Redux State Debugger

Real-time Redux state inspector and unnecessary re-render detector for React applications, available in VS Code and as a Vercel-deployable web dashboard.

Why This Exists

While leading frontend architecture for a large-scale React platform at T-Mobile, I kept running into the same problem: engineers couldn't easily see why their components were slow. They'd add console.log statements everywhere, open Chrome DevTools in one window and VS Code in another, and lose context constantly.

So I built this extension — a Redux state visualiser and re-render detector that lives inside your editor, where you're actually writing code.

Features

Web Dashboard

Deploy the debugger UI to Vercel and connect a running React/Redux app with a session id. The dashboard shows state, actions, render hotspots, payload previews, latency, and setup code for the active session.

VS Code Debugger Dashboard

Open Redux Debugger: Open Dashboard inside the Extension Development Host or installed extension. It shows every top-level Redux slice, the action that last changed it, nested state paths, reducer duration, action payloads, and render hotspots.

🌳 Redux State Tree

Visualise your entire Redux store as an interactive tree directly in the VS Code sidebar. Updates in real time as actions are dispatched.

⚡ Action History

See every dispatched action with:

• Action type and payload
• Timestamp
• Processing duration (ms)

🚨 Re-render Detector

Automatically flags components that are re-rendering unnecessarily:

• Shows which components re-rendered and how many times
• Lists which props changed (or didn't change — the common culprit)
• Links directly to the component file
• Warning threshold configurable per project

📊 Performance Report Export

Export a full JSON report of actions and re-renders for post-session analysis.

Installation

From VS Code Marketplace

Search for "Redux State Debugger" in the Extensions panel.

Manual Installation

git clone https://github.com/pradeep-kumar-dharmavarapu/vscode-redux-debugger
cd vscode-redux-debugger
npm install
npm run package
code --install-extension redux-state-debugger-1.0.0.vsix

Deploy the web dashboard to Vercel

npm install
npm run build
vercel deploy

The deploy uses:

• web/index.html, web/app.js, and web/styles.css for the dashboard
• api/update.js for event ingestion
• api/events.js for polling dashboard data
• api/session.js for quick session creation
• api/clear.js for clearing a dashboard session

The included API uses warm serverless memory so the project is immediately deployable. For a public multi-user product, replace api/_store.js with durable storage such as Vercel KV, Upstash Redis, or Postgres before launch.

Setup

For a complete real-app walkthrough, see docs/REAL_APP_SETUP.md.

Step 1 — Add the middleware to your Redux store

import { configureStore } from '@reduxjs/toolkit';
import { reduxDebuggerMiddleware } from './src/middleware';
import rootReducer from './reducers';

const store = configureStore({
  reducer: rootReducer,
  middleware: (getDefaultMiddleware) =>
    getDefaultMiddleware().concat(
      reduxDebuggerMiddleware({
        port: 8765,                              // must match extension port
        enabled: process.env.NODE_ENV === 'development',
        trackRerenders: true,
      })
    ),
});

export default store;

For a Vercel dashboard session, use the endpoint and session id shown in the dashboard:

reduxDebuggerMiddleware({
  endpoint: 'https://your-debugger.vercel.app',
  sessionId: 'session-from-dashboard',
  enabled: process.env.NODE_ENV === 'development',
});

Step 2 — (Optional) Track component re-renders

import { withRerenderTracking } from './src/middleware';

function MyExpensiveComponent({ data, onUpdate }: Props) {
  return <div>{/* ... */}</div>;
}

// Wrap with tracker — zero cost in production (NODE_ENV check built in)
export default withRerenderTracking(MyExpensiveComponent, 'MyExpensiveComponent', {
  endpoint: 'https://your-debugger.vercel.app',
  sessionId: 'session-from-dashboard',
});

Step 3 — Start the debugger in VS Code

Open the Command Palette (Cmd+Shift+P) → Redux Debugger: Start Monitoring

Run your React app. The sidebar panels will populate automatically.

Configuration

Add to your .vscode/settings.json:

{
  "reduxDebugger.enableRerenderDetection": true,
  "reduxDebugger.rerenderThreshold": 3,
  "reduxDebugger.maxActionHistory": 100,
  "reduxDebugger.highlightUnnecessaryRerenders": true
}

The Problem This Solves

Before this extension:

Engineer suspects performance issue
→ Opens Chrome DevTools
→ Switches between DevTools and VS Code
→ Adds console.log to component
→ Dispatches action
→ Searches through console output
→ Tries to correlate with Redux DevTools
→ 20 minutes wasted

With Redux State Debugger:

Engineer opens VS Code sidebar
→ Sees re-render warning on component in real time
→ Clicks component → opens file directly
→ Fixes the memoisation issue
→ 2 minutes

This is the exact workflow improvement I built at T-Mobile that reduced debugging time across a team of 10+ engineers.

Architecture

React App (browser)
    │
    ├── Redux Middleware (middleware.ts)
    │   ├── Intercepts every dispatched action
    │   ├── Captures state snapshots
    │   └── POSTs to local VS Code server or Vercel API
    │
    └── withRerenderTracking HOC
        └── Tracks component render counts + prop changes

VS Code Extension
    │
    ├── HTTP Server (port 8765)
    │   └── Receives data from browser
    │
    ├── ReduxStateTreeProvider → State Tree panel
    ├── ActionHistoryProvider  → Action History panel
    └── RerenderDetectorProvider → Re-render Detector panel

Vercel Dashboard
    │
    ├── /api/update  → receives action, state, and render events
    ├── /api/events  → dashboard polling endpoint
    ├── /api/session → session id creation
    └── /web/*       → browser dashboard UI

Contributing

PRs welcome. Key areas for contribution:

• True WebSocket support (replace HTTP polling)
• Time-travel debugging (replay actions)
• Integration with Redux Toolkit's RTK Query
• Support for Zustand and Jotai

Author

Built by Pradeep Kumar Dharmavarapu — Frontend Architect at Wipro, working on T-Mobile, Hitachi Energy, ABB, and Visa platforms.

This extension grew out of a real production problem on a large-scale React platform. If it saves you the same debugging pain, give it a ⭐.

License

MIT
