WebSocket Console

Test and debug WebSocket endpoints directly from VS Code.

This extension provides a simple WebSocket console inside VS Code, so you can quickly connect to a server, send messages, inspect responses, and reuse common payloads.

Features

• 🔌 Connect to any WebSocket endpoint
  • Supports ws:// and wss:// URLs.
• 💬 Send and receive messages
  • Console-style log with timestamps.
• 🧩 JSON pretty-print
  • If a message is valid JSON, it is automatically formatted with indentation.
• ⭐ Message presets
  • Save frequently used messages as presets.
  • Click a preset to quickly load it back into the input.
  • Presets are persisted between panel sessions.

Getting Started

Command

Open the WebSocket Console via the Command Palette:

1. Press Ctrl+Shift+P / Cmd+Shift+P.
2. Run: WebSocket: Open WebSocket Console.

This opens a panel with:

• WebSocket URL input
• Connect / Disconnect buttons
• Status display
• Message log
• Presets section
• Message input and Send button

Usage

1. Enter a WebSocket URL

   Example:

   ws://localhost:8080


   or

   wss://your-server.example.com/socket


2. Click Connect

   • The status text will change (Connecting → Connected).
   • Connection events are logged in the console area.

3. Send messages

   • Type plain text or JSON in the message input.
   • Click Send.
   • Outgoing messages are logged as >>.
   • Incoming messages are logged as <<.
   • JSON payloads are pretty-printed automatically if possible.

4. Use presets

   • Type a message in the input.
   • Click Save current as preset.
   • A small button appears under “Presets”.
   • Click a preset button to load that message back into the input.

Example: Local echo server (for testing)

You can spin up a simple local WebSocket echo server with Node.js:

// server.js
const WebSocket = require("ws");

const wss = new WebSocket.Server({ port: 8080 });

wss.on("connection", (ws) => {
  console.log("Client connected");

  ws.on("message", (message) => {
    console.log("received:", message.toString());
    ws.send(message.toString()); // echo back
  });

  ws.on("close", () => {
    console.log("Client disconnected");
  });
});

console.log("WebSocket server running on ws://localhost:8080");

Then:

npm init -y
npm install ws
node server.js

In VS Code:

• Open WebSocket Console
• URL: ws://localhost:8080
• Click Connect
• Send any message and see it echoed back.

Requirements

• VS Code 1.80.0 or later.
• A reachable WebSocket server (local or remote) to connect to.

Extension Settings

This extension currently does not add any custom settings.
Future versions may provide configuration options for:

• Default URL
• Auto-reconnect behavior
• Log size / trimming

Known Issues

• Some public WebSocket test servers may block connections from VS Code’s webview environment.
• Error details for WebSocket failures are limited by the browser/WebSocket API and may appear as generic errors.

If you run into issues, try testing with a local WebSocket server first.

Release Notes

0.1.0

• Initial release.
• WebSocket console panel.
• JSON pretty-print for messages.
• Message presets with persistence.

Contributing

Suggestions and contributions are welcome!

• Open an issue or pull request on the repository:
  • https://github.com/vijaydoba/WebSocket-Console.git
