Universal Database Client

A free, feature-rich database client for Visual Studio Code — built for speed, designed for developers who work with tables containing 10M to 100M+ rows.

✨ Features

🔌 Multi-Database Connectivity

• PostgreSQL — Full support including schemas, functions, procedures, materialized views
• Amazon RDS — Seamless connectivity to AWS-hosted databases
• Amazon Redshift — Optimized for data warehouse workloads
• MySQL — (coming soon)
• SQLite, Redis, MongoDB — (planned)

🔐 Enterprise-Grade Security

• SecretStorage API — Passwords never stored in plaintext; uses VS Code's encrypted vault
• SSH Tunneling — Connect through bastion hosts with password, private key, or SSH agent authentication
• SSL/TLS — Full support with CA certificates, client certs, and client keys
• Proxy Support — SOCKS5, HTTP, and HTTPS proxy connectivity

📝 Premium SQL Editor

• Syntax Highlighting — Real-time tokenized highlighting for keywords, functions, types, strings, comments, and numbers
• Smart Autocomplete — Context-aware suggestions for SQL keywords, table names, and column names (type users. to see columns of the users table)
• Inline Query Execution — Green ▶ play buttons appear in the gutter next to each SQL statement — click to run just that query
• Client-Side Linter — Real-time warnings for unclosed strings and unbalanced parentheses, shown as ⚠️ icons in the line gutter
• Error Line Highlighting — When a query fails, the exact error line is highlighted in red with a descriptive tooltip
• State Persistence — Your SQL editor content is automatically saved and restored across VS Code restarts and reloads
• Query Bookmarks — Save frequently-used queries with custom names for instant recall from the sidebar
• SQL Formatting — One-click SQL beautification
• Dark Theme Optimized — Carefully layered z-index architecture ensures text is always visible in any VS Code theme

⚡ Blazing-Fast Results Viewer

• Server-Side Pagination — Only fetches the rows you need; handles 100M+ row tables effortlessly
• Configurable Page Size — 50, 100, 500, 1000, or 5000 rows per page
• Server-Side Sorting — Click column headers to sort — executes ORDER BY on the server, not in the browser
• Server-Side Search — Filter results with debounced search queries executed on the database
• Multi-Row Selection — Click, Shift+Click, and Ctrl/Cmd+Click for row selection
• Column Resizing — Drag column borders to resize
• Inline Cell Editing — Double-click any cell to edit values directly in the table (requires primary key)
• Insert & Delete Rows — Full CRUD operations from the results grid
• Data Type Badges — NULL, boolean, and JSON values displayed with color-coded badges
• Copy Support — Right-click context menu to copy cells, rows, or columns; Ctrl+C for selected rows

📈 Built-In Charting

• Chart Types — Bar, Line, Pie, Doughnut, and Radar charts generated from query results
• Customizable — Select X-axis label column, Y-axis value column, and color theme
• Color Themes — Neon Blue, Emerald Green, Amethyst Purple, Sunset Orange, and Spectrum Multi-color
• Export — Save charts as PNG images

📤 Export Engine

• Column Selection — Choose which columns to include before exporting
• CSV — RFC 4180 compliant, Excel-compatible with proper quoting
• JSON — Pretty-printed with full type preservation
• SQL INSERT — Generate INSERT statements for data migration
• Full Dataset Export — Exports all rows (not just the current page)

🌳 Database Explorer Sidebar

• Tree View — Browse schemas, tables, views, columns, functions, procedures, and materialized views
• Table Preview — Click any table to instantly run SELECT * FROM with pagination
• Saved Queries — Dedicated tree section for your bookmarked queries
• Connection Status — Visual indicators showing connected/disconnected state
• Connection Colors — Color-code your connections for quick visual identification

🔄 Schema Diff

• Cross-Connection Comparison — Compare schemas between any two database connections
• Table Diff — Detect added, removed, and modified tables
• Column Diff — Detect added, removed, and modified columns (type changes, nullability, defaults)
• Primary Key Diff — Detect primary key changes
• SQL Migration Generation — Auto-generate ALTER TABLE statements to sync schemas

🗺️ ERD Diagrams

• Auto-Generated — Entity-Relationship diagrams rendered from your live database schema
• Foreign Key Visualization — See relationships between tables
• SVG Export — Save diagrams as SVG files

🏗️ Query Builder

• Visual Query Construction — Build SELECT queries with a point-and-click interface
• Table & Column Selection — Pick tables and columns from dropdowns
• WHERE Clauses — Add filter conditions visually
• JOIN Support — Build multi-table queries with visual join configuration

🚀 Getting Started

1. Install the extension from the VS Code Marketplace
2. Click the database icon in the Activity Bar (left sidebar)
3. Click + to add a new connection
4. Fill in your connection details (host, port, database, user, password) and click Save
5. Click your connection to connect, then explore schemas, tables, and views
6. Click any table to open the Query Panel, or use the Query Editor to write custom SQL

⌨️ Keyboard Shortcuts

🏗️ Architecture

src/
├── extension.ts                    # Entry point & command registration
├── core/
│   ├── interfaces/                 # IDatabaseDriver, IConnectionConfig, types
│   ├── security/                   # SecureStorageManager (SecretStorage API)
│   ├── tunnel/                     # SSH tunnel manager (ssh2)
│   ├── proxy/                      # SOCKS5/HTTP proxy support
│   ├── export/                     # CSV, JSON, SQL export engine
│   ├── diff/                       # Schema diff service
│   ├── erd/                        # ERD diagram generator
│   ├── queryBuilder/               # Visual query builder service
│   ├── savedQueries/               # Query bookmark manager
│   └── ConnectionManager.ts        # Connection lifecycle & driver pool
├── drivers/
│   ├── DriverFactory.ts            # Factory pattern for database drivers
│   ├── postgres/                   # PostgreSQL driver + SQL dialect
│   ├── mysql/                      # MySQL driver + SQL dialect
│   ├── mssql/                      # SQL Server driver + SQL dialect
│   ├── sqlite/                     # SQLite driver + SQL dialect
│   └── redshift/                   # Redshift driver + SQL dialect
├── providers/
│   ├── DatabaseTreeProvider.ts     # Sidebar tree view data provider
│   ├── DatabaseTreeItem.ts         # Tree node types & icons
│   ├── SQLCompletionProvider.ts    # IntelliSense autocomplete
│   ├── SQLHoverProvider.ts         # Hover tooltips for SQL tokens
│   └── SavedQueriesProvider.ts     # Saved queries tree provider
└── webview/
    ├── WebviewPanelManager.ts      # postMessage bridge & state management
    └── html/
        ├── connectionForm.html     # Connection configuration form
        └── queryPanel.html         # SQL editor + results + charts UI

🛠️ Development

# Install dependencies
npm install

# Watch mode (auto-recompile on save)
npm run dev

# Type-check without emitting
npm run compile

# Production build (webpack)
npm run build

# Package as VSIX
npx @vscode/vsce package

# Press F5 in VS Code to launch Extension Development Host

🤝 Contributing

Contributions are welcome! Please open an issue or pull request on GitHub.

📄 License

MIT
