Bloblang for VS Code
Bloblang highlighting, diagnostics, formatting, completion, hover, definitions,
and references, powered by Bloblang developer tools.
The extension manages the blobl tool for editor features and terminal linting
and formatting. An installed tool starts without waiting for the network and
works offline; stable releases are checked in the background.
If another extension also provides Bloblang, disable one provider to avoid duplicate
language servers. This extension includes its own grammars and needs no Benthos
extension.

Open a .blobl or .bloblang file. Bloblang is also highlighted inside YAML
mapping, request_map, result_map, args_mapping, fields_mapping, check,
and test bloblang values, including literal/folded blocks and quoted/plain
scalars. The test bloblang key is a legacy alias for mapping; prefer mapping
in new files. Values can start on the line after the key and span multiple lines,
including nested output_batches expressions. ${! ... } interpolation is
highlighted in YAML strings.
In valid YAML documents, embedded Bloblang receives server diagnostics, hover,
completion and navigation with positions mapped to the original document. Mapping
values also receive formatting; interpolation expressions are not formatted.
External mapping: from "mapping.blobl" values support file navigation and missing
file diagnostics.

With a CUE extension providing the host grammar, CUE mapping strings (ordinary,
raw and multiline) and interpolation receive highlighting. CUE language server
features continue to belong to the CUE extension.
With the default settings, activation prepares blobl and makes it available in
new VS Code integrated terminals. The language server starts when you open a
Bloblang document or a YAML document with bloblang.yaml.enabled enabled.
Set bloblang.cli.enabled to false to disable the integrated terminal PATH
contribution. Existing terminals may need to be relaunched after installation or
an update.
blobl --version
blobl lint mappings/
blobl lint --fix mappings/
blobl lint --format json config.yaml
blobl fmt --write mappings/
blobl fmt --check '**/*.blobl'
Quote glob patterns so blobl expands them; ** matches recursively. Linting is
static and does not execute mappings or load sample files. --fix applies only
available safe fixes. fmt --check returns 1 for formatting changes; lint
returns 1 for warnings or errors, and usage/configuration failures return 2.
See the CLI reference
for stdin, YAML handling and all options.
The tool runs on the VS Code extension host. In Remote SSH, WSL or a dev
container, that is the remote machine, WSL distribution or container. Downloads
match that host's OS and CPU: Linux, macOS and Windows, each with amd64 (x64) and
arm64 builds. Remote installation and terminal PATH changes apply to that host.
On first installation, the extension reads the public blobl-release.json
manifest from GitHub Releases, downloads the raw binary from its version-tagged
release, and checks that blobl --version matches the manifest before using it.
No GitHub token is needed. Later activations reuse the verified cached tool and
check for stable updates in the background at most about once a day. A failed
download or version check keeps the installed tool usable. Background installs
take effect on the next server start; Bloblang: Check for Tool Updates checks
immediately and restarts an active managed language server after an update.
Use blobl --version in a new integrated terminal to check the selected CLI.
A cached legacy language-server from an earlier extension can still provide
editor features offline, but it does not provide the blobl terminal commands.
For shells outside VS Code, run Bloblang: Install CLI for External Terminals.
Choose an absolute folder on the extension host; the defaults are ~/.local/bin
on Linux/macOS and %LOCALAPPDATA%\Bloblang\bin on Windows. The command copies
the managed binary and asks before replacing a different existing file. Add that
folder to your shell's PATH if needed, then open a new terminal and run
blobl --version. The command reports the installed path and PATH instructions;
it does not edit shell profiles or the Windows registry. This copy remains after
extension removal and is updated only when you run the install command again.
Commands and settings
- Bloblang: Restart Language Server restarts using the current settings.
- Bloblang: Show Language Server Logs opens server output.
- Bloblang: Check for Tool Updates installs the latest stable managed tool.
- Bloblang: Install CLI for External Terminals copies the managed CLI to a
folder you choose.
- Bloblang: Format Embedded Mappings formats Bloblang in the active YAML file
while preserving the surrounding YAML. Short scalar values keep their quoting
style; mappings that wrap onto multiple lines use literal blocks. Changed folded
blocks are rewritten as literal blocks. Your default YAML formatter stays usable.
- Use Format Document in Bloblang files.
- With Bloblang v0.2.2+, use F2 (Rename Symbol) on
let variables,
lambda parameters or named maps. Rename respects scope, follows literal
.apply("name") references through imports, and works in embedded YAML.
Field paths and computed map names are not renamed. See the server's
rename guide.
bloblang.server.path overrides the managed server with a path or PATH command.
It supports ${workspaceFolder} and ${userHome}; relative paths are resolved
from the first workspace folder. bloblang.server.args supplies arguments exactly
as configured for a custom server. For a custom blobl, set the arguments to
["lsp"]; the managed tool selects lsp automatically. A custom server path
disables automatic managed tool preparation and integrated terminal CLI exposure.
bloblang.yaml.enabled controls YAML server features (highlighting is always
available). bloblang.trace.server enables protocol logging. Lifecycle messages
stay in the output channels. A quiet status bar indicator shows starting, ready,
or failed; click it to open server logs. Initialization shows no notification.
Startup failures offer logs and settings.
Workspace configuration and linting
Create .bloblangrc.json in your project. VS Code automatically provides
configuration completion and validation through the bundled schema. Each document
uses the nearest configuration from its directory up to the deepest containing
workspace root, inclusive. Embedded mappings use the YAML file's location.
A nested configuration replaces ancestor settings; configurations are not merged.
Loose documents and CLI inputs use the nearest Git project boundary, or search
up to the filesystem root outside Git. Configuration edits, creation and deletion
apply without restarting the server. Defaults are 80 columns and YAML previews.
All lint rules are enabled:
prefer-with and prefer-any start as hints; the others start as warnings:
{
"formatter": { "printWidth": 80 },
"preview": { "format": "yaml" },
"lint": {
"enabled": true,
"rules": {
"correctness/environment/require-fallback": "warn",
"correctness/variables/no-unused-let": "warn",
"style/assignments/prefer-grouped": {
"severity": "warn",
"minAssignments": 3
},
"style/objects/prefer-with": "hint",
"style/objects/prefer-without": "warn",
"style/objects/combine-without": "warn",
"style/arrays/prefer-any": "hint"
}
}
}
CLI directory and glob scans honor .gitignore and .bloblangignore, including
nested ignore files. Add Gitignore-style patterns in files.exclude, relative to
the configuration file's directory:
{
"files": {
"exclude": ["generated/**"],
"respectGitignore": true
}
}
Set files.respectGitignore to false to skip .gitignore while retaining the
other exclusions. --no-ignore bypasses ignore rules for a CLI run; explicitly
named files also bypass them. These settings control CLI file selection and do
not suppress diagnostics in open editor documents.
printWidth accepts integers from 20 to 1000. Set preview.format to json
for JSON previews. Hovers, inlay tooltips, and output previews use the same format
and width; short collections stay together when they fit. The formatter preserves
comments and string contents, collapses short expressions, wraps longer ones,
and keeps unary operators adjacent to their operands, such as index(-1). Width
guides expression layout; preserved strings and comments can exceed it.
Long method chains break after dots. Lambda bodies wrap independently, keeping
short calls such as .join("; ") together (Bloblang v0.2.2+).

Rule keys remain flat for autocomplete; their slash-separated IDs group related
rules. Each accepts off, hint, info, warn, or error, or an object with
severity and its documented options. Only style/assignments/prefer-grouped
accepts minAssignments (at least 3). VS Code reports invalid configuration through
the schema; the server falls back to defaults without stopping other language
features.
| Rule |
Suggestion |
correctness/environment/require-fallback |
Handle an unset env() with a default or explicit failure. |
correctness/variables/no-unused-let |
Report a binding that is never referenced in its scope. |
style/assignments/prefer-grouped |
Group consecutive field assignments when output state allows it. |
style/objects/prefer-with |
Use .with(...) for a projection of the receiver's same-named fields. |
style/objects/prefer-without |
Use .without(...) when copying an object then deleting fields. |
style/objects/combine-without |
Combine consecutive .without(...) calls. |
style/arrays/prefer-any |
Use .any(...) for a filtered array existence check. |
For example, env("ARTIFACT_DIR").or("./artifacts") supplies a default, and
env("ARTIFACT_DIR").or(throw("ARTIFACT_DIR is required")) explicitly fails.
An unset environment variable returns null, so .catch(...) by itself does not
handle it; .not_null().catch(...) does.
Suppress a rule for the next source line with its full ID:
# bloblang-lint-disable-next-line correctness/environment/require-fallback -- guaranteed by the launcher
root.artifact_dir = env("ARTIFACT_DIR")
Lint diagnostics use these IDs in standalone and embedded YAML mappings. Only
style/objects/combine-without offers a Quick Fix, when both calls have literal
string arguments and the expression contains no comments. For YAML, that fix is
available in plain scalars and literal blocks; quoted and folded scalars receive
diagnostics without edits. The server does not provide a Fix All action.
The other rules provide suggestions to review. .with() omits missing fields,
where object construction retains null; .assign() merges nested objects,
where direct field assignments replace them; .any() short-circuits, which can
change predicate errors or side effects. Formatting does not apply lint refactors.
See the server's lint guide
for the rule conditions and examples.

For mapping.blobl, create the sibling mapping.sample.json,
mapping.sample.yaml, or mapping.sample.yml to get runtime previews and type
guidance:
{"$bloblang":{"input":{"name":"Ada"},"meta":{"topic":"people"}}}
$bloblang:
input:
name: Ada
meta:
topic: people
Metadata is optional. The file envelope is required. Supply an optional root
inside $bloblang to preview mappings that update an existing output (for example,
a result_map), while input stays the separate value read through this.
#!root and #!root_from can override that initial output. Missing automatic samples
produce an informational suggestion to add a sample; static language features
still work. Multiple matching sibling sample files produce a diagnostic so sample
selection is unambiguous. Invalid sample files or directives disable preview,
while static diagnostics, documentation and navigation remain available. Changes,
creation and deletion of sample files refresh previews.
YAML inline mappings are numbered in document order from 001. For
pipeline.yaml, selection checks an explicit adjacent comment first, then
pipeline.sample-001.json for the first mapping, then the shared
pipeline.sample.json. JSON, YAML, and YML are supported at each level. External
from mappings and ${! ... } interpolations do not consume a number.
Interpolations use the shared sibling sample. Selected files use the $bloblang
envelope above.
# bloblang-sample: pipeline.sample-001.json
check: |
!errored() && this.state != "processing-ready"
Place the comment immediately before the mapping key, at the same indentation.
Explicit sample paths resolve relative to the YAML file. A missing explicit file
produces an error for that mapping; missing automatic samples remain informational.
File creation, updates, and deletion refresh previews.
Leading directives override fields from the selected sample. #!sample and
#!sample_from supply the entire sample and resolve automatic sibling ambiguity:
#!input {"name":"Ada"}
#!meta {"topic":"people"}
root.name = this.name.uppercase()
root.topic = meta("topic")
Use #!sample {"input":{"name":"Ada"},"meta":{"topic":"people"}} to provide
the entire sample inline. #!input_from, #!meta_from, #!root_from, and
#!sample_from load JSON/YAML files relative to the mapping file; these files require the
$bloblang envelope. A missing explicitly referenced file is an error at the
directive. Multiline arguments use comment continuation lines:
#!sample |
#| input:
#| name: Ada
#| meta:
#| topic: people
root = this
Sample hover shows the original input this and selected expression values.
Hovering a variable name in let name = expression shows its assigned value when
a valid sample is available, and later $name references use their current scope.
Hovering the assignment target root shows the input at the first assignment,
then the prior output before later assignments. Reading root on the right hand
side evaluates the actual output state, which may be unavailable before its first
assignment. Assignment end hints show the resulting output.
Evaluation uses complete preceding statements, preserving named maps, imports,
variables, and message metadata. Completion can use a known sample value's type;
without a sample, ordinary documentation and completion remain available.
For large values, Show Input and Show Output lenses open the full formatted
preview in a temporary YAML or JSON file using the originating document's settings.
With Bloblang v0.2.3+, hover and inlay tooltip bodies are capped at 4 KiB / 60
lines. Large values show a Preview truncated notice at the top and point to
these lenses. Collections, nesting and long strings are limited before formatting;
mapping evaluation and the full preview still use the complete sample.
Open Sample lenses open the selected sample files.

Build and package
Install Bun, Go matching the sibling server's go.mod, and a C
compiler for schema generation. Keep bloblang beside this repo while
building the extension:
bun install --frozen-lockfile
bun run check
bun run package
code --install-extension vscode-bloblang-0.3.1.vsix
The universal package contains dist/extension.js, language grammars/configuration,
and schemas/bloblangrc.schema.json; it contains no server binary. JavaScript
dependencies are bundled. The extension downloads a matching raw blobl binary
into VS Code global storage on the extension host and reuses it on later starts.
Set BLOBLANG_REPO to use another checkout for schema generation. The previous
BLOBLANG_LSP_REPO variable and ../bloblang-lsp directory remain supported
while existing local checkouts migrate.
Development can use bloblang.server.path pointing to a sibling server binary.
For blobl, also set bloblang.server.args to ["lsp"].
The configuration schema is generated from the server rule registry; run
bun run schema after changing rules or options. Packaging regenerates it before
building. Run bun run build:watch, then launch an Extension Development Host.
Grammar tests use checked-in host grammar fixtures and run without other projects or editor
extensions. bun run build:smoke builds dist/smoke.cjs, an extension host test
module; run it with an isolated VS Code profile and extensions directory to check
activation, sampled hover, completion, formatting, YAML mapping, diagnostics, and
restart without interference from other Bloblang extensions.
License
MIT
