team).

Tip: If the extension is active for the project, you will see an item for ngx-module in the VS Code status bar.

2. Tell the extension where your shared ngx-module lives

You only need to do this once per machine.

1. Open the Command Palette in VS Code (Ctrl+Shift+P or Cmd+Shift+P).
2. Run: NGX Module Linker: Configure NGX module Path.
3. In the folder picker, select the root folder of the shared ngx-module project (the repo containing the library code).

From now on, the extension will remember this directory and reuse it across sessions.

This is stored as the VS Code setting:

ngxModuleLinker.ngxModulePath

3. Build and link ngx-module into your current WebFactory DE Angular app

When you’re inside a supported WebFactory DE Angular app:

1. Either open the Ngx Module Linker sidebar (icon in the Activity Bar) and click Build & Link, or open the Command Palette and run NGX Module Linker: Build and Link.
2. Wait for the build and linking to finish.
3. Start or refresh your WebFactory DE Angular app – it will now use the shared ngx-module from the directory you configured.

If you only want to build the library without linking it:

1. Open the Command Palette.
2. Run: NGX Module Linker: Build Library.

4. Check and change the ngx-module branch

You can see which ngx-module branch you are on directly in the VS Code status bar.

To change it:

1. Open the Command Palette.
2. Run: NGX Module Linker: Switch Branch.
3. Pick the branch you want from the list.

The status bar will update to reflect the new branch.

You will also see the updated branch and link status in the Ngx Module Linker sidebar.

How it works behind the scenes (non-technical)

• The extension keeps track of a single shared installation of your ngx-module library on your machine.
• When you hit Build or Build & Link, it:
  • builds that shared library, and
  • connects your current WebFactory DE Angular app to it, so they use the same codebase.
• The status bar and the sidebar panel constantly check whether your app is actually using that shared library and show you:
  • which Git branch of ngx-module is active, and
  • whether the app is currently Linked to it or not.

You don’t need to know the underlying commands or file system details – the extension handles that for you and just shows you clear status labels and buttons.

For developers of this extension (optional)

If you work on the extension itself:

1. Run npm install.
2. Press F5 in VS Code to start a new Extension Host with this extension loaded.
3. In a supported Angular project, open the Command Palette and try:
   • NGX Module Linker: Configure NGX module Path
   • NGX Module Linker: Switch Branch
   • NGX Module Linker: Build Library
   • NGX Module Linker: Link
   • NGX Module Linker: Build and Link
   • NGX Module Linker: Open NGX Module in New Window
   • NGX Module Linker: Start NGX (npm start)

Publishing to the VS Code Marketplace

Publishing is done with vsce.

Prerequisites:

• You must be signed in to an Azure DevOps organization that hosts the VS Code Marketplace publisher.
• You need a VS Code Marketplace Personal Access Token (PAT) with permission to publish.

Common scripts:

• npm run package
• npm run publish
• npm run publish:patch
• npm run publish:minor
• npm run publish:major
• npm run deploy

Notes:

• vsce publish will prompt for a PAT if you are not already authenticated.
• Ensure publisher in package.json matches the Marketplace publisher name.
