Kotlin Debug — VS Code Extension User Guide

Overview

Kotlin Debug is a VS Code debug extension based on the DAP (Debug Adapter Protocol), powered by the kotlin-debugger JAR. It lets you debug Kotlin/JVM programs directly inside VS Code without needing IntelliJ IDEA.

---

Installation

Option 1: Install from VSIX (Recommended)

1. Download the .vsix file from GitHub Releases
2. Open VS Code and press Cmd+Shift+P (Mac) or Ctrl+Shift+P (Windows/Linux)
3. Search for and select "Extensions: Install from VSIX..."
4. Select the downloaded .vsix file

Option 2: Build and install from source

git clone https://github.com/schizobulia/kt-debugger.git
cd kt-debugger

# Build the extension (also builds the debugger JAR)
bash scripts/vscode-ext.sh build

# Install into VS Code
bash scripts/vscode-ext.sh install

Prerequisites

• VS Code >= 1.80.0
• Java 11+ (must be on PATH or configured via kotlin-debug.javaHome)
• A built kotlin-debugger-1.0-SNAPSHOT-all.jar (included automatically when packaged)

---

Quick Start

Step 1: Generate a debug configuration

Open the Command Palette (Cmd+Shift+P) and run:

Kotlin Debug: Generate Launch Configuration

Follow the wizard to pick a configuration type; a .vscode/launch.json is created automatically.

Step 2: Set breakpoints

Click to the left of a line number in any .kt file to set a breakpoint (red dot).

Step 3: Start debugging

Press F5 or click the "Run and Debug" icon in the sidebar, then select the configuration you created.

---

Debug Modes

Launch Mode (Recommended)

The extension starts your application automatically and attaches the debugger. No manual program startup needed.

Add the following to .vscode/launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "kotlin",
      "request": "launch",
      "name": "Kotlin: Launch and Debug",
      "command": "java -agentlib:jdwp=transport=dt_socket,server=y,suspend=y,address=5005 -jar ${workspaceFolder}/build/libs/your-app.jar",
      "port": 5005,
      "cwd": "${workspaceFolder}",
      "sourcePaths": [
        "${workspaceFolder}/src/main/kotlin"
      ]
    }
  ]
}

Gradle project example:

{
  "type": "kotlin",
  "request": "launch",
  "name": "Kotlin: Launch via Gradle",
  "command": "./gradlew run -Dorg.gradle.jvmargs=\"-agentlib:jdwp=transport=dt_socket,server=y,suspend=y,address=5005\"",
  "port": 5005,
  "cwd": "${workspaceFolder}",
  "sourcePaths": [
    "${workspaceFolder}/src/main/kotlin"
  ]
}

Launch mode parameters:

Parameter	Required	Default	Description
command	✅	—	Command to start the app; must include JDWP debug arguments
port	✅	—	Debug port; must match the address in the command
host		"localhost"	Debug host address
cwd		"${workspaceFolder}"	Working directory for the command
env		{}	Additional environment variables
sourcePaths		[]	Kotlin source paths (used for breakpoint mapping)
preLaunchWait		kotlin-debug.defaultPreLaunchWait	Timeout (ms) to wait for the app to start; the extension polls the port automatically

How it works: The extension runs command in a terminal named "Kotlin Debug Target", polls host:port until the port is open, then attaches via DAP.

Application takes a long time to start? The default port polling timeout is controlled by the kotlin-debug.defaultPreLaunchWait global setting (default: 30 seconds). You can increase it in VS Code settings, or override it per-session by adding "preLaunchWait": 60000 (e.g. 60 s) to your launch.json configuration.

Attach Mode

Manually start the application, then attach the debugger. Useful when you need precise control over how the program starts.

Step 1: Start the target program with JDWP arguments

# suspend=y: program waits for the debugger before executing (good for debugging startup logic)
java -agentlib:jdwp=transport=dt_socket,server=y,suspend=y,address=5005 -jar your-app.jar

# suspend=n: program runs immediately; debugger can attach at any time
java -agentlib:jdwp=transport=dt_socket,server=y,suspend=n,address=5005 -jar your-app.jar

# Gradle project
./gradlew run --debug-jvm

Step 2: Configure launch.json

{
  "type": "kotlin",
  "request": "attach",
  "name": "Kotlin: Attach to JVM",
  "host": "localhost",
  "port": 5005,
  "sourcePaths": [
    "${workspaceFolder}/src/main/kotlin"
  ]
}

Attach mode parameters:

Parameter	Required	Default	Description
host		"localhost"	Target JVM host address
port	✅	—	Debug port
sourcePaths		[]	Kotlin source paths

---

Debug Features

Breakpoints

Line breakpoints

Click to the left of a line number in a .kt file to set a breakpoint (red dot). Press F9 to toggle the breakpoint on the current line.

Conditional breakpoints

Right-click a breakpoint → "Edit Breakpoint..." → enter a condition expression. The program only pauses here when the condition evaluates to true.

Supported condition syntax:

Type	Examples
Numeric comparison	i == 5, count > 10
String comparison	name == "test"
Boolean variable	isEnabled, !isDone
Member access	person.age >= 30
Compound condition	x > 3 && y < 8
Method call	list.isEmpty()
Null check	obj != null

Hit Count (Hit Condition) Breakpoints

Right-click a breakpoint → "Edit Breakpoint..." → choose Hit Count. The program only pauses when the breakpoint has been hit the specified number of times.

Supported hit condition formats:

Format	Meaning
5	Pause on the 5th hit
== 5	Pause on the 5th hit
>= 5	Pause starting from the 5th hit
> 5	Pause after the 5th hit

Useful for debugging inside loops — set a hit count to skip the first N iterations.

Function Breakpoints

In the "BREAKPOINTS" section of the "Run and Debug" sidebar, click "+ Add Function Breakpoint" and enter a function name. The debugger pauses whenever that function is entered.

Supported name formats:

Format	Example	Meaning
ClassName.methodName	MainKt.compute	Pause when MainKt.compute() is entered
methodName (no class)	compute	Pause when any compute() method is entered

Logpoints

Right-click a breakpoint → "Edit Breakpoint..." → choose Log Message. Prints a log message when hit, without pausing the program.

Exception breakpoints

In the "BREAKPOINTS" section of the "Run and Debug" sidebar, configure automatic suspension on exceptions:

• Caught Exceptions — pause on all caught exceptions
• Uncaught Exceptions — pause on uncaught exceptions (recommended default)

When an exception breakpoint is hit, the "Exception Info" panel shows:

• Exception type and message
• Full Java stack trace
• cause chain (for nested exceptions)

Variables

When the debugger is paused, the "VARIABLES" panel shows:

• Local variables of the current function
• Fields of the this object
• Method parameters

Variables support expanding to inspect object internals. Values are displayed in Kotlin format (Int, String, List<T>, etc.).

Inline Values

When the debugger is paused, the editor automatically inlines the current values of variables at the end of each code line — no hover needed. Covers ±10 lines around the paused line. Works automatically, no configuration required.

Hover Evaluation

During a debug session, hovering over a variable name shows its current value in a tooltip.

Can be toggled with the kotlin-debug.enableHoverEvaluation setting.

Expression Evaluation (Debug Console)

Type expressions in the "DEBUG CONSOLE" panel at the bottom:

Type	Examples	Notes
Simple variable	x, name, count	Read local variables or fields
Member access	person.name, obj.field	Access object fields
Nested access	a.b.c, person.address.city	Multi-level field access
Array access	arr[0], matrix[1][2]	Access array/list elements
Method call	obj.toString(), list.size()	Invoke methods
Literal	42, "hello", true	Integer, string, boolean

> person.name
"Alice"
> numbers[0] + numbers[1]
30
> calculator.add(10, 20)
30

Watch

Add watch expressions in the "WATCH" panel; values are updated automatically each time the debugger pauses:

user.email
list.size()
array[index]

Call Stack

The "CALL STACK" panel shows the full call chain for the current thread. Click any frame to jump to its source location and switch to that frame's local variables view.

Kotlin inline function frames are intelligently expanded — each inline call appears as a distinct frame.

Stepping

Shortcut	Action
F5	Continue
F10	Step Over
F11	Step Into
Shift+F11	Step Out
Shift+F5	Stop Debugging
F9	Toggle Breakpoint

---

Coroutine Debugging

When debugging a Kotlin program, a "Kotlin Coroutines" panel appears in the "Debug" sidebar (visible only during a Kotlin debug session).

The panel shows all coroutines with:

• Coroutine ID and name
• Current state (RUNNING / SUSPENDED / CREATED)
• Dispatcher information
• Call stack frames (click a frame to jump to the corresponding source)

The panel refreshes automatically each time the debugger pauses (breakpoint hit, step completed, exception, etc.) — powered by DebugAdapterTracker intercepting DAP stopped events. You can also click the refresh icon in the panel header or run "Kotlin Debug: Refresh Coroutines" from the Command Palette to refresh manually.

Requires the target program to depend on the kotlinx.coroutines library.

---

Hot Code Replace

Reload modified classes into the running JVM without restarting.

How to use:

1. Edit Kotlin source code and recompile (run Gradle's classes task)
2. While the debug session is active, trigger hot replace via any of:
   • Command Palette (Cmd+Shift+P) → "Kotlin Debug: Hot Code Replace"
   • Right-click inside a .kt editor → "Kotlin Debug: Hot Code Replace"
   • Click "$(sync) Hot Code Replace" in the status bar

Limitation: JVM hot replace only supports changes inside method bodies. Adding/removing fields, changing method signatures, or modifying class hierarchy are not supported.

---

CodeLens Actions

In .kt files, CodeLens buttons appear automatically above the following patterns:

Code pattern	Buttons shown
fun main(	▶ Run Debug
@JvmStatic fun main(	▶ Run Debug
@Test fun testXxx(	▶ Run Test Debug Test

• Debug — detects project type (Gradle / plain JAR) automatically and starts a debug session
• Run Test / Debug Test — runs the corresponding unit test via ./gradlew test --tests "ClassName.methodName"

Can be toggled with the kotlin-debug.enableCodeLens setting.

---

Status Bar Indicator

The current debugger state is shown in the VS Code status bar (bottom-left):

State	Display	Meaning
Ready	$(debug) Kotlin Debug	Debugger ready, no active session
Debugging	$(debug-alt) Debugging Kotlin	Debug session active (orange highlight)
Error	$(error) Kotlin Debug Error	Debugger encountered an error (red highlight)

Clicking the status bar item opens the debug quick menu:

• Generate Debug Configuration
• Start Debugging
• Hot Code Replace
• Show Debug Logs
• View Documentation

---

Configuration Generation Wizard

Run "Kotlin Debug: Generate Launch Configuration" from the Command Palette (Cmd+Shift+P) to interactively create a debug configuration:

1. Select configuration type:

   • Launch — start via a JAR file directly
   • Attach — attach to an already-running JVM
   • Gradle Launch — start via Gradle

2. Enter the debug port (default 5005)

3. Enter additional parameters depending on type (JAR path / host address, etc.)

4. The configuration is written to .vscode/launch.json. If a configuration with the same name already exists, you can choose to replace it or add it as a new entry.

---

Global Extension Settings

Search kotlin-debug in VS Code settings (Cmd+,) to configure:

Setting	Type	Default	Description
kotlin-debug.javaHome	string	""	Custom Java installation path; takes priority over JAVA_HOME and system java
kotlin-debug.buildBeforeDebug	boolean	false	Automatically build before each debug session (Gradle: ./gradlew classes; Maven: mvn compile -q)
kotlin-debug.debuggerJarPath	string	""	Custom path to the kotlin-debugger JAR; auto-detected if not set
kotlin-debug.enableCodeLens	boolean	true	Show CodeLens buttons above main functions and @Test methods
kotlin-debug.enableHoverEvaluation	boolean	true	Show variable values on hover during debugging
kotlin-debug.defaultSourcePaths	string[]	["${workspaceFolder}/src/main/kotlin"]	Default source paths used when not specified in launch.json
kotlin-debug.enableDapLogging	boolean	false	Enable detailed DAP protocol message logging in the output panel. Disabled by default. Enable only when troubleshooting debugger connection issues.
kotlin-debug.defaultPreLaunchWait	number	30000	Default time (ms) to poll the debug port in launch mode before attaching. Increase if your application takes a long time to start. Per-session override: preLaunchWait in launch.json.

Example (settings.json):

{
  "kotlin-debug.javaHome": "/usr/lib/jvm/java-17-openjdk",
  "kotlin-debug.buildBeforeDebug": true,
  "kotlin-debug.enableCodeLens": true,
  "kotlin-debug.enableHoverEvaluation": true,
  "kotlin-debug.defaultSourcePaths": [
    "${workspaceFolder}/src/main/kotlin",
    "${workspaceFolder}/src/test/kotlin"
  ],
  "kotlin-debug.enableDapLogging": false,
  "kotlin-debug.defaultPreLaunchWait": 60000
}

Java lookup order: kotlin-debug.javaHome → JAVA_HOME environment variable → java on system PATH.

---

Logs & Diagnostics

After a debug session starts, a "Kotlin Debugger Logs" channel appears in the VS Code Output panel (Cmd+Shift+U), showing:

• DAP communication logs
• Debugger process stderr output
• Extension internal state (source path detection, JAR search, etc.)

If the debugger crashes, an error notification is shown; details are available in the log channel.

---

Command Palette Commands

Press Cmd+Shift+P to run any of the following extension commands:

Command	Description
Kotlin Debug: Generate Launch Configuration	Interactively generate a launch.json configuration
Kotlin Debug: Debug Main Function	Debug the main function in the current file
Kotlin Debug: Show Debug Menu	Open the debug quick menu
Kotlin Debug: Hot Code Replace	Trigger hot code replace (available during debugging)
Kotlin Debug: Refresh Coroutines	Refresh the coroutines view
Kotlin Debug: Run Test	Run the test method at the current cursor position
Kotlin Debug: Debug Test	Debug the test method at the current cursor position

---

Typical Workflow Examples

Gradle project debugging

1. Configure launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "kotlin",
      "request": "launch",
      "name": "Debug Gradle App",
      "command": "./gradlew run -Dorg.gradle.jvmargs=\"-agentlib:jdwp=transport=dt_socket,server=y,suspend=y,address=5005\"",
      "port": 5005,
      "cwd": "${workspaceFolder}",
      "sourcePaths": ["${workspaceFolder}/src/main/kotlin"]
    }
  ]
}

2. Enable automatic pre-debug build (optional):

{
  "kotlin-debug.buildBeforeDebug": true
}

3. Press F5 to start debugging.

Debugging a remote service

{
  "type": "kotlin",
  "request": "attach",
  "name": "Attach to Remote Service",
  "host": "staging.example.com",
  "port": 5005,
  "sourcePaths": ["${workspaceFolder}/src/main/kotlin"]
}

Ensure the firewall allows port 5005 and the remote program was started with address=*:5005 (not address=127.0.0.1:5005).

Debugging a Kotlin test

1. Open a test file and find a method annotated with @Test
2. ▶ Run Test and Debug Test CodeLens buttons appear above the method
3. Click Debug Test to debug that single test case

---

Frequently Asked Questions

Q: "Cannot find kotlin-debugger JAR file"

A: The JAR was not found. Check these locations:

• release/kotlin-debugger-1.0-SNAPSHOT-all.jar
• build/libs/kotlin-debugger-1.0-SNAPSHOT-all.jar
• Or set kotlin-debug.debuggerJarPath to a custom path.

Run bash scripts/build.sh to rebuild.

Q: Port connection fails ("Failed to attach")

A:

1. Confirm the target program was started with JDWP arguments
2. Confirm the port in launch.json matches the address in the JDWP arguments
3. Check that the firewall/network allows the port
4. If started with suspend=n, make sure the program has not exited already

Q: Breakpoints are never hit

A:

1. Verify sourcePaths points to the actual .kt source directory
2. Confirm the program was compiled with debug info (Gradle includes it by default)
3. If buildBeforeDebug is enabled, verify the build succeeded

Q: Hot code replace has no effect

A:

1. Make sure you recompiled the modified files first
2. JVM hot replace only supports changes inside method bodies; adding/removing fields, changing method signatures, or modifying class hierarchy are not supported

Q: Coroutines view is empty

A: Confirm the target program depends on kotlinx.coroutines and the debugger is successfully attached. Click the refresh button in the view header to force an update.
