🗺️ CodeAtlas — AI Context Intelligence for VS Code
Give AI a GPS Map of Your Codebase.
CodeAtlas is the local-first architectural intelligence engine for developers and AI coding assistants (Google Antigravity, Claude Code, Cursor, Windsurf, Devin, and Copilot).
✨ Features at a Glance
- 🌐 Interactive 2D / 3D Architecture Graph Canvas: Explore full-codebase dependencies with real-time WebGL force-directed graphs and Spotlight tracing.
- 🌡️ 7-Mode Architecture Heatmap: Switch dynamically between
Language, Cluster, Git Churn, Instability, Blast Radius Impact, Debt Hotspot, and Size coloring.
- ⚡ CodeLens "Explain with Graph": 1-click CodeLens above classes, functions, and files to spotlight-zoom the visualizer camera directly to relevant subgraph nodes.
- 🔥 Live "Blast Radius" Telemetry: Status Bar (
$(flame) Blast: X files) and QuickPick impact analysis showing direct callers and cascading dependents with 1-click prompt export for AI assistants.
- 🔄 Automated AI Rules & Live Architecture Sync: Keep
.cursorrules, CLAUDE.md, AGENTS.md, and GEMINI.md continuously synchronized with live codebase DAG blueprints between <!-- CODEATLAS:START_ARCHITECTURE_MAP --> tags.
- 🛡️ AI Linter Guard & Auto-Repair: Active editor diagnostics for circular dependencies and DDD layer violations with instant QuickFix refactoring actions.
- 🏢 Multi-Repo & Microservices Global Mesh: Aggregate monorepo packages or decentralized polyrepos into a unified architecture graph with automated REST/HTTP endpoint discovery.
- 🌳 Codebase Architecture & Map Sidebar: Instant AST symbol explorer (Classes, Functions, Interfaces, Cyclomatic Complexity).
- 📦 Token-Budgeted Context Export: Right-click any file to generate secret-redacted, compressed AST signatures (saving up to 92% LLM tokens).
- ⚡ Model Context Protocol (MCP) Integration: Connects with 16 native tools for real-time autonomous agent querying.
- 🔒 100% Local-First & Zero Telemetry: Embedded SQLite (
.atlas/atlas.db) powered by Node 22 native SQLite with automatic secret sanitization.
🚀 Quick Start
1. Install the Extension (.vsix)
CodeAtlas is packaged as a standard VS Code Extension (.vsix) and is fully compatible with VS Code, Google Antigravity, Cursor, Windsurf, and other VS Code-based editors.
- Download or build the
codeatlas-official-2.0.0.vsix file.
- Open your editor (VS Code, Antigravity, Cursor, etc.).
- Go to the Extensions view (
Ctrl+Shift+X on Windows/Linux or Cmd+Shift+X on macOS).
- Click the
... (Views and More Actions) icon at the top right of the Extensions panel.
- Select "Install from VSIX..." from the dropdown menu.
- Locate and select the
codeatlas-official-2.0.0.vsix file to install it.
2. Index Your Workspace
Open any project folder in your IDE, open the Command Palette (Ctrl+Shift+P or Cmd+Shift+P) and run:
CodeAtlas: Index / Refresh Codebase
CodeAtlas will scan your directory, extract AST symbols via Tree-sitter, link module dependencies, and build a local SQLite graph in .atlas/atlas.db.
3. Open the Interactive 3D/2D Graph View
- Click the CodeAtlas icon in the left Activity Bar to open the Sidebar panel.
- Or click the Graph View button at the top-right of any open editor tab.
- Or run
CodeAtlas: Open Interactive Graph View from the Command Palette.
4. Connect to Your AI Assistant (1-Click MCP Setup)
Open your integrated terminal and run:
atlas mcp setup
This automatically configures Google Antigravity, Cursor, Claude Desktop, Windsurf, Roo Code, Trae, Zed, and Continue to query CodeAtlas on demand!
⌨️ Commands & Shortcuts
Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) and type CodeAtlas:
| Command |
Description |
CodeAtlas: Open Interactive Graph View |
Opens the 3D/2D force-directed dependency graph tab |
CodeAtlas: Index / Refresh Codebase |
Re-indexes AST symbols, dependencies, and git churn |
CodeAtlas: Analyze Blast Radius Impact |
Real-time impact analysis of active file and 1-click prompt export for AI |
CodeAtlas: Sync AI Rules & Architecture Map |
Synchronizes live DAG architecture blueprint into .cursorrules / CLAUDE.md |
CodeAtlas: Open Multi-Repo & Microservices Map |
Aggregates monorepos or polyrepos into a global architecture network |
CodeAtlas: Export Architecture Schema (.codeatlas.json) |
Exports service schema for multi-repo sharing and service mesh mapping |
CodeAtlas: Export Context for AI Agent |
Generates a compressed context pack for the active file or task |
CodeAtlas: Generate Git PR Context |
Creates a comprehensive architectural blast-radius summary for Pull Requests |
CodeAtlas: Generate AI Agent Rules |
Generates evidence-backed guidelines for AI agents |
CodeAtlas: Run Cypher Graph Query |
Executes graph queries across codebase dependencies |
CodeAtlas: Toggle Real-time Watcher |
Enables/disables live background indexing on file save (Ctrl+S) |
CodeAtlas: Start MCP Server |
Starts Model Context Protocol stdio server |
CodeAtlas: Run Architecture Audit |
Audits security vulnerabilities, DDD layers, and dead code |
CodeAtlas: Search Codebase Symbols |
Full-text and symbol search with BM25 ranking |
CodeAtlas: Initialize Workspace |
Initializes CodeAtlas .atlas/ database |
CodeAtlas: Scan Workspace |
Fast metadata and tech-stack structure scan |
CodeAtlas: Run Health Diagnostics |
Evaluates overall repository health score (0-100) |
CodeAtlas: Validate AI Rules |
Validates rule syntax and detects conflicting instructions |
CodeAtlas: Clean Cache & Database |
Safely resets and clears local SQLite cache |
- File Explorer: Right-click any file or folder ➔ CodeAtlas: Export Context for AI Agent.
- Editor Tab: Right-click in the active editor ➔ CodeAtlas: Export Context for AI Agent.
- Editor Title Bar: Click the Graph icon to view the dependency radius of the active file.
- CodeLens: Click
⚡ Explain with Graph above any function/class to spotlight it in the visualizer canvas.
- Status Bar: Click
$(flame) Blast: X files in the bottom-right corner to inspect impact radius.
⚙️ Extension Settings
| Setting |
Default |
Description |
codeatlas.autoIndexOnSave |
true |
Automatically update AST symbols incrementally when files are saved. |
codeatlas.defaultGraphDimension |
"3D" |
Default graph layout dimension ("3D" WebGL or "2D" Canvas). |
codeatlas.maxContextTokens |
12000 |
Token budget limit for generated AI context packs. |
🔒 Security & Privacy
CodeAtlas operates strictly offline and on-device:
- All databases and indexes are stored in
.atlas/atlas.db inside your workspace.
- Built-in
SecretScanner automatically redacts API keys, cloud tokens, private keys, and passwords before exporting context or serving MCP queries.
- Zero cloud telemetry, zero remote tracking.
