FlowNote

FlowNote is a VS Code extension for viewing AI-generated .code-flow/*.json traces in a debugger-like workflow.

Demo

Step through a trace — Use Flow Controls (Prev / Next, Parent Call / Parent Resume) while the editor highlights the current step.

Copy Prompt for AI — Generate a trace from your entrypoint, then step the resulting flow in the list and editor.

MVP features

• Open a trace file from .code-flow/*.json
• Inspect steps in the Flow Controls view (activity bar) and switch traces from the in-panel selector
• Move with Next / Previous, and jump parent call / resume with Previous Parent Call / Next Parent Resume
• Highlight the current line or range in the editor
• Copy an AI prompt template for generating new JSON trace files
• Optional: scaffold a Todo clean-architecture markdown example via Create Todo Example Files

Trace schema v1

{
  "version": 1,
  "name": "OCR job flow",
  "entry": {
    "file": "src/jobs/run-ocr.ts",
    "line": 12
  },
  "steps": [
    {
      "id": "step-1",
      "file": "src/jobs/run-ocr.ts",
      "line": 12,
      "title": "Run OCR job",
      "summary": "Enter runOcrJob() and prepare the job context.",
      "depth": 0,
      "kind": "enter",
      "next": "step-2"
    },
    {
      "id": "step-2",
      "parentStepId": "step-1",
      "file": "src/jobs/run-ocr.ts",
      "line": 18,
      "title": "Call buildExecutor from runOcrJob",
      "summary": "Show the concrete buildExecutor() call site before stepping into the child function.",
      "depth": 0,
      "kind": "call",
      "next": "step-3",
      "range": {
        "startLine": 18,
        "endLine": 18,
        "startColumn": 5,
        "endColumn": 17
      }
    },
    {
      "id": "step-3",
      "parentStepId": "step-1",
      "file": "src/ocr/executor.ts",
      "line": 44,
      "title": "Build executor",
      "summary": "Enter buildExecutor() and construct the OCR executor with dependencies.",
      "depth": 1,
      "kind": "enter",
      "next": "step-4"
    },
    {
      "id": "step-4",
      "parentStepId": "step-1",
      "file": "src/ocr/executor.ts",
      "line": 44,
      "title": "Return from buildExecutor",
      "summary": "Record that buildExecutor() exits here, even if the parent will handle the returned value later.",
      "depth": 1,
      "kind": "return",
      "next": "step-5"
    },
    {
      "id": "step-5",
      "parentStepId": "step-1",
      "file": "src/jobs/run-ocr.ts",
      "line": 18,
      "title": "Resume runOcrJob at the same call site",
      "summary": "After buildExecutor() returns, the flow comes back to the same buildExecutor() call line in runOcrJob().",
      "depth": 0,
      "kind": "resume",
      "next": "step-6"
    },
    {
      "id": "step-6",
      "parentStepId": "step-1",
      "file": "src/jobs/run-ocr.ts",
      "line": 19,
      "title": "Call execute from runOcrJob",
      "summary": "After returning to the parent function, trace the next child call from the same runOcrJob() flow.",
      "depth": 0,
      "kind": "call"
    }
  ]
}

Recommended writing rules:

• A call / enter / return / resume step should describe the function you are actually in at that moment.
• Do not mix "what this function does" and "what it will call next" in the same step title.
• If you want to show a downstream function call from the current function, add a separate kind: call step right after it.
• For kind: enter, prefer a range that covers the whole function body through its final return line, or the function end for void functions.
• When a step enters a deeper function, keep tracing until that child function returns, then continue with the next meaningful step in the parent function.
• Each kind: call should be paired with a child kind: return step, even when the child returns void.
• After that child return, add a kind: resume step on the same parent call site, and only then move to the next line below.
• The default shape is call -> enter -> return -> resume -> next parent step, and if the next parent step is another child call then it becomes call -> enter -> return -> resume -> call.
• Use kind: call for concrete call sites such as Call AddTodoUseCase.execute or Call todoRepository.save.
• When you want to highlight only a call site like save() or execute(), use range.startColumn and range.endColumn on the same line.
• If you include a code: snippet with explanatory comments, write the comment on the line above the code you are describing, not as a trailing inline comment.

UI note:

• kind is color-coded in the sidebar, detail panel, and code highlight so enter, call, return, and resume are easier to distinguish while stepping.

Commands

• FlowNote: Open Trace
• FlowNote: Next Step
• FlowNote: Previous Step
• FlowNote: Previous Parent Call
• FlowNote: Next Parent Resume
• FlowNote: Copy Prompt for AI
• FlowNote: Create Todo Example Files

With the Flow Controls webview focused, arrow keys move steps: Up/Down for previous/next step, Left/Right for parent call / parent resume.

Workflow

1. Open a source file and place the cursor on the entrypoint.
2. Run FlowNote: Copy Prompt for AI.
3. Ask your preferred AI to generate .code-flow/generated-trace.json.
4. Run FlowNote: Open Trace.
5. Move through the trace in the Flow Controls tab and inspect highlighted code.

Optional: run FlowNote: Create Todo Example Files to scaffold .code-flow/example/ markdown and a sample trace for trying the UI.

Development

pnpm install
pnpm check
pnpm build

Optional: pnpm lint, pnpm format (see package.json scripts).

Press F5 in VS Code to launch the extension development host.
