AlibreScript

AlibreScript

stephensmitchell

|
4 installs
| (0) | Free
AlibreScript API support with type hints, autocomplete, examples, and interactive notebooks for Alibre Design
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

AlibreScript for VS Code

Note: This extension is in early development. Features and functionality are actively being developed.

Complete AlibreScript development environment with automatic autocomplete, type hints, 45+ examples, and interactive notebooks.

Quick Start - Get Autocomplete in 3 Seconds

  1. Create a new Python file
  2. Add one line: from AlibreScript import *
  3. Start coding - full autocomplete for all 47 AlibreScript classes!
# Auto-import all AlibreScript classes (for VS Code autocomplete only)
from AlibreScript import *

# Now get full autocomplete!
MyPart = Part('My Part')  # ← Type 'Part(' and see parameter hints
sketch = MyPart.          # ← Type 'MyPart.' and see all methods

That's it! One line gives you professional IDE support for AlibreScript.


Features

IntelliSense & Type Hints

  • Full type hints for all AlibreScript API methods
  • Parameter documentation on hover
  • Autocomplete for classes, methods, and properties
  • Type checking with Pylance/Pyright

Built-in Examples

  • 40+ ready-to-use example scripts
  • From basic parts to advanced assemblies
  • User interface examples
  • Import/export demonstrations

Interactive Notebooks

  • Jupyter notebook templates for learning
  • Step-by-step tutorials
  • Experiment with API calls interactively

Code Snippets

  • Quick snippets for common operations
  • Part creation, sketches, features
  • User input dialogs
  • Assembly constraints

Commands

  • AlibreScript: New Script from Template - Create scripts from templates
  • AlibreScript: Open Example - Browse and open examples
  • AlibreScript: New Interactive Notebook - Start a new notebook
  • AlibreScript: View API Documentation - Open official docs

Getting Started

Prerequisites

  • Visual Studio Code 1.75 or higher (or VS Codium)
  • Python extension for VS Code (required)
  • Pylance extension (required)
  • Python 3.6 or higher installed
  • Python Debugger extension (required)
  • Jupyter extension (optional, for notebooks)

Note: The extension is designed for Python 3 development. However, AlibreScript runs inside Alibre Design using IronPython 2.7.10. The extension provides modern Python 3 type hints and IntelliSense for development, which enhances the coding experience even though the actual execution environment uses IronPython 2.7.10.

Quick Start

  1. Create a new script:

    • Press Ctrl+Shift+P
    • Type "AlibreScript: New Script from Template"
    • Choose a template
  2. Use code snippets:

    • Type alibre- and see available snippets
    • Example: alibre-part → creates a new part
  3. Get autocomplete:

    MyPart = Part('My Part')
    MyPart.  # <- Autocomplete shows all methods with docs!

  4. Open examples:

    • Press Ctrl+Shift+P
    • Type "AlibreScript: Open Example"
    • Browse 40+ examples

Examples Included

  • Basic Operations

    • Creating parts and sketches
    • Extrusions and cuts
    • Reference geometry
  • Advanced Features

    • Lofts and sweeps
    • Assemblies and constraints
    • Parameters and configurations
  • User Interface

    • Input dialogs
    • Option windows
    • Custom forms
  • Data Integration

    • CSV import
    • Spreadsheet reading
    • File export (STL, STEP, IGES)

Snippets Reference

Prefix Description
alibre-part Create a new part
alibre-sketch Add a sketch
alibre-circle Add a circle
alibre-line Add a line
alibre-rectangle Add a rectangle
alibre-extrude-boss Extrude boss feature
alibre-extrude-cut Extrude cut feature
alibre-dialog Options dialog
alibre-save Save part
alibre-template Complete script template

Type Hints in Action

The extension provides full type information:

# Autocomplete shows method signature
MyPart.AddExtrudeBoss(
    Name='Boss',      # str
    Sketch=sketch,    # Sketch
    Depth=10.0,       # float
    Flip=False        # bool
)  # Returns: Any

# Hover over methods to see documentation
sketch.AddCircle(...)  # Shows: "Adds a circle to the sketch"

Interactive Notebooks

Start a new notebook to experiment:

  1. Command: "AlibreScript: New Interactive Notebook"
  2. Choose from:
    • Getting Started
    • Part Creation Tutorial
    • Sketch Tutorial
    • Advanced Features

Notebooks allow you to run code cells individually and see results instantly!

Configuration

Settings

  • alibrescript.enableTypeHints - Enable type hints and autocomplete (default: true)
  • alibrescript.alibrePath - Path to Alibre Design installation

Customizing Stubs

The extension includes pre-built type stubs in the stubs/ directory. These are automatically configured when you open an AlibreScript file.

API Coverage

Complete stubs for:

  • Part operations (extrusions, cuts, lofts, sweeps, etc.)
  • Sketch operations (lines, circles, arcs, splines, etc.)
  • Assembly operations (constraints, components, etc.)
  • Reference geometry (planes, axes, points)
  • Parameters and configurations
  • User interface (dialogs, forms, input)
  • Import/export (STL, STEP, IGES, SAT, etc.)
  • Materials and properties

Troubleshooting

Autocomplete not working?

  1. Make sure Pylance extension is installed
  2. Check that Python language mode is active
  3. Reload window: Ctrl+Shift+P → "Reload Window"

Type hints not showing?

  1. Open settings: Ctrl+,
  2. Search for "Python Analysis"
  3. Set "Type Checking Mode" to "basic" or "standard"

Contributing

Found a bug or have a suggestion? Please report it on our GitHub repository!

Resources

  • Official AlibreScript Examples
  • Alibre Design Website
  • Community Forum

License

MIT License - See LICENSE file for details

Disclaimer

This is a community-developed extension and is not officially affiliated with or endorsed by Alibre, Inc.


Made for the Alibre community
