QuantumLang for VS Code

Official QuantumLang language support by Quantum Technology.

This extension keeps VS Code integration thin and reliable. It launches the qtlc compiler in language-server mode, forwards editor requests, and displays the results. Parsing, diagnostics, semantic analysis, formatting, rename, code actions, package routing, and cache ownership remain inside qtlc.

Features

• Syntax highlighting for .qn files.
• .qn language/page icons without replacing the user's active file icon theme.
• Diagnostics from qtlc server.
• Hover, go-to-definition, and completion.
• Document symbols and semantic-token support.
• Code actions and code-action resolve for import fixes and rename preview.
• Formatting, range formatting, prepare-rename, and rename.
• Build and run commands that call the configured qtlc binary.
• Package-root and target selection for multi-root workspaces.
• Preflight and cache-dashboard commands for troubleshooting.

Requirements

Install qtlc before using the extension. The extension does not bundle the compiler.

Recommended Linux install path:

sudo ./qtlc/scripts/install-system.sh
qtlc --version

The default extension setting is:

"quantumlang.qtlcPath": "qtlc"

If qtlc is not on PATH, set quantumlang.qtlcPath to an absolute binary path. On Linux this is often /usr/local/bin/qtlc.

See qtlc/docs/INSTALL.md for user-local, system, custom-prefix, dry-run, and uninstall details. After installing qtlc on PATH, the extension can keep the default quantumlang.qtlcPath value of qtlc.

Quick Start

1. Install or build qtlc.
2. Open a folder with quantum.toml or a .qn file.
3. Run QuantumLang: Preflight.
4. Run QuantumLang: Restart Language Server.
5. Open a .qn file and check diagnostics, hover, and completion.

For installed-extension smoke testing, use:

installed-smoke-workspace/

That workspace has no repo-relative settings, so it proves the installed extension can find an installed compiler.

Commands

• QuantumLang: Select Package Root
• QuantumLang: Build
• QuantumLang: Run
• QuantumLang: Show Server Output
• QuantumLang: Preflight
• QuantumLang: Restart Language Server
• QuantumLang: Cache Dashboard
• QuantumLang: Cache Summary
• QuantumLang: Clear Current Package Cache
• QuantumLang: Clear Code-Action Cache
• QuantumLang: Format Document
• QuantumLang: Rename Symbol

Build and run commands open VS Code terminals in the selected package root and call the configured quantumlang.qtlcPath.

Settings

{
  "quantumlang.qtlcPath": "qtlc",
  "quantumlang.packageTarget": "app",
  "quantumlang.traceProtocol": false,
  "quantumlang.format.trimTrailingWhitespace": true,
  "quantumlang.format.ensureFinalNewline": true
}

quantumlang.qtlcPath supports absolute paths and ${workspaceFolder}.

quantumlang.packageTarget selects the package target used by editor queries when a package has more than one target.

quantumlang.traceProtocol asks the server for compact protocol traces while debugging editor integration.

Language Server Boundary

VS Code extension
  -> qtlc server process
  -> newline-delimited JSON-RPC requests
  -> compiler query and code-action products
  -> JSON-RPC responses and publishDiagnostics notifications

The TypeScript extension owns editor transport only:

• start, stop, and restart qtlc server
• send document lifecycle messages
• forward hover, definition, completion, formatting, rename, and code-action requests
• display diagnostics and workspace edits returned by the server
• show status, preflight, cache, and server-output UI

Compiler behavior stays in qtlc.

Syntax Highlighting

The extension contributes a TextMate grammar at:

syntaxes/quantumlang.tmLanguage.json

It provides stable scopes for keywords, imports, function declarations, function calls, primitive types, strings, numbers, comments, operators, and punctuation. The active VS Code color theme controls the final colors.

File Icons

The extension contributes light and dark icons on the quantumlang language registration. They are intended as .qn language/page icons:

image/qn-file-dark.svg
image/qn-file-light.svg

The extension does not contribute a full VS Code file-icon theme, because VS Code allows only one active Explorer icon theme at a time. Shipping a complete QuantumLang icon theme would replace the user's Material/Icon Set/Codicons theme and make other file icons disappear.

If the active file-icon theme supports language icons or has no mapping for .qn, VS Code can show the QuantumLang icon for .qn files. If the active file-icon theme overrides unknown files with its own default document icon, .qn files may use that theme's default until the theme itself adds a QuantumLang mapping.

Package Routing

Editor requests use the nearest parent quantum.toml for the active .qn document. This keeps nested sample projects and multi-root workspaces routed to the correct package root.

The selected package root is persisted in workspace state. The selected package target appears in the status bar and in hover/status details so it is clear which compiler context answered a request.

Local Development

From the repository root:

cmake --build qtlc/build
cd qtlc/ide/vscode
npm install
npm run compile

Open qtlc/ide/vscode in VS Code and run the Run QuantumLang Extension launch configuration. It opens the bundled sample workspace:

sample-workspace/

The sample workspace contains:

quantum.toml
src/main.qn
src/math.qn

Use it to test diagnostics, hover, go-to-definition, completion, formatting, rename, and code actions without touching compiler fixtures.

Protocol Smoke

After npm install, run:

npm run smoke:protocol

Set QTLC_PATH=/absolute/path/to/qtlc if the default built binary path is not correct. If node_modules/ is not present, the smoke exits as skipped so C++ test flows do not require Node dependencies.

Packaging

Build and inspect an installable .vsix package:

cd qtlc/ide/vscode
npm install
npm run package:check
npm run package:vsix

Release metadata can be checked without building the full package:

npm run package:release-check

The package is written to:

dist/quantumlang-0.1.0.vsix

Packaging uses:

vsce package --no-dependencies

The extension is a transport adapter and does not bundle compiler/runtime logic. Users install qtlc separately.

Release packages keep the public project documents visible in the VSIX: README.md, CHANGELOG.md, and LICENSE.md.

If a previous packaging run accidentally created a file named dist, run:

npm run package:prepare-output
npm run package:vsix

The standalone extension .gitignore keeps node_modules/, out/, dist/, local .vsix packages, extension-host test folders, logs, coverage, and local editor state out of the qtlang-vscode repository.

The .vscodeignore file keeps source, sample workspaces, local launch files, installed dependencies, and development-only scripts out of the packaged extension.

Install Local VSIX

code --install-extension dist/quantumlang-0.1.0.vsix --force

Then run:

Developer: Reload Window
QuantumLang: Restart Language Server

VSIX Smoke

When Node dependencies and the VS Code CLI are available:

npm run smoke:vsix

The smoke builds the .vsix, checks that dist/*.vsix exists, and installs it with code --install-extension. If the VS Code CLI is missing, it reports a clean skip.

Platform Notes

• Linux: qtlc on PATH or an absolute path such as /usr/local/bin/qtlc should launch directly.
• macOS: VS Code launched from Finder may not inherit shell PATH; prefer an absolute quantumlang.qtlcPath.
• Windows: use C:\\path\\to\\qtlc.exe or ${workspaceFolder}\\path\\to\\qtlc.exe.

Preflight

QuantumLang: Preflight writes an operational report to the QuantumLang output channel:

• configured quantumlang.qtlcPath
• expanded active qtlc path
• qtlc --version
• selected package root
• selected package target
• checked-source cache health
• code-action cache health
• source snapshot counts and bytes
• recent memory-pressure notification count

Cache Tools

Cache tools are UI wrappers over server-owned debug methods:

• QuantumLang: Cache Dashboard
• QuantumLang: Cache Summary
• QuantumLang: Clear Current Package Cache
• QuantumLang: Clear Code-Action Cache

The extension only displays returned facts. Cache ownership and eviction decisions stay inside qtlc server.

Formatting And Rename

Formatting and rename are server-owned editor features. The extension forwards VS Code requests and applies returned edits. It does not format source or compute rename edits in TypeScript.

Supported paths:

• document formatting
• range formatting
• prepare-rename validation
• rename workspace edits
• public rename preview through codeAction/resolve

Formatting settings:

{
  "quantumlang.format.trimTrailingWhitespace": true,
  "quantumlang.format.ensureFinalNewline": true
}

Marketplace Metadata

Public extension identity:

Company:      Quantum Technology
Repository:   https://github.com/quantumgat/qtlang-vscode
Package:      quantumlang
Display name: QuantumLang
Publisher:    quantumtechnology
License:      MIT

Marketplace metadata:

• package name: quantumlang
• display name: QuantumLang
• publisher: quantumtechnology
• company: Quantum Technology
• license: MIT
• Q&A disabled, with support routed to project issues
• dark QuantumLang gallery banner
• GitHub packaging workflow badge
• workspace extension kind

Screenshots and demo assets must be approved before they are referenced from marketplace release notes. See release-assets/README.md.

Optional CI Packaging

The optional GitLab CI packaging job lives at:

.gitlab/ci/qtlc-vscode-vsix.yml

The job installs Node dependencies, runs npm run package:check, builds the .vsix, and publishes dist/*.vsix as short-lived CI artifacts.

Versioned Settings

Versioned setting migration notes live in:

MIGRATIONS.md

Update MIGRATIONS.md, CHANGELOG.md, and the manual smoke checklist when a release changes installed-user settings or command behavior.

Troubleshooting

For common setup, path, server-start, packaging, cache, formatting, and rename problems, see:

TROUBLESHOOTING.md
