Chaos Monkey for VS Code

Chaos Monkey is a VS Code extension that scans Python projects for dependency issues, visualizes the dependency graph, simulates failures, analyzes risk, and generates a local AI-backed report.

Features

• Scan a Python workspace for service modules and dependency relationships
• Build a Cytoscape dependency graph in a VS Code webview
• Simulate failure effects across the dependency graph
• Analyze structural issues such as cycles, hotspots, orphans, and leaf nodes
• Generate a written report from scan, analysis, and vulnerability findings
• Optional local AI report generation via llama-cpp-python and a local model file

Architecture

This repository contains two main parts:

1. VS Code extension frontend

   • src/extension.ts starts the backend and registers commands
   • src/graphPanel.ts builds the webview panel and communicates with the backend
   • src/sidebar.ts provides a sidebar tree view for discovered services
   • media/graph.js renders Cytoscape graphs and handles panel controls

2. Python backend

   • backend/app/main.py starts a FastAPI server
   • backend/app/routers/scan.py, analyze.py, simulate.py, recommend.py expose REST endpoints
   • backend/app/services/ contains scanning, analysis, simulation, and graph-building logic
   • backend/config.env stores backend configuration and local model path

Prerequisites

• VS Code
• Python 3.11 or newer available on the system PATH
• pip installed
• Node.js / npm for building the extension
• Optional: a local llama-cpp-compatible model file for AI report generation

Installation

1. Open the extension folder in VS Code.
2. Install Node dependencies if you want to build the extension locally:

npm install

3. Compile the extension and copy media files:

npm run compile

4. Install backend Python dependencies:

cd backend
pip install -r requirements.txt

5. Set up the local Llama model (one-time):

python setup_llama.py

This downloads and caches the default model in backend/models/llama/.

6. Optionally configure a specific local model path in backend/config.env:

LLAMA_CPP_MODEL_PATH=

Set this only if you want the backend to use a pre-downloaded model file.

Using the Extension

Commands

• Chaos: Scan Project — scan the open workspace for Python dependency data
• Chaos: Open Graph — open the graph panel and interact with the scan results

Webview Controls

• Scan — runs a scan from the panel using the current workspace path
• Simulate — simulates failure effects on the discovered graph
• Analyze — sends dependencies and services to the backend for structural analysis
• Write Report — requests the backend to generate a vulnerability report

Local AI Report Support

The extension supports offline report generation using a local llama-cpp model via llama-cpp-python.

How it works

• Backend dependencies are installed from backend/requirements.txt
• setup_llama.py downloads and caches a local model in backend/models/llama/
• backend/app/services/analyzer.py automatically loads the local model path
• The /recommend endpoint uses the local model to generate AI report text
• If no model is available, the backend falls back to a standard generated report

Model file placement and configuration

By default, setup_llama.py downloads the model to:

backend/models/llama/

If you prefer to use a pre-downloaded model, set the path in backend/config.env:

LLAMA_CPP_MODEL_PATH=C:/Users/PRERAK PATEL/Desktop/ChaosMonkey/extension/backend/models/llama/7B/your-model.gguf

The model file must be compatible with llama-cpp-python (GGUF format). This is a local-only model, not a cloud service.

Backend Endpoints

• POST /scan/ — scans a Python project path and returns services, dependencies, vulnerabilities, and graph data
• POST /analyze/ — analyzes dependency relationships and returns structural findings
• POST /simulate/random — simulates failure effects over discovered services and dependencies
• POST /recommend/ — generates a written report and optionally writes chaos-report.txt to the project root

Configuration

backend/config.env

The project currently stores backend config values here. Example:

MYSQL_USER=root
MYSQL_PASSWORD=passwd
MYSQL_HOST=host.docker.internal
MYSQL_PORT=3306
MYSQL_DB=mydb
LLAMA_CPP_MODEL_PATH=

Set LLAMA_CPP_MODEL_PATH only if you have a compatible local model and want to override the default cached download.

To change the backend port, set BACKEND_PORT in backend/config.env or in your environment. Example:

BACKEND_PORT=8001

If not set, the backend will default to port 8000.

Build and Package

• npm run compile — compile TypeScript and copy media assets to out/
• npm run watch — run tsc in watch mode for development
• npm run package — package the extension with vsce
• npm run publish — publish using vsce

Notes

• The extension activation installs backend dependencies automatically, but Python must still be present.
• If LLAMA_CPP_MODEL_PATH is not set or the model fails to load, the report feature still returns a fallback generated summary.
• The backend is based on FastAPI and runs locally at http://127.0.0.1:8000.

Troubleshooting

• If the scan fails, verify the backend is running and Python is installed.
• If AI report generation fails, check backend/config.env and ensure llama-cpp-python can load the specified model.
• Use the VS Code debug console to inspect backend logs printed from src/extension.ts.

License

MIT
