Jupyter Live Share

A VS Code extension that lets teachers share files (.ipynb, .py, .txt, .md, etc.) with students in real-time via browser.

한국어 설명은 Notion 문서를 참고해주세요: Notion 문서 바로가기

Key Features

• Real-time Jupyter Notebook Sharing (.ipynb): Cell edits, execution outputs, and cell add/delete are synced instantly
• Text File Sharing (.py, .txt, .md, etc.): Syntax highlighting and Markdown rendering support
• Live Cursor Tracking: Teacher's cursor position, line highlight, and text selection are displayed on students' screens in real-time
• Live Chat: Teachers chat from the VS Code sidebar, students from the browser or VS Code Viewer Chat panel (with spam rate limiting)
• Teacher Message Highlighting: Teacher messages are displayed with a green background for easy identification
• Live Polls: Number mode (1, 2, 3...) and text mode (custom labels) with real-time bar chart results (one vote per student, no re-voting)
• Teacher Display Name: Set a custom name before starting a session (default: "Teacher")
• Drawing/Annotation: Draw on notebooks with pen/highlighter/eraser in the Teacher Preview panel, shared live with students
• Teacher Preview Panel: Preview exactly what students see, with drawing tools included
• Scroll Sync: Teacher's scroll position is accurately synced to students via cell-relative anchor
• Local Image Sharing: Local images in Markdown/HTML are auto-converted to base64 for transmission
• Cloudflare Tunnel: External HTTPS access without a dedicated server
• 100 Concurrent Viewers: Supports classroom-scale connections (configurable)
• Dark/Light Mode: Theme toggle in the viewer

How It Works

[Teacher VS Code] → Extension → HTTP/WebSocket Server → Cloudflare Tunnel
                                                              ↓
                                           [Student Browser] ← HTTPS URL

1. Teacher runs Start Session in VS Code
2. A local server (default port 48632) starts and generates an external URL via Cloudflare Tunnel
3. Students open the URL in a browser and enter their name
4. File edits are transmitted in real-time via WebSocket
5. Two-way communication through chat and polls

Installation

Search for Jupyter Live Share in VS Code Extensions (Ctrl+Shift+X) and install.

Usage

Starting a Session

1. Open a .ipynb, .py, .md, .txt, or other file in VS Code
2. Enter a display name in the Jupyter Live Share sidebar panel (default: "Teacher")
3. Click Start Session
   • Or Ctrl+Shift+P → Jupyter Live Share: Start Session
4. Share the URL shown in the status bar with students (auto-copied to clipboard)
5. The sidebar shows session info (URL, filename, viewer count) + chat panel
6. You can start a session without opening a file first (students see an empty screen until you open one)

Stopping a Session

• Click Stop Session in the sidebar
• Or Ctrl+Shift+P → Jupyter Live Share: Stop Session

Live Chat

Teacher (VS Code):

• Chat area appears in the sidebar when a session starts
• Send messages from the sidebar
• Uses the display name set before session start (default: "Teacher"), not counted as a viewer
• Teacher name shown in green, student names in blue
• Teacher messages highlighted with green background

Student (Browser Viewer):

• Click the Chat button at the bottom to open the chat panel on the right
• Must enter a name to chat (saved to localStorage for auto-fill on reconnect)

Student (VS Code Open Viewer):

• Chat via the Viewer Chat panel in the terminal area
• When using Open Viewer, the in-viewer chat is hidden and separated into its own panel
• Connects via a dedicated chatOnly WebSocket (not counted as a viewer)

Common:

• Poll start/end events are shown as system messages in chat (with results)
• Spam protection: Students limited to 5 messages per 10 seconds, 500ms minimum interval (no limit for teachers)
• Max 500 characters per message

Live Polls

Teachers can run real-time polls with students.

Poll Modes:

• Number Mode: Options displayed as numbers (1, 2, 3...) — default, 2–10 options
• Text Mode: Custom labels (e.g., "Agree", "Disagree", "Not sure")

From VS Code Sidebar (Recommended):

1. Click Create Poll in the Jupyter Live Share sidebar
2. Enter a question → select mode (Number/Text) → configure options
   • Number mode: choose count (2–10)
   • Text mode: enter labels, one per line
3. A poll banner appears on students' browsers, and a system message is posted in chat

From VS Code Command Palette:

1. Ctrl+Shift+P → Jupyter Live Share: Create Poll
2. Enter a question → choose option count (2–5, number mode only)

From Browser (Teacher, localhost access):

1. Click the Poll button at the bottom of the viewer
2. Enter a question → select mode → configure options → Start Poll

Ending a Poll:

• VS Code sidebar: Click End Poll
• Command Palette: Ctrl+Shift+P → Jupyter Live Share: End Poll
• Browser: Click the End Poll button
• Final results are posted as a system message in chat

Student Voting:

• A poll banner appears at the top when a poll is active
• Number mode: click a number button (1–10) to vote
• Text mode: click a label button to vote
• One vote per student — no re-voting (buttons are disabled after voting)
• Results update as a live bar chart (with labels in text mode)

Settings

Supported File Types

Cloudflare Tunnel

This extension uses Cloudflare Tunnel (cloudflared) for external access. On the first session start, the binary is automatically downloaded from Cloudflare's official GitHub releases and reused for subsequent sessions.

License

MIT
