DB Cruiser

DB Cruiser is a MySQL database explorer and SQL console for Visual Studio Code. It adds a database view to the activity bar so you can save connections, browse schema objects, inspect table details, and run SQL without leaving your editor.

Features

• Save and manage MySQL connections from the DB Cruiser activity bar view.
• Browse schemas, tables, views, columns, keys, indexes, foreign keys, and triggers.
• Open table data views directly from the tree.
• Test saved connections before using them.
• Open a SQL console bound to a selected connection or schema.
• Choose the active schema and row limit from the console toolbar.
• Run selected SQL or the whole editor with Cmd+Enter on macOS or Ctrl+Enter elsewhere.
• View query results and object details in a VS Code webview panel.

Getting Started

1. Open the DB Cruiser activity bar view.
2. Select Add MySQL Connection.
3. Enter the connection name, host, port, username, password, and optional default schema.
4. Expand the saved connection to browse available schemas and database objects.
5. Open SQL Console from a connection or schema to start running queries.

SQL Console

The SQL console opens as a DB Cruiser panel with schema and row limit controls, a SQL editor, run and clear actions, and a results area. It is not backed by a .sql file, so closing the console does not prompt you to save a temporary query document.

Commands

DB Cruiser contributes these commands to VS Code:

• DB Cruiser: Add MySQL Connection
• DB Cruiser: Refresh
• DB Cruiser: Remove Connection
• DB Cruiser: Test Connection
• DB Cruiser: Open SQL Console
• DB Cruiser: Run Query
• DB Cruiser: Select Console Schema
• DB Cruiser: Inspect Object
• DB Cruiser: Open Data View

Settings

• dbCruiser.mysql.maxRows: Maximum rows displayed for ad hoc MySQL query results. Defaults to 500.

Security

DB Cruiser stores MySQL passwords in VS Code SecretStorage. Non-secret connection metadata is stored in VS Code's extension storage.

Requirements

DB Cruiser currently supports MySQL-compatible databases. You need network access from VS Code to the target database server and database credentials with permission to inspect metadata and run the queries you choose.

Feedback

If something does not work as expected, open an issue with the database version, the action you were taking, and any error message shown by VS Code.
