APICompass

Automated API Route Visualizer for VS Code

APICompass is a Visual Studio Code extension that scans your backend codebase and gives you an organized, clickable tree of every REST API endpoint - right inside the editor sidebar. It supports Express.js, NestJS, Flask, Django, FastAPI, and Go (Gin, Echo, Chi, Fiber, net/http) out of the box, and updates automatically as you edit your code.

The Problem

In any non-trivial backend project, API routes end up spread across dozens of files:

routes/user.routes.js
routes/auth.routes.js
controllers/api/v1/orders.js
app/blueprints/auth.py
project/urls.py

When someone asks "Where is the handler for GET /api/v1/users/profile?", the answer usually involves Ctrl+F, guessing file names, or asking a teammate. This wastes time, especially during onboarding, code reviews, and refactoring.

The Solution

APICompass scans the workspace using static analysis, extracts every route definition it can find, and presents them in a structured sidebar panel. One click takes you straight to the source file and line where the route is defined.

Features

Supported Frameworks & Patterns

Express.js (JavaScript / TypeScript)

app.get('/users', handler);
app.post('/users', handler);
router.put('/users/:id', handler);
app.delete('/users/:id', handler);
app.route('/items').get(listItems).post(createItem);
app.use('/api', router); // same-file mount prefix auto-resolved

// Cross-file: prefix applied to routes in imported router files
const usersRouter = require('./routes/users');
app.use('/api/users', usersRouter); // routes in users.js get /api/users prefix

NestJS (TypeScript / JavaScript)

@Controller('users')
export class UsersController {
  @Get()           // GET /users
  findAll() {}

  @Get(':id')      // GET /users/:id
  findOne() {}

  @Post()          // POST /users
  create() {}

  @Put(':id')      // PUT /users/:id
  @Delete(':id')   // DELETE /users/:id
  @Patch(':id')    // PATCH /users/:id
}

Flask (Python)

@app.route('/users')
def get_users(): ...

@app.route('/users', methods=['POST'])
def create_user(): ...

bp = Blueprint('api', __name__, url_prefix='/api')
@bp.route('/items')          # resolves to /api/items
def get_items(): ...

# Cross-file: prefix applied to routes in imported blueprint files
from .users import users_bp
app.register_blueprint(users_bp, url_prefix='/api/users')

Django (Python)

urlpatterns = [
    path('users/', views.user_list),
    path('users/<int:pk>/', views.user_detail),
    re_path(r'^articles/(?P<year>[0-9]{4})/$', views.year_archive),
]

FastAPI (Python)

@app.get("/users")
async def get_users(): ...

@router.post("/items")
async def create_item(): ...

@app.get("/users/{user_id}")
async def get_user(user_id: int): ...

@app.api_route("/custom", methods=["GET", "POST"])
async def custom(): ...

# Cross-file: prefix applied to routes in imported router files
from .routers.users import router as users_router
app.include_router(users_router, prefix="/api/users")

Go (Gin, Echo, Chi, Fiber, net/http)

// Gin, Echo, Fiber
r.GET("/users", handler)
r.POST("/users", handler)

// Chi (PascalCase methods)
r.Get("/items", handler)
r.Post("/items", handler)

// net/http
http.HandleFunc("/health", handler)

Quick Start

Prerequisites

• Visual Studio Code 1.85 or later
• Node.js 16 or later (for building from source)

Install from Source

# Clone the repository
git clone <repo-url> apicompass
cd apicompass

# Install dependencies
npm install

# Build the extension
npm run compile

# Run tests
npm test

Launch in Development Mode

1. Open the apicompass folder in VS Code.
2. Press F5 (or choose Run > Start Debugging).
3. A new Extension Development Host window opens.
4. Open any project that contains Express, NestJS, Flask, Django, FastAPI, or Go routes.
5. Click the APICompass icon in the activity bar (left sidebar).
6. Routes are listed automatically. Click any route to jump to its definition.

Package as .vsix

npm run package        # produces apicompass-0.1.0.vsix

Install the .vsix file via Extensions > ··· > Install from VSIX… in VS Code.

Configuration

Open Settings (Ctrl+,) and search for apicompass.

Commands

Architecture

src/
├── models/route.ts             Core data types (Route, HttpMethod, ParseResult)
├── parsers/
│   ├── parser.ts               Abstract RouteParser (Strategy pattern)
│   ├── parserFactory.ts        Creates parsers by framework (Factory pattern)
│   ├── expressParser.ts        Express.js route extraction
│   ├── flaskParser.ts          Flask route extraction
│   ├── djangoParser.ts         Django URL pattern extraction
│   ├── fastApiParser.ts        FastAPI route extraction
│   ├── goParser.ts             Go (Gin, Echo, Chi, Fiber, net/http) route extraction
│   └── nestJsParser.ts         NestJS controller route extraction
├── services/
│   ├── routeManager.ts         Orchestrates scanning, caching, and events
│   ├── routeExporter.ts        Export to JSON and OpenAPI 3.0
│   └── fileScanner.ts          Workspace file discovery
├── views/
│   ├── treeDataProvider.ts     VS Code TreeDataProvider (grouped views)
│   └── treeItem.ts             Individual tree items with icons
├── utils/
│   ├── logger.ts               OutputChannel-based logger (Singleton)
│   ├── config.ts               Reads VS Code settings (Singleton)
│   └── deduplicateRoutes.ts    Route deduplication utility
└── extension.ts                Entry point - wires everything together

Design Patterns Used

Testing

# Run all tests
npm test

# Run with coverage report
npm run test:coverage

Current coverage:

Test fixtures for Express, NestJS, Flask, Django, FastAPI, and Go are in test/fixtures/.

Project Context

This extension was built as the Semester 4 Project for the BITS Pilani WILP Full Stack Engineering programme. It is designed to demonstrate concepts from across the curriculum:

Roadmap

• [x] Cross-file mount prefix resolution (Express, Flask, FastAPI) - done
• [x] Same-file app.use() / url_prefix / include_router prefix resolution - done
• [x] NestJS decorator support (@Get(), @Post(), @Controller()) - done
• [x] FastAPI support (@app.get(), @app.post()) - done
• [x] Go support (Gin, Echo, Chi, Fiber, net/http) - done
• [x] Route deduplication - done
• [x] Keyboard shortcuts and context menus - done
• [x] Export routes to JSON / OpenAPI stub - done
• [x] CI/CD pipeline (GitHub Actions) - done
• [x] Production packaging (.vscodeignore, CHANGELOG, LICENSE) - done
• [ ] Publish to VS Code Marketplace

Contributing

# Install dependencies
npm install

# Lint source and test files
npm run lint

# Check formatting
npm run format:check

# Auto-fix formatting
npm run format

# Run tests
npm test

# Run tests with coverage
npm run test:coverage

# Build for production
npm run compile

# Package as .vsix
npm run package

License

This project is licensed under the MIT License.
