Raspberry Pi Pico Visual Studio Code extension

Note: The extension is currently under development.

This is the official Visual Studio Code extension for Raspberry Pi Pico development. This extension equips you with a suite of tools designed to streamline your Pico projects using Visual Studio Code and the official Pico SDK.

For comprehensive setup instructions, refer to the Getting Started guide PDF.

Download latest Beta 📀

Features

Project Setup and Management

Project Generator: Easily create and configure new projects with support for advanced Pico features like I2C and PIO. The generator targets the Ninja build system and allows customization during project creation.
Quick Project Setup: Initiate new Pico projects directly from the Explorer view, when no workspace is open.
MicroPython Support: Create and develop MicroPython-based Pico projects with support provided through the MicroPico extension.

Configuration and Tool Management

Automatic CMake Configuration: Automatically configures CMake when loading a project.
Version Switching: Seamlessly switch between different versions of the Pico SDK and tools.
No Manual Setup Required: Automatically handles environment variables, toolchain, SDK, and tool management.
Includes an Uninstaller: Easily remove the extension along with all automatically installed tools and SDKs.

Build, Debug, and Documentation

One-Click Compilation and Debugging: Automatically configure OpenOCD, Ninja, and CMake, allowing you to compile and debug with a single click.
Offline Documentation: Conveniently access Pico SDK documentation directly within the editor, even when offline.
Version Switching: Seamlessly switch between different versions of the Pico SDK and tools.
No Manual Setup Required: The extension handles environment variables, toolchain, SDK, and tool management for you.
One-Click Compilation: Compile projects directly from the status bar with your selected SDK and tools.
Offline Documentation: Access Pico SDK documentation offline.
Quick Project Setup: Quickly create new Pico projects from the Explorer view when no workspace is open.
MicroPython Support: Create MicroPython-based Pico projects with support provided through the MicroPico extension.

Requirements by OS

Supported Platforms: Raspberry Pi OS (64-bit), Windows 10/11 (x86_64), macOS Sonoma (14.0) and newer, Linux x64 and arm64

Visual Studio Code v1.92.1 or later

Raspberry Pi OS and Windows

No additional requirements are needed.

macOS

To meet the requirements for macOS, run the following command in Terminal to install necessary tools:

xcode-select --install

This command installs all of the necessary tools, including but not limited to:

Git 2.28 or later (ensure it's in your PATH)
Tar (ensure it's in your PATH)

Linux

Python 3.9 or later (ensure it’s in your PATH or set in settings)
Git 2.28 or later (ensure it’s in your PATH)
Tar (ensure it’s in your PATH)
[Optional] gdb-multiarch for debugging (x86_64 only)
[Optional] udev rules installed to use OpenOCD and picotool without sudo, for debugging and loading
For [Ubuntu 22.04], install libftdi1-2 and libhidapi-hidraw0 packages to use OpenOCD

Extension Settings

This extension provides the following settings:

raspberry-pi-pico.cmakePath: Specify a custom path for CMake.
raspberry-pi-pico.python3Path: Specify a custom path for Python 3 (machine scoped).
raspberry-pi-pico.ninjaPath: Specify a custom path for Ninja.
raspberry-pi-pico.gitPath: Specify a custom path for Git.
raspberry-pi-pico.cmakeAutoConfigure: Provide a GitHub personal access token (classic) with the public_repo scope. This token is used to check for available versions of the Pico SDK and other tools. Without it, the extension uses the unauthenticated GitHub API, which has a lower rate limit and may lead to restricted functionality if the limit is exceeded. The unauthenticated rate limit is per public IP address, so a token is more necessary if your IP is shared with many users.

CMake Tools Extension Integration

For more complex projects, such as those with multiple executables or when the project name is defined as a variable, this extension can integrate with the CMake Tools extension to enhance CMake parsing. You can enable CMake Tools integration during project generation under the Advanced Options. Additionally, to manually enable it, adjust the following settings in your settings.json:

raspberry-pi-pico.cmakeAutoConfigure: Set from true to false.
raspberry-pi-pico.useCmakeTools: Set from false to true.

For optimal functionality, consider enabling:

cmake.configureOnEdit: true
cmake.automaticReconfigure: true
cmake.configureOnOpen: true

When prompted, select the Pico kit in CMake Tools, and set your build and launch targets accordingly. Use CMake Tools for compilation, but continue using this extension for debugging, as CMake Tools debugging is not compatible with Pico.

VS Code Profiles

If you work with multiple microcontroller toolchains, consider installing this extension into a VS Code Profile to avoid conflicts with other toolchains. Follow these steps:

Download the sample profile from here.
Open Command Palette with Ctrl+Shift+P (or Cmd+Shift+P on macOS) and select Profiles: Import Profile.
Import the downloaded file to install the extension in a dedicated Pico profile.
This setup helps isolate the Pico extension from other extensions, reducing the risk of conflicts.

Known Issues

Custom Paths: Custom paths for Ninja, Python3, and Git are not stored in CMakeLists.txt like SDK and Toolchain paths. You need to build and configure projects through the extension to use these custom paths.

GitHub API Rate Limit ("Error while retrieving SDK and toolchain versions")

If you encounter issues retrieving available Pico SDK versions, it may be due to GitHub API rate limits. To resolve this, create a personal access token (classic PAT) with the public_repo scope and set it in the global (User) extension settings to increase your rate limit.

Build Instructions

For advanced users who want to build the extension .vsix file, follow these steps:

Install nodejs (Instructions Windows)
Install Yarn globally: npm install -g yarn
Install VSCE globally: npm install -g @vscode/vsce
Run yarn in the project directory to install dependencies.
Build the extension with: vsce package.

This will generate a .vsix file, which you can install in VS Code using code --install-extension path-to.vsix or via the GUI: Extensions > three dots > Install from VSIX.
