Sinclair BASIC for Visual Studio Code
Disclaimer: This is an independent, unofficial community extension providing development tools for the Sinclair BASIC programming language on ZX Spectrum and compatible retro computers. It is not affiliated with, sponsored by, or endorsed by Sinclair Research, Amstrad, Sky, or any of their successors.
A comprehensive VS Code extension for developing Sinclair ZX Spectrum BASIC applications, supporting both Standard Sinclair BASIC (.bas) and an optional modern pseudo-language (.jbas) with labels, line comments, line-number renumbering, automatic .tap compilation, integrated emulator, and interactive step-by-step debugging (DAP).
Universal Extension: Fully compatible with both VS Code Desktop and VS Code for the Web (vscode.dev & github.dev) with 0 installation requirements.
Features
1. Dual Language Support
2. Autocompletion & IntelliSense (.bas & .jbas)
- Comprehensive Sinclair BASIC Keywords: Instant completion for all Sinclair ZX Spectrum BASIC statements (
PRINT, LET, IF, FOR, NEXT, GO TO, POKE, etc.), functions (PEEK, CHR$, CODE, INKEY$, SCREEN$, ATTR, POINT, RND, BIN, USR, etc.), and display attributes (BORDER, PAPER, INK, FLASH, BRIGHT, INVERSE, OVER).
- Rich Documentation & Syntax Previews: Each keyword item includes syntax reference and detailed markdown explanation.
- Smart Snippet Templates: Expand common structures like
FOR...TO...NEXT, IF...THEN, DEF FN, and PRINT AT with interactive tab stops.
- Control Code Completion: Typing inside
{ in string literals suggests bas2tap control codes (INK, PAPER, FLASH, BRIGHT, INVERSE, OVER, AT, TAB, CODE).
- Label Completion in
.jbas: Typing @ automatically suggests jump labels defined across the current document.
- Standard VS Code Formatting: Formats full document or selection with
Shift+Alt+F, right-click "Format Document", or on save via editor.formatOnSave.
- Converts All Keywords to UPPERCASE: Ensures authentic Sinclair BASIC appearance and style.
- Zero False Positives:
- Text inside double quotes (
"...") is 100% strictly preserved.
REM comments and JBAS single-quote comments (' ...) are 100% strictly preserved.
- JBAS
@labels are strictly preserved.
- Variables containing keyword substrings (e.g.
score, total, stopwatch, point1) are never touched.
4. Intelligent Line Renumbering (.bas)
- Renumbers program lines starting at line 10 with step 10 (or user-configured values).
- Automatically updates all jump and line references:
GO TO / GOTO
GO SUB / GOSUB
RESTORE
RUN
LINE
THEN <line>
- Multi-target computed jumps:
ON x GO TO 10, 20, 30
- Zero false positives: Strings (
PRINT "GOTO 10") and REM comments are completely untouched.
5. Subroutine Code Folding (.bas)
- Semantic Subroutine Folding: Detects function calls using
GO SUB <line> or GOSUB <line> (as well as computed multi-targets like ON x GOSUB 100, 200).
- Folds the subroutine body starting at its target definition line and ending at its corresponding
RETURN statement.
- Fully protects against false positives in string literals and
REM comments.
- Notice:
.jbas files use modular @labels without line numbers and preserve their own standard structural folding.
6. Jump Target Navigation / Go to Definition (Ctrl+Click / F12)
- Interactive Navigation in
.bas: Hold Ctrl (or Cmd on macOS) and click on any target line number following GO SUB, GOSUB, GO TO, GOTO, RUN, RESTORE, or computed jumps (ON x GO SUB 100, 200) to jump directly to that line definition in the code.
- Interactive Navigation in
.jbas: Ctrl+Click on @label jumps directly to @label:.
- Zero False Positives: Does not trigger on coordinates (
PRINT AT 10, 20), variable assignments, string literals ("GO SUB 500"), or comments (REM GO SUB 500).
7. Interactive BASIC Debugger (Native VS Code DAP + Turbo80)
- Native VS Code Debugging Experience (DAP): Full step-by-step debugger integrated with VS Code's native floating debug toolbar, Variables inspector, and Call Stack panels.
- Full Speed with Zero Overhead: Intercepts the ZX Spectrum 48K ROM statement dispatcher (
0x1B3D) via native Turbo80 breakpoint conditions (bpConds), running at full 50 FPS emulation speed without throttling until a breakpoint or step is hit.
- Control with Native VS Code Shortcuts:
F5: Start / Continue execution.
F6: Pause execution at current statement.
F10: Step Over (Line-by-line step).
F11: Step Into (Statement-by-statement step, traversing multi-statement lines LET a=1: LET b=2).
Ctrl+Shift+F5: Restart debugging session.
Shift+F5: Stop debugging and close emulator.
- Statement-Level Inline Breakpoints (
Shift+F9): Set breakpoints on individual statements within the same line, clicking internal glyphs or using Shift+F9. Turbo80 tracks both the line (PPC 0x5C45) and statement index (SUBPPC 0x5C47).
- Live RAM Variable Inspection: Decodes the Sinclair BASIC RAM variable table in real time:
- Numbers (5-byte Sinclair floating-point format).
- Text strings (with byte-by-byte length and character code inspection).
FOR loop control variables (current value, limit, step, loop line).
- Transparent Source Mapping (
.jbas <-> .bas): Place breakpoints directly in .jbas source files. Line mapping automatically translates breakpoints to compiled .bas TAP lines, scanning forward through comments and whitespace, and pauses on the exact statement in the active .jbas file.
- Clean Retro Display: The emulator screen remains 100% clean and authentic without cluttered UI buttons, letting VS Code handle all debug controls.
- Built-in Pure JavaScript TAP Generator: Blazing fast, zero external dependencies (no
bas2tap executable required). Automatically encodes Sinclair BASIC keywords, Spectrum floating-point numbers, UDGs, and headers with autostart line. Full byte-for-byte parity with bas2tap whitespace rules, avoiding unwanted double spaces when programs are listed by the ZX Spectrum ROM (e.g., LET py=0, CHR$ 18). An optional fallback to external bas2tap is available via settings.
- Built-in Web Emulator (Turbo80): Instant execution inside a VS Code tab with zero external installs. Features authentic audio, CRT shader effects, 48K/128K model selection, and on-screen keyboard support.
- Instant Web Sharing via Turbo80.com: Generate a public, shareable link with one click (
Sinclair BASIC: Share on Turbo80.com). Compiles your .bas or .jbas to .tap (or takes any existing .tap), uploads it, copies the https://turbo80.com/?load=... link directly to your clipboard, and lets your friends and colleagues test your game immediately in any browser with zero setup.
- External Desktop Emulator Support: One-click build and launch in external emulators (e.g. Fuse, CSpect, Retro Virtual Machine) if preferred.
9. Import Sinclair BASIC & JBAS from TAP Files
- One-Click TAP Import: Right-click any
.tap file in the Explorer (or run Sinclair BASIC: Import BAS and JBAS from TAP from the Command Palette) to instantly extract the Sinclair BASIC program stored on the tape.
- Dual Output Formats:
- Standard Sinclair BASIC (
.bas): Full numbered source code reconstructing all statements, functions, operators, and screen attributes.
- Modern Pseudo-Language (
.jbas): Converts jump targets (GO TO, GO SUB, THEN, RESTORE, etc.) to clean @labels, converts REM to modern ' single-quote comments, removes line numbers, and automatically indents routine bodies.
- Full Encoding & Control Code Fidelity: Automatically detokenizes Sinclair BASIC tokens, decodes hidden floating-point numbers (including protected loader lines), UDGs (
{A}..{U}), control codes ({PAPER n}, {INK n}, {AT row, col}, {TAB x}, {CODE n}), and special characters ({(c)}, £).
- Instant Editor Opening: Opens the extracted code directly in the VS Code editor with full syntax highlighting, navigation, and debugging support.
10. Authentic ZX Spectrum +3 BASIC Retro Mode
- One-Click Retro Mode Toggle: Click the
$(sparkle) ZX Retro: ON/OFF status bar item or run Sinclair BASIC: Toggle Retro Mode.
- Authentic +3 BASIC 3-Sound Audio Engine:
- Line Confirmation Tone on Enter (
media/sound/zx_click.wav): When you submit a syntactically valid line of BASIC, emits the authentic positive line acceptance tone (105 ms) and automatically formats keywords to UPPERCASE.
- Syntax Error Buzz on Enter (
media/sound/zx_error.wav): If the line has a syntax error (e.g. unclosed quotes, invalid statements, missing line numbers in .bas), emits the authentic ZX Spectrum warning/error rasp buzz (255 ms).
- Cursor Navigation Click (
media/sound/zx_cursor.wav): Emits the subtle mechanical keyboard tick (22 ms) when navigating lines or moving the cursor with arrow keys (throttled to 55 ms to match genuine key-repeat cadence).
- Zero Latency: Sounds are pre-loaded in memory via a persistent background audio engine.
- Auto-Uppercase Formatting on Enter: When you press
Enter on a valid line, all Sinclair BASIC keywords are instantly formatted to UPPERCASE (print "hello" -> PRINT "hello"), strictly preserving string literals ("...") and comments (REM, ').
- +3 BASIC Line Number Substitution: When you enter a numbered BASIC line (
.bas) whose line number already exists in the document and press Enter, it automatically replaces the existing line with the new formatted content and cleans up the input line, emulating the ZX Spectrum +3 BASIC statement entry. Typing only a line number (e.g. 10 + Enter) deletes that line from the program.
- Direct
RUN Command: In Retro Mode, typing run (without a line number) and pressing Enter formats it to RUN, plays the confirmation OK beep, removes the RUN command line from your source code, and immediately launches the emulator.
- Clean Retro Display (Zero Distractions): Automatically applies authentic ZX Spectrum +3 Paper 7 / Border 7 (
#D9D9D9) background and blue block cursor (#2A2AF0), sets the bold 8x8 ZX Spectrum font, displays the +3 BASIC bottom bar with the 4 diagonal Spectrum stripes, closes the bottom panel, and hides tabs, breadcrumbs, minimap, and line numbers margin for true ZX Spectrum immersion.
- 100% Reversible Switch: Toggling off (even after restarting VS Code) instantly restores the user's original theme, tabs, breadcrumbs, colors, font, minimap, line numbers, and single-group editor layout.
Commands & Shortcuts
All commands are accessible from the Command Palette (Ctrl+Shift+P / Cmd+Shift+P), the editor toolbar (top-right buttons), editor context menu, and Explorer file context menu:
| Command |
Identifier |
Shortcut |
Description |
| Debug in Web Emulator (Turbo80) |
sinclairBasic.debugTurbo80 |
F5 |
Starts interactive step-by-step debugging in Turbo80 with native VS Code debug bar and variable inspection. |
| Compile JBAS to TAP |
sinclairBasic.compileJBas |
Ctrl+Shift+B |
Generates .bas versions in dist/ (including <name>.sinclair.bas translating bas2tap wildcards to standard CHR$) and builds .tap from the optimal 1x1 version. |
| Transpile JBAS to BAS |
sinclairBasic.transpileJBas |
Ctrl+Shift+T |
Generates 4 versions in dist/ (<name>.bas 1x1, <name>-step10.bas, <name>-comments.bas, and <name>.sinclair.bas with standard CHR$) and opens step10 in editor. |
| Compile BAS to TAP |
sinclairBasic.compileBas / buildTap |
Ctrl+Shift+B |
Compiles .bas directly to .tap and generates dist/<name>.sinclair.bas translating bas2tap wildcards to standard CHR$. |
| Import BAS and JBAS from TAP |
sinclairBasic.importTap |
— |
Decodes a .tap file and extracts both standard .bas and modern .jbas versions. |
| Import BAS from TAP |
sinclairBasic.importTapToBas |
— |
Extracts standard numbered .bas from a .tap file. |
| Import JBAS from TAP |
sinclairBasic.importTapToJBas |
— |
Extracts modern .jbas (with @labels and ' comments) from a .tap file. |
| Share on Turbo80.com |
sinclairBasic.shareTurbo80 |
— |
Compiles/locates .tap, uploads it, and copies a ready-to-play https://turbo80.com/?load=... link to clipboard. |
| Format Keywords to Uppercase |
sinclairBasic.formatKeywords |
Shift+Alt+F |
Formats document or selection converting all Sinclair BASIC keywords to uppercase (preserving strings and comments). |
| Renumber BAS Lines (.bas) |
sinclairBasic.renumber / renumberBas |
Ctrl+Alt+R |
Renumbers lines in .bas (10 by 10) and updates all jump references (GOTO, GOSUB, RESTORE, etc.). |
| Run in Emulator |
sinclairBasic.runEmulator |
Ctrl+F5 |
Compiles to TAP and launches the configured emulator (built-in Turbo80 Webview or external Fuse). |
| Run in Web Emulator (Turbo80) |
sinclairBasic.runTurbo80 |
— |
Forces execution in the built-in Turbo80 web emulator tab. |
| Run in External Emulator |
sinclairBasic.runExternalEmulator |
— |
Forces execution in the configured external desktop emulator. |
| Toggle Retro Mode |
sinclairBasic.toggleRetroMode |
— |
Toggles authentic +3 BASIC retro mode (paper 7 white canvas, ZX 8x8 font, line audio feedback). |
Configuration Settings
You can customize the extension via VS Code Settings (settings.json):
{
"sinclairBasic.retroMode.enabled": false,
"sinclairBasic.retroMode.beepOnEnter": true,
"sinclairBasic.retroMode.beepOnError": true,
"sinclairBasic.retroMode.beepOnCursor": true,
"sinclairBasic.retroMode.formatOnEnter": true,
"sinclairBasic.retroMode.replaceExistingLine": true,
"sinclairBasic.replaceExistingLineNumber": false,
"sinclairBasic.emulatorType": "turbo80",
"sinclairBasic.turbo80Model": "48k",
"sinclairBasic.turbo80Crt": true,
"sinclairBasic.emulatorPath": "C:\\Program Files (x86)\\Fuse\\fuse.exe",
"sinclairBasic.emulatorArgs": [],
"sinclairBasic.outputDirectory": "dist",
"sinclairBasic.autoStartLine": 0,
"sinclairBasic.renumberStart": 10,
"sinclairBasic.renumberStep": 10,
"sinclairBasic.optimizePrintAttributes": true
}
sinclairBasic.retroMode.enabled: Enables authentic ZX Spectrum retro experience with keyclick sound on Enter and auto-formatting.
sinclairBasic.retroMode.beepOnEnter: Emits authentic Sinclair ZX Spectrum 48K ROM keyclick tone (~987 Hz square wave) upon pressing Enter.
sinclairBasic.retroMode.formatOnEnter: Automatically formats Sinclair BASIC keywords to UPPERCASE upon pressing Enter on a line.
sinclairBasic.optimizePrintAttributes: Enabled by default (true). Automatically folds constant PRINT attributes (AT, PAPER, INK, FLASH, BRIGHT, etc.) into compact control code strings for peak ZX Spectrum execution speed while letting developers write standard, natural Sinclair BASIC in .jbas.
sinclairBasic.emulatorType: Set to "turbo80" (default, opens embedded web emulator) or "external" (launches Fuse or desktop emulator).
sinclairBasic.turbo80Model: Emulated ZX Spectrum machine (48k, 128k, plus2, plus2a, plus3, 16k).
sinclairBasic.turbo80Crt: Enables/disables authentic CRT television shader filter.
sinclairBasic.autoStartLine: When set to 0, the extension automatically detects the first line number in the BASIC file.
Acknowledgements & Credits
- Turbo80 (Built-in Offline ZX Spectrum Emulator): Powered by Turbo80 created by José Enrique García (Incinerator). Bundled locally for 100% offline emulation without requiring an active internet connection.
- ROMs & Legal Notice:
- Amstrad: Copyright holder of the Sinclair ZX Spectrum (16K, 48K, Spectrum+, 128K) and Amstrad (+2, +2A, +3) ROMs (© 1982-1987 Sinclair Research Ltd / Amstrad), with permission kindly granted for redistribution with emulators ("Amstrad have kindly given their permission for the redistribution of their copyrighted material but retain that copyright").
- Timex: TC2048, TC2068, and TS2068 ROM modifications are in the public domain.
- Interface 1: ROM is © 1983 Sinclair Research Ltd.
- esxDOS: esxDOS 0.8.9 (© 2005-2021 Papaya Dezign, Miguel Guerreiro, https://esxdos.org/) included with permission.
- +D and DISCiPLE: ROMs included with permission from Datel.
- ZXDB: Software metadata powered by ZXDB (Einar Saukas and contributors, ODbL 1.0) and World of Spectrum.
Development & Debugging
- Clone and open this repository in Visual Studio Code:
git clone https://github.com/rtorralba/vscode-sinclair-basic.git
cd vscode-sinclair-basic
code .
- Press
F5 (or go to Run and Debug -> Run Sinclair BASIC Extension).
- A new Extension Development Host window will open.
- Open any
.bas or .jbas file (such as in your game project) and test syntax highlighting, commands, and shortcuts!
Running Automated Tests
Run the standalone Node test runner (zero external dependencies required):
npm test
License & Copyright
GNU Affero General Public License v3.0 (AGPL-3.0).
Copyright (C) 2026 Raül Torralba.
Renuncia de garantía / Disclaimer (AS IS): El software se proporciona "tal cual" (AS IS), sin garantía de ningún tipo, expresa o implícita. En ningún caso el autor será responsable de ningún reclamo, daño u otra responsabilidad derivada del uso de este software.
See the full LICENSE file for complete details.
