Fast, offline IC10 language support for Stationeers, powered by a native Rust
language server.
The language server and generated reference data are bundled with the
extension. You do not need Python, a Stationeers installation, or a separately
installed language server.
This is an independent community project. It is not affiliated with,
endorsed by, or sponsored by RocketWerkz.
Quick start
- Install Stationeers IC10 Toolkit from your editor's Extensions view.
- Open or create a file ending in
.ic10.
- Start typing an instruction or hover an existing symbol.
define Solar HASH("StructureSolarPanel")
alias sensor d0
start:
l r0 sensor Horizontal
yield
j start
Language features activate automatically for .ic10 files.
Features
- Syntax highlighting for instructions, labels, registers, devices, macros,
constants, enum values, numbers, and comments.
- Context-aware completion for instructions, operands, registers, device pins,
constants, enums, labels, prefab hashes, and
HASH/STR literal macros.
- Hover help for instructions, registers (
r0-r15, sp, and ra), device
references (d0-d5 and db), constants, enums, symbols, reagent hashes,
computed HASH("...") values, packed STR("...") display strings, prefab
names, and numeric prefab hashes.
- Signature help generated from IC10 command syntax.
- Go to definition for labels, defines, and aliases in the current document.
- Diagnostics for unknown or deprecated instructions, operand counts, malformed
literal macros, invalid
STR text, duplicate symbols, missing labels, invalid
labels, and the 128-line program limit.
- Document symbols for labels, defines, and aliases.
The parser remains useful while a line is incomplete or invalid, making the
extension suitable for normal incremental editing.
Commands
Open the Command Palette and run:
- IC10: Restart Language Server — stops and restarts the language server.
Settings
| Setting |
Default |
Purpose |
ic10.server.path |
Empty |
Absolute path to a custom ic10-lsp executable. Leave empty to use the bundled server. |
ic10.trace.server |
off |
Logs LSP communication at messages or verbose level. |
Settings can be changed through Preferences: Open Settings (UI) by
searching for Stationeers IC10 Toolkit.
Release packages are built separately for:
- Windows x64 and ARM64
- Linux x64 and ARM64
- macOS Intel and Apple silicon
The extension runs in the workspace extension host, including compatible
Remote Development environments. A custom server can be selected with
ic10.server.path when a platform package is unavailable.
Troubleshooting
The language server did not start
- Open View: Output.
- Select Stationeers IC10 Toolkit from the channel list.
- Run IC10: Restart Language Server.
- Check that you installed the package matching the host that runs the
extension. For remote workspaces, this is normally the remote host.
If you configured ic10.server.path, confirm that it points to an executable
for the current operating system.
Language features are not active
Confirm that the file ends in .ic10 and that the language mode shown in the
status bar is IC10.
Collecting a protocol trace
Set ic10.trace.server to messages or verbose, reproduce the problem, and
include the relevant output in a bug report. Review the trace before sharing it
because it can contain source text.
Privacy
The extension runs locally. It does not include telemetry and does not send
source code or Stationeers data to an external service.
Support and contributing
License and attribution
Project source code is available under the
MIT License.
Stationeers names, reference material, and images remain the property of
RocketWerkz and its licensors; see the
third-party notices.
