Seeed XIAO Zephyr Assistant (VS Code extension)

Create and open XIAO Zephyr projects, manage the extension environment, browse XIAO boards, Grove modules, and expansion boards, then hand build/flash/monitor actions to Zephyr tooling.

The extension reads repository metadata directly, so browsing works offline without a Zephyr toolchain installed. Create and execute actions call the seeed-zephyr CLI. Grove modules expand to the examples and board matrix recorded in the repository.

创建和打开 XIAO Zephyr 项目,管理插件环境,浏览 XIAO 板子、Grove 模块和扩展板, 再把构建/烧录/监视操作交给 Zephyr 工具链。浏览直接读取仓库元数据,因此无需安装 Zephyr 工具链也能离线浏览;创建和执行操作会调用 seeed-zephyr CLI。Grove 模块 会展开显示仓库中记录的示例和板级矩阵。

Install

Search Seeed XIAO Zephyr in the Extensions view of Cursor, Windsurf, VSCodium, Gitpod, or Eclipse Theia, or install from the Open VSX listing.

Build, flash, and monitor actions call the seeed-zephyr CLI. Install it with pip install seeed-zephyr, and for the full Zephyr toolchain (SDK + west workspace) use the one-line installer in the project README. The sidebar is organized into Welcome, Projects, Environment, and Catalog views. Use Welcome for common setup and project actions. Use Projects to create or open a project, select the project board and serial port, and run project actions including Upload & Monitor. Use Environment to check Status, update repository content from the Repository group, and manage the selected seeed-zephyr command from the CLI group. Install Latest CLI installs the newest published CLI into extension storage and selects it automatically; Reinstall CLI force-installs the newest package again; Verify CLI checks the selected CLI version and required plugin commands; Choose CLI Version installs a specific published version. Managed CLI installation uses Python 3.12 or newer and searches for a suitable Python before creating its venv. Install and reinstall actions verify info --json, list ports --json, and create --help before saving the managed CLI version. Serial port detection is provided by the selected CLI; Auto Port uses the detected serial port when no port has been selected yet, and Select Port opens the detected-port picker. In that picker, Auto Detector keeps automatic detection enabled, and a concrete port saves the user's selection for later upload and monitor actions. Upload & Monitor flashes the project and opens the serial monitor after upload. When testing from a source checkout, select the checkout's scripts/seeed-zephyr command. Catalog is visible by default, with Boards, Grove Modules, and Expansion Boards collapsed until opened.

在 Cursor、Windsurf、VSCodium、Gitpod 或 Eclipse Theia 的扩展面板搜索 Seeed XIAO Zephyr 安装,或从 Open VSX 页面安装。 构建/烧录/监视会调用 seeed-zephyr CLI,用 pip install seeed-zephyr 安装即可。 左侧栏分为 Welcome、Projects、Environment 和 Catalog。在 Welcome 里放常用入口。在 Projects 里创建或打开项目、选择项目开发板和串口，并运行项目操作。 在 Environment 里查看 Status，仓库内容放在 Repository 分组，CLI 工具版本 放在 CLI 分组。Install Latest CLI 会安装最新发布的 CLI，并自动切换插件使用它； Reinstall CLI 会强制重新安装最新版；Verify CLI 会检查当前 CLI 版本和插件依赖的 基础命令；Choose CLI Version 用于指定发布版本。插件托管 CLI 使用 Python 3.12 或更新 版本，并会先查找可用 Python 再创建 venv。安装和重新安装会先验证 info --json、 list ports --json 和 create --help，通过后才保存托管 CLI 版本。串口检测由当前选择的 CLI 提供；没有手动选择串口时，Auto Port 会使用检测到的串口；点击 Select Port 会打开检测结果选择框，其中 Auto Detector 会保持自动检测，选择具体端口则会保存给后续 Upload 和 Monitor 使用。Upload & Monitor 会先上传项目，上传后直接打开串口监视器。 从源码测试时，选择当前仓库里的 scripts/seeed-zephyr。 Catalog 默认显示，Boards、Grove Modules、Expansion Boards 默认收起。

Develop

cd tools/vscode-extension
npm install
npm run watch      # bundle in watch mode

Press F5 in VS Code with this folder open to launch an Extension Development Host. Open the repository root as a workspace folder so the catalog populates.

按 F5 启动扩展开发宿主;把仓库根作为工作区文件夹打开,目录就会填充。

Build and package

npm run check-types   # type-check only
npm run build         # production bundle to dist/
npm run package       # produce a .vsix with vsce

Publish

Publishing runs from GitHub Actions (.github/workflows/release-vscode.yml) and targets both the VS Code Marketplace and Open VSX. Bump version in package.json, commit, then push to main:

git commit -am "release: extension 0.2.0" && git push

The workflow reads the new version, sees it is not on Open VSX yet, and publishes it. An unchanged version is detected as already released and skipped.

The workflow publishes to each registry whose token secret is set: VSCE_PAT for the VS Code Marketplace and OVSX_PAT for Open VSX. A missing token skips that registry. Publishing a higher version updates the extension for installed users automatically.

Configuration
