Inline SQL

A Visual Studio Code extension that provides syntax highlighting, autocomplete, validation, and formatting for SQL strings embedded in your code.

No markers or special tags required — SQL is detected automatically.

Getting Started

Requires VS Code 1.85 or later. To install a locally built release, run Extensions: Install from VSIX... from the Command Palette and choose the .vsix file.

Open a supported source file containing SQL, for example:

const query = `select id, name from users where active = true`;

SQL highlighting, keyword completion and validation work without a database connection. Place the cursor inside the string and run Inline SQL: Format SQL at Cursor, or use Inline SQL: Format All SQL in File. To share formatting preferences with other tools, add the configuration file described below.

See CHANGELOG.md for release notes and CONTRIBUTING.md for development and packaging instructions.

Supported Languages

Features

Syntax Highlighting

SQL keywords, types, functions, and literals are highlighted inside string literals with categorized colors. Works with both light and dark themes.

Autocomplete

• SQL Keywords — DML statements, clauses, JOIN variants, functions
• Snippet Templates — e.g. SELECT ... FROM ..., INSERT INTO ... VALUES ...
• Schema-Aware (optional) — Table and column names from a live database connection

Triggers on . (for table.column) and Space (after keywords).

Validation / Linting

• Real-time SQL syntax checking
• Auto-dialect detection — C# files use TransactSQL, others default to MySQL
• Configurable dialect: auto, mysql, postgresql, transactsql, sqlite
• Smart skip for SQL fragments and T-SQL specific syntax
• Multi-statement T-SQL blocks — SET XACT_ABORT, BEGIN TRANSACTION, DECLARE blocks are split into individual statements; procedural commands are skipped while DML statements (INSERT, DELETE, UPDATE, SELECT) are validated
• Interpolation placeholders are normalized for parser compatibility

Formatting

• Format SQL at cursor position or all SQL strings in file
• Configurable indent, keyword casing, and dialect
• Shared .sql-formatter.json support with automatic discovery inside the workspace
• Preserves host code indentation and interpolation expressions
• Escapes inserted newlines in ordinary quoted strings
• Leaves strings with host-language escapes, multiline SQL values and single-line raw strings unchanged when safe rewriting is not supported

Commands

Settings

All settings are under the inlineSql.* namespace.

Detection

Validation

When set to auto, the dialect is inferred from the host language:

Formatting

These formatting settings can be set per workspace folder. Formatting and validation have separate dialect settings: .sql-formatter.json does not change inlineSql.validation.dialect.

Shared .sql-formatter.json configuration

Starting with 0.2.0, both formatting commands automatically read .sql-formatter.json, so the extension and the sql-formatter CLI can share formatting preferences:

{
  "language": "postgresql",
  "tabWidth": 2,
  "keywordCase": "upper",
  "useTabs": false,
  "linesBetweenQueries": 1
}

The extension searches from the source file's directory up to its owning workspace folder, including that folder. The nearest file wins; parent configuration files are not merged. In multi-root and remote workspaces, each document uses its own workspace folder. Untitled documents and files outside a workspace use VS Code settings.

Values in the JSON file override the extension's settings. Missing language, tabWidth, and keywordCase values use inlineSql.formatting.dialect, inlineSql.formatting.indent, and inlineSql.formatting.uppercase, respectively. Other omitted options use the formatter's defaults. Saved changes, additions and deletions take effect on the next formatting command, without restarting VS Code.

For example, src/.sql-formatter.json takes precedence over a file at the project root when formatting src/query.ts. Configuration outside the owning workspace folder is never searched. To keep CLI and extension formatting consistent, explicitly set language, tabWidth and keywordCase in the shared file; omitted values can differ because the extension falls back to VS Code settings.

Supported options: language, tabWidth, useTabs, keywordCase, identifierCase, dataTypeCase, functionCase, indentStyle, logicalOperatorNewline, expressionWidth, linesBetweenQueries, denseOperators, and newlineBeforeSemicolon. $schema metadata is accepted. params (SQL value substitution) and paramTypes (placeholder parsing configuration) are not supported by this source-code formatter. Host-language interpolation expressions remain intact, including when identifier casing changes.

Use valid JSON without comments or trailing commas. Invalid JSON, unsupported options, invalid values or unreadable configuration files stop formatting with a warning; the document remains unchanged. Configuration files are limited to 64 KiB; integer limits are 0–16 for tabWidth, 1–10000 for expressionWidth, and 0–100 for linesBetweenQueries.

Database Connection (Optional)

Define connections in User settings (machine scope), not repository settings. Database access and loading optional drivers require a trusted workspace, following the VS Code Workspace Trust guide. Set passwordEnv to an environment variable available to the VS Code extension host; plaintext password remains supported but is deprecated.

Connection object:

{
  "inlineSql.connections": [
    {
      "name": "local-dev",
      "driver": "postgres",   // postgres | mysql | mssql
      "host": "localhost",
      "port": 5432,
      "database": "mydb",
      "user": "dev",
      "passwordEnv": "INLINE_SQL_DB_PASSWORD"
    }
  ],
  "inlineSql.activeConnection": "local-dev"
}

Note: Database drivers (pg, mysql2, mssql) must be installed in your workspace for schema features to work.

Connection objects require name, driver, host and database; port, user, passwordEnv and the deprecated password are optional. When passwordEnv is set, it takes precedence over password; an undefined environment variable prevents the connection. With remote development, install the driver and provide the environment variable where the extension host runs.

Schema completion refreshes expired metadata on demand. Use Inline SQL: Refresh Schema Cache after changing credentials or when an immediate refresh is needed. Database queries read schema metadata; the extension does not execute the SQL strings from your source files.

Troubleshooting

How It Works

1. String Extraction — Language-specific parser extracts all string literals, handling comments, escape sequences, and nested interpolations
2. Interpolation Replacement — Template expressions are replaced with SQL-safe placeholders for parser compatibility
3. Classification — Two-tier approach:
   • Fast path: String starts with a SQL keyword (SELECT, INSERT, CREATE, etc.)
   • Scoring: String meets inlineSql.detection.minKeywords (default: 2), includes a qualifying statement keyword, and is at least 20 characters
4. Highlighting — Decoration API provides categorized highlighting compatible with semantic tokenization.

License

MIT
