SPL - Semantic Prompt Language for VS Code

Language support for executable SPL Markdown workflows. Features turn on for .md files whose frontmatter declares extension: semantic-prompt-language. Syntax highlighting for SPL fences and blockquotes is also available in other Markdown files.

Features

• Diagnostics from the interpreter's own parser, updated as you type.

• Completions for keywords, built-ins, tools, modifiers, $env/$args, visible bindings, and @name references in blockquotes.

• Copilot inline context for SPL notebook code cells: native syntax rules and parser-checked examples guide AI ghost-text suggestions toward SPL colon-and-indentation blocks, let declarations and model calls instead of Python. Requires a Copilot version exposing context provider API v1; registration status appears in Output > SPL Language Server. Copilot decides whether to use the supplied context, so AI suggestions can still need correction. This does not replace Copilot, make additional model calls, or change suggestions in Python or Markdown instruction cells.

• Hover, Go to Definition and document symbols that follow SPL's lexical scopes.

• Highlighting for spl fences, colored blockquote instructions, and contrasting @name references only inside blockquotes. Instructions use the theme's string color; references use its variable color (or the default text color for themes without a variable color). Ordinary prose and fenced examples do not receive blockquote/reference highlighting. spl fences are also highlighted in the Markdown preview.

• Snippets: splworkflow for a new document, plus ask, askschema, agent, restrict, try, retry, tools and control flow inside fences.

• Native notebooks for existing workflow Markdown: edit SPL fences and natural-language blockquotes as runnable cells, with rendered commentary, execution counts, formatted results, brief live runtime logs, and errors in cell outputs and the Problems panel.

The language server only reads source: it never runs workflows, calls tools or contacts models. Notebook execution is explicit and requires a trusted workspace. Language server errors appear in Output > SPL Language Server; execution logs appear in Output > SPL Notebook.

Block syntax migration

Breaking change: replace block braces with : followed by a newline and an indented nonempty body. Use spaces (4 recommended); indentation tabs, inline suites, unexpected indentation and dedents that do not match a prior level are syntax errors. Use pass for an otherwise empty body. Blank and comment-only lines are ignored for indentation. Semicolons separate simple statements only. Dictionaries {...} and interpolation {expr} are unchanged; newlines inside (), [] and dictionaries remain insignificant, and explicit \ continuation still works.

Despite the Python-like layout, every block remains a lexical child scope: let declares locally, and assignment updates the nearest existing declaration. Anonymous value blocks begin with a bare colon. See the language reference.

Notebook workflows

1. Open a workflow .md file and run SPL: Open as Notebook, or use Reopen Editor With... > SPL Workflow Notebook. Ordinary Markdown stays in its normal editor by default.
2. Select SPL Runtime as the kernel. Existing spl fences become SPL code cells; top-level blockquotes become executable code cells with the Markdown language. Instruction cells show plain text without the outer > markers; those markers are restored on save. Commentary remains rendered, editable Markdown.
3. Use the cell Run button or VS Code's notebook shortcuts to execute any cell. A final expression, return, or success displays its value; objects and lists are indented. Explicit log(...) messages and final natural-language replies appear beneath the cell. A separate live log output shows cell progress, runtime information, warnings and errors, keeping the last 20 lines and at most 4,000 characters, including a truncation notice when older content is omitted. AI transcripts, reasoning and per-statement traces stay in Output > SPL Notebook. Explicit log(...) messages, final replies, results and error outputs are not subject to this brief-log limit. Full runtime logs remain in the output channel.
4. To add an instruction cell, insert a code cell, switch its language to Markdown, and enter an instruction such as Double @count.. Blank lines and Markdown inside the instruction are supported; the whole cell is saved as a blockquote automatically. Use a normal Markdown cell for non-executable notes. Instructions such as Invoke @factorial with 15 as argument -> @fact15 belong in these Markdown-language code cells, not SPL cells. In an SPL cell, use exact syntax instead: let fact15 = factorial(15). An unexpected '@' at end of statement error can mean an instruction was entered in an SPL cell; switch its language to Markdown.
5. Save normally: the file remains executable Markdown, not .ipynb. Frontmatter, commentary, and unchanged fences are preserved, including CRLF/BOM. Edit document model and preamble settings by reopening the saved file in the text editor.

Each open notebook has an isolated worker process holding its variables, mutable objects, and function closures. Cells run sequentially in the order you request, not document order; reruns use the current state without replaying earlier cells. Undefined dependencies are reported as runtime errors. A failure retains assignments already performed, as in Jupyter. Changing or deleting source does not undo its previous execution; rerun the cell or reset the session. Natural-language cells hand queued runtime actions back immediately instead of waiting for a post-tool model reply. When MCP tools are configured, the turn finishes normally so external calls can complete and their results are retained. The SDK's abort notification for an intentional action handoff is not an execution failure; unexpected aborts, failed handoffs and other backend errors are still reported. Syntax errors are highlighted while editing, and runtime failures point to the responsible cell (including previously defined functions). Edited function definitions must be rerun before their old failure location can be highlighted again.

SPL: Reset Notebook Session (also in the notebook toolbar), closing the notebook, reloading VS Code, or stopping a running cell clears shared state. Stop terminates the worker, including infinite SPL loops; rerun prerequisite cells afterward. Existing outputs may describe the old session and are not saved to the Markdown file. Sessions never automatically run on open.

The worker uses node from PATH; set spl.notebook.nodePath to an absolute Node.js executable if needed. Deterministic cells run offline. Copilot model calls require Node.js 20.19+ or 22.12+, and the same Copilot credentials as the CLI (spl login or supported environment credentials). Relative tool paths resolve beside the notebook file. Workflows can modify files, run commands, and contact external services when explicitly executed; only run trusted workflows. Checkpointed human input, record/replay, and custom MCP configuration remain CLI features.

Install

Requires VS Code 1.82+. To build from a checkout (Node.js 20+), run in vscode/:

npm install
npm run package
code --install-extension spl-lang-vscode-1.0.0.vsix

For development, open this folder and press F5 to start an Extension Development Host.

Develop

npm run build
npm run typecheck
npm test

• src/extension.ts starts the client; src/server.ts is the language server (IPC or --stdio).
• src/copilotContext.ts supplies SPL notebook syntax context to Copilot inline completions.
• src/features.ts uses the parser from ../lang/src, bundled into out/ by build.mjs.
• src/markdownPreview.ts highlights spl fences in the Markdown preview.
• src/notebook.ts registers the native serializer, controller, diagnostics and session lifecycle.
• src/notebookFormat.ts roundtrips Markdown and parses individual executable cells.
• src/notebookKernel.ts manages isolated processes; src/notebookWorker.ts runs the interpreter.
• Tests cover the language server, TextMate scope assertions in test/*.spl, and tokenizing every file in ../lang/examples, plus notebook Markdown roundtrips, shared state, formatted outputs, error locations and cancellation of infinite loops.

When the language changes, update syntaxes/spl.tmLanguage.json together with the grammar. Keep links outside this folder absolute so they work on the Marketplace.
