CodeMap Visualizer

Visualize your entire codebase as an interactive map — files, folders, imports, function calls, CSS, environment variables, and database connections, all in one place.

What is this?

CodeMap Visualizer is a VS Code extension that scans your project and renders a live, interactive graph of your codebase. Instead of reading code file by file, you can see the entire structure at a glance — how files connect to each other, which files are entry points, which are unused, and where your database/env/CSS dependencies live.

Built with tree-sitter for accurate parsing (no regex hacks), rendered as SVG with full pan, zoom, drag, and isolate interactions.

Features

🗂️ Folder Boxes

• Every folder in your project is rendered as a rounded, colored box
• Files are placed inside their folder box — structure mirrors your actual project layout
• Each folder gets a unique color deterministically derived from its name (consistent across runs)
• Folder boxes are draggable — move them anywhere on the canvas
• Folder-to-folder connections are shown as thick curved edges when any files across two folders import each other

🔗 Edges — Import & Call Connections

• Import edges — blue curved bezier lines
• Call edges — orange dashed curved lines (when an imported function is actually called)
• Folder-to-folder edges — thick colored curves summarizing cross-folder dependencies
• Every edge has a circle dot at the source end and an arrowhead at the target end
• Edges are bezier curves — they never overlap confusingly like straight lines

📁 Folder Collapse / Expand

• Double-click any folder box → folder collapses to just its header bar
• All nodes inside hide, but connections are preserved — edges reroute to the collapsed box center
• Double-click again → folder expands back, edges restore to original positions
• Useful for hiding irrelevant parts of the graph while focusing on what matters

🎨 CSS / Style Files

• .css, .scss, .sass, .less files are scanned and shown in a dedicated 🎨 CSS / Styles section (purple)
• @import connections between CSS files are tracked as edges
• JS/TS files that import './App.css' get a purple edge connecting them to the CSS file
• Tooltip shows class names defined in the file

🔑 Environment Files

• .env, .env.local, .env.development, .env.production, .env.test etc. shown in a dedicated 🔑 Environment section (yellow)
• Only key names are scanned — values are never read or shown (security by design)
• Keys are categorized in the tooltip:
  • DB keys — DB_HOST, DATABASE_URL, MONGO_URI, REDIS_URL etc.
  • API/Secret keys — JWT_SECRET, API_KEY, OAUTH_TOKEN etc.
• Files using dotenv get a yellow edge connecting them to the .env node

🗄️ Database / Schema Files

• .sql, .prisma, and Python ORM files shown in a dedicated 🗄️ Database section (teal)
• Content-based detection — filename alone is never enough to classify a file as a DB file
• What is detected:
  • SQL — CREATE TABLE statements → table names extracted
  • Prisma — model User { } blocks → model names extracted
  • Python ORM — classes inheriting from Base, db.Model, Document, DeclarativeBase etc.
• What is correctly excluded:
  • Pydantic BaseModel — these are API schemas, not database models
  • FastAPI request/response models are NOT classified as DB files
• Code files that import DB clients (mongoose, prisma, @prisma/client, sequelize, typeorm, knex, pg, mysql2, sqlite3, redis, ioredis, pymongo, motor, sqlalchemy, tortoise, peewee, mongoengine, django.db) get a 🗄️ badge on their node and a teal edge to the schema file

⭐ Entry Point Detection

• Files with 0 incoming imports (nothing imports them) get a gold border
• These are your app entry points — index.ts, main.py, app.js etc.
• Helps you understand where execution starts

🔴 Unused File Detection

• Files with no connections at all (neither imports nor imported by anything) are collected into a dedicated 🗑 Unused Files section at the bottom of the graph
• The section is collapsed by default — double-click to expand and browse all unused files
• This keeps the main graph clean — only connected files are visible on load
• The section is draggable — reposition it anywhere on the canvas
• Unused files are rendered with a gray dimmed style inside the section
• Tooltip shows a ⚠️ unused badge on each file inside

🖱️ Full Interaction Model

💬 Rich Tooltips

• File node hover → filename, folder path, LOC, function count, function names (up to 10), DB usage badge
• Edge hover → source file → target file, edge type (import/call/db-use/env-use/css-import), imported symbol names
• Folder box hover → folder name, file count, "click to isolate" hint
• CSS node hover → class count, class names, @import list
• ENV node hover → total keys, DB keys list, API/Secret keys list (values always hidden)
• DB node hover → table names (SQL), model names (Prisma/ORM)

🔍 Drilldown Folder Mode

• Right-click any folder in the VS Code Explorer sidebar → select "Generate CodeMap for this Folder"
• The map is scoped only to that folder — perfect for large monorepos where you want to focus on one app or module
• Same 3-step folder picker as the full project command, but anchored to the selected folder as root
• Step 1 — pick which top-level subfolders inside the selected folder to include
• Step 2 — for each picked subfolder that has further subfolders, choose specific subfolders, "📄 root files only", or "✅ Select ALL" recursively
• Step 3 — for each Step 2 subfolder that has even deeper subfolders, choose specific sub-subfolders, "📄 root files only", or "✅ Select ALL"
• If a subfolder has no further subfolders → included directly, the next step is skipped for it
• Dismissing any step → the entire folder is included
• Implemented via codemap-visualizer.generateForFolder command registered in extension.ts, wired to the explorer/context menu in package.json

Supported Languages

How to Use

Option 1 — Command Palette (full project)

1. Open any project folder in VS Code
2. Press Ctrl+Shift+P
3. Type Generate Codebase Map → press Enter
4. Step 1 of 3: A folder picker appears — select one or more top-level folders to explore (multi-select supported)
5. Step 2 of 3: For each selected folder that has subfolders, a second picker appears — choose specific subfolders, root files only, or "Select ALL"
6. Step 3 of 3: For each subfolder picked in Step 2 that has further subfolders, a third picker appears — choose specific sub-subfolders, root files only, or "Select ALL"
7. The interactive map opens in a webview panel beside your editor

Option 2 — Right-click any folder (drilldown mode)

1. Right-click any folder in the VS Code Explorer sidebar
2. Select "Generate CodeMap for this Folder"
3. Same 3-step folder picker appears, scoped to the folder you right-clicked
4. Useful for large monorepos — drill into a specific app or module without scanning everything

3-Step Folder Picker — How it works

• If a folder has no subfolders → it's added directly, the next step is skipped for it
• Dismissing any step → the entire folder is included
• Picking "✅ Select ALL" → entire folder included recursively
• Picking "📄 root files" → only files directly in that folder (no subdirectory recursion)

Running in Development

# Clone and install
git clone https://github.com/taruntrk/codemap-visualizer.git
cd codemap-visualizer
npm install

# Build
node esbuild.js

# Open in VS Code and press F5 to launch Extension Development Host
code .

To test on a specific project:

code --new-window \
  --extensionDevelopmentPath="/path/to/codemap-visualizer" \
  "/path/to/your/project"

Project Structure

src/
  extension.ts          ← entry point, registers commands
  scanner/
    scanner.ts          ← walks folder tree, filters files by type
    graphBuilder.ts     ← builds graph from parsed results
  parsers/
    jstsParser.ts       ← JS/TS/JSX/TSX parser (tree-sitter)
    pythonParser.ts     ← Python parser (tree-sitter)
    cssParser.ts        ← CSS/SCSS/LESS parser (@import + classes)
    envParser.ts        ← .env parser (keys only, never values)
    dbParser.ts         ← SQL/Prisma/Python ORM parser
  webview/
    panel.ts            ← VS Code webview panel + full SVG visualization
grammars/
  tree-sitter-typescript.wasm
  tree-sitter-javascript.wasm
  tree-sitter-python.wasm
  web-tree-sitter.wasm

Requirements & Dependencies

For Using the Extension

• VS Code ^1.115.0 — minimum version required
• No manual installs needed — everything is bundled inside the extension

For Development / Building from Source

System Requirements:

• Node.js v18+ — Download
• npm v8+ — comes with Node.js
• Git — for cloning

Install all dependencies:

git clone https://github.com/taruntrk/codemap-visualizer.git
cd codemap-visualizer
npm install

Runtime dependencies (bundled automatically):

Dev dependencies (only needed for building):

Bundled WASM grammars (no install needed, already in /grammars):

Build commands:

# Development build
node esbuild.js

# Production build (minified)
node esbuild.js --production

# Watch mode (auto-rebuild on save)
node esbuild.js --watch

To publish on VS Code Marketplace:

npm install -g @vscode/vsce
vsce login <publisher-name>
vsce publish

Pending Work / TODO

This section tracks what is planned next.

🔮 FUTURE — Planned Features

1. 🌐 Frontend ↔ Backend API Call Matching

What: Automatically match fetch('/api/users') in JS/TS frontend with @app.get('/api/users') in Python/Node backend and draw an edge between them.

How:

• Detect fetch(), axios.get(), axios.post() in JS parser — extract URL
• Detect FastAPI/Flask route decorators @app.get(...), @router.post(...) in Python parser — extract route path
• Match both in graphBuilder.ts — new edge type 'api-call' (pink/magenta)
• Style as dashed pink line in panel.ts

Files to change: jstsParser.ts, pythonParser.ts, graphBuilder.ts, panel.ts

2. 🤖 AI Enrichment Layer

What: Show an AI-generated summary on each node — "what this file does", category (auth/db/api/util etc.)

How:

• Integrate Claude API / VS Code LLM API in the extension
• Send file content (or function list), receive summary
• Fill summary and category fields on each node (currently null)
• Show summary in tooltip; category-based color/grouping option in layout

Files to change: extension.ts (API call), graphBuilder.ts (add fields), panel.ts (tooltip + display)

3. 🔍 Search / Filter Bar

What: A search box in the toolbar — type a filename, only matching nodes highlight/focus, rest dim.

How:

• Add <input id="searchBox" placeholder="Search file..."> in getToolbar()
• On input event, filter nodes array by fileName
• Matching nodes bright, non-matching dim (same CSS classes used in isolation)
• Escape → clear search, restore full view

Files to change: panel.ts only

4. 📦 Performance — Large Projects (1000+ files)

What: Very large projects scan slowly and SVG becomes laggy.

Improvements planned:

• Better skip of node_modules, .git, dist, build, __pycache__ (configurable ignore list)
• SVG virtualization — only render nodes in the visible viewport
• Compute graph layout in a Web Worker so the UI thread doesn't block

5. ⚙️ Settings / Configuration

What: Let users control via VS Code settings:

• Which file extensions to scan
• Which folders to ignore (custom .codemapignore file support)
• Max file count limit
• Default zoom level
• Auto-collapse on/off toggle

Files to change: package.json (contributes.configuration), extension.ts (read settings), scanner.ts (apply filters)

6. 🗺️ Minimap

What: A small overview minimap in the corner of the canvas — shows the full graph scaled down with a viewport rectangle. Click/drag on minimap → jump to that area.

How: Second smaller SVG element, scaled-down render of same graph data, viewport rect overlay.

Files to change: panel.ts only

7. 📸 Export Graph as Image / JSON

What:

• PNG/SVG export — toolbar button → save current graph SVG to file
• JSON export — download raw graph JSON (nodes[] + edges[]) for external tools

How:

• SVG serialization → Blob → download link
• vscode.postMessage → extension writes file

Files to change: panel.ts, extension.ts

Known Issues

• Very large projects (1000+ files) may take a few seconds to scan
• Frappe / Django projects with many apps — open a specific app subfolder for faster and more focused results
• Frappe Document base class not yet detected as ORM (coming soon)

Release Notes

0.0.2

• Unused Files section — collapsed pill bar by default at bottom of graph, double-click to expand; unused nodes no longer rendered in folder boxes
• CSS / Styles, Environment, Database sections — now collapsed by default as pill bars; double-click to expand/collapse
• Draggable sections — CSS, ENV, DB, and Unused Files sections can be dragged anywhere on the canvas
• No overlap between sections — pill width is now calculated from label text length so sections never overlap each other
• Sections on separate rows — CSS/ENV/DB on first row, Unused Files on its own row below
• fitView fix — initial zoom/pan now fits only connected code nodes; large unused file counts no longer cause extreme zoom-out with graph in top-left corner
• Double-click expand fix — pointer-events: all on section rects ensures double-click works reliably on transparent backgrounds

0.0.1

• Initial release
• JS/TS/Python scanning with tree-sitter (WASM, no native bindings)
• Interactive SVG visualization with folder boxes and curved bezier edges
• Folder collapse/expand with edge rerouting to collapsed box center
• Folder drag moves all contained nodes + updates all connected edges live
• CSS, ENV, Database file support with dedicated sections
• Content-based DB file detection — Pydantic BaseModel correctly excluded
• 20+ DB client detections for usage badge (mongoose, prisma, sqlalchemy, etc.)
• Isolate on click for nodes, edges, and folders
• Ctrl+Click opens file in VS Code beside current editor
• Entry point gold border, unused files collected in dedicated section
• Tooltip on hover for all element types
• Reset View button
• Drilldown folder mode — right-click any folder in Explorer → "Generate CodeMap for this Folder" → scoped 3-step picker for that folder only
• 3-step folder picker — Step 1: pick top-level folders; Step 2: pick specific subfolders, root files only, or select all recursively; Step 3: pick specific sub-subfolders, root files only, or select all recursively
