C4 Architecture As A Code

VS Code extension for C4/Structurizr architecture modeling — write, validate, and render architecture diagrams directly from code. Powered by Langium.

Overview
Features
Installation
Quick Start
Model Context Protocol
Development
Project Structure
Contributing
License

Overview

C4 Architecture As A Code brings the C4 model and the Structurizr DSL into your VS Code workflow. Describe your software architecture as text, get instant validation, intellisense-style hints, and a live diagram preview — no separate tooling required.

It is a port of the reference Structurizr DSL to the Langium/TypeScript stack, and runs on the desktop (VS Code) and in the browser (vscode.dev).

Features

📐 Structurizr DSL support

The language server is a port of the reference Structurizr DSL to the Langium/TypeScript stack. It implements the same DSL surface — the C4 and deployment models, view definitions, and the directives that shape them — and emits Structurizr-compatible workspace JSON. The intent is behavioural parity: a workspace written for Structurizr parses, validates and renders here the same way, unchanged.

🔍 Intelligent Language Server (Langium-based)

Syntax highlighting with a generated TextMate grammar
Semantic tokens (macros, classes, properties)
Inlay hints — inline name:, description:, technology: labels
Document links — Ctrl+Click on !include paths and extendsUri to navigate
Scope provider — hierarchical identifiers and cross-file references
CodeLens — actions above each view and above the workspace

🖼️ Diagram Preview

Render any view as an interactive Structurizr diagram
Auto-refresh on every change or on save (varp.diagram.autoRefresh)
Remote Structurizr themes, with a webview fallback when the server cannot fetch them
Export the current diagram to SVG or DrawIO (.drawio)
Import a layout from a .drawio file back into the view
Export the full Structurizr workspace JSON (.json)
One-click preview via CodeLens: "Show As Structurizr Diagram"

🧩 Views & Filtering

All view types: System Landscape, System Context, Container, Component, Deployment, Dynamic, Filtered, Custom
Rich include/exclude expressions (element.tag==, element.type==, relationship==, afferent/efferent coupling, star expressions)
!elements and !relationships directives for per-view element injection
Automatic layouts, animations, theming, terminology

🔗 Modularity

!include of other files (relative paths, directories, remote URLs)
extendsUri workspace inheritance
${CONST} constant substitution across files

🤖 MCP server

Optional built-in Model Context Protocol server (varp.mcp.autoStart) that exposes the resolved model to AI assistants over streamable HTTP on 127.0.0.1 (see Model Context Protocol)

🌐 Desktop and web

Runs on desktop VS Code and in the browser (vscode.dev)

Installation

From VS Code Marketplace (recommended)

Open VS Code
Go to the Extensions view (Ctrl+Shift+X)
Search for "C4 Architecture As A Code"
Click Install

From VSIX

Build the extension (see Development) or download a release .vsix
In VS Code, open the Extensions view (Ctrl+Shift+X)
Click the ⋮ menu → Install from VSIX...
Select the .vsix file

Pre-Release Channel

To test the latest unreleased build, use the Switch to Pre-Release option in the extension details page (Marketplace installs only).

Quick Start

Create a .dsl file and start writing your architecture:

workspace {
    model {
        user = person "User"
        system = softwareSystem "Software System" {
            web = container "Web Application"
            db  = container "Database"
            web -> db "Reads/Writes"
        }
        user -> system "Uses"
    }

    views {
        systemContext system {
            include *
            autolayout
        }
    }
}

Click "Show As Structurizr Diagram" above the systemContext block to render the diagram.

Model Context Protocol

With varp.mcp.autoStart enabled, the extension starts a built-in MCP server (streamable HTTP on 127.0.0.1) that exposes the resolved C4 model to AI assistants. It is available in the desktop build only.

Tools

Tool	Description
`list-projects`	List all root workspace documents (projects) that currently have a resolved C4 model.
`list-views`	Catalog of all views in a project: key, type, title, description, element/relationship counts and a `byType` breakdown; optionally filtered by type.
`read-project-summary`	Summary of a project: element counts by type, total relationships, and available views.
`search-element`	Search elements in a project by id, name, type or tags.
`read-element`	Full details of an element: attributes, outgoing relationships, and the views that include it.
`read-view`	Details of a single view: metadata, elements and relationships (with names resolved).
`read-deployment`	Deployment tree: deployment nodes, infrastructure nodes and deployed instances (with instance counts).
`query-graph`	Neighbourhood of an element: ancestors, descendants, siblings, children, parent and/or direct incoming/outgoing relationships.
`query-incomers-graph`	Recursive graph of elements that (directly or transitively) depend on the given element, up to a depth/node cap.
`query-outgoers-graph`	Recursive graph of elements the given element (directly or transitively) depends on, up to a depth/node cap.
`find-relationships`	Find model relationships by optional source, destination and/or tag.
`find-relationship-paths`	Find paths (sequences of relationships) between two elements via BFS; with `includeIndirect=false` only a direct relationship is returned.
`query-by-tags`	Query elements by tags: `allOf` (must have every tag), `anyOf` (at least one), `noneOf` (must have none).
`query-by-tag-pattern`	Query elements whose any tag matches a pattern by prefix, contains or suffix.
`query-by-metadata`	Query elements by a property (key/value): only key matches presence, key+value matches the value by the operator.
`read-model-json`	Raw Structurizr model JSON (`json.model`): people, software systems, deployment nodes with their relationships.
`read-view-json`	Raw Structurizr view JSON for a view key: elements with computed positions/sizes, relationships and dimensions.
`read-raw-workspace-json`	Complete resolved Structurizr workspace JSON: model, views, configuration, styles/themes, documentation and more.
`batch-read-elements`	Read full details of multiple elements in one call; not-found ids are reported in `missing`.
`element-diff`	Side-by-side comparison of two elements: attributes, properties, tags and relationships.
`subgraph-summary`	Compact summary of all descendants of an element: per-element metadata, tags, relationship counts and a breakdown by type.

Prompts

Prompt	Description
`summarize-project`	Instruct the model to summarize a C4 project: its elements, relationships and views.
`explore-element`	Instruct the model to deep-dive into one element: its details, relationships and views.

Resources

Resource	Description
`projects`	List of all C4 projects (root workspace document URIs).
`project`	Flattened C4 model (elements, relationships, views) of a project.

Development

Prerequisites

Node.js 24.18.0
npm

Setup

# 1. Install dependencies
npm install

# 2. Build (generate grammar, compile, bundle, run tests)
npm run build

# 3. Launch the Extension Development Host
#    In VS Code: press F5 (or use the provided launch configuration)

Useful Commands

Command	Description
`npm run build`	Full local build: grammar + typescript + bundle + tests
`npm run build:ci`	CI build: grammar + typescript + bundle + tests + package `.vsix`
`npm test`	Run the test suite (Vitest)
`npm run package`	Create a `.vsix` installable package

Grammar

The DSL grammar lives in src/language/c4.langium. After editing the grammar, regenerate the Langium artifacts:

npx langium generate

Project Structure

src/
├── generated/            # Langium-generated AST, module, and grammar artifacts
├── language/             # Language server (Langium) implementation
│   ├── c4.langium        # C4 DSL grammar definition
│   ├── c4-json-generator.ts          # Structurizr-compatible render JSON generator
│   ├── c4-json-generator-handler.ts  # JSON build lifecycle & caching
│   ├── c4-json-enricher.ts           # documentation, decisions, health checks, DSL identifiers
│   ├── c4-dsl-source.ts              # retained portable DSL (base64) of the workspace
│   ├── c4-json-compare.ts            # golden-test JSON comparator
│   ├── c4-drawio-layout.ts           # DrawIO layout reader
│   ├── c4-validator.ts               # Validation checks
│   ├── c4-scope-provider.ts          # Reference scoping & includes
│   ├── c4-document-builder.ts / c4-include-resolver.ts  # !include and extendsUri loading
│   ├── c4-inlay-hints.ts / c4-code-lens.ts / c4-document-link.ts  # LSP features
│   ├── c4-binary-file-system.ts / c4-base64.ts  # web file-system bridge
│   └── main.ts / main.browser.ts     # Language server entry points
├── extension/            # VS Code extension host
│   ├── init.ts           # Extension activation & command registration
│   ├── diagram-preview.ts  # Structurizr diagram webview (themes, export, layout import)
│   ├── workspace-file-requests.ts / workspace-metadata.ts
│   ├── c4-snippets.ts / patterns.ts / capabilities.ts  # Sidebar views
│   ├── hmac.ts / config.ts
│   └── mcp/              # built-in MCP server (tools, prompts, resources)
css/                      # Structurizr rendering styles
js/                       # Structurizr rendering engine (JointJS, Dagre, panzoom)
test/fixtures/            # DSL → expected JSON golden tests

Contributing

Contributions are welcome!
