SPUD

Spec-driven Product UX & Domain logic (SPUD).

Opinionated user-journey-as-code and business-process-as-code guide rails (with write-time validation) for product designers in the AI era.

Problem: people set out to build a product without having fully thought through what they want to build. When there is ambiguity on what to build, many development iterations are burned as you figure-it-out-as-you-go.

Solution: SPUD is a specification-first approach to product development that guides you (in an opinionated way) to create user journey and business process flows up-front; thereby making it easier for an AI to know what you want and build more effectively.

SPUD enables you to quickly generate flow diagrams that are both human (.svg files) and machine -readable (.dot files). Machine-readable product and business specifications can be used to more effectively guide an AI agent towards building a well-specified product.

SPUD's approach reduces iteration cycles and reduces the time it takes to build an end-to-end product while forcing you, a human, to think up-front and articulate at a high level what you're building prior to any implementation.

Feature requests

If you encounter an issue or want to see a feature, simply open an issue here on github. We'd love to hear from you.

Screenshots

Business process (yaml):

Auto-rendered business process (dot diagram):

User journey (yaml):

Auto-rendered user journey (dot diagram):

Roadmap (yaml):

Auto-rendered roadmap (dot diagram):

Tokenomics (yaml):

Auto-rendered tokenomics (dot diagram):

Recommended accompanying VScode extension:

• Redhat yaml extension
• Error Lens (usernamehw.errorlens)

---

Types of processes:

1. business-process-as-code
2. user-journey-as-code
3. product-roadmap-as-code
4. tokenomics-as-code

1. business-process-as-code

Business processes are written in .yaml

PBAC Validator

BPAC is a minimalist, opinionated user journey format.

A business process is written in yaml (the top level key in the .yaml file should be "bpac") and is designed to be written by and read by non-expert humans, while simultaneously being easily interpreted by a machine.

This is a VS Code extension for validating Business-Process-As-Code (BPAC) YAML files.

BPAC will render your .yaml and produce business process flowcharts that you can use to define, articulate, organise, commmunicate around and operate your business.

Usage

1. Open a .yaml that conforms to the bpac format
2. Run the command bpac: Validate current file or let the extension validate automatically on save.

It then highlights any matching problems directly in the active document.

Highly recommended: Error Lens extension

Next destinations

BPAC start, task, and decision nodes accept a single destination ID or an array of destination IDs. Each destination must match a task id in the same process:

next: ASSESS

next: [FIND, END]

The existing array of {to, condition} objects remains supported for labelled arrows, and may be mixed with plain IDs:

next:
  - FIND
  - to: END
    condition: no_time_left

BPAC draws only the explicitly listed outgoing connections. End tasks still must not contain next. UJAC steps also accept a single ID or an array of IDs; their explicit next destinations replace automatically generated outgoing connections.

Business process overview

Saving a BPAC process or its sibling configuration generates out/groups.dot and out/groups.svg with a Business processes header. All sibling BPAC processes (.yaml and .yml) appear as ellipses labelled with filename, process ID, and name, enclosed by their configured coloured groups.

Define optional groups in bpac.config.groups in config.yaml or config.yml:

bpac:
  config:
    groups:
      - id: DEFAULT
        name: Default group
        description: General business processes
        color: '#aaffaa'
      - id: SALES
        name: Sales
        description: Sales processes
        color: '#aaddff'

Assign a process using bpac.process.group: DEFAULT.SALES. Each segment must match a configured group ID; duplicate configured IDs are rejected. Omit the field to show the process in a neutral Ungrouped ellipse (no implicit default). Only populated groups and their ancestors are shown. Nested groups use the same compact, non-overlapping layout as user journeys, implemented in the shared renderer.

The blue filename opens the source YAML; the rest of its ellipse opens the individual process SVG. The basename groups is reserved for the overview. Invalid sibling YAML and invalid group configuration/references are reported as rendering errors. Graphviz must be installed. To regenerate the SVG from its positioned DOT file, use:

dot -Kneato -n2 -Tsvg out/groups.dot -o out/groups.svg

Rendering regression tests:

npm run compile && node --test tests/bpac-groups.test.js tests/ujac-groups.test.js tests/output-status.test.js tests/status-validation.test.js tests/paths.test.js tests/editor-decorations.test.js

Rules

• validates task structure by task type
• requires all-caps task ids
• requires all-caps next.to targets
• rejects extra keys on next objects
• rejects next on end tasks
• verifies that each next.to references an existing task id

event bus (NATS) integration

Every time a transition to the next task in bpac.tasks:[task] occurs, an event can be fired on NATS. This is a powerful approach for linking your biz process into your organization.

For example, BP_TASK emits with value "BP_SALES_001.ASSESS->IS_TIME_AVAIL"

This reads "A biz process task emits an event. The bp with id BP_SALES_001 transitioned from task.id=ASSESS to task.id=TIME_AVAIL

This is a very powerful approach and allows for:

• logging and auditing of all bp transitions
• isolation and decoupling of tasks
• event-driven architecture
• durable workflows (e.g. temporal.io)
• retry capability

Note: ensure NATS has Jetstream enabled for persistence

Note: ensure all calls are idempotent. This facilitates retries and the saga pattern.

---

2. user-journey-as-code

User journeys are written in .yaml

UJAC Validator

UJAC is a minimalist, opinionated user journey format.

A user journey is written in yaml (the top level key in the .yaml file should be "ujac") and is designed to be written by and read by non-expert humans, while simultaneously being easily interpreted by a machine.

This is a VS Code extension for validating User-Journey-As-Code (UJAC) YAML files.

UJAC will render your .yaml and produce business process user journey charts that you can use to define, articulate, organise, commmunicate around and operate your business.

Unlike a BP, a user journey is outward looking. A user journey is more wordy and loosely described, whereas a business process is more well-defined and specific.

Usage

1. Open a .yaml that conforms to the ujac format
2. Run the command pac-validator: Validate current file or let the extension validate automatically on save.

It then highlights any matching problems directly in the active document.

Highly recommended: Error Lens VScode extension

Configuration groups

ujac.config.groups is an optional array in the configuration document. It may be omitted or set to []. Each group requires a unique ALL-CAPS id (letters, digits, and underscores), a non-empty, non-whitespace name and description, and a six-digit RGB hex color (#RRGGBB). Unknown group fields are rejected.

ujac:
  config:
    user_acquisition_stages: []
    personas: []
    groups:
      - id: DEFAULT
        name: Default group
        description: General user journeys
        color: '#aaffaa'

An explicit journey ujac.group is a group ID or a dot-separated path from the outermost group to the innermost subgroup, such as:

ujac:
  # Other journey fields omitted
  id: BROWSE_WEB3
  group: DEFAULT.SUB_GROUP

This journey belongs to SUB_GROUP inside DEFAULT. Define both DEFAULT and SUB_GROUP as separate entries in ujac.config.groups; configuration IDs remain simple IDs, not dotted paths. Deeper nesting, such as DEFAULT.SUB_GROUP.LEAF, is supported. Nesting is defined by the journey path; the same configured group may appear under different parents as separate instances in the overview.

Every path segment must match a group id in the sibling config.yaml. Unknown IDs are highlighted at the group value, including when groups are empty, omitted, or no configuration exists. The group is optional; omitting it retains the schema's DEFAULT annotation without inserting or validating an implicit value.

Alternate paths in a journey

In ujac.journey_steps, omit path or set it to 0 for a step on the main journey. Use a positive integer for an alternate branch. Consecutive steps with the same positive value make up that branch. The branch replaces the immediately preceding happy-path step, forks from the happy-path step before it (or the overview), and rejoins at the next happy-path step. For example, the journey below keeps FIRST_IMPRESSION on the main path and provides an alternate route through COMPARE_OPTIONS and REVIEW_DETAILS before UNDERSTAND:

ujac:
  journey_steps:
    - id: AWARENESS
      name: Become aware
      touchpoints: []
      emotions: []
    - id: FIRST_IMPRESSION
      name: Form a first impression
      touchpoints: []
      emotions: []
    - id: COMPARE_OPTIONS
      name: Compare options
      path: 1
      touchpoints: []
      emotions: []
    - id: REVIEW_DETAILS
      name: Review details
      path: 1
      touchpoints: []
      emotions: []
    - id: UNDERSTAND
      name: Understand the offer
      path: 0
      touchpoints: []
      emotions: []

Here, path: 0 is equivalent to omitting path. A different positive value, such as path: 2, identifies a separate alternate lane farther to the right; it does not mean “the second step” or make a branch continue from path 1.

Any UJAC journey step may also have an optional next field containing either one step id or an array of step IDs from the same journey_steps list. When next is set, it overrides that step's automatically generated outgoing connections; list any automatic target you want to retain alongside other destinations. Each target must match an existing step ID:

  journey_steps:
    - id: LOGIN_OPEN
      name: Open the login modal
      touchpoints: []
      emotions: []
    - id: LOGIN_RETRY
      name: Guide the user to try again
      next: [LOGIN_OPEN, LOGIN_SUPPORT]
      touchpoints: []
      emotions: []
    - id: LOGIN_SUPPORT
      name: Contact support
      touchpoints: []
      emotions: []

Business processes supporting journey steps

Each journey step accepts an optional supporting_bps array of unique business process IDs (uppercase letters, digits, and underscores). Omit it or use supporting_bps: [] when no processes are linked:

  journey_steps:
    - id: LOGIN_INITIATE
      name: Initiate SSO login
      supporting_bps: [AUTH]
      touchpoints: []
      emotions: []

Each ID must match bpac.process.id declared in a .yaml or .yml file directly inside the adjacent ../bps/ directory. For example, resources/ujs/login.yaml can reference AUTH declared in resources/bps/auth.yaml; the filename does not have to match the ID. Configuration IDs, task IDs, and processes in other directories do not count. Unknown references are highlighted individually in the journey. Unreadable or malformed process files are reported at supporting_bps, rather than silently ignored.

Validation uses unsaved contents of open process files and refreshes open journeys when adjacent process files are opened, edited, saved, closed, created, or deleted. These links do not change the journey's diagram connections.

System journey overview

Journey ujac.id values must be unique across sibling journey YAML files. Duplicates are reported at the ID in each affected open document and identify the conflicting filenames. Validation includes unsaved edits in open documents and refreshes when sibling files are edited, created, or deleted.

Saving a ujac: journey or its sibling configuration regenerates out/groups.dot and out/groups.svg from all journey .yaml and .yml files in that directory, with a User journeys header. Each journey is an ellipse labelled with its filename, ujac.id (when present), and name, nested inside a larger ellipse using its configured group's name and color. Dotted group paths produce nested subgroup ellipses, with each journey drawn once inside its innermost group and enclosed by all its ancestors. Direct members and subgroups share their parent's space without overlapping. Rows use each member's actual dimensions, and group ellipses fit their contents with compact padding rather than reserving subgroup-sized cells for every journey. Only groups with journeys or populated descendants are shown. Journeys without an explicit group appear in a neutral Ungrouped ellipse; no implicit DEFAULT is inserted. The blue, underlined filename links to its source YAML. Click the rest of the journey ellipse in the SVG to open its individual diagram.

The overview uses positioned Graphviz ellipses rather than rectangular clusters. Render it manually with dot -Kneato -n2 -Tsvg out/groups.dot -o out/groups.svg. The basename groups is reserved for the overview. Invalid sibling YAML or unknown group references are reported as rendering errors.

Features

• validates task structure by task type
• requires all-caps task ids
• requires all-caps next.to targets
• rejects extra keys on next objects
• rejects next on end tasks
• verifies that each next.to references an existing task id

---

3. product-roadmap-as-code

Specify a product roadmap in .yaml file format.

root key of the .yaml file should be: roadmap:

The root value is one roadmap object with an items array. The bundled resources/roadmap.schema.json is registered automatically for YAML files with a root roadmap: key. Each roadmap accepts only id, version, status, title, description, role_id, and items keys; unknown keys are rejected. Legacy arrays of roadmaps are still supported, but all entries must have the same status because they share one rendered file.

roadmap:
  id: PRODUCT_ROADMAP
  version: 0.0.1
  status: draft
  title: Product roadmap
  items:
    - title: Initial release
      description: Launch core features
      date: '2027-01-01'

Each item accepts only the following fields:

Field	Required	Constraint
title	Yes	String, at most 255 characters
description	Yes	String, at most 2047 characters
date	Yes	Valid calendar date in YYYY-MM-DD format
group	No	Non-negative number, default 0
path	No	Non-negative integer, default 0

The group and path defaults are JSON Schema annotations; validation does not insert them into the YAML document. Consumers should treat an omitted group or path as 0.

path: 0 (or an omitted path) keeps an item on the main roadmap. A positive integer marks an alternate branch: consecutive items with the same positive value form one branch, replacing the preceding happy-path item and rejoining at the next happy-path item. Higher values appear in lanes farther to the right. For example, these alternate milestones form path 1 between the two main-path items:

roadmap:
  items:
    - title: Define the approach
      description: Agree on the main direction.
      date: '2027-01-01'
    - title: Build the initial option
      description: Continue along the main roadmap.
      date: '2027-02-01'
      # path: 0 # optional - default is 0
    - title: Evaluate an alternative
      description: Explore a different implementation.
      date: '2027-02-15'
      path: 1
    - title: Validate the alternative
      description: Check the alternate implementation.
      date: '2027-03-01'
      path: 1
    - title: Launch
      description: Deliver the selected outcome.
      date: '2027-04-01'
      path: 0

The main route continues through Build the initial option to Launch. Path 1 branches from Define the approach and rejoins at Launch. Use path: 2 for another alternate lane at that position; path numbers can be sparse and do not have to form a sequence.

Groups and roles are configured in a sibling config.yml (or config.yaml):

roadmap:
  config:
    groups:
    - id: 0               # number, matched against item `group`
      name: Default Group # string
      color: '#2563EB'    # #RRGGBB
    roles:
    - role: CEO           # ALL CAPS
      color: '#7C3AED'    # #RRGGBB

Roadmap documents also pass through src/roadmap/semanticConstraints.ts when opened, edited, or saved. It checks that roadmap ids are unique in the folder and, when a config file exists, that each role_id is one of roadmap.config.roles[].role.

On save, each roadmap is rendered to <output-directory>/<file>.dot and <output-directory>/<file>.svg, using the status directories described above, next to the .yaml: a grey overview box (title, id/version, owner in its role color, description) followed by the items connected top to bottom. Each item is filled with its group's color (group 0 when omitted). A grey "today" line is drawn wherever a past item is followed by a future one. As with BPAC and UJAC, any string ending in .md becomes a link and an empty docs/<ROADMAP_ID>.<name>.md is created if missing.

4. tokenomics-as-code

Specify the tokenomics of your token in .yaml file fomat.

The root key of your .yaml file should be tokenomics:

The required version field is a SemVer 2.0.0 string, such as 0.0.0 or 1.2.3-rc.1+build.42, matching the version convention in the other formats.

Positive total_supply and nTokens values may use underscores as digit separators (for example, 1_000_000_000).

On save (and when the extension starts with the document open), Graphviz renders the segments as a pie chart to out/<file>.svg beside the source YAML. No .dot file is written: the chart definition is passed directly to Graphviz. Each slice uses its segment's colour and its nTokens / total_supply share; the legend shows segment names, percentages, and token amounts. Percentages are also drawn halfway around each slice at 62% of the pie radius, with black or white text chosen for contrast. A single allocation has its 100% label at the centre. Graphviz lays out the chart; the renderer overlays these labels in the SVG.

Below the pie chart, the SVG includes a line chart titled "tokens released (cumulative) over time". Its x-axis runs from launch_date through the longest segment schedule (lockup_period_days + vesting_days); its y-axis shows cumulative released tokens. Tokens remain locked until the lockup ends, then vest over vesting_days according to its optional vesting_profile (default: linear). Supported profiles are linear, square (t²), hyperbolic (t / (1 + 5(1 − t))), and exponential ((e^(5t) − 1) / (e^5 − 1)), where t is the elapsed fraction of the vesting duration. A segment with zero vesting duration is released in full when its lockup ends.

Below that, a second line chart titled "token released (cumulative) by allocation over time" shows one color-coded cumulative release curve for each segment, with an allocation legend. Its y-axis maximum is the largest segment's nTokens, not total_supply.

A third line chart titled "token released per day by allocation over time" shows the tokens released each day for each segment, with the same allocation colors and a legend. Its y-axis is scaled to the highest daily release across all segments. All three line charts have white backgrounds.

A grey overview box above the chart shows the token name/symbol, id and v<version>, total supply, decimals, launch date, and description. Total supply and decimals appear on separate lines, matching the other diagram conventions. Markdown descriptions link to sibling docs files as in the other renderers. Rendering reports an error for empty segments, duplicate segment ids, invalid amounts/durations/colours or dates, or allocations that do not sum to total_supply.

Run the rendering regression tests with Graphviz installed:

npm run compile && node --test tests/tokenomics.test.js

vesting_profile

Let (t) be the elapsed fraction of the vesting period, clamped to ([0,1]). The released fraction is:

Linear: (f(t)=t)
Square: (f(t)=t^2)
Hyperbolic: (f(t)=\dfrac{t}{1+5(1-t)})
Exponential: (f(t)=\dfrac{e^{5t}-1}{e^5-1})

For an allocation of (N) tokens, the amount released is (Nf(t))
