CMake Project Wizard

Scaffold modular C/C++ CMake subprojects with a CLion-style workflow — multi-target management, clangd IntelliSense, and modern LLVM native debugging via lldb-dap — directly inside Visual Studio Code.

Overview

CMake Project Wizard brings CLion's modular project ergonomics to VS Code. It scaffolds structured C/C++ CMake subprojects, wires up clangd as the single language-server source of truth, generates lldb-dap debug configurations, and keeps your workspace hygienic with an automatic file watcher that cleans up stale CMake and launch entries when folders are deleted.

It is an orchestration layer, not a reimplementation. The heavy lifting (AST analysis, builds, debugging) is delegated to the best-in-class LLVM and Microsoft extensions it bundles.

Features

🧱 CLion-Style Project Scaffolding

• Right-click any folder in the Explorer → New CMake Subproject...

• Interactive wizard prompts for:

  • Subproject identifier (validated against strict C/C++ naming rules)
  • Target type — Executable, Static Library, or Shared Library
  • Language — C++ or C
  • Standard — C++14/17/20/23 or C99/11/17/23 (your configured default is offered first)

• Generates a clean, modular layout:

  <target_name>/
  ├── CMakeLists.txt
  ├── include/
  │   └── <target_name>.hpp (or .h)
  └── src/
      └── main.cpp (or <target_name>.cpp)


• Automatically wires the root CMakeLists.txt with add_subdirectory(<target_name>) and ensures set(CMAKE_EXPORT_COMPILE_COMMANDS ON).

🧠 Clangd IntelliSense (Zero Config)

On workspace load, .vscode/settings.json is configured to make clangd the authoritative engine:

• Disables Microsoft IntelliSense (C_Cpp.intelliSenseEngine: "disabled") to prevent duplicate squigglies and CPU spikes.
• Sets clangd.arguments:
  • --compile-commands-dir=${workspaceFolder}/build
  • --header-insertion=iwyu
  • --completion-style=detailed
  • --background-index
  • --clang-tidy
• Points cmake.buildDirectory at ${workspaceFolder}/build and exports compile commands.

🐞 LLDB-DAP Debugging

• Launch configurations use modern type: "lldb-dap" for native LLVM debugging.
• Binary paths auto-map to ${workspaceFolder}/build/<target>/<target>.
• Each executable target gets a Debug Subproject: <target> entry in .vscode/launch.json.

🎯 Active Target & Build Type (Status Bar)

• CLion-style status bar controls for the active target and build type.
• Build types: Debug, Release, RelWithDebInfo, MinSizeRel.
• Build / Run / Debug commands act on the active target.

🧹 Dynamic Synchronizer & Auto-Cleanup

• A FileSystemWatcher monitors workspace changes.
• When a subproject folder is deleted, it automatically:
  • Strips the matching add_subdirectory(...) from the parent CMakeLists.txt.
  • Removes the obsolete lldb-dap debug target from launch.json.
  • Resets the active target if it was the deleted one.
• Toggle with cmakeProjectWizard.autoCleanupOnDelete.

📦 Git Hygiene Automation

Auto-maintains a sensible .gitignore:

build/
bin/
cmake-build-*/
.idea/
.vscode/*
compile_commands.json
!.vscode/launch.json
!.vscode/settings.json

Bundled Extensions

CMake Project Wizard installs and depends on the following via extensionDependencies:

Requirements

• VS Code ^1.75.0
• CMake >= 3.15 on your PATH
• A working LLVM toolchain (clang, clangd, lldb-dap) for full functionality
• The bundled extensions are installed automatically on first activation

Getting Started

1. Install CMake Project Wizard from the Marketplace (dependencies install automatically).
2. Open an empty folder as your workspace root.
3. Right-click the folder in the Explorer → New CMake Subproject...
4. Follow the wizard (name → type → language → standard).
5. Run CMake Project Wizard: Configure CMake Project from the Command Palette.
6. Use the status bar to pick your active target and build type, then Build, Run, or Debug.

Commands

All commands are available under the CMake Project Wizard category in the Command Palette (Ctrl/Cmd+Shift+P).

Extension Settings

Known Limitations

• Target discovery is lightweight. It parses add_subdirectory() from the root CMakeLists.txt rather than the CMake File API, so targets defined via nested globbing or generator expressions may not appear.
• preLaunchTask assumes a matching task. Debug configs reference CMake: build <target>; ensure a corresponding task exists or remove the line.
• cmake-tools command IDs vary by version. cmake.setBuildType is wrapped in a try/catch — the status bar remains authoritative if the API differs.
• The file watcher is broad (**/*). On large monorepos you may want to narrow its scope.
• Full CLion parity (proprietary refactoring/analysis) is not reimplemented — it is delegated to clangd, cmake-tools, and lldb-dap.

Contributing

Issues and pull requests are welcome on the GitHub repository.

License

Released under the MIT License.

Author

Nikhil Chaurasia Publisher: siliconembedsoft-hq GitHub: SiliconEmbedSoft
