Native Windows Debugging (dbgeng)

Debug native Windows code - C and C++ programs, services, and even the Windows kernel - straight from Visual Studio Code, using the same engine that powers WinDbg.

You set breakpoints, step through code, and inspect variables with the familiar VS Code debugging UI, while the real work is done by the Windows debug engine (dbgeng) underneath - no fragile text scraping of WinDbg output.

Documentation - Getting started - Configuration reference

Remote process	Kernel driver	Local program

What you can do

• Debug a local program - launch an .exe under the debugger, break at entry, step, and inspect locals.
• Debug a running process - attach to a program that is already running, by its process ID.
• Debug a remote process - debug a process on another machine over the network with a dbgsrv process server.
• Debug a Windows driver - attach to a kernel-debug-enabled target (a VM or second machine) for kernel-mode debugging.
• Open a crash dump - post-mortem debugging of a .dmp file.

Before you start

You need a 64-bit Windows machine with:

• Visual Studio Code and this extension. The debug adapter is bundled inside it, so there is nothing else to build, download, or point at.
• Debugging Tools for Windows, which provides dbgeng.dll (usually C:\Program Files (x86)\Windows Kits\10\Debuggers\x64\dbgeng.dll). Install it through the Windows SDK or WDK installer (tick Debugging Tools for Windows). The adapter finds it automatically; set dbgengPath only to pin a specific copy.
• PDB symbols for the code you want to step through.

Quick check that the engine is present: Test-Path "C:\Program Files (x86)\Windows Kits\10\Debuggers\x64\dbgeng.dll"

Your first debugging session

1. Open your C++ workspace and create .vscode/launch.json with a dbgeng configuration:

   {
     "version": "0.2.0",
     "configurations": [
       {
         "name": "Debug my program",
         "type": "dbgeng",
         "request": "launch",
         "program": "${workspaceFolder}/build/Debug/myapp.exe",
         "stopAtEntry": true
       }
     ]
   }


2. Click the editor gutter to set a breakpoint.

3. Press F5. With stopAtEntry: true the debugger pauses at the program's entry point; otherwise it runs until it hits your breakpoint.

4. Use the debug toolbar to continue (F5), step over (F10), step into (F11), and step out (Shift+F11). Inspect locals and the call stack in the side panels, use the Watch pane, and evaluate expressions in the Debug Console.

That is a full local debugging loop. For the guided, ten-minute version see Getting started.

Common configurations

Each block below is one configuration inside the configurations array of .vscode/launch.json. Full detail in the launch and attach reference.

Launch a program

{
  "name": "Debug myapp",
  "type": "dbgeng",
  "request": "launch",
  "program": "${workspaceFolder}/build/Debug/myapp.exe",
  "args": "--config dev input.txt",
  "stopAtEntry": true
}

Launch with CMake Tools - with the CMake Tools extension installed you can omit program; the adapter uses the active launch target (and builds it, prompting you to pick one if needed):

{
  "name": "Debug (CMake target)",
  "type": "dbgeng",
  "request": "launch"
}

Attach to a running process - ${command:dap-dbgeng.pickProcess} opens a process picker at debug time:

{
  "name": "Attach to a process",
  "type": "dbgeng",
  "request": "attach",
  "processId": "${command:dap-dbgeng.pickProcess}"
}

Debug a remote process - run dbgsrv -t tcp:port=5005 on the target, then:

{
  "name": "Attach on TARGETPC",
  "type": "dbgeng",
  "request": "attach",
  "processId": 4321,
  "connectionString": "tcp:port=5005,server=TARGETPC"
}

Debug a Windows driver (kernel) - the target must be set up for kernel debugging (bcdedit /debug on):

{
  "name": "Kernel debug",
  "type": "dbgeng",
  "request": "attach",
  "kernel": true,
  "connectionString": "net:port=50005,key=1.2.3.4"
}

Open a crash dump:

{
  "name": "Open dump",
  "type": "dbgeng",
  "request": "attach",
  "dumpFile": "${workspaceFolder}/crashes/app.dmp"
}

Configuration attributes

The options you will reach for most (see the reference for the full set and defaults):

Extension setting:

• dap-dbgeng.adapterPath - absolute path to a dap-dbgeng.exe to use instead of the bundled adapter. Leave empty to use the bundled one.

What is supported

Line and conditional breakpoints; step over / into / out, including instruction-level stepping in the Disassembly view; call stack with on-demand frame loading; variables, scopes, and registers, plus set-variable; expression evaluation in the Watch pane and Debug Console; and the Disassembly view. See Supported features for the full, honest list of what is and is not supported.

Learn more

• Documentation and guides: svnscha.github.io/dap-dbgeng
• Troubleshooting: svnscha.github.io/dap-dbgeng/troubleshooting
• Source and issues: github.com/svnscha/dap-dbgeng
• Release notes: CHANGELOG.md
