ZPL Toolchain for VS Code

Production-ready ZPL editing support powered by the wider zpl-toolchain project.

This extension brings parser, validator, formatter, and diagnostic documentation into VS Code-family editors while staying aligned with the same core runtime used by the CLI and language packages.

What this extension does

• Syntax highlighting for ZPL command streams (^ / ~ command leaders).
• Live diagnostics from the shared WASM core validator.
• Format support via the same formatter used across the toolchain.
• Rich hovers for commands and command parameters (types, ranges, enums, units).
• Explain diagnostic quick action/command for fast issue triage.
• Safe quick fixes for high-confidence automatable issues (add missing ^XZ, ^FS).
• Command + enum completions while authoring labels.

Part of the wider toolchain

This extension is one piece of the full zpl-toolchain ecosystem:

• GitHub: https://github.com/trevordcampbell/zpl-toolchain
• Core TypeScript package: @zpl-toolchain/core
• Print package: @zpl-toolchain/print
• CLI wrapper: @zpl-toolchain/cli
• Release/process docs: docs/RELEASE.md, docs/TESTING.md, docs/VSCODE_EXTENSION.md

Extension identity:

• Extension ID: trevordcampbell.zpl-toolchain
• Package name (package.json#name): zpl-toolchain

Settings

• zplToolchain.profileJson — optional inline printer profile JSON.
• zplToolchain.diagnostics.debounceMs — debounce delay for diagnostics refresh.
• zplToolchain.format.indent — formatter style (none, label, field).
• zplToolchain.format.compaction — optional compaction (none, field, default: field), independent of indentation mode.
  • field keeps printable field blocks (^FO/^FT/^FM/^FN ... ^FS) on one line while preserving expanded setup/global flow when format.indent = none.
• zplToolchain.hover.enabled — enable/disable command hovers.
• zplToolchain.themePreset — optional token-color preset (custom, default, high-contrast, minimal).

Formatter defaults contributed for [zpl]:

• editor.defaultFormatter = trevordcampbell.zpl-toolchain
• editor.formatOnSave = true
• editor.suggest.showDetails = true
• editor.suggest.showInlineDetails = false
• editor.suggest.showStatusBar = true

IntelliSense note:

• Command completion rows are intentionally compact (opcode + name + [CATEGORY/SCOPE]) and rich docs are provided through suggestion details/hover.
• Suggestion details are editor-controlled UI; this extension can provide details content and defaults, but cannot force side-vs-bottom placement.

Use Command Palette:

• ZPL Toolchain: Apply Theme Preset
• ZPL Toolchain: Toggle ^FX Comment

Local development

npm ci
npm run test:ci
npm run package:vsix

Note: package:vsix uses npx @vscode/vsce@3.7.1, so first run on a fresh machine needs network access to fetch that pinned VSCE version.

Run in Extension Development Host from VS Code/Cursor with F5.

Integration test note (linux/arm64):

• The test runner now auto-detects a local VS Code-family CLI executable (code, code-insiders, cursor, codium) and uses it when available.
• You can still override explicitly with VSCODE_EXECUTABLE_PATH=/path/to/code (the executable must support --extensionDevelopmentPath and --extensionTestsPath flags).
• If no suitable executable is available, tests are skipped by default unless FORCE_VSCODE_INTEGRATION=1.

Install from VSIX (pre-publish or internal testing)

1. Build the VSIX with npm run package:vsix
2. In VS Code/Cursor:
   • open Command Palette
   • run Extensions: Install from VSIX...
   • select the generated zpl-toolchain-<version>.vsix

Distribution

• Visual Studio Marketplace (vsce)
• Open VSX (ovsx)
