VS Code Maximo Developer Tools

Deploy Maximo Automation Scripts, inspection forms, reports, screen definitions and Maximo configuration directly from Visual Studio Code. Scripts may be written in JavaScript, Python or TypeScript, and several resources can be deployed together in order with a deployment manifest.

The extension allows developers to describe the automation script through the use of a scriptConfig variable and then deploy the script directly to Maximo from Visual Studio Code. The provided NAVIAM.AUTOSCRIPT.DEPLOY automation script provides support for build pipelines and automated deployment of automation scripts from a Git repository.

VS Code Maximo Developer Tools
Table of Contents
Configuration
Features
Remote Debugging
Requirements

Configuration

Visual Studio Code Settings

After installation the connection details for the target instance of Maximo must be provided. The connection settings are found in the VS Code Settings (⌘ + , or ctrl + ,) under the Maximo heading. The table below provides a list of the available settings.

Maximo Settings

The following are settings available under the Naviam > Maximo group.

Setting	Default	Description
Allow Untrusted Certs	false	When checked, ignores SSL validation rules.
API Key		The Maximo API key that will be used to access Maximo. If provided, the user name and password are ignored if configured.
Configuration Timeout	5	The number of minutes to wait for the configuration to complete.
Context	maximo	The part of the URL that follows the hostname, by default it is `maximo`.
Custom CA		The full chain for the server CA in PEM format.
Debug Port	4711	The debug port for connecting a remote debugger for automation scripts.
Extract DBC Location	Current open folder	Directory where extracted screen DBC files will be stored.
Extract Inspection Forms Location	Current open folder	Directory where extracted inspection files will be stored.
Extract Location	Current open folder	Directory where extracted script files will be stored.
Extract Reports Location	Current open folder	Directory where extracted BIRT reports will be stored.
Extract Screen Location	Current open folder	Directory where extracted screen XML files will be stored.
Host		The Maximo host name without the http/s protocol prefix.
Maxauth Only	false	Both Maxauth and Basic headers are usually sent for login, however on WebLogic if Basic fails the Maxauth header is ignored. When checked, only the Maxauth header is sent.
Port	443	The Maximo port number, 80 for http, 443 for https or a custom port such as 9080.
Proxy Host		The proxy host name.
Proxy Password		The proxy password for proxy authentication.
Proxy Port	3128	The proxy port number.
Proxy User		The proxy username for proxy authentication.
Timeout	30	The time in seconds to wait for Maximo to respond.
Use SSL	true	When checked, SSL will be used, the provided port must be configured for SSL.
User		The user that will be used to connect to Maximo.
Webpack Mode	development	The webpack mode, `development` or `production`, used to build a TypeScript script before it is deployed.

The Authentication Type setting has been removed and replaced with automatic detection of authentication type.

.devtools-config.json

A file named .devtools-config.json can be created in the root directory of the project folder to override the VS Code settings. This file is a JSON formatted file and contains the setting attributes to override, any settings not included in the file will be taken from the VS Code settings.

The password and apiKey attributes will be automatically encrypted on save. If the password or apiKey needs to be updated, the encrypted value can be replaced with the new plain text value, which will again be automatically encrypted on save.

Sample

{
    "name": "Short name to identify the environment",
    "description": "Longer description of the configured environment",
    "selected":"Optional attribute that indicates that the environment is currently selected when multiple configurations are available",
    "host":"The Maximo host name",
    "port":80|443,
    "context":"maximo",
    "useSSL":true|false,
    "username":"The Maximo username",
    "password":"The Maximo user's password",
    "apiKey":"A Maximo API key",
    "allowUntrustedCerts":true|false,
    "configurationTimeout": 5,
    "timeout":30,
    "ca":"A PEM formatted CA",
    "maxauthOnly":true|false,
    "extractLocation":"Path to the script extract directory",
    "extractLocationScreens":"Path to the screens extract directory",
    "extractLocationForms":"Path to the forms extract directory",
    "extractLocationReports":"Path to the reports extract directory",
    "extractLocationDBC":"Path to the DBC extract directory",****
    "proxyHost":"The proxy host",
    "proxyPort": "The proxy port number",
    "proxyUsername": "The proxy authentication user name",
    "proxyPassword": "The proxy authentication password",
    "debugPort": " The debug port for connecting a remote debugger for automation scripts"
}

Since .devtools-config.json may contain sensitive connection information it should never be checked into Git. A .gitignore entry for .devtools-config.json is automatically created the first time the .devtools-config.json is used by the extension to ensure that it is not accidentally included in a commit.

Multiple Configurations

The .devtools-config.json may contain a single configuration or a JSON array of configurations. If an array of environment configurations is provided then the selected environment is displayed in the status bar. Clicking the status bar environment name opens a quick pick list to select the active environment. In the image below the Test environment has been selected as can be seen in the status bar and the leading checkbox for the Test entry in the quick pick.

Select Environment

Note that the name attribute is required when defining multiple environments. Configurations without the name attribute will be excluded from the selection.

Logging Settings

The following are settings available under the Naviam > Maximo > Logging group.

Setting	Default	Description
Append	true	When checked, appends to the current log file.
Follow	true	When checked, if the current log is displayed in the editor the cursor will remain at the end of the file.
Open Editor On Start	true	When checked, opens the log file editor when logging is started.
Output File		The absolute or relative path to the log file. If using a relative path, it will be relative to the current open folder.
Timeout	30	The number of seconds between requests for the log file, this should be less than the connection timeout.

Maximo Configuration

The very first time the extension connects to Maximo, it will add several required automation scripts to Maximo. To deploy these scripts, the extension requires the user be in the Maximo Administrators group and have access to the MXSCRIPT and MXAPIDOMAIN object structures. To perform the configuration, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Deploy Automation Script. You will be prompted for a password and then a dialog will be displayed prompting you to configure Maximo.

Configure Maximo Prompt

Click the Yes button to proceed. The configuration should take less than a minute and a progress indicator will be displayed in the bottom right of the screen.

Configure Maximo Progress

Upon completion a dialog will be displayed confirming the configuration was successful.

Configuration Complete

The extension is now ready to deploy automation scripts. After the initial configuration, any user that is in the Maximo Administrators group or has been granted the Deploy Automation Script permission under the NAVIAM_UTILS object structure as shown below can deploy scripts from Visual Studio Code.

Naviam Utils Deploy Automation Script Permission

For log streaming, any user that is in the Maximo Administrators group or has been granted the Stream Log permission under the LOGGING application as shown below, has access to stream the Maximo log to Visual Studio Code.

Logging Stream Log Permission

Maximo Configuration Details

As part of the configuration, an integration object named NAVIAM_UTILS is created and the automation scripts listed below are also created.

Script	Description
NAVIAM.AUTOSCRIPT.ADMIN	Script for managing Maximo administrative actions.
NAVIAM.AUTOSCRIPT.DBC	Script to extract object configurations as DBC.
NAVIAM.AUTOSCRIPT.DEPLOY	The primary script used for deploying and managing automation scripts.
NAVIAM.AUTOSCRIPT.DEPLOY.HISTORY	Created after the first script is deployed. Contains a JSON with a history of all scripts deployed.
NAVIAM.AUTOSCRIPT.EXTRACT	Script for extracting scripts from Maximo.
NAVIAM.AUTOSCRIPT.FORM	Script for managing inspection forms.
NAVIAM.AUTOSCRIPT.LIBRARY	Script library for applying deployment object defined in JSON deploy files.
NAVIAM.AUTOSCRIPT.LOGGING	Script for streaming the Maximo log.
NAVIAM.AUTOSCRIPT.OBJECTS	Script to extract JSON object configurations.
NAVIAM.AUTOSCRIPT.REPORT	Script for managing BIRT reports.
NAVIAM.AUTOSCRIPT.SCREENS	Script for managing Maximo screen definitions.
NAVIAM.AUTOSCRIPT.STORE	Script for managing the storage of the deploy history.

scriptConfig Variable

Each script must define a variable named scriptConfig that is a JSON object describing how to deploy the script. The extension uses these values to populate the corresponding values of the AUTOSCRIPT and SCRIPTLAUNCHPOINT Maximo Business Objects. At a minimum the autoscript attribute is required, all other attributes are optional. All configuration attributes are available and are defined by their label name without spaces, in camel case. The example below provides the basic structure.

A properties, maxvars, or messages property may be included within the scriptConfig. Each of these is a JavaScript array (enclosed in brackets []), of objects with each property corresponding to the Maximo attribute name for the value. Each value in the array will create or update a Maximo property, maxvars, or message. A special property of "delete":"true" can be specified to delete a property, maxvar, or message in the target system. For a property entry a property of initialPropValue can be provided to set the initial value of the property if it does not already exist in the system.

All value names within the scriptConfig map to the application label, without spaces and in camel case. For example if the label in the application is Before Save the corresponding value name is beforeSave.

On Deploy Properties

There are three options for triggering script actions when a script is deployed. The onDeploy property can be defined with a value specifying the name of a function within in the deployed script that will be called when the script is deployed, the onDeployScript property can be defined with the name of another script that will be invoked when the the current script is deployed or if a script with the same name as the current script with .DEPLOY appended to the name exists, it will be automatically invoked. The deploy script will automatically be delete after execution unless the deleteDeployScript property is set to false.

The following four global variables are provided to the deployment scripts.

Variable	Type	Description
onDeploy	boolean	Variable that can be checked within a script to determine if it is being run at deploy time.
request	com.ibm.tivoli.maximo.oslc.provider.OslcRequest	The OslcRequest object for the process deploying the script.
service	com.ibm.tivoli.maximo.script.ScriptService	The standard service class provided to all automation scripts.
userInfo	psdi.security.UserInfo	The UserInfo object for the current user.
updateProgress	function	Function that takes a string parameter and updates the deployment progress message.

When using a script for deploy actions, that script file may be named the same as the primary script with -deploy or .deploy appended to the file name and with the same extension to have it automatically deployed with the primary script. For example if a script is contained in a file named example.js the deployment script can be saved in a file named example-deploy.js or example.deploy.js and the deployment script will be deployed to Maximo first so it is available to be called by the primary script at deploy time.

JSON Deploy File

As of version 1.13.0 a JSON document can be used to define select objects to deploy along with the script. Providing a JSON file with the same name as the primary script, with a .json file extension will cause the tooling to deploy the objects defined in the JSON document along with the script.

Currently Actions, Cron Tasks, Domains, End Points, Enterprise Services, Escalations, Integration Objects, Loggers, Maximo Objects, Messages, Presentation Changes, Properties, Publish Channels and Queries are available. The JSON schemas for these objects are provided in the project under the .vscode directory and your .vscode/settings.json will be updated to provide intellisense support in configuration json files.

A JSON deploy file can also be deployed on its own by opening it and selecting Deploy to Maximo. Attributes that the target Maximo version does not have are skipped and noted in the log.

Synonym domain fields

Fields backed by a Maximo synonym domain, such as an action type, a cron task accessLevel or a domain domainType, take the localized value of the target Maximo, which is what extraction writes. On an English Maximo that is, for example, "domainType": "TABLE".

To write a file that deploys on a Maximo of any base language, give the internal value between exclamation marks instead. It is resolved to the target's default localized value on deploy:

{
    "domains": [
        {
            "domainId": "MYTABLEDOM",
            "domainType": "!MAXTABLE!"
        }
    ]
}

A value that starts with ! must be an internal value written as !VALUE!. An internal value the synonym domain does not have fails the deployment with a message naming the value and the synonym domain. The editor suggests the English values and accepts any other value.

JSON Pre-deploy File

As of version 1.14.0 there is support for a JSON deploy file that is applied prior to deploying the automation script. To have the JSON deploy file applied prior to deploying the automation script, name the file the same as the primary script with .predeploy.json as the suffix. The extension will automatically find the file and apply it before deploying the automation script.

As of version 1.23.0 support was added for deploy and predeploy file validation.

The pre-deploy file is a legacy format that only declares Maximo objects. Maximo objects now belong in the JSON deploy file under objects, which also supports _retain, see Deploying Maximo Objects. The pre-deploy file and its schema keep working unchanged.

For example if a script is contained in a file named example.js the pre-deploy JSON file will be named example.predeploy.json.

Example Deploy JSON

Below is an example deploy JSON that will create or update two messages and a property and then delete the third message example.exampleMessage3.

{
    "messages": [
        {
            "msgGroup": "example",
            "msgKey": "exampleMessage",
            "value": "An example message"
        },
        {
            "msgGroup": "example",
            "msgKey": "exampleMessage2",
            "value": "An example message 2"
        },
        {
            "_delete": true,
            "msgGroup": "example",
            "msgKey": "exampleMessage3"
        }
    ],
    "properties": [
        {
            "propName": "example.property",
            "description": "Example property",
            "propValue": "Example value"
        }
    ]
}

Retaining Customer Values

A product usually ships the same deploy file for the first installation and for every upgrade. Without further markers, an upgrade overwrites every value the customer changed after installation. The _retain property lists the values that the customer owns once the record exists in Maximo. It is currently supported for actions, cron tasks, domains, end points, enterprise services, escalations, external systems, integration objects, loggers, Maximo objects, messages, properties, publish channels and queries.

{
    "cronTasks": [
        {
            "cronTaskName": "EXAMPLESYNC",
            "className": "com.example.SyncCronTask",
            "_retain": ["cronTaskInstance"],
            "cronTaskInstance": [
                {
                    "instanceName": "EXAMPLESYNC01",
                    "schedule": "1h,*,0,*,*,*,*,*,*,*",
                    "active": false,
                    "_retain": ["schedule", "active"]
                }
            ]
        }
    ]
}

On the first installation the values from the file are applied as defaults. On later deployments:

A property named in _retain, such as schedule, keeps the value currently set in Maximo.
A collection named in _retain, such as cronTaskInstance or a domain's values, also keeps the rows the customer added that the file does not declare.

The JSON schema offers only the properties that can be retained. If a deployment that uses _retain fails, the customer values saved during it are kept in the DOCINFO database table. The next deployment asks whether to restore them or discard them, and cancelling the prompt cancels the deployment before anything is changed.

Presentation Changes

presentations changes part of an existing application or system presentation, such as LIBRARY, instead of deploying the whole screen. Each entry names the app and lists changes, applied in order:

{
    "presentations": [
        {
            "app": "MASTERPM",
            "changes": [
                {
                    "add": {
                        "name": "tab",
                        "id": "example_tab",
                        "label": "Example",
                        "children": [{ "name": "section", "id": "example_section", "label": "Details" }]
                    },
                    "after": { "name": "tab", "id": "main" }
                },
                { "modify": { "name": "tab", "id": "jobplanseq" }, "set": { "label": "Sequence" }, "unset": ["sigoption"] },
                { "move": { "name": "section", "id": "qbe_grid3" }, "into": { "name": "tab", "id": "example_tab" } },
                { "remove": { "name": "pushbutton", "id": "obsolete_btn" } }
            ]
        }
    ]
}

Operation	Control exists	Control missing
`add`	Replaced in place with the new content, the placement is ignored	Inserted at the placement
`modify`	The attributes in `set` are set and the attributes in `unset` removed	Fails
`move`	Moved, with its content, to the placement, which is required	Fails
`remove`	Removed with its content	Reported, nothing is changed

A control is referenced as { "name", "id" }: it is found by id anywhere in the presentation, and a different element name fails the deployment.
An added control is { "name", "id", ...attributes, "children": [...] }. Every element needs an id, and attribute values are strings.
The placement is one of before or after a control, or into a container as its last child. Without one, add appends to the root.
Because an existing control is replaced, deploying the same file again gives the same result. Several files can change the same application without undoing each other's work if each adds its content under a control of its own, such as its own tab: deploying one file again replaces only that control.
A sigoption attribute in an application presentation must name an existing signature option of the application. Signature options are not created here; create them in an earlier deployment, such as an earlier manifest entry.
The labels Maximo keeps in MAXLABELS follow the result, as for a whole screen deploy.
Every change in the file is resolved before anything is written: an unknown control or signature option fails the deployment and nothing in the file is applied. A whole screen deploy of the same application later replaces these changes.

Deploying Maximo Objects

Maximo objects, with their attributes, relationships and indexes, are declared under objects in a JSON deploy file. When the file is deployed, by default Maximo will be placed in Admin Mode if required and a database configuration performed. The top level boolean properties noAdminMode and noDBConfig can be set to not perform a configuration if it requires Admin Mode or skip the database configuration completely. A file deployed as a configuration entry of a deployment manifest leaves the database configuration to a databaseConfiguration entry.

{
    "noAdminMode": true,
    "objects": [
        {
            "object": "EXAMPLE",
            "description": "Example table",
            "_retain": ["description"],
            "attributes": [
                { "attribute": "NOTE", "description": "Note", "title": "Note", "type": "ALN", "length": 50, "_retain": ["length", "title"] }
            ],
            "relationships": [
                { "relationship": "EXAMPLEWO", "child": "WORKORDER", "whereClause": "wonum = :wonum", "_retain": ["whereClause"] }
            ]
        }
    ]
}

An object, attribute or relationship takes its own _retain. The values only set when the object is created, such as persistent or uniqueColumn, cannot be retained, and neither can indexes.

Note: When deploying a Maximo Object with Admin Mode and Database Configuration, the user must have Maximo permissions to place Maximo in Admin Mode and run Database Configuration.

If e-signature is enabled for the Manage Admin Mode or Apply Configuration Changes options, the extension offers to disable it temporarily while the configuration is applied and restores the original settings afterwards.

If a configuration requires Maximo to be in Admin Mode a confirmation dialog will be displayed, requiring confirmation before the configurations are applied. If the configurations are not applied, the script will also not be deployed, however the configurations will be staged and can be manually applied at a later time.

Deploy Maximo Object

Prettier Compatibility

Maximo requires that JavaScript objects have quoted properties, as shown below. If you are using Prettier as your code formatter it may automatically remove these quotes, which will result in errors when deploying. To retain the quotes go to the Visual Studio Code Settings (⌘ + , or ctrl + ,), select Prettier, then find the Quote Props setting and select the preserve option.

JavaScript / Nashorn Example

main();

function main() {
    // entry point for the script.
}

var scriptConfig = {
    autoscript: 'EXAMPLE_SCRIPT',
    description: 'An example script for deployment',
    version: '1.0.4',
    active: true,
    allowInvokingScriptFunctions: true,
    logLevel: 'INFO',
    autoScriptVars: [
        {
            varName: 'examplevar',
            description: 'An example variable',
            varBindingValue: 'Example value'
        }
    ],
    scriptLaunchPoints: [
        {
            launchPointName: 'EXAMPLELP',
            launchPointType: 'OBJECT',
            description: 'An example launch point for Labor',
            objectName: 'LABOR',
            save: true,
            add: true,
            update: true,
            beforeSave: true,
            launchPointVars: [
                {
                    varName: 'examplevar',
                    varBindingValue: 'Example binding'
                }
            ]
        }
    ]
};

Python / Jython

For Python / Jython scripts the same JSON script configuration is used, just triple quote it as a string value.

def main():
    # entry point for the script.
    pass

main()

scriptConfig = """{
    "autoscript": "EXAMPLE_SCRIPT",
    "description": "An example script for deployment",
    "version": "1.0.4",
    "active": true,
    "allowInvokingScriptFunctions": true,
    "logLevel": "INFO",
    "autoScriptVars": [
        {
            "varName": "examplevar",
            "description": "An example variable",
            "varBindingValue": "Example value"
        }
    ],
    "scriptLaunchPoints": [
        {
            "launchPointName": "EXAMPLELP",
            "launchPointType": "OBJECT",
            "description": "An example launch point for Labor",
            "objectName": "LABOR",
            "save": true,
            "add": true,
            "update": true,
            "beforeSave": true,
            "launchPointVars": [
                {
                    "varName": "examplevar",
                    "varBindingValue": "Example binding"
                }
            ]
        }
    ]
}"""

Features

Deploy to Maximo

To deploy a script, screen definition, inspection form, report, JSON deploy file or deployment manifest, open the file in Visual Studio Code, then bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Deploy to Maximo. If this is the first time deploying after starting Visual Studio Code you will be prompted for your Maximo password as this extension does not store passwords. The file is then deployed as seen below.

Deploy Script

Deploy Automation Script

When deploying an automation script, after the script has been deployed you can view the script in Maximo. Each deployment replaces the script launch point configuration with the configuration defined in the scriptConfig JSON. A script written in TypeScript is built before it is deployed, see Deploy TypeScript Script.

Maximo Automation Script

Deploy TypeScript Script

Automation scripts may be written in TypeScript in a webpack project, which compiles them to JavaScript for Maximo. Every TypeScript file that declares a scriptConfig variable is built as its own script, named after its autoscript value. Files without a scriptConfig are helpers, which are included in the scripts that import them.

To deploy a script, open its TypeScript file and select Deploy to Maximo. The extension builds the project and deploys the result. Deploying a helper file shows an error that names the script to deploy instead. The predeploy and deploy JSON files are placed beside the TypeScript file, following the same naming as for JavaScript and Python scripts. The Webpack Mode setting selects whether scripts are built in development or production mode.

Initialize a TypeScript Project

To start a new TypeScript project, open an empty workspace folder, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Initialize Maximo TypeScript Project. You are prompted for the script name, such as naviam.script.name, and a description. The extension then creates a webpack project in the root of the first workspace folder containing:

src/index.ts, a starter script with a scriptConfig block for the name and description entered, which is opened in the editor.
webpack.config.js and webpack-entries.js, which build every TypeScript file declaring a scriptConfig into its own Nashorn compatible script. Production builds are written to dist and development builds to dist-dev.
deploy.manifest.json, a deployment manifest with an entry for src/index.ts, ready for further scripts and configuration to be added.
package.json, tsconfig.json, .babelrc and TypeScript declarations for Nashorn and the Maximo Manage Java API, so the Maximo classes are available with code completion.

Initialization stops without changing anything if any of these files already exist in the folder. Once the files are written, the extension offers to run npm install to fetch the project dependencies. If npm is not found, it offers to install Node.js with Homebrew on macOS or winget on Windows. Scripts can then be deployed with Deploy to Maximo as described above, or built by hand with npm run webpack.

Deploy Screen

Deploy Inspection Form

Deploy Screen

When deploying an inspection form the form is matched based on the inspection form name, not the inspection number since it may differ between the source and target systems. If the form already exists the current form is revised and the form definition completely replaces the previous configuration. The option attribute activateOnDeploy can be specified in the inspection form JSON to indicate that the new revision should be marked as active when the form is deployed.

The sourceVersion attribute indicates the version of the source system. Inspection forms are portable between versions as long as the target system is the same or a later version than the source.

Deploy Report

When deploying a report, the report must be registered in the reports.xml file found the in the same folder with the report design file. The reports.xml follows the same syntax as the Maximo reporting tools.

When a report is deployed its request page is automatically generated.

Deployment Manifest

A deployment manifest lists several resources to deploy in order, for example the configuration, scripts, screens and reports that make up one feature. It is a JSON file with a manifest property that is an array of entries. Selecting Deploy to Maximo on the manifest deploys each entry in the order it is listed.

Name the file something.manifest.json to get completions and validation as you type.

The whole manifest is checked before anything is sent to Maximo. If any entry is wrong, for example a missing file, an unknown kind or the wrong file extension for the kind, nothing is deployed and every problem is reported at once. Once deployment starts it stops at the first entry that fails, so nothing is applied on top of a resource that did not deploy.

Paths may be relative or fully qualified. A relative path is resolved against the folder of the manifest that declares it. DBC scripts cannot be listed in a manifest.

Entry Kinds

Each entry declares what it is with a kind, and is deployed as exactly that. A script entry deploys only the script itself, so its predeploy and deploy JSON files are listed as their own configuration entries.

`kind`	Accepts	What it does
`configuration`	`.json`	Applies a JSON deploy file.
`databaseConfiguration`	no path	Applies any pending database configuration, taking Admin Mode if Maximo requires it and you agree.
`automationScript`	`.ts` `.js` `.py` `.jy`	Deploys the script. A TypeScript script is built first.
`deployScript`	`.ts` `.js` `.py` `.jy`	Installs the script in Maximo, runs it once, then removes it.
`inspectionForm`	`.json`	Deploys an inspection form.
`screen`	`.xml`	Deploys a screen definition.
`report`	`.rptdesign`	Deploys a BIRT report.
`manifest`	`.json`	Deploys another manifest at that point, as if its entries were listed here.

Entries without a kind are deprecated. They still deploy as before, with a script also deploying its predeploy and deploy JSON files, so existing manifests keep working and can be migrated one entry at a time. Deploying such a manifest shows a notification, and the log names each entry to update.

Disabling an Entry

Any entry may set "disabled": true to skip it without removing it from the manifest, which is useful while a resource is being reworked or when only part of a manifest is wanted. A disabled entry is not validated, so the file it names may be missing or incomplete. Disabling a manifest entry skips the nested manifest and everything in it. The notification shown when the deployment finishes says how many entries were skipped.

{ "kind": "automationScript", "path": "scripts/matcher.js", "disabled": true }

Keeping Changes Made in Maximo

Set "createOnly": true on an entry when you do not want a deployment to overwrite an item that was deployed earlier and may have been modified since. The item is deployed when it does not exist in Maximo yet; when it exists, it is left unchanged. automationScript, inspectionForm, screen and report entries accept it. The notification shown when the deployment finishes says how many entries were left unchanged.

{ "kind": "automationScript", "path": "scripts/example.config.js", "createOnly": true }

Example Manifest

{
    "manifest": [
        { "kind": "configuration", "path": "config/objects.json" },
        { "kind": "databaseConfiguration" },
        { "kind": "automationScript", "path": "scripts/matcher.js" },
        { "kind": "deployScript", "path": "scripts/backfill-matcher-data.js" },
        { "kind": "inspectionForm", "path": "inspection_form.json" },
        { "kind": "screen", "path": "screens/wotrack.xml" },
        { "kind": "report", "path": "REPORT_FOLDER/birt_report_name.rptdesign" },
        { "kind": "manifest", "path": "features/matching.manifest.json" }
    ]
}

Extract Automation Scripts

To extract the scripts currently deployed to Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract Automation Scripts. The extension will query Maximo for the available scripts and display a list of scripts to select from. Once the desired scripts have been selected, click the OK button to extract the scripts. Scripts are saved to the directory specified in the Extract Location setting. If the setting has not been configured, the scripts are extracted to the current workspace folder.

Extract Automation Script

Extract Screen Definitions

To extract the screens from Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract Screen Definitions. The extension will query Maximo for the available screens and display a list of screens to select from. Once the desired screens have been selected, click the OK button to extract the screens. Screens are saved to the directory specified in the Extract Screen Location setting. If the setting has not been configured, the screen definitions are extracted to the current workspace folder.

Extract Screen Definition

The screen definition XML is consistently formatted when extracted to assist with comparison. To ensure the formatting remains consisted, when using the standard XML formatter ensure that the Space Before Empty Close Tag is unchecked.

Extracted Metadata

As of version 1.6.0 extracted screens will include a metadata tag that contains the conditional properties configuration. It also includes the security group and condition definitions that support creating the security group if it doesn't exist and creating or updating the conditional expressions. The metadata tag is removed as part of the import process and will error if you attempt to import the exported presentation XML through the front end user interface.

Extract Inspection Forms

To extract inspection forms from Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract Inspection Forms. The extension will query Maximo for the latest inspection forms and display a list of available forms to select from. Once the desired inspection forms have been selected, click the OK button to extract the inspection forms. Inspection forms are saved to the directory specified in the Extract Inspection Forms Location setting. If the setting has not been configured, the inspection forms are extracted to the current workspace folder. The extracted files are named with the inspection form name, with dashes - replacing spaces and with a .json file extension.

The extract includes the source inspection form and revision number. Note that these values are for reference purposes only and a new inspection form and revision number will be generated in the target system.

Extract Screen Definition

Extract Reports

To extract reports from Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract BIRT Reports. The extension will query Maximo for the registered reports and display a list of available reports to select from. Once the desired reports have been selected, click the OK button to extract the reports. Reports are saved to the directory specified in the Extract Reports Location setting. If the setting has not been configured, the reports are extracted to the current workspace folder. The extracted reports are saved to a sub folder named with the REPORTFOLDER value from Maximo. Additionally, the report attributes, parameters and resource references are written to a reports.xml file in the REPORTFOLDER folder. The reports.xml has the same syntax as the standard Maximo tools report.xml files. If the report has resources, those are extracted to a sub folder with the same name as the report, without the .rptdesign extension.****

Extract Report

Extract JSON Deploy Files

To extract JSON deploy files from Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract Maximo JSON. A list of available object types to extract will be displayed. The list includes object types found in the table below.

Type	Description
Actions	Maximo actions
Cron Tasks	Maximo cron tasks, including instances and parameter
Domains	Domains and the domain values
End Points	Maximo integration end points and their property values
Enterprise Services	Enterprise services, with their nested objects and processing rules
Escalations	Maximo escalations
External Systems	External systems, with their channels, services and controls
Integration Objects	Maximo integration object structures
Loggers	Maximo logger definitions
Messages	Maximo messages
Objects	Maximo objects, including attributes, relationships and indexes
Properties	Maximo system properties
Publish Channels	Publish channels, with their integration controls and processing rules
Queries	Maximo queries

Once the type has been selected a list of available objects will be displayed and the list desired objects can be selected. Once the list of objects is selected click the OK button to extract the configurations. If a script file is open, the results are added to the script's .json deploy file, which is created if it does not exist. If a JSON deploy file is open, the results are added to that file. Otherwise, including when the open file is a deployment manifest or an inspection form, the results are copied to the clipboard and can be pasted into a JSON deploy file later.

Extract DBC Files

To extract DBC scripts from Maximo, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Extract Maximo DBC. A list of available object types to extract will be displayed. The list includes object types found in the table below.

Type	Description
Attribute	Maximo attributes from the selected Maximo object.
Automation Script	Automation scripts
End Point	Integration end points
Enterprise Service	Integration enterprise services
External System	Integration external systems
Interaction	Integration interactions
Invocation Channel	Integration invocation channels
Message	Maximo system messages
Object	Maximo Object / Table definition, including indexes and relationships
Object Structure	Data from a selected integration object structure, filter by a provided where clause
Property	Maximo system properties
Publish Channel	Integration publish channels
Records by Object Structure	Data from a selected Maximo object structure, filter by a provided where clause.
Table Data	Data from a selected Maximo object, filter by a provided where clause.
Web Service	Integration web service

Once the type has been selected a list of available objects will be displayed and the list desired objects can be selected. Once the list of objects is selected a prompt to input a file will be displayed. Enter a file name, with files ending in .dbc creating DBC formatted file, while .db2, .ora and .sqs create SQL scripts.

Extract DBC Script

For Records by Object Structure and Table Data there is an additional step, where you must provide a SQL where clause to filter the records extracted from the system.

Note: When extracting configurations, if the destination file exists, the contents will be overwritten with the value extracted from Maximo.

Compare with Maximo

To compare the current script or screen definition with the script or screen on the server, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Compare with Maximo. The extension will query Maximo for the current script or screen that is in the editor based on the scriptConfig variable or <presentation id="" attribute and open a new window, providing the Visual Studio Code diff editor.

Compare Script

Compare Screen

Log Streaming

To stream the Maximo log to a local file click the Maximo Log status bar item to toggle streaming. The rotating status icon indicates that the log is currently streaming.

Stream the Maximo Log

If you are streaming logs from a Maximo Application Suite environment with multiple pods, a list of pod names and IP addresses will be displayed so you can select the pod to stream the log from. The name of the pod will be displayed while the log is streaming.

Select Server

This feature uses API keys to communicate with other pods in the cluster and will create a temporary API key for the user streaming the log if one does not exist. This temporary key is good for 24 hours and is removed when the user stops streaming.

Insert Unique Id

When editing a screen definition XML, ensuring that the id attribute is unique can be annoying, especially when copying and pasting sections of the screen. Maximo generates unique id attribute values based on the current time since epoch in milliseconds and now you can too.

To insert or update the id attribute of a tag to the unique value of the current time in milliseconds since epoch, bring up the Visual Studio Code Command Palette (View > Command Palette... or ⌘ + shift + p or ctrl + shift + p) and select Insert Unique Id for Maximo Presentation Tag or press ctrl + ⌘ + i or ctrl + alt + i).

Update unique Id

Snippets

The Maximo Developer Tools extension provides snippets for all the built in classes including the majority of methods on the mbo, service and userInfo built in objects. While not providing a full language server it should provide a majority of common methods on the implicit variables.

There are also snippets for common functions such as a close function or the scriptConfig variable. If there are any additional snippets you would like added please contact us at support@naviam.io.

Snippets in action

Pressing ctrl+space will bring up help information for each snippet, describing what the snippet does with information about the parameters. Snippet information

Remote Debugging

Remote debugging is available for Manage 9.x where Java 17 is used. The extension lets VS Code attach to automation scripts running inside the Maximo JVM so you can debug Jython and JavaScript/Nashorn script execution from your local workspace.

The Maximo debugger runs as an in-process Debug Adapter Protocol (DAP) server inside the JVM. To connect successfully, the debug port, by default 4711, must be reachable from your machine either through local container port exposure or through OpenShift port-forwarding.

When VS Code attaches, the extension checks whether the matching debugger Jar is already available in the target Maximo environment. If it is missing or out of date, the extension uploads the current version and the NAVIAM.AUTOSCRIPT.DEBUG automation script starts the debug server.

[!WARNING] Remote Debugging is experimental. Do not use it on a production system.

Remote Debug

Before Starting

Before starting a debug session, make sure the following are true:

The target system is Maximo Manage 9.x running on Java 17.
The VS Code settings naviam.maximo.host and naviam.maximo.debugPort point to the target Maximo system and debug port.
The Maximo debug adapter is enabled and reachable on the configured port.
The local script file name matches the Maximo automation script name.
The local workspace includes the script directories you want VS Code to map back to Maximo.
VS Code can communicate with the debug port directly or by using port-forwarding.

The attach debugger configuration does not define the remote host or port. The extension always uses naviam.maximo.host and naviam.maximo.debugPort from the Maximo settings when it opens the debug connection.

Because source mapping is filename-based, the local file name must match the Maximo script name. Local .py and .js files are indexed by upper-cased file base name when breakpoints are mapped back to deployed scripts.

Attach Configuration Example

Add an attach configuration to .vscode/launch.json similar to the following:

{
    "version": "0.2.0",
    "configurations": [
        {
            "type": "autoscript",
            "request": "attach",
            "name": "Attach to Maximo Automation Script",
            "scriptRoots": ["${workspaceFolder}"]
        }
    ]
}

Configuration fields:

scriptRoots: Local folders scanned recursively for .py and .js files used for source mapping.

Connection settings:

naviam.maximo.host: The Maximo host name used for the debug connection.
naviam.maximo.debugPort: The remote debug port used for the debug connection. This must match the Maximo-side debug adapter port.

The Maximo property naviam.autoscript.debug.host controls the bind address on the Maximo side. The VS Code extension connects using naviam.maximo.host and naviam.maximo.debugPort.

Typical Workflow

Confirm naviam.maximo.host and naviam.maximo.debugPort are configured in the Maximo VS Code settings.
Confirm the Maximo-side debug properties are configured and the debug port is reachable.
Open the local workspace that contains the automation scripts to debug.
Add or select the Attach to Maximo Automation Script launch configuration.
Set breakpoints in the local .py or .js script files.
Start the attach configuration from VS Code.
Trigger the automation script in Maximo.
Inspect variables, evaluate expressions, review console output, and step through execution.

Debugging Features

Attach from VS Code to Maximo over TCP
Line breakpoints
Conditional breakpoints
Manual breakpoints from script code
Step in
Step over
Step out
Paused stack frame inspection
Expression evaluation
Console stdout/stderr forwarding

Variable inspection

The debugger exposes locals and other visible bindings and supports:

Simple scalar rendering
Lazy variable expansion
Collection, map, and array expansion
Cycle protection
Expansion depth limits
Reflective Java object inspection
Custom higher-signal views for selected Maximo runtime types

For many Java-backed objects the following variables will be visible:

Bean properties
Instance fields
__meta__
__methods__

For Maximo types the debugger adds custom summaries and children for objects such as:

ScriptService
MboRemote
MboSetRemote
UserInfo

Manual and Conditional Breakpoints

Standard VS Code line breakpoints work without modifying the script source, but manual breakpoints can also be added in script code when needed.

For Jython:

if debugger.isEnabled():
    debugger.breakpoint("before save")

For JavaScript/Nashorn:

if (__autoscript_debugger.isEnabled()) {
    __autoscript_debugger.breakpoint('before save', 42);
}

Conditional breakpoints are evaluated in the script language, not in Java. For example:

Jython: mbo.getString("ASSETNUM") == "13170"
JavaScript/Nashorn: mbo.getString("ASSETNUM") === "13170"

Do not rely on Java-style .equals(...) in conditional breakpoint expressions.

Maximo Properties

Property	Description
naviam.autoscript.debug.enabled	Enables the in-process debug adapter. Typical value: `true`
naviam.autoscript.debug.port	TCP port exposed by the debug adapter. Default: `4711`
naviam.autoscript.debug.host	Bind host for the adapter listener. Default: `0.0.0.0`
naviam.autoscript.debug.js.exclude	Exact script names to exclude from JavaScript/Nashorn debugger integration, matching is case-insensitive and separators can be commas, whitespace, or both.

Caught and uncaught exception stopping is controlled by VS Code exception breakpoints (All Exceptions and Uncaught Exceptions) for the active debug session.

JavaScript / Nashorn Notes

JavaScript instrumentation is only applied while a debug client is attached.
Scripts listed in naviam.autoscript.debug.js.exclude do not receive injected debugger bindings or standard line stepping.
Excluded JavaScript scripts continue through Maximo's native JavaScript execution path.
The runtime debugger alias for JavaScript is __autoscript_debugger.
JavaScript expression evaluation and conditional breakpoints run against a captured visible-bindings snapshot for the paused frame.

Limitations

Source mapping is filename-based rather than driven by authoritative Maximo metadata, so the file name must match the script name. The VS Code extension indexes local .py and .js files by upper-cased file base name, and if multiple files collapse to the same key, the last indexed file wins.
The debugger is built around a single in-process adapter and a single active paused script. One VS Code client attaches to one Maximo-hosted TCP listener, and only one script execution can remain suspended at a time. If another script hits a breakpoint while one is already paused, that second pause is skipped.
Jython tracing is intentionally limited to the top-level automation script body. Stepping and line events do not try to expose arbitrary non-script Python frames, imported library internals, or Java call stacks as normal debugger frames.
JavaScript/Nashorn frames are reconstructed from instrumentation snapshots rather than from a live lexical debugger API. Parent lexical scopes are not fully exposed as live frames, and evaluate/watch expressions run against the captured visible-bindings snapshot for the paused location.
Step out from the top-level script body usually runs to completion because there is no outer script frame to stop on.
JavaScript instrumentation only applies while a debug client is attached. Excluded scripts from naviam.autoscript.debug.js.exclude continue down Maximo's native JavaScript path and do not expose debugger bindings or standard VS Code line stepping.
Variable inspection is intentionally conservative for Java and Maximo objects. The debugger prefers read-safe summaries, fields, and selected bean properties over invoking getters that may mutate state, trigger persistence work, or perform expensive remote access.
The transport model assumes direct TCP reachability from VS Code to the Maximo JVM host and port. There is no built-in authentication, proxying, or remote session brokering in the debugger itself.
Debugging only works with Java 17 and does not work with Maximo 7.6.

Troubleshooting

If breakpoints are not hit, confirm that the local file name matches the deployed Maximo script name.
If VS Code cannot attach, verify that the debug port is exposed or port-forwarded and that naviam.maximo.host and naviam.maximo.debugPort point to the reachable target.
If a second script does not pause while another script is already stopped, this is expected because only one paused execution is supported at a time.
If JavaScript breakpoints are skipped, check whether the script is listed in naviam.autoscript.debug.js.exclude.

Requirements

Maximo 7.6.0.8 or higher, Maximo Application Suite 8 is supported.
Files must have a .js, .py, .jy or .ts extension for scripts, .xml for screens, .rptdesign for BIRT reports and .json for inspection forms, JSON deploy files and deployment manifests.
TypeScript scripts require Node.js and npm to build.
This extension requires Maximo to support Nashorn scripts, which requires Java 8.
Initial configuration must be done by a user in the administrative group defined by ADMINGROUP MAXVARS entry. Typically this is MAXADMIN.

Maximo Developer Tools

Naviam

VS Code Maximo Developer Tools

Table of Contents

Configuration

Visual Studio Code Settings

Maximo Settings

.devtools-config.json

Sample

Multiple Configurations

Logging Settings

Maximo Configuration

Maximo Configuration Details

scriptConfig Variable

On Deploy Properties

JSON Deploy File

Synonym domain fields

JSON Pre-deploy File

Example Deploy JSON

Retaining Customer Values

Presentation Changes

Deploying Maximo Objects

Prettier Compatibility

JavaScript / Nashorn Example

Python / Jython

Features

Deploy to Maximo

Deploy Script

Deploy TypeScript Script

Initialize a TypeScript Project

Deploy Screen

Deploy Inspection Form

Deploy Report

Deployment Manifest

Entry Kinds

Disabling an Entry

Keeping Changes Made in Maximo

Example Manifest

Extract Automation Scripts

Extract Screen Definitions

Extracted Metadata

Extract Inspection Forms

Extract Reports

Extract JSON Deploy Files

Extract DBC Files

Compare with Maximo

Compare Script

Compare Screen

Log Streaming

Insert Unique Id

Snippets

Remote Debugging

Before Starting

Attach Configuration Example

Typical Workflow

Debugging Features

Variable inspection

Manual and Conditional Breakpoints

Maximo Properties

JavaScript / Nashorn Notes

Limitations

Troubleshooting

Requirements
