SF Dependency Analysis

Visual dependency graph for Salesforce DX projects — map Apex classes, LWC components, triggers, and identify unused code.

Features

Interactive Dependency Graph

Force-directed interactive graph rendered with D3.js
Click any node to see its connections highlighted
Drag nodes to rearrange the layout
Zoom, pan, and fit-to-view controls
Search to find and highlight specific classes/components
Export the graph as SVG

Dependency Tracking

Connection Type	Example
Apex → Apex (extends)	`class MyService extends BaseService`
Apex → Apex (implements)	`class MyBatch implements Database.Batchable`
Apex → Apex (instantiation)	`new MyHelper()`
Apex → Apex (static calls)	`MyUtils.doSomething()`
Apex → Apex (type references)	`MyDTO record;`
LWC → Apex (imports)	`import getRecords from '@salesforce/apex/MyController.getRecords'`
LWC → LWC (composition)	`<c-child-component>` in templates
Trigger → SObject	`trigger AccountTrigger on Account`
Trigger → Handler class	`AccountTriggerHandler.handle()`
Aura → Apex controller	`controller="AccountController"`
Aura → Aura (composition)	`<c:ChildComponent />` in markup
Aura → Aura (dynamic)	`$A.createComponent("c:Dialog")`
Aura → Events	`$A.get("e.c:RecordUpdated")`

Unused Code Detection

Classes and components are flagged as unused with confidence levels:

High confidence — Regular class with no incoming references, no special annotations
Medium confidence — Has some annotations but no references found
Low confidence — Abstract/virtual classes or interfaces (may be used polymorphically)

Smart entry point detection — The analyzer knows that these are NOT unused:

Schedulable, Batchable, Queueable implementations
@RestResource, @InvocableMethod, @AuraEnabled annotated classes
Exposed LWC components with targets in meta XML
Triggers (platform-invoked)
User-configured entry points

Unused Classes & Components — Tree view grouped by confidence level
Dependencies — Stats overview and selected-node detail

Diagnostics

Unused classes appear as warnings/info in the VS Code Problems panel.

How It Works

This extension runs entirely locally — it performs static analysis of source files on disk using VS Code's filesystem APIs. It does not connect to a Salesforce org, make API calls, or send any data over the network. All parsing is regex-based against your local .cls, .cmp, .html, and .trigger files.

Getting Started

Open a Salesforce DX project (must have sfdx-project.json)
Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P)
Run "SF Analysis: Show Dependency Graph"
The graph opens in a side panel — explore your codebase!

Commands

Command	Description
`SF Analysis: Show Dependency Graph`	Run analysis and open the interactive graph
`SF Analysis: Refresh Dependency Graph`	Re-run analysis (also triggered on file save)
`SF Analysis: Find Unused Classes & Components`	Quick-pick list of unused items
`SF Analysis: Focus on Class/Component`	Search and zoom to a specific node
`SF Analysis: Impact Analysis`	Select a class to see everything that would break if it changes
`SF Analysis: Find Circular Dependencies`	Detect and report all cycles in the graph
`SF Analysis: Export Dependency Report (JSON)`	Export full analysis to a JSON file

Screenshots

SF Analysis: Show Dependency Graph Description SF Analysis: Find Circular Dependencies SF Analysis: Impact Analysis -- what breaks if I change this?

Configuration

Setting	Default	Description
`sfDependencyAnalysis.excludePatterns`	`["/node_modules/", "/.sfdx/"]`	Glob patterns to exclude
`sfDependencyAnalysis.entryPoints`	`[]`	Classes to always consider "used"
`sfDependencyAnalysis.includeTestClasses`	`false`	Include @IsTest classes in the graph
`sfDependencyAnalysis.graphLayout`	`"force-directed"`	Layout algorithm

Architecture

src/
├── extension.ts              # Entry point, command registration
├── types.ts                  # Shared TypeScript types
├── parsers/
│   ├── apexParser.ts         # Regex-based Apex class parser
│   ├── auraParser.ts         # Aura component bundle parser
│   ├── lwcParser.ts          # LWC HTML/JS/XML parser
│   └── triggerParser.ts      # Apex trigger parser
├── analyzers/
│   └── dependencyAnalyzer.ts # Graph builder, unused detection, traversal
├── providers/
│   └── treeProviders.ts      # Sidebar tree views
└── webview/
    └── graphWebview.ts       # D3.js interactive graph panel

test/
├── __mocks__/vscode.ts       # VS Code API mock
├── parsers/
│   ├── apexParser.test.ts
│   ├── auraParser.test.ts
│   ├── lwcParser.test.ts
│   └── triggerParser.test.ts
└── analyzers/
    └── dependencyAnalyzer.test.ts

Development

# Install dependencies
npm install

# Compile
npm run compile

# Watch mode
npm run watch

# Run tests
npm test

# Run in VS Code
# Press F5 to launch Extension Development Host

Roadmap

[x] Aura component support
[x] Circular dependency detection
[x] Impact analysis ("what breaks if I change this?")
[x] JSON report export
[x] Unit test suite (Jest)
[ ] Custom object / field dependency tracking
[ ] Flow → Apex connections
[ ] Managed package boundary detection
[ ] Hierarchical layout mode
[ ] Dependency depth slider (show N hops from selected node)
[ ] Export dependency report as CSV
[ ] VS Code CodeLens integration (inline reference counts)

License

MIT
