PinPoint - VS Code Extension

Pick UI elements and inject structured context directly into your AI coding agent - without full-screen screenshots.

Overview

PinPoint is a VS Code extension that replaces the tedious "screenshot → paste → explain" workflow with instant, structured UI context capture. Hover over elements in a running web app, click to capture, and get AI-optimized context automatically injected into your chat.

Problem it solves

• Screenshot fatigue: No more full-page screenshots that add noise
• Ambiguity: AI agents often misunderstand UI intent from images
• Token waste: Screenshots consume expensive API tokens
• Context loss: Missing the structural HTML context AI agents need

Solution

Instead of screenshots, PinPoint captures:

• Robust selectors (data-testid → stable ID → role+aria → position-based)
• Element + parent HTML (clean, truncated)
• Layout info (bbox, positioning, viewport context)
• Computed style diffs (what's explicitly set vs. inherited)
• Optional element screenshot (for visual edge cases)

All formatted as AI-friendly markdown, ready to paste.

Installation

1. Clone the repository
2. npm install
3. npm run compile
4. In VS Code: Run Extension (F5) or package with vsce package

Usage

Quick Start

1. Start the picker: Run command PinPoint: Start Picker
2. Enter URL: Type the localhost or external URL to inspect
3. Hover & click: Hover over elements in the browser; click to capture
4. Chat opens: Formatted context is automatically injected
5. Add your instruction: Type "Make this button look like..." and send

Commands

• PinPoint: Start Picker - Launch browser + inspect mode
• PinPoint: Stop Picker - Cancel and close browser
• PinPoint: Toggle Screenshot - Enable/disable element screenshots
• PinPoint: Set Mode - Choose Quick Fix / Layout / CSS / Visual
• PinPoint: Clear Selection - Clear multi-select queue

Settings

{
  "pinpoint.defaultMode": "quick-fix",        // quick-fix | layout | css | visual
  "pinpoint.screenshotEnabled": false,         // Enable screenshots by default
  "pinpoint.contextRadius": 1                  // Parent levels to include (0-3)
}

Capture Modes

Quick Fix (default)

Minimal, fast capture for one-liner fixes.

Output:

## UI Element Context

**URL:** http://localhost:3000
**Selector:** `button[data-testid="submit"]`
**Role:** button
**Text:** "Submit Form"

### Element Structure
<button data-testid="submit" class="btn-primary">Submit Form</button>

### Key Styles
- display: block
- padding: 12px 24px
- background-color: #3b82f6

### Layout
- Position: absolute, top: 100px, left: 200px
- Size: 120px × 40px

---

Layout

Element + parent HTML + layout-critical styles.

CSS

Computed style diff (what's explicitly set vs. inherited) + class list.

Visual

Screenshot + bbox + minimal metadata.

Architecture

Components

Extension Host (src/extension.ts)

• Commands, settings, status bar UI
• Lifecycle management (cleanup on deactivate)

Browser Session Manager (src/browser/)

• Puppeteer-core Chrome launch with temp profile
• Cleans up on exit (no profile pollution)

Extraction Pipeline (src/extraction/)

• SelectorExtractor: Robust selectors with confidence scoring
• DomExtractor: Element + parent HTML (clean, truncated)
• StyleExtractor: Computed styles + parent diff
• LayoutExtractor: Bbox, viewport, scroll info
• ScreenshotExtractor: Element screenshot via Puppeteer
• Redactor: Truncates text, strips data URLs, removes event handlers

Schemas (src/schemas/)

• Zod-validated MaxContext (internal format)
• Mode-specific exporters (QuickFix, Layout, CSS, Visual)

Chat Injection (src/export/)

• ContextFormatter: Markdown generation for AI agents
• Direct VS Code chat input injection via workbench.action.chat.open

Picker Controller (src/picker/)

• Orchestrates extraction pipeline
• Manages multi-element selection (Shift+click)
• Handles temp file cleanup

Technical Details

Browser Control

• Puppeteer-core (CDP) for robust element selection
• Managed Chrome instance (temp profile, auto-cleanup)
• Overlay hover effect + click detection

Screenshots

• Element-level via elementHandle.screenshot()
• Saved to .claude/tmp/element-<timestamp>.png
• Auto-referenced in chat via @ mention
• Auto-deleted on extension close

Data Flow

Click element →
  Extract selectors (robust priority order)
  Extract DOM (element + parents, cleaned)
  Extract styles (computed + parent diff)
  Extract layout (bbox, viewport, scroll)
  Optional: screenshot
  Redact sensitive data (truncate, strip URLs)
→ Format as markdown
→ Inject to VS Code chat
→ User adds instruction + sends

Selector Priority

1. data-testid, data-test, data-qa (explicit automation attributes)
2. Non-UUID id (stable, semantic)
3. role + unique aria-label (accessibility)
4. Stable class combo (avoid utility classes)
5. Position-based (nth-of-type) fallback

Style Diff

Computes parent styles, keeps only layout-critical properties:

• Display, position, dimensions (width, height)
• Spacing (margin, padding)
• Flexbox/Grid (flex-direction, justify-content, gap, etc.)
• Overflow, z-index

Troubleshooting

Chrome not found

Make sure Chrome/Chromium is installed. On Windows, check Program Files/Google/Chrome. On macOS, check /Applications/Google Chrome.app.

Inspector gets stuck

Press Escape to cancel, or run PinPoint: Stop Picker.

Screenshots not saving

Check that .claude/tmp/ is writable. The extension creates it automatically.

Selectors are unstable

If you see UUIDs or random hashes in captured selectors, that's a sign the app doesn't use stable IDs. The picker falls back to position-based selectors, which may break if the DOM changes.

Development

Build

npm run compile

Watch

npm run watch

Test in VS Code

Press F5 to launch extension in a new VS Code window.

License

MIT
