RISC-V Toolchain

Build, disassemble, and convert RISC-V programs directly from VS Code using a Docker-based GNU toolchain.

🚀 Compile RISC-V code right on Windows! No need to switch to Linux or set up complex toolchains. Just install this extension, run Docker Desktop, and you're ready to build, disassemble, and flash RISC-V programs—all from within VS Code.

Features

Sidebar Build Panel

A dedicated sidebar panel provides quick access to all build controls including architecture selection, optimization levels, and bare-metal configuration.

One-Click Compilation

Compile C/C++ source files to RISC-V ELF executables with a single click. The extension automatically detects open C/C++ files in your workspace.

Bare-Metal Mode

Enable the Bare-Metal toggle when you want to compile code for running directly on hardware without an operating system. This mode:

• Uses minimal startup code (crt0) for proper CPU initialization
• Links with a bare-metal linker script for memory layout control
• Produces standalone executables suitable for embedded systems, FPGAs, or RISC-V simulators
• Perfect for writing bootloaders, firmware, or hardware test programs

Disassembly Viewer

View the compiled assembly output with syntax highlighting. Filter the disassembly using grep patterns to find specific instructions or symbols.

Using the Filter Feature

The filter input allows you to search through disassembly output using grep patterns:

• Enter a function name (e.g., main) to jump to that symbol
• Use instruction patterns (e.g., addi, lw, sw) to find specific operations
• Search for register names (e.g., a0, sp) to track register usage
• Combine patterns with \| for multiple matches (e.g., main\|loop)

Binary Conversion

Convert ELF executables to raw binary format suitable for flashing to embedded devices or FPGA memory initialization.

Integrated Error Highlighting

GCC compiler errors and warnings are parsed and displayed directly in the VS Code editor with proper line highlighting and problem panel integration.

Custom Linker and Startup Scripts

You can compile using your own linker scripts and startup assembly files for full control over memory layout and initialization:

• Provide a custom linker script (.ld) to define memory regions, section placement, and entry points
• Supply your own startup code (crt0.S) to handle stack setup, BSS clearing, and hardware initialization
• Place custom scripts in your project directory and the toolchain will use them automatically when bare-metal mode is enabled

Make and Bash Scripts for Automation

For advanced workflows, you can use Makefiles or Bash scripts with the Docker toolchain:

Example Makefile:

CC = docker run --rm -v $(PWD):/work ranaumarnadeem/riscv-toolchain riscv64-unknown-elf-gcc
CFLAGS = -march=rv32imac -mabi=ilp32 -O2

all: program.elf

program.elf: main.c
	$(CC) $(CFLAGS) -o /work/$@ /work/$<

Example Bash Script:

#!/bin/bash
DOCKER_IMAGE="ranaumarnadeem/riscv-toolchain"
docker run --rm -v "$(pwd):/work" $DOCKER_IMAGE \
    riscv64-unknown-elf-gcc -march=rv32imac -mabi=ilp32 -O2 \
    -o /work/output.elf /work/main.c

Architecture Support

Support for multiple RISC-V architecture configurations:

• RV32I, RV32IM, RV32IMAC, RV32IMAFC
• RV64I, RV64IM, RV64IMAC, RV64IMAFC
• Custom architecture strings

Optimization Levels

Choose from standard GCC optimization levels:

• O0 (No optimization)
• O1 (Basic optimization)
• O2 (Recommended)
• O3 (Aggressive optimization)
• Os (Optimize for size)
• Oz (Aggressive size optimization)

Requirements

• Docker Desktop installed and running
• Pull the Docker image before first use:

docker pull ranaumarnadeem/riscv-toolchain

Getting Started

1. Install Docker Desktop and ensure it is running
2. Pull the RISC-V toolchain Docker image
3. Open a C or C++ file in your workspace
4. Click the RISC-V icon in the activity bar to open the sidebar
5. Select your target architecture and optimization level
6. Click Build to compile your program

Extension Settings

This extension contributes the following settings:

• riscv-toolchain.dockerImage: Docker image to use for compilation (default: ranaumarnadeem/riscv-toolchain)
• riscv-toolchain.defaultArch: Default architecture preset (default: 32imac)
• riscv-toolchain.defaultOptimization: Default optimization level (default: O2)
• riscv-toolchain.bareMetal: Use bare-metal build by default (default: false)

Commands

The extension provides three main action buttons in the sidebar:

Build Button

Compiles your C/C++ source file into a RISC-V ELF executable. This runs the GCC compiler with your selected architecture, optimization level, and bare-metal settings. The resulting .elf file contains the compiled program with debug symbols.

Dump Button (Disassemble)

Disassembles the compiled ELF file and displays the assembly instructions in a new editor tab. Use this to:

• Verify the compiler generated the expected instructions
• Debug optimization issues
• Understand how your C code translates to RISC-V assembly
• Check instruction encodings for specific extensions (e.g., compressed, floating-point)

Binary Button

Converts the ELF executable to a raw binary file (.bin). This strips all headers and debug information, producing a flat binary image suitable for:

• Flashing directly to embedded device memory
• Loading into FPGA block RAM
• Initializing memory in HDL simulations
• Burning to ROM/Flash chips

• RISC-V: Build - Compile the current file
• RISC-V: Disassemble - View disassembly of compiled ELF
• RISC-V: Convert to Binary - Convert ELF to raw binary
• RISC-V: Select Source File - Choose a source file to build
• RISC-V: Refresh - Refresh the sidebar panel

Troubleshooting

Docker not found

Ensure Docker Desktop is installed and the Docker daemon is running. You can verify by running docker --version in a terminal.

Build fails with permission errors

On Linux/macOS, ensure your user has permission to run Docker commands without sudo. Add your user to the docker group:

sudo usermod -aG docker $USER

Image not found

Pull the toolchain image manually:

docker pull ranaumarnadeem/riscv-toolchain

License

MIT License - see the LICENSE file for details.
