MASO VS Code Extension

A VS Code extension that provides comprehensive support for .maso files with JSON validation, syntax highlighting, and real-time diagnostics.

The extension automatically detects .maso files and provides real-time validation with detailed error messages, as shown above where an invalid mode "unknown" is highlighted with a clear diagnostic message.

Features

• Automatic recognition: .maso files are automatically recognized as JSON
• Schema validation: Real-time validation of MASO file structure
• Advanced diagnostics: Detects structure errors, missing fields, and incorrect types
• Specific validations:
  • Unique process IDs
  • Non-negative times
  • Valid processing modes (regular, burst)
  • Mode-specific structure:
    • Regular: service_time required
    • Burst: threads with bursts of type cpu or io
• Syntax highlighting: MASO-specific keywords highlighted
• Autocompletion: Suggestions for valid fields

MASO File Structure

Regular Mode

{
  "metadata": {
    "name": "Process Name",
    "version": "1.0.0",
    "description": "Process description"
  },
  "processes": {
    "mode": "regular",
    "elements": [
      {
        "id": "A",
        "arrival_time": 0,
        "service_time": 3,
        "enabled": true
      }
    ]
  }
}

Burst Mode

{
  "metadata": {
    "name": "Burst Mode Exercise",
    "version": "1.0.0",
    "description": "Processes with threads and bursts"
  },
  "processes": {
    "mode": "burst",
    "elements": [
      {
        "id": "P1",
        "arrival_time": 0,
        "enabled": true,
        "threads": [
          {
            "id": "T0",
            "enabled": true,
            "bursts": [
              {
                "type": "cpu",
                "duration": 3
              },
              {
                "type": "io",
                "duration": 2
              }
            ]
          }
        ]
      }
    ]
  }
}

Requirements

• VS Code 1.102.0 or higher

Configuration

This extension contributes the following settings:

• maso.validation.enabled: Enable/disable MASO file validation (default: true)
• maso.validation.strictMode: Enable strict validation mode (default: false)

Commands

• MASO: Validate File: Manually validate the current MASO file

Development Installation

1. Clone this repository

   git clone https://github.com/vicajilau/maso_vs_extension.git
   cd maso_vs_extension


2. Install dependencies

   npm install


3. Compile the extension

   npm run compile


4. Test the extension

   • Press F5 to open a new VS Code window with the extension loaded
   • Create or open a .maso file to test the features

Development and Commands

Main Commands

• npm run compile: Compile TypeScript and run linting
• npm run watch: Compile in watch mode (recompiles automatically)
• npm run test: Run automated tests
• npm run test:unit: Run tests with unit focus
• npm run test:watch: Watch tests during development
• npm run vsce:package: Create VSIX package for distribution
• npm run vsce:publish: Publish to marketplace

Development Workflow

1. During active development:

   npm run watch


   This maintains automatic compilation while you edit the code.

2. To test changes:

   • Press F5 to launch extension in debug mode
   • Use Ctrl+Shift+F5 to reload the extension window

3. Before committing:

   npm run compile  # Verify everything compiles without errors


4. To create a new version:

   # 1. Compile and verify
   npm run compile

   # 2. Run tests to ensure quality
   npm test

   # 3. Create VSIX package
   npm run vsce:package

   # 4. Install locally to test
   code --install-extension maso-file-support-0.0.1.vsix


Testing

The extension includes comprehensive automated tests to ensure validation accuracy:

• Type validation tests: Verify correct data types (string, integer, boolean)
• Value validation tests: Check non-negative numbers and valid ranges
• Structure tests: Ensure required fields and proper nesting
• Mode-specific tests: Validate regular vs burst mode differences
• Error detection tests: Confirm proper diagnostic messages

# Run all tests
npm test

# Run tests in watch mode during development
npm run test:watch

# Test from VS Code: Use "Run Extension Tests" debug configuration

See TESTING.md for detailed testing documentation.

Continuous Integration

The project uses GitHub Actions for automated testing:

• ✅ Multi-platform testing: Tests run on Ubuntu, Windows, and macOS
• ✅ Automated on push: Tests run automatically on every push to main
• ✅ Pull request checks: Tests run on every pull request
• ✅ Linting and type checking: Code quality checks before tests
• ✅ Extension packaging: Automatic VSIX creation on successful tests

Status:

Why compile before packaging?

• TypeScript → JavaScript: Source code is in TypeScript but VS Code runs JavaScript
• Bundling: esbuild combines all files into a single optimized dist/extension.js
• Verification: Type checking and linting run to detect errors
• Optimization: Code is minified and optimized for production
• VSIX package: Only includes compiled JavaScript, not source code

Project Structure

maso_vs_extension/
├── .github/
│   └── assets/               # Demo images and assets
│       ├── demo.png         # Demo screenshot
│       └── icon.png         # Extension icon
├── maso_files/               # Example files
│   ├── burst.maso           # Burst mode example
│   └── regular.maso         # Regular mode example
├── src/
│   └── extension.ts         # Main extension code
├── test/                     # Test suite (outside of src)
│   └── extension.test.ts    # Automated tests
├── syntaxes/
│   └── maso.tmGrammar.json  # Grammar for syntax highlighting
├── dist/                     # Compiled JavaScript (generated)
├── out/                      # Test compilation output (generated)
├── package.json              # Extension configuration
├── language-configuration.json # Language configuration
├── TESTING.md               # Testing documentation
└── README.md

Contributing

Contributions are welcome! Please follow these steps:

To Contribute

1. Fork the repository

2. Create a branch for your feature:

   git checkout -b feature/new-functionality


3. Make changes and compile:

   npm run compile  # Verify it compiles without errors


4. Test the extension:

   # Create test package
   npm run vsce:package

   # Install it locally
   code --install-extension maso-file-support-x.y.z.vsix


5. Commit and push:

   git add .
   git commit -m "feat: description of changes"
   git push origin feature/new-functionality


6. Create Pull Request

Conventions

• Commits: Use Conventional Commits

  • feat: for new features
  • fix: for bug fixes
  • docs: for documentation changes
  • refactor: for refactoring

• Code:

  • Use TypeScript with strict types
  • Run linting before commit
  • Add comments for complex logic

Reporting Issues

If you find a bug or have a suggestion:

1. Check that a similar issue doesn't already exist
2. Create a new issue with:
   • Clear description of the problem
   • Steps to reproduce
   • Example .maso file if relevant
   • VS Code and extension version

License

This project is under the MIT license.
