Maintainability Risk Analyzer

A Visual Studio Code extension for identifying JavaScript code that may present maintainability risks using software metrics and the Maintainability Index (MI), with an optional LLM-based explanation feature.

Overview

Maintainability Risk Analyzer performs static analysis on JavaScript code and identifies maintainability risks based on calculated software metrics.

The extension supports:

• .js
• .mjs
• .cjs

The analysis is performed locally using an Abstract Syntax Tree (AST). The LLM is not used to calculate software metrics, the Maintainability Index, or risk categories. It is only used to provide contextual explanations and refactoring suggestions based on the analysis results.

Metrics

The extension uses three main software metrics:

1. Halstead Volume (HV)
2. Cyclomatic Complexity (CC)
3. Lines of Code (LOC)

These metrics are used to calculate the Maintainability Index:

MI = max(0, ((171 - 5.2 × ln(HV) - 0.23 × CC - 16.2 × ln(LOC)) × 100) / 171)

Risk Classification

Features

JavaScript Analysis

• Analyze the active JavaScript file.
• Analyze JavaScript files in the workspace.
• Parse source code using an AST.
• Calculate HV, CC, LOC, and MI.
• Classify maintainability risk as Low, Medium, or High.

Editor Feedback

• Display diagnostics for identified risks.
• Highlight analyzed functions according to their risk level.
• View analysis details through hover information.
• View a summary of the analysis results.

Hover information can include:

• Maintainability Index
• Halstead Volume
• Cyclomatic Complexity
• Lines of Code
• Risk category
• Deterministic explanation of the identified risk

LLM-Based Explanation

The Explain Maintainability Risk feature provides contextual explanations and refactoring suggestions for analyzed functions.

The LLM receives the relevant code snippet and the results produced by the local analysis, including:

• HV
• CC
• LOC
• MI
• Risk category
• Deterministic risk explanation

The LLM is used only to explain the existing analysis results. It does not determine the metric values or risk category.

Export

Analysis results can be exported as a JSON workspace report.

LLM Integration

The extension uses a Vercel backend as a proxy between the extension and the OpenAI API.

VS Code Extension
        ↓
Vercel Backend
        ↓
OpenAI API
        ↓
Vercel Backend
        ↓
VS Code Extension

The backend is used to keep the OpenAI API key outside the extension.

Commands

Open the Command Palette in Visual Studio Code (Ctrl+Shift+P / Cmd+Shift+P) and search for:

• Maintainability: Analyze Current JavaScript File
• Maintainability: Analyze JavaScript Workspace
• Maintainability: Show Maintainability Summary
• Maintainability: Explain Maintainability Risk
• Maintainability: Explain Maintainability Risk at Cursor
• Maintainability: Export Workspace Report (JSON)
• Maintainability: Test LLM Proxy Connection

Installation

From Visual Studio Code Marketplace

1. Open Visual Studio Code.
2. Open the Extensions view.
3. Search for Maintainability Risk Analyzer.
4. Select the extension and click Install.

From VSIX

If a .vsix package is provided:

1. Open Visual Studio Code.
2. Open the Extensions view.
3. Click the ... menu.
4. Select Install from VSIX....
5. Select the .vsix file.
6. Reload Visual Studio Code if prompted.

Usage

1. Open a JavaScript File

Open a JavaScript file with one of the supported extensions:

.js
.mjs
.cjs

2. Run the Analysis

Use:

Maintainability: Analyze Current JavaScript File

You can also use:

Maintainability: Analyze JavaScript Workspace

to analyze JavaScript files in the workspace.

3. Review Maintainability Results

After the analysis is completed, review the metrics and risk information shown in the editor.

You can also:

• hover over an analyzed function,
• inspect diagnostics and highlights,
• open the maintainability summary.

4. Explain a Maintainability Risk

Select a function with an identified maintainability risk and run:

Maintainability: Explain Maintainability Risk

or:

Maintainability: Explain Maintainability Risk at Cursor

The extension sends the relevant code and locally calculated analysis results to the backend. The returned LLM response is then displayed as a contextual explanation and refactoring suggestion.

5. Export the Analysis

Use:

Maintainability: Export Workspace Report (JSON)

to export the analysis results as a JSON report.

Configuration

The extension provides several optional settings:

• maintainabilityRiskAnalyzer.showLowRiskDiagnostics
  Display Low Risk functions as diagnostic information. Disabled by default.

• maintainabilityRiskAnalyzer.analyzeOnSave
  Automatically analyze JavaScript files when they are saved. Enabled by default.

• maintainabilityRiskAnalyzer.llm.model
  Model name passed to the LLM backend.

• maintainabilityRiskAnalyzer.llm.maxSnippetCharacters
  Maximum length of a function snippet sent to the LLM.

• maintainabilityRiskAnalyzer.privacy.sendCodeToLLM
  Controls whether the analyzed function snippet and metric results are sent to the LLM backend.

• maintainabilityRiskAnalyzer.llm.proxyEndpoint
  Endpoint used for the LLM proxy backend.

• maintainabilityRiskAnalyzer.llm.proxyToken
  Optional access token for the proxy backend.

• maintainabilityRiskAnalyzer.llm.requestTimeoutMs
  Maximum waiting time for an LLM backend request.

Development

Clone the repository and install the dependencies:

npm install

Compile the extension:

npm run compile

For development with automatic recompilation:

npm run watch

To create a VSIX package:

npm run package

This generates a .vsix file that can be installed manually in Visual Studio Code.

Backend Development

The LLM proxy is located in the backend-vercel directory.

cd backend-vercel
npm install

Configure the required environment variables:

OPENAI_API_KEY=your_openai_api_key
OPENAI_MODEL=gpt-4.1-mini
ALLOWED_MODELS=gpt-4.1-mini,gpt-4o-mini
MAX_SNIPPET_CHARS=6000

Limitations

• The extension analyzes JavaScript files only.
• The LLM explanation feature requires access to the configured backend.
• The LLM does not calculate software metrics, Maintainability Index values, or risk categories.
• The function code snippet may be sent to the configured LLM backend when the explanation feature is used.

Academic Context

This extension was developed as part of an academic research project on JavaScript code maintainability analysis using software metrics and an LLM-based explanation feature.

The Maintainability Index and risk classification are calculated deterministically by the extension. The LLM is used as a supporting component to explain the analysis results and provide contextual refactoring suggestions.

License

This project is licensed under the MIT License.
