MCP Kali Workspace

AI-Powered Penetration Testing with GitHub Copilot and Kali Linux

Integrate Kali Linux security tools directly into VS Code through Model Context Protocol (MCP), enabling GitHub Copilot to execute security commands, automate reconnaissance, and assist with CTF challenges in real-time.

Features

• 🚀 One-Command Setup - Configure workspace for Kali MCP integration with a single command
• 🤖 AI-Assisted Security Testing - GitHub Copilot can execute Kali tools (nmap, gobuster, nikto, etc.)
• 🎯 Workspace-Specific - Each project gets its own isolated MCP configuration
• 🔧 Automatic Configuration - Creates Python venv, installs dependencies, configures MCP server
• 🔒 Secure - Connects to remote Kali VM via configurable endpoint
• 💾 SMB/Network Share Compatible - Venv stored in local cache to avoid symlink issues
• 🪟 Cross-Platform - Works on Windows, Linux, and macOS
• 🧹 Easy Cleanup - Remove workspace configuration with one command

Companion Extensions

Enhance your security testing with AnyRAG Pilot - Index your security research, CTF write-ups, payloads, and vulnerability reports with AI-powered semantic search. Search them directly from Copilot Chat while using MCP Kali Workspace for powerful penetration testing insights at your fingertips.

Requirements

On Your Kali VM

• Kali Linux with kali-server-mcp installed
• kali-server-mcp running on port 5000:

  kali-server-mcp --ip 0.0.0.0 --port 5000


On Your Development Machine

• VS Code 1.102 or later
• Python 3.8+
• GitHub Copilot subscription
• Network access to Kali VM

Quick Start

1. Install Extension

Install from VS Code Marketplace or via .vsix:

code --install-extension mcp-kali-workspace-0.1.0.vsix

2. Open a Workspace

Open any folder/workspace where you want Kali integration.

3. Run Setup Command

• Press Ctrl+Shift+P (or Cmd+Shift+P on Mac)
• Type: MCP Kali: Setup Workspace
• Enter your Kali VM IP address (e.g., 192.168.110.23)

4. Reload Window

When prompted, reload VS Code to activate the MCP server.

5. Start Using!

Open GitHub Copilot Chat (Ctrl+Alt+I) and ask:

• "Run an nmap scan on 192.168.1.1"
• "Use gobuster to enumerate directories on http://target.com"
• "Help me solve this CTF web challenge"

What Gets Created

The extension creates the following structure:

In Your Workspace

your-workspace/
├── .mcp-kali/
│   ├── mcp_server.py         # MCP protocol bridge
│   ├── requirements.txt       # Python dependencies
│   └── mcp-wrapper.sh         # Execution wrapper (or .cmd on Windows)
└── .vscode/
    └── mcp.json               # MCP server configuration

In Your Home Directory

~/.cache/mcp-kali-workspace/   # (Linux/macOS)
└── venv/                       # Shared Python virtual environment
    ├── bin/
    ├── include/
    ├── lib/
    └── pyvenv.cfg

%USERPROFILE%\.cache\mcp-kali-workspace\  # (Windows)
└── venv\                       # Shared Python virtual environment
    ├── Scripts\
    ├── Lib\
    └── pyvenv.cfg

Note: The Python virtual environment is stored in your home directory's cache to avoid symlink issues with SMB shares and network drives. This venv is shared across all workspaces using the extension.

How It Works

1. Extension Installation - Creates shared Python venv in ~/.cache/mcp-kali-workspace/ and installs dependencies
2. Workspace Setup - Downloads latest mcp_server.py from GitLab and creates workspace configuration
3. Local MCP Server - Runs mcp_server.py from workspace's .mcp-kali/ directory using shared venv
4. Remote Kali API - Connects to kali-server-mcp on your Kali VM (port 5000)
5. GitHub Copilot - Uses MCP protocol to invoke Kali security tools
6. Tool Execution - Commands execute on Kali VM, results return to VS Code

Usage Examples

Network Reconnaissance

@workspace Run nmap -sV -T4 192.168.1.0/24

Web Application Testing

Help me enumerate directories on http://target.com using gobuster

CTF Assistance

I found a login form at http://ctf.com/login - help me test for SQL injection

Custom Security Tasks

Run nikto against https://example.com and analyze the results

Troubleshooting

MCP Server Not Connecting

Check Kali Server:

# On Kali VM
curl http://localhost:5000/health

Should return: {"status":"healthy"}

Check VS Code Output:

• View → Output
• Select "MCP" from dropdown
• Look for connection errors

Python Environment Issues

Remove workspace configuration and re-run setup:

• Press Ctrl+Shift+P
• Run: MCP Kali: Remove Workspace Configuration
• Run: MCP Kali: Setup Workspace

Or manually delete .mcp-kali/:

rm -rf .mcp-kali

Clean Cache Directory

The cache directory is automatically cleaned when you uninstall the extension. If you want to manually recreate the shared venv:

# Linux/macOS
rm -rf ~/.cache/mcp-kali-workspace

# Windows
rmdir /s %USERPROFILE%\.cache\mcp-kali-workspace

Then reload VS Code (the extension will recreate the venv on activation).

Network Connectivity

Verify you can reach Kali from your dev machine:

curl http://<kali-ip>:5000/health

Configuration

Custom Kali Port

Edit .vscode/mcp.json:

{
  "servers": {
    "kaliMcp": {
      "type": "stdio",
      "command": "/path/to/.mcp-kali/mcp-wrapper.sh",
      "args": [
        "--server",
        "http://<kali-ip>:<custom-port>"
      ]
    }
  }
}

Multiple Kali Servers

You can configure multiple Kali instances by editing mcp.json manually.

Privacy & Security

• Local Execution - MCP server runs locally in your workspace
• Network Only - Only connects to Kali VM you specify
• No Telemetry - Extension doesn't collect or send usage data
• Workspace Isolation - Each workspace has independent configuration

Contributing

Contributions welcome! Please check the repository for contribution guidelines.

License

MIT License - See LICENSE file for details

Resources

• Model Context Protocol
• Kali MCP Server
• GitHub Copilot

Disclaimer

This tool is for authorized security testing only. Users are responsible for ensuring they have permission to test target systems. Unauthorized access is illegal.

Made with ❤️ for security professionals, CTF players, and bug bounty hunters
