Srijika Language Support

Additive VS Code integration for code-first Srijika UI components. VS Code's built-in TypeScript/TSX language service remains responsible for standard TypeScript, React JSX, HTML attributes, navigation, and IntelliSense. Srijika only adds the stricter authoring contract used by Studio.

The extension validates documents ending in the resolved uiSuffix (.ui.tsx by default) with @srijika/tsx-compiler when they are opened, changed, or saved. Compiler diagnostics are shown as editor squiggles, and compiler-provided text edits are exposed as Quick Fixes. Inside intrinsic JSX opening tags it also suggests the supported props and event bindings such as onClick={props.onOpen}. The extension does not contain a second set of Srijika syntax rules; completions and diagnostics use the shared compiler catalog. Typing < also offers only the intrinsic HTML elements supported by the current Srijika compiler. Generated projects enable Emmet for TSX and VS Code's normal CSS language suggestions for .css files.

In Next.js App Router projects, the same compiler recognizes exact registered next/link, next/image, and project-local presentation component imports. Open page, layout, and route sources also receive shared server/client boundary diagnostics. Preview metadata is source-only; the extension never imports those runtime modules. See docs/NEXT_FRAMEWORK_ADAPTER.md.

Install in VS Code

Install Srijika Language Support from the Visual Studio Marketplace or search for it in VS Code's Extensions view. The stable extension identifier is srijika.srijika-language-support.

For a local Srijika Studio development build:

1. From the Srijika Studio repository run pnpm --filter srijika-language-support install:local.
2. Reload VS Code.
3. Open the complete Srijika project folder and run its pinned install once. React IntelliSense needs the project's react and @types/react packages; opening only a loose file cannot provide that project context. Generated projects deliberately use VS Code's built-in TypeScript SDK instead of forcing a platform-specific node_modules/typescript SDK path.

If every JSX tag reports that react/jsx-runtime or JSX.IntrinsicElements is missing, first finish Install / Sync, then run Developer: Reload Window. Those messages come from an incomplete/stale React project, not from a Srijika restriction. After reload, normal TSX support and Srijika diagnostics run together.

The generated project recommends srijika.srijika-language-support automatically. Run Srijika: Open Setup and Language Support Guide at any time for this guide.

Current project Structure Graph

Open the Srijika Activity Bar and use the hierarchy icon in the Structure view, or run Srijika: Open Current Project Structure Graph. Unlike the migration graph, this panel does not require a migration session. It scans the currently selected configured project and renders its live source architecture:

App
|-- Features -> Feature -> Slot -> Part
`-- Shared -> UI / Widget / Headless Capability
                    |
        UI -> Connector -> Hook / Store / Logic / API / Types

Click an owner to expand its exact files. Click a file to see incoming and outgoing imports, named exports, capability, package dependencies, unresolved imports, and strict-rule findings, then open the source directly. Blue edges stay inside one owner, green edges consume Shared, dashed amber edges cross owners, and red edges/nodes come only from matching validator evidence. Search, violations-only filtering, dependency visibility, collapse, zoom, refresh, and saved panel state are built in.

The scanner uses the same bounded file/byte limits, symlink rejection, configuration, aliases, and architecture validator as the editor diagnostics. In a monorepo it discovers each bounded package with its own srijika.config.json; Switch project changes the graph without granting one package access to another package's source.

React migration dashboard

Open the Srijika Activity Bar container and expand Migration, or run Srijika: Open React Migration Dashboard. This is a real VS Code webview over the shared migration engine and the persisted target session; it does not keep an alternate plan in extension storage.

1. Choose the existing React folder. It is treated as an immutable source.
2. Keep New target folder to type or browse to a separate target. The suggested sibling path ends in -srijika.
3. Use Current workspace target only when the open workspace is an eligible empty target or already contains the same resumable migration. A normal populated project is rejected; this option never authorizes in-place conversion or overwrite.
4. Run Start / Resume Migration. The dashboard displays the bounded file inventory, canonical Feature / Slot / Part / Shared owner tree, ordered migration slices, applied/verified progress, and exact blockers.
5. Use Refresh status after CLI, MCP, Studio, or another agent advances the same session. Use Run verification for engine-owned project checks and Full session JSON for the complete uncapped machine-readable plan, or Open target to continue in a separate VS Code window.

The readiness card inspects the current extension host for the OpenAI Codex/ChatGPT extension and checks the selected target for a readable Srijika entry in .vscode/mcp.json or .mcp.json. Detected and Configured mean the local pieces exist; the MCP client remains responsible for reporting its authenticated live connection. Copy Codex handoff copies a target- and session-aware instruction that tells Codex to resume through the fixed Srijika MCP review/apply/verify sequence.

VS Code decides where an Activity Bar container is placed, so an extension cannot force itself onto the right edge. To keep Migration on the right, enable View -> Appearance -> Secondary Side Bar, then use the Migration view title menu and Move View -> Secondary Side Bar. The Structure tree can remain on the left while the migration dashboard stays on the right.

Interactive architecture graph

After a migration session exists, choose Open Architecture Graph in the Migration dashboard, use its title-bar hierarchy icon, or run Srijika: Open Migration Architecture Graph. The graph opens in a full editor panel so a real project is not compressed into the sidebar.

The initial view is compact: Application -> Features / Shared / Project -> Feature -> Slot -> Part. Click an owner to expand its source modules. Selecting an owner or module shows its role, source path, canonical target paths, imported modules/packages, named exports, and engine-linked violations. Applied modules come from a bounded read-only inspection of the real converted target, so the UI -> Connector -> Hook/Store/API edges and exports are exact. Pending work is marked as planned source. Named source exports are loaded lazily through the migration engine's bounded, immutable slice context; the webview never reads arbitrary paths or keeps a second architecture plan.

Graph edges have explicit meanings:

• gray: ownership hierarchy;
• blue: import inside one owner;
• green: import from a Shared owner;
• dashed amber: cross-owner source dependency that migration must review; and
• red node border: an actual unresolved import or engine-reported migration, Srijika diagnostic, architecture, target-graph, or verification failure.

A cross-owner edge is not automatically mislabeled as a violation. It becomes red only when engine evidence fails. Search, import-edge visibility, violations-only filtering, collapse, zoom, refresh, and exact source opening are available from the same panel.

Feature architecture and ownership

Srijika validates the feature-slot-part-v1 downward ownership model across the whole project. The canonical source tree is the resolved {featuresRoot}/<feature> (src/features/<feature> by default). A feature owns optional slots/; each slot may own optional parts/. Parent stores and hooks may be consumed anywhere below their owner, while child-private modules cannot move upward or sideways into a parent or sibling.

Ownership is promoted only as far as its real consumers require: one Part keeps it in that Part; two Parts promote it to their Slot; two Slots promote it to their Feature; and two Features promote it to the resolved sharedRoot (src/shared by default).

Home feature
|-- Home.ui.tsx                    required, props-only UI
|-- Home.connector.tsx             required runtime gateway
|-- useHome.ts                     optional public Hook gateway
|-- home.store.ts                  optional; Home + all descendants
|-- home.logic.ts                  optional business rules
|-- home.api.ts                    optional HTTP boundary
|-- home.types.ts                  optional owner contracts
`-- slots/navigation
    |-- Navigation.ui.tsx          required slot UI
    |-- Navigation.connector.tsx   required runtime gateway
    |-- useNavigation.ts           optional public Hook gateway
    |-- navigation.store.ts        Navigation subtree only
    `-- parts/user-menu
        |-- UserMenu.ui.tsx
        |-- UserMenu.connector.tsx required runtime gateway
        |-- useUserMenu.ts         optional public Hook gateway
        |-- userMenu.store.ts      UserMenu subtree only
        `-- userMenu.logic.ts      UserMenu subtree only

Those flat Hook/Store paths are the small-owner mode. Adding another behavior or state concern moves the gateway to hooks/useHome.ts or stores/home.store.ts and creates only owner-prefixed private files beside it. The extension rewires imports and removes the root gateway atomically; both locations can never coexist.

Cross-feature code has three canonical, non-freehand shapes. The paths below show the default sharedRoot; configured roots and suffixes are resolved before discovery or creation:

src/shared/ui/button
|-- Button.ui.tsx                  required pure props/events UI
`-- button.types.ts                optional; no runtime imports

src/shared/widgets/user-menu
|-- UserMenu.ui.tsx                required pure reusable UI
|-- UserMenu.connector.tsx         required and only runtime UI gateway
`-- useUserMenu.ts                 optional strict runtime chain

src/shared/capabilities/auth
|-- useAuth.ts                     optional public React gateway
|-- auth.store.ts                  optional shared client state
|-- auth.logic.ts                  optional rules
|-- auth.api.ts                    optional transport
`-- auth.types.ts                  optional contracts

A Shared UI Primitive allows only UI and optional Types. A Shared Widget uses the same Connector -> Hook -> Store -> Logic -> API chain as a Feature. A Headless Capability has no UI or Connector and must contain at least one Hook, Store, Logic, or API layer. Shared code can never import a Feature or another owner's private internals.

Allowed access:

When two siblings need a private module, do not cross-import it. Promote it to their nearest common owner. Pure files ending in the resolved uiSuffix (.ui.tsx by default) never import stores, hooks, or Connectors; a matching Connector performs that wiring and supplies typed props. Run Srijika: Check Feature Architecture to validate the complete workspace.

The extension resolves the complete project contract before it discovers, previews, or creates files. srijika.config.json requires exact sourceOfTruth: "tsx" and a normalized configured entry ending in the resolved UI suffix. An omitted architecture object uses defaults; an explicit object must declare profile feature-slot-part-v1. Its twelve optional overrides are the Feature/Shared roots, Slot/Part/Hook/Store directory names, and UI/Connector/Store/Logic/API/Types suffixes. Roots are bounded, project-relative, non-overlapping, and symlink-safe. Directory names and suffixes are case-insensitively distinct; suffixes are basename-only and no one suffix may end with another. Invalid explicit configuration fails closed.

Root tsconfig.json is parsed as JSONC. extends is rejected, references must be absent or empty, and compilerOptions.baseUrl must be omitted. Only exact and slash-delimited terminal /* compilerOptions.paths aliases are portable; their first target must stay inside the project. Vite-only aliases do not become architecture aliases until the same mapping exists in that root TypeScript configuration.

The configured entry remains authoritative and is included in the bounded scan even if it is outside the ownership roots. It is still a behavior-free UI and receives SRIJIKA4119 computed-module, SRIJIKA4120 unresolved-alias, and SRIJIKA4121 missing/outside-root source-import checks. Complete scans reject symlinks or partial results and are capped at 4,096 sources, 32,768 entries, 4,096 directories, depth 32, 4 MiB per source, and 24 MiB total.

For an existing application, the versioned adoption.ownership block can select managed roots and mark complete owners as adopted. VS Code uses the same resolved plan as the CLI: adopted owners receive strict architecture and UI diagnostics, pending owners stay report-only, and the Structure Graph displays governed/pending/blocked/excluded coverage without claiming partial adoption is complete. See docs/BROWNFIELD_ADOPTION.md.

Every UI rejects identifier/property Hooks, browser/runtime globals, local or external state/router/request/query behavior, and callable utilities. Only type-only imports, safe React JSX support, JSX-only presentational bindings, and CSS/image/icon/font/audio/video assets are accepted. Types is passive and must use import type/export type. Logic keeps deterministic business rules but rejects React/query/router/state lifecycle, browser globals, and transport APIs/modules; transport belongs in API.

Fast application runtime

The Structure title bar now provides Run App, Stop App, and Doctor. Run App starts the project's real Vite server on a strict port, so React Fast Refresh and Srijika's Connector preview bridge stay active while UI Sources change. The extension and CLI share project detection and command planning.

Node compatibility mode is the default. Set srijika.runtime to bun only when you want the optional Bun-powered Vite turbo path; if Bun is unavailable or the project is not Vite-based, Srijika reports the reason and safely falls back to Node. Dependency installation still follows the detected lockfile and package manager, so changing the JavaScript runtime never silently changes the resolved dependency graph.

Strict visual creation

Open the Srijika Activity Bar icon and expand the Structure view. Every canonical Feature, Slot, and Part owner has an inline + action. The same flow is also available by right-clicking an exact ownership folder in the normal VS Code Explorer and running Srijika: Add Strict Feature / Shared Owner...:

{featuresRoot} -> New Feature
Feature root  -> Feature capabilities or New Slot
Slot root     -> Slot capabilities or New Part
Part root     -> Part capabilities only
{sharedRoot}  -> New Shared UI Primitive, New Shared Widget, or New Headless Capability
Shared owner  -> Only the capabilities valid for that exact shared owner kind

For an existing Feature, Slot, or Part, the form first shows its complete file checklist. Created files stay visible as checked, disabled Created entries; missing Connector, Hook, Store, Logic, API, and Types entries can be selected individually or with Select all missing files and created as one safely rewired batch. New Slot and New Part remain separate choices in the same form, so completing an owner never hides child creation.

If Hook or Store already exists, Add private Hook / Store behavior accepts a suffix such as Keyboard or Filters. It derives useOwnerKeyboard.ts or ownerFilters.store.ts and switches the capability from flat to expanded mode when necessary. index.ts, custom prefixes, mixed layouts, and deeper hooks//stores/ folders are rejected by the same workspace validator.

For a new Feature, Slot, or Part, enter one normalized PascalCase name and tick only the optional Hook, Store, Logic, API, and Types you need. UI + Connector are always required. The visual form displays every exact path while you type, without rebuilding the form or losing input focus. The extension derives every path, rejects arbitrary folders and alternate names, preflights duplicates, and commits the validated files together without overwrite. When an existing custom Connector needs a new Hook boundary, Srijika preserves its behavior and inserts only the required Hook import and call. The sidebar and Explorer command both use the same scaffold engine as the strict project contract.

Complexity policy

The shared Srijika compiler reports editor diagnostics when a file ending in the resolved uiSuffix (.ui.tsx by default) exceeds any of these project rules:

• 200 meaningful lines in the exported UI function. Its local or resolved owner-local type-only props interface, blank lines, and comments are excluded from this function count.
• 300 meaningful lines in the complete resolved UI Source file.
• 16 top-level component contract members. Data props, events, ReactNode slots, and optional props all count.

Because these diagnostics come from @srijika/tsx-compiler, Studio and the VS Code extension always enforce the same policy.

Command

• Srijika: Check Current UI File (srijika.checkCurrentFile) validates the active document ending in the resolved uiSuffix and writes a summary to the Srijika output channel.
• Srijika: Check Strict Project Architecture (srijika.checkArchitecture) validates Feature and Shared ownership with the same project rule engine.
• Srijika: Open Migration Architecture Graph (srijika.openMigrationArchitecture) opens the session-backed interactive ownership, import/export, Shared dependency, and violation graph.
• Srijika: Open Current Project Structure Graph (srijika.openProjectArchitecture) opens the live configured-project graph without requiring a migration session, including monorepo package selection.
• Srijika: Add Strict Feature / Shared Owner... (srijika.addOwnershipCapability) opens the strict visual scaffold form from the Structure + action or Explorer folder context menu.
• Srijika: Refresh Structure (srijika.refreshStructure) refreshes the Feature -> Slot -> Part and canonical Shared owner hierarchies.
• Srijika: Run App (srijika.runApp) starts the real strict-port Vite app.
• Srijika: Stop App (srijika.stopApp) terminates the managed VS Code task.
• Srijika: Run Doctor (srijika.doctor) audits Node, Bun, package manager, lockfile, and project scripts through the shared developer engine.
• Srijika: Sync Owner Vitest / Playwright Tests (srijika.syncOwnerTests) safely creates or updates the generated Vite or Next.js owner-test harness, while preserving authored fixtures and refusing unknown file collisions.
• Srijika: Show Owner Test Evidence (srijika.showTestEvidence) reads the generated Vitest and Playwright JSON reports and shows every owner as passed, failed, uncovered, or not-run. Missing reports and verification gates never appear green.
• Srijika: Verify All Owner Tests (srijika.verifyOwnerTests) synchronizes the adapter and package contract, installs the resolved test toolchain and Chromium, then runs architecture, typecheck, Vitest, and Playwright gates.

Development

pnpm --filter srijika-language-support typecheck
pnpm --filter srijika-language-support test
pnpm --filter srijika-language-support build
pnpm --filter srijika-language-support install:local

The build bundles the extension and compiler for Node.js while leaving the VS Code runtime API external. Output is written to dist/extension.cjs.
