Forma User Guide

Forma is a VS Code extension that converts Markdown into live document previews and PDFs. Open a Markdown file and use the Preview or PDF buttons in the editor title bar, or run commands from the Command Palette.

Japanese Version: 日本語版.

Initial Setup

1. Open a VS Code workspace containing your Markdown files.
2. If using project-specific templates, run Forma: Initialize Project Config once.
3. Edit the files generated inside the .forma directory at the root of the workspace, then open the preview with Forma: Open Preview.

This initialization command does not overwrite existing files. If a target file does not exist in the .forma directory, the extension's built-in defaults are used.

Exporting PDF

With the Markdown file active, run Forma: Export PDF. By default, <filename>.pdf is created in the same directory as the target Markdown file. The PDF uses the configurations defined in .forma/export.scss and puppeteer.json.

If you want the PDF to open automatically after export, set forma.common.useAutoOpenPDF to true. The default is false.

Project Files

As described in Initial Setup, running Forma: Initialize Project Config creates a .forma directory directly under the workspace root. This is the Forma configuration directory dedicated to that workspace. You can place the following files here:

• default.scss: Standard preview theme
• print.scss: Print preview theme applied when selected via theme: print
• export.scss: Dedicated theme used during PDF export
• parser.js: Defines hooks for transforming Markdown and HTML
• puppeteer.json: Settings for paper size, margins, browser launch arguments, destination, etc.

By defining forma.theme.libraries, forma.parser.libraries, and forma.puppeteer.libraries in your VS Code settings, you can use named libraries. For example:

// VSCode Configuration
{
  "forma.theme.libraries": [{ "name": "foo", "path": "@/path/to/foo.scss" }]
}

Note: @ is an alias representing the workspace root directory.

With this configured, you can select and use it from the Markdown front matter like this:

---
theme: foo
---

You can also change the names of configuration files to load by modifying forma.theme.entry, forma.parser.entry, and forma.puppeteer.entry.

Front Matter

In default Forma, the following front matter properties are available:

• theme: Specifies the named theme to use
• parser: Specifies the named parser to use
• puppeteer: Specifies the named Puppeteer configuration to use
• numbering: Adds numbers to the beginning of specified headings
• header: Defines document header content
• footer: Defines document footer content

These front matter properties are used as follows:

---
theme: foo
parser: var
puppeteer: hoge
numbering: 1-3
header:
  - Top-left header
  - Top-center header
  - Top-right header
footer:
  - Bottom-left footer
  - Bottom-center footer
  - Bottom-right footer
---

Details on Numbering

numbering accepts a number or hyphen-separated numbers. For example, specifying 1 prefixes level 1 headings (# Heading) with a number, displaying them as # 1. Heading. Numbers are sequential starting from 1 and are applied to all headings at the same level; however, any heading immediately following <!-- IGNORE-NUM --> is excluded from the sequential count.

Details on Headers and Footers

Specification Method

Specify 2 or 3 strings for header and footer. When 2 strings are provided, they appear on the left and right; when 3 are provided, they appear on the left, center, and right. The following special variables can also be used:

• title: Displays the first level 1 heading in the page
• date: Displays the date of printing or previewing in YYYY-MM-DD format
• page: Displays the page number

Styling

Headers and footers can be styled in two places.

First is defaultHeaderFooterFont inside puppeteer.json. Here, you can specify shared properties for both headers and footers, such as size (font size) and color (text color). For example:

// puppeteer.json
"defaultHeaderFooterFont": {
  "size": "12px",
  "color": "#ff0000"
}

With this setting, the font size of the header and footer becomes 12px, and the text color becomes red.

Second is directly within the front matter:

---
header:
  - item: Bottom-right footer
    style: "font-size: 12px; color: #ff0000"
  - Top-right header
---

With this configuration, only "Bottom-right footer" will be styled in red with a 12px font size.

Document Directives

The following directives can be used within Markdown:

• <!-- TOC -->: Creates a table of contents from level 1 to 6.
• <!-- TOC[2] -->: Restricts the table of contents to levels 1 through 2.
• <!-- TOC[2,4] -->: Includes levels 2 through 4.
• <!-- IGNORE-TOC -->: Excludes the next heading from the table of contents.
• <!-- IGNORE-NUM -->: Excludes the next heading from numbering.
• <!-- ID[custom-id] -->: Sets an alias on the next heading for internal linking.
• A line containing only ---: Inserts a page break.

HTML, footnotes, task lists, image sizing like ![Alt](https://github.com/proxaxis/forma/raw/HEAD/image.png =320x200), containers, autolinks, and Prism syntax highlighting for major programming languages and configuration formats are supported.

Web and scripting languages

• typescript
• json
• yaml
• markdown
• bash
• shell-session

Backend and systems languages

• python
• php
• java
• c
• cpp
• csharp
• go
• rust
• ruby
• kotlin
• swift

Database and configuration formats

• sql
• graphql
• docker
• ini
• toml

Images and Output Destinations

Images with relative paths are resolved relative to the Markdown file. Paths beginning with @/ are resolved relative to the workspace root. In puppeteer.json, destination: "." outputs the PDF to the same directory as the source file, destination: "@" outputs to the workspace root, and destination: "@/exports" outputs to an exports directory beneath it.
