Archctl - Architecture Linter for VS Code

Enforce clean architecture patterns and dependency rules with real-time feedback

Overview

The Archctl VS Code extension brings powerful architecture linting directly into your editor. Get instant feedback on architecture violations as you code, helping you maintain clean architecture patterns and enforce dependency rules across your codebase.

This extension integrates seamlessly with the Archctl CLI tool to provide real-time diagnostics for:

Layer Boundary Violations - Catch unwanted dependencies between architectural layers
Dependency Rule Violations - Enforce which modules can import from which layers
Circular Dependencies - Detect and eliminate cyclic dependencies
Architecture Pattern Enforcement - Maintain Clean Architecture, Hexagonal, or custom patterns

Getting Started

Prerequisites

Install Archctl CLI:
```
npm install -g archctl
```
Initialize your project:
```
cd your-project
archctl init
```
This creates a .archctl/archctl.config.json file that defines your architecture rules.

Install the Extension

Open VS Code
Go to Extensions (Ctrl+Shift+X / Cmd+Shift+X)
Search for "Archctl"
Click Install

Features

Real-Time Architecture Validation

The extension automatically runs architecture checks and displays violations as inline diagnostics:

Error Squiggles: Architecture violations appear directly in your code
Problems Panel: View all violations in the Problems panel
Hover Information: See detailed violation messages and suggestions
Auto-Run on Save: Checks run automatically when you save files (configurable)

Commands

Access these commands via the Command Palette (Ctrl+Shift+P / Cmd+Shift+P):

Archctl: Run Architecture Check - Manually trigger an architecture check
Archctl: Clear Diagnostics - Clear all architecture diagnostics

Smart Diagnostics

Each violation includes:

Rule ID: The specific rule that was violated
Severity: Error, Warning, or Info
Message: Clear description of the violation
Suggestion: Helpful hints on how to fix the issue (when available)
Location: Precise line and column information

Configuration

Configure the extension via VS Code settings:

`archctl.autoRunOnSave`

Type: boolean
Default: true
Description: Automatically run architecture checks when files are saved

`archctl.debounceDelay`

Type: number
Default: 1000 (milliseconds)
Description: Delay before running checks after file changes

Example Settings

{
  "archctl.autoRunOnSave": true,
  "archctl.debounceDelay": 1500
}

Supported File Types

The extension monitors changes to:

TypeScript (.ts, .tsx)
JavaScript (.js, .jsx, .mjs, .cjs)
Python (.py)
Java (.java)

How It Works

Activation: The extension activates when you open a workspace containing .archctl/archctl.config.json
File Watching: Monitors file changes in supported languages
Architecture Check: Runs archctl lint --format json to analyze your code
Diagnostics: Parses violations and displays them as VS Code diagnostics
Real-Time Updates: Re-runs checks automatically when files change (with debouncing)

Example Workflow

Define your architecture in .archctl/archctl.config.json:

{
  "layers": [
    { "name": "domain", "description": "Core business logic" },
    { "name": "application", "description": "Use cases" },
    { "name": "infrastructure", "description": "External integrations" }
  ],
  "rules": [
    {
      "kind": "allowed-layer-import",
      "id": "domain-isolation",
      "fromLayer": "domain",
      "allowedLayers": ["domain"]
    }
  ]
}

Write code that violates a rule:

// src/domain/user.ts
import { Database } from '../infrastructure/database'; // Violation!

See the violation immediately in your editor:
- Red squiggle under the import
- Error in Problems panel: "Layer 'domain' cannot import from 'infrastructure'"
- Suggestion: "Consider using dependency injection or moving this to the application layer"
Fix the violation and watch the diagnostic disappear automatically

Troubleshooting

Extension Not Working?

Check for config file: Ensure .archctl/archctl.config.json exists in your workspace root
Verify Archctl CLI: Run archctl lint in your terminal to confirm the CLI works
Check Output Panel: View "Archctl" in the Output panel for debug logs
Reload Window: Try reloading VS Code (Ctrl+Shift+P → "Developer: Reload Window")

No Diagnostics Appearing?

Ensure archctl.autoRunOnSave is enabled
Manually trigger a check: Command Palette → "Archctl: Run Architecture Check"
Check that your files match the configured layer mappings

Performance Issues?

Increase archctl.debounceDelay to reduce check frequency
Temporarily disable archctl.autoRunOnSave for large refactorings

Contributing

Found a bug or have a feature request? Please open an issue on the GitHub repository.

Development

Clone the repository:

git clone https://github.com/qiuethan/archctl.git
cd archctl/vscode-extension

Install dependencies:
```
npm install
```
Open in VS Code and press F5 to launch the Extension Development Host
Make changes and test in the development window

License

MIT License - see LICENSE for details
