Lmaobox MCP Server VS Code Extension

This extension is a zero-config MCP server for Lmaobox Lua inside VS Code. It installs the runtime automatically, registers the MCP server, and exposes Lmaobox tools in Copilot Chat and other MCP-capable clients.

Quick Start

1. Install the extension from the VS Code Marketplace.
2. Wait a few seconds after VS Code startup. The extension activates on startup and installs/configures the MCP runtime automatically.
3. Open Copilot Chat and use MCP tools. No manual server install is required in the normal case.

If you want to force a reinstall or update, run Lmaobox Context: Install Or Update Runtime from the Command Palette.

What it does

1. Downloads the runtime archive matching the extension version from GitHub Releases.
2. Verifies the archive with the published checksums.txt file.
3. Extracts the server binary plus smart_context, types, and bundled automation assets into the extension runtime folder.
4. Writes the modelContextProtocol.servers.lmaobox-context entry into user settings.

The goal is "install extension and it just works": runtime download, MCP registration, and docs/types availability are handled by the extension.

Lua Language Server Requirement

This extension requires sumneko.lua and attempts to install it automatically during setup.

• If sumneko.lua is already installed, setup proceeds immediately.
• If it is missing, the extension requests installation automatically.
• If installation cannot complete (offline policy/store issue), MCP still starts, but Lua lint diagnostics may be reduced until sumneko.lua is available.

MCP is configured with --prefer-lua-ls, so the Lua language server is the primary lint/diagnostic source for predictable workspace-aware checks.

Included Lua Snippets

The extension also ships first-party Lua snippets for common Lmaobox scripting patterns, including:

• callback registration templates
• local player guards
• common client, draw, and trace helpers

Start typing prefixes such as lm.createMove, lm.draw, lm.localPlayer, or lm.traceLine in a Lua file.

Expected release assets

The extension expects these files on the GitHub release matching the extension version tag:

• lmaobox-context-runtime_windows_amd64.zip
• lmaobox-context-runtime_linux_amd64.zip
• lmaobox-context-runtime_linux_arm64.zip
• lmaobox-context-runtime_darwin_amd64.zip
• lmaobox-context-runtime_darwin_arm64.zip
• checksums.txt

Publishing

1. Update this extension version to match the Go runtime release tag without the leading v.
2. Publish the GitHub tag so .github/workflows/release.yml produces the runtime archives.
3. Package or publish this extension to the VS Code Marketplace.

Commands

• Lmaobox Context: Install Or Update Runtime
• Lmaobox Context: Open Runtime Folder
• Lmaobox Context: Open Bundled Docs Folder

Configuration

• lmaoboxContext.autoConfigureMcp (default: true) : Automatically writes/updates the MCP server entry in VS Code user settings.
• lmaoboxContext.releaseTag (default: empty) : Override runtime tag. Empty means v<extension-version>.
• lmaoboxContext.repoOwner / lmaoboxContext.repoName : Override GitHub source for runtime release assets.

Troubleshooting

If MCP does not start or tools are missing:

1. Run Lmaobox Context: Install Or Update Runtime.
2. Run Lmaobox Context: Open Runtime Folder and verify files exist: : lmaobox-context-server(.exe), types, and smart_context.
3. Open VS Code settings JSON and verify: : modelContextProtocol.servers.lmaobox-context exists and points to the runtime executable.
4. Restart VS Code after reinstall.

If GitHub release assets are unavailable for your version, set lmaoboxContext.releaseTag temporarily to a valid tag.

Notes On Snippets

This extension includes first-party snippets maintained with the MCP/runtime integration. It does not bundle third-party snippet packs.
