ROS 2 Workbench

ROS 2 Workbench

sh-u-x-in

|
39 installs
| (0) | Free
A Visual Studio Code extension for Robot Operating System (ROS) 2 development.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

ROS 2 Workbench

A Visual Studio Code extension supporting Robot Operating System 2 (ROS 2) development on Windows, Linux and macOS.

Package contents sidebar and ROS 2 status page

This project is derived from ranchhandrobotics/rde-ros-2 and ms-iot/vscode-ros (both MIT licensed), with thanks; see the license details at the bottom and ThirdPartyNotices.

🇨🇳 中文说明:README.zh-CN.md

Features

  • Automatic ROS environment setup — Detects the distribution and loads the environment when a ROS 2 workspace opens; supports pixi environments and custom setup scripts, and re-collects automatically when shell configuration files change.
  • ROS 2 status page — Start the extension's resident helper (an rclpy process talking to DDS directly) with one click to inspect nodes / topics / services / parameters / lifecycle; subscribe to topics, call services, send action goals (structured forms), and open oversized parameters as full content.
  • Package contents sidebar — Shows each package's executables, launch files, Python exports, resources and headers based on the actual install directory; inline run / build buttons and click-to-source navigation. Rows carry health markers (missing artifact / broken symlink / missing source) and source-vs-install modification times, package hovers show the last build time, entries the latest build no longer declares are hidden as "leftovers" behind a title-bar eye toggle, and clicking a row re-verifies it against disk.
  • Build integration — Ctrl+Shift+B smart build (multi-select packages + argument presets); the build command is fully customizable via a settings template; pre-build checks catch install-method (symlink/copy) and layout (merged/isolated) conflicts with fix suggestions.
  • Run & launch — ros2 run / ros2 launch with argument presets and per-target memory; targets never cross-contaminate.
  • One-key run (Ctrl+F10) — Runs the active Python/C++ source file or launch file; detects compiled-but-not-installed targets, and — unless silenced via ROS2.run.staleWarning — shows a non-modal warning when the installed copy is older than its source.
  • Testing — Integrated with the VS Code Test Explorer: discovers C++ gtest and Python pytest tests automatically, with run/debug and result parsing.
  • Language services — Completion, hover, definition, formatting and diagnostics for .msg/.srv/.action; include-graph-driven navigation, hover, completion and D1-D14 diagnostics for .xacro/.urdf; launch files (py/XML/YAML) completion and include navigation.
  • Code snippets — Curated Python (rclpy) and C++ (rclcpp) snippets covering nodes, publishers/subscribers, services, actions, parameters, logging and launch files.
  • IntelliSense configuration — Automatically maintains include paths for cpptools and clangd (engine auto-detected or selectable) and merges compile_commands.json; per-engine entry override tables can replace or drop individual managed entries, and an optional tidy mode keeps the managed .clangd block sorted.
  • Package creation wizard — Generates C++ / Python / mixed packages: dependency picker with builtin packages pre-checked and user-overridable descriptions (ROS2.packages.userIndex), naming and reserved-name validation, launch/resource templates; the generated CMakeLists.txt pins the C++ standard for the detected ROS 2 distribution, and generated teaching comments follow the UI language.
  • ROS 2 terminal — Creates terminals with the ROS environment pre-loaded (bash/zsh/fish/pwsh/cmd all supported); right-click a folder to build or scaffold quickly.
  • rosdep / Doctor — Shortcuts for rosdep dependency installation and ros2 doctor diagnostics.
  • Bilingual UI — English and Simplified Chinese interfaces, following the VS Code display language.

Getting started

  1. Install the extension (the C/C++ and Python extension dependencies are installed automatically).
  2. Open a ROS 2 workspace containing a package.xml; the extension activates and loads the environment automatically.
  3. Click the ROS distribution tag on the bottom status bar to open the status page; use the "ROS 2 Packages" icon in the activity bar for the package contents view.

Development status

This extension is under rapid active development — features and behavior may change between versions. Development and testing were done primarily on Linux (ROS 2 Humble); Windows has not been systematically tested, so unexpected behavior is possible there (the status page in particular). If you run into problems, please report them at Issues — feedback directly drives what gets fixed next.

Configuration

Key settings (see docs/configuration.md):

  • ROS2.env.* — distribution / setup script / pixi environment;
  • ROS2.build.template + ROS2.build.presets / ROS2.run.* / ROS2.launch.* — the template & preset mechanism for the three commands (flat string + key-value table, editable directly in the Settings UI);
  • ROS2.build.installMethod / ROS2.build.installLayout — install method (auto / symlink / copy) and layout;
  • ROS2.ide.* — IntelliSense engine selection, per-engine managed-entry override tables, managed .clangd sorting;
  • ROS2.packages.userIndex — user-supplied descriptions for dependency candidates;
  • ROS2.search.* — workspace scan exclusions, symlink following and timeouts.

Documentation

Full documentation (usage / tutorials / testing / configuration / IntelliSense / snippets / pixi / troubleshooting — in English and Simplified Chinese) lives in the repository docs/ directory.

Support

Please report problems at Issues with the ROS distribution, operating system, reproduction steps and relevant logs from the "ROS 2" output channel.

Contributing

Issues and PRs are welcome; see CONTRIBUTING.md.

License & acknowledgements

This project is released under the MIT License. Derived from Ranch Hand Robotics' rde-ros-2 and Microsoft's vscode-ros; upstream copyright notices are retained per their terms.
