SV Matchit — Custom Keyword Jump

Jump/select between keyword pairs, not just brackets — built for HDL languages like SystemVerilog where a single file nests module → class → `ifdef → function → begin/end → fork/join_any many levels deep, and VS Code's built-in "Jump to Bracket" (Ctrl+Shift+\) has no idea begin should jump to its end.

This extension binds to the same Ctrl+Shift+\ shortcut and acts as a drop-in replacement for the built-in command, understanding language keywords in addition to brackets.

Features

• Jump (Ctrl+Shift+\) — place the cursor on any configured open/close keyword and jump to its match, correctly skipping over nested pairs of the same kind.
• Select (svMatchit.select) — same lookup, but selects the exact character range from the open keyword to the close keyword.
• Select full lines (svMatchit.selectLines) — same lookup, but expands the selection to whole lines instead of the exact character range — handy for yanking or deleting an entire begin…end / `ifdef…`endif block in one motion.
• Built-in SystemVerilog keyword set — module/endmodule, class/endclass, function/endfunction, task/endtask, begin/end, case/casex/casez/randcase → endcase, fork → join/join_any/join_none, covergroup → endgroup, common `uvm_*_utils_begin/end macros, and more — works out of the box, no settings.json config required.
• Preprocessor-aware — `ifdef/`ifndef/`elsif/`else/`endif branches are matched as a mutually-exclusive chain, so an imbalance inside one `ifdef branch never corrupts matching in a sibling branch or the surrounding code.
• Fully configurable / extensible — add your own pairs or override the defaults per languageId via settings.json, for any language, not just SystemVerilog.
• Diagnostics built in — SV Matchit: Find Unmatched Keyword scans the whole file and lists every unmatched open and every stray close, jumping straight to the first one, so tracking down a missing end/endfunction/`endif doesn't mean bisecting the file by hand.

Commands

None of these ship with a default keybinding except svMatchit.jump (Ctrl+Shift+\ / Cmd+Shift+\) — wire the rest up to whatever key you like.

Configuration

Two independent, combinable sources of keyword pairs. Both are optional — the built-in SystemVerilog defaults work with zero configuration.

matchit.brackets — literal pairs, supports many-to-one / one-to-many

"matchit.brackets": {
    "systemverilog": [
        ["begin", "end"],
        ["fork", "join"],
        ["fork", "join_any"],
        ["fork", "join_none"],
        ["class", "endclass"]
    ]
}

Anything you list here is merged with the built-in defaults for that languageId (duplicates are automatically de-duplicated, so re-declaring a default pair is harmless). Use this to add project-specific macros or a different language entirely.

Do not add `ifdef/`ifndef/`endif here — those are handled by a dedicated, branch-aware matcher (see Features above) so that a missing `endif in one conditional branch doesn't cascade into every branch after it. Declaring them again in matchit.brackets re-introduces exactly that failure mode.

matchit.matchingKeywords — regex pairs, strict 1:1

"matchit.matchingKeywords": {
    "bsv": [
        ["\\brule\\b", "\\bendrule\\b"],
        ["\\baction\\b", "\\bendaction\\b"]
    ]
}

Use this when a pair needs full regex control and there's exactly one opener and one closer (no many-to-one / one-to-many cases).

Requirements

VS Code ^1.74.0. No other dependencies.

Known limitations

• Matching is a single flat stack shared across every configured pair in the file: any open/close keyword pair present anywhere in the document participates in the same nesting check as every other pair. This is what makes deep, mixed-keyword nesting (module → `ifdef → case → fork/join_any) resolve correctly, but it also means a genuinely missing closer anywhere in the file can surface as a "no match" error on an unrelated, correctly-written keyword elsewhere. Run SV Matchit: Find Unmatched Keyword to locate the actual source.
• Comments (//, /* */) and string literals ("...") are stripped before matching, so keywords mentioned inside them are ignored — but only double-quoted strings are recognized as strings.

Release Notes

See CHANGELOG.md.

License

MIT © quindeptrai
